Audiovox D710 Instruction Manual

Audiovox 7" portable dvd player owner's manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C HA RGE
POW ER
D710/D710PK
D7104/D7104PK
7" Portable DVD Player

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D710 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Audiovox D710

Summary of Contents for Audiovox D710

  • Page 1 C HA RGE POW ER D710/D710PK D7104/D7104PK 7" Portable DVD Player...

  • Page 2: Table Of Contents

    Table of Contents A. Introduction ... 7 B. DVD and Disc Information ... 7 C. Contents ... 8 D. Powering and installation ... 8 E. Vehicle Installation ... 9 F. Controls, Indicators, and Connectors... 10 G. Loading and Playing a Disc ... 11 H.
  • Page 3 Important Safety Instructions Some of the following information may not apply to your particular product; however, as with any electronic product, precautions should be observed during handling and use. Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water.
  • Page 4 Wait for about one hour till the moisture evaporates before operating the unit. When using your portable DVD player, do not sit or stand too close to the screen. To use a headset safely, please keep the following in mind: - Do not play your headset at a high volume.
  • Page 5 CAUTION WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD,DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. FCC Information This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference which may cause undesired operation.
  • Page 6 Manufacturer/Responsible Party Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 This class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

  • Page 7: Introduction

    A. Introduction Thank you for choosing the portable DVD player. The main features include a 7" wide Screen (16:9 Aspect Ratio) Liquid Crystal Display (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in hotels, offices or your home.

  • Page 8: Contents

    7. 1 x Product Registration Card 8. 1 x eMusic Card * D710 & D710PK can operate on a fully charged battery about 2 hours; D7104 & D7104PK can operate on a fully charged battery about 4 hours. ** Only for D710PK and D7104PK.

  • Page 9: Vehicle Installation

    E. Vehicle Installation Installing the DVD Player onto the Seat Back in a Car (Refer to Figure 2) Carrying Bag Opened Carrying Bag Closed Elastic Straps Vehicle Headrest Vehicle Seat Back 1). Unfold the carrying bag, and place the DVD player on the bag beneath the elastic straps.

  • Page 10: Controls, Indicators, And Connectors

    F. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 3) CHARGE P OWER S E TUP ZOOM DISPLAY REPEAT M ENU AUDIO PUSH TO CLOSE OPEN SUBTITLE Figure 3...

  • Page 11: Loading And Playing A Disc

    1) Charge/Power LED Power Button 3) Setup Button 4) Zoom Button 5) Display Button 6) Repeat Button Previous Button Next Button 9) Menu Button 10) Stop Button 11) UP/AUDIO button * Connecting to this headphone jack will disable the internal speakers.

  • Page 12: Basic Operation

    H. Basic Operation POWER OPEN PLAY PAUSE STOP NEXT PREVIOUS LEFT/RIGHT/UP/DOWN MENU REPEAT DISPLAY SUBTITLE AUDIO ZOOM SETUP Turn the unit on Remove/load the disc Start Play/Execute item or setting Still Picture (1 time) Stop at the present playing point / (2 times) Stop playback of the DVD/CD Go to the next chapter, track or scene during playback...

  • Page 13: Menu

    I. Menu A DVD is divided into sections called titles and chapters. When you play a DVD, a root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu.
  • Page 14 c. Press “DISPLAY” button a third time to display the Elapsed Time for the chapter. The heading will disappear automatically in 3 seconds. TT 01 01 CH 02 17 Chapter Elapsed Time Screen Display d. Press “DISPLAY” button a fourth time to display the Remaining Time for the chapter.
  • Page 15 2. Subtitle During disc playback press SUBTITLE button to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are multiple languages press SUBTITLE button again to se- lect another subtitle language.
  • Page 16 4. Zoom During playback press ZOOM button to enlarge the picture by 2x, 3x or 4X with the current zoom multiple. Press ZOOM button one time, the picture will be enlarged 2X. Press ZOOM button a second time, the picture will be enlarged 3X. Press ZOOM button a third time, the picture will be enlarged 4X.
  • Page 17 b. Press the REPEAT button again to repeatedly play the current title. Title Repeat ON Screen Display c. Press the REPEAT button a third time to repeat all chapters and titles. All Repeat ON Screen Display d. Press the REPEAT button a fourth time, to resume normal playback. Repeat Off Screen Display...

  • Page 18: Playing Audio Cds

    K. PLAYING AUDIO CDS When a CD is Loaded into the unit, the Menu Screen will appear. You can use Up and DOWN button to choose the song you desired. Press OK to play. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: •...

  • Page 19: Playing Jpeg Files

    L. Playing JPEG Files 1) Load a JPEG disc onto the disc tray. 2) A screen showing folders or picture files contained on the disc will be displayed automatically after loading. 3) Press and OK button to select a folder or a picture. If a picture is selected, photo slideshow will start with the selected picture.

  • Page 20: Connecting To Other Equipment

    M. Connecting to Other Equipment 1. AV Out Connecting to a TV or Another Monitor ( Refer to Figure 4) 1) Connect one end (1/8" stereo plug) of the audio cable (not supplied) into the unit’s AUDIO OUT jack, and connect the other end (2 terminals, RCA jack) to the Left and Right channel input jacks on your TV or monitor.

  • Page 21: Setup

    N. Setup Press SETUP button to display the Main screen of the SETUP Menu on the screen. Press SETUP button again to exit the SETUP Menu. 1) Press SETUP, the ‘GENERAL SETUP PAGE’ will display on the screen. Gen eral Video Display OSD Lang Screen Saver...
  • Page 22 b) Select ‘OSD LANG’ using the DOWN button, and then press the RIGHT button to enter the submenu. Choose the language you desire as the display language. Press the LEFT button to return. Gen eral Video Display OSD Lang Screen Saver Last Memory Set OSD Language OSD Language Screen Display...
  • Page 23 d) Select ‘LAST MEMORY’ by using the DOWN button. and then press the RIGHT button to enter the submenu. Choose Last Memory on or off using the UP/DOWN buttons and then press OK button to con- firm the setting. Press the LEFT button to return. Gen eral Video Password Preferen Display...
  • Page 24 2) Select ‘VIDEO SETUP PAGE’ by using the LEFT/RIGHT buttons, press OK button to enter the VIDEO SETUP PAGE. Gen eral Video Brightness Con trast Go To Video Setup Page Video Setup Page Screen Display a) Select ‘BRIGHTNESS’ by using the UP or DOWN button, then press OK button.
  • Page 25 3) Select ‘PASSWORD’ using the LEFT or RIGHT buttons, then press the OK button to enter the submenu. Gen eral Video Password Password Setup Page Password Go To Passwo rd Setup Page Password Setup Page Screen Display Press OK button twice to enter the PASSWORD CHANGE PAGE. Input the Old Password or the Default Password, the New Password, and the Confirmed New Password.
  • Page 26 4) With no disc inside the player select ‘PREFERENCE’ using the LEFT or RIGHT button, then press OK button to enter the ‘PREFERENCE PAGE’. Gen eral Video Preference Page Audio Subtitle Disc M enu Parental Default Go To Preference Page Preference Page Screen Display a) Select ‘AUDIO’...

  • Page 27: Preferred Subtitle Language

    b) Select ‘SUBTITLE’ using the DOWN button, then press OK button to enter the submenu. Select the desired subtitle lan- guage or OFF using the UP or DOWN buttons, then press OK to confirm the setting. Press LEFT to return. Gen eral Video Password Preferen Preference Page...
  • Page 28 d) Select ‘PARENTAL’ using the DOWN button, then press OK button to enter the submenu. Gen eral Video Password Preferen Preference Page Audio Subtitle Disc M enu Parental Default Set Parental Control Parental Preference Screen Display Select the parental level you desire using the UP or DOWN button for discs with lock-out function or multiple rating levels.

  • Page 29: Specifications

    Weight : 1.65 lbs (0.75 kg) Dimensions (W x D x H): 8.19 X 6.14 X1.57 inches Built in lithium polymer battery: 7.4V,1300mAh for D710/D710PK; P. Rechargeable Built-in Battery Use The DVD player utilizes a long-life Li-Polymer battery for portability.
  • Page 30 Each full recharge takes approximately five hours. During recharge, the red indicator will stay on. Once fully recharged, the red light will turn off. At this point you may remove the wall plug and stop charging. Precautions Related to Battery Recharge: 1.

  • Page 31: Troubleshooting

    Q. Troubleshooting PROBLEM • Make sure the DVD player is connected No sound or distorted sound properly. Make sure all cables are securely inserted into the appropriate jacks. • You can’t advance through the opening Can’t advance credits and warning information that appears through a movie at the beginning of movies because the disc is programmed to prohibit that action.
  • Page 32 Troubleshooting (Cont) PROBLEM • Check the type of disc you put into disc Disc won’ t play tray. This DVD player only plays DVDs and audio CDs. •Your DVD player has been designed to process regional management information that is stored on DVD discs. The regional code for your player is 1 (The U.S.,U.S.

  • Page 33: Day Limited Warranty

    90 DAY LIMITED WARRANTY Applies to Audiovox Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within ninety (90) days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.

This manual is also suitable for:

D7104D7104pkD710pk
