- Page 1 D2017PK PORTABLE 10.2" LCD MONITOR AND DVD PLAYER...
- Page 2 An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is in “park”...
-
Page 3: Table Of Contents
Content A. Introduction ... 4 B. Cautions and Warnings ... 4 C. Contents ... 6 D. Powering and Installation ... 6 E. Vehicle Installation ... 7 F. Controls, Indicators and Connectors ... 8 G. Loading and Playing a Disc ... 9 H. -
Page 4: Introduction
A. Introduction Thank you for choosing the D2017PK portable DVD player. The main features include a 10.2" Wide Screen (16:9 Aspect Ratio) Liquid Crys- tal Display (LCD) monitor and a DVD player. The unit applies the latest state of the art electronics and is designed for use in vehicles, hotels, offices or your home. - Page 5 operation, never cover or block the slots and openings with a cloth or other material. It is hazardous to replace the battery incorrectly. Replace the battery only with the same or equivalent type. In order to protect the environment, please dispose the battery properly. Do not use the unit in temperatures higher than 95 degrees Fahr- enheit or 35 degrees Celsius.
-
Page 6: Contents
7.Regional Coding Both the DVD player and disc are coded by region. These regional codes must match in order for the disc to play. If the codes don’t match, the disc won’t play. This unit’s code is region 1. DVDs with other regional codes cannot be played in this unit C. -
Page 7: Vehicle Installation
E. Vehicle Installation Installing the DVD Player onto the seat back in a car (Refer to Figure 2) Carry Bag Opened Carry Bag Closed Elastic Straps Vehicle Headrest Vehicle Seat Back 1). Unfold the carry bag, and place the DVD player on the bag beneath the elastic straps. -
Page 8: Controls, Indicators And Connectors
F. Controls, Indicators, and Connectors 1. Unit View (Refer to Figure 3) 7 8 9 Figure 3 1) Release Button of Battery 2) DC 9-12V Input Jack 3) AV Jack 4) AV In/Out SW 5) USB Port 6) Power On/Off SW 7) SD/MMC/MS Slot 8) Power LED 9) Remote Control Sensor... -
Page 9: Loading And Playing A Disc
2. Remote Control (Refer to Figure 4) 1) DVD/SD-USB Button 2) Display Button 3) Skip -Button 4) Menu Button 5) Left Button 6) Angle Button 7) Stop Button 8) Setup Button 9) Numbers Button 10) Bright- Button 11) Audio Button 12) Subtitle Button 13) Up Button 14) Skip+ Button... -
Page 10: Basic Operation
H. Basic Operation POWER OPEN PLAY /PAUSE STOP NEXT PREVIOUS FORWARD REVERSE LEFT/RIGHT/UP/DOWN ENTER NUMBERS MENU REPEAT DISPLAY SUBTITLE AUDIO ZOOM SETUP Turn the unit on/off Remove/load the disc Start Play/Execute item or setting Still Picture (1 time) Stop at the present playing point / (2 times) Stop playing Go to the next chapter, track or scene during play back... -
Page 11: Menu
I. Menu A DVD is divided into sections called titles and chapters. When you play a DVD’s root menu of the disc will appear on the screen of your TV or Monitor. The contents of the menu vary from disc to disc. Press MENU during playback to display the menu. - Page 12 2. SUBTITLE During disc playback press ‘SUBTITLE’ to select the subtitle language you desire*, with the current Subtitle Language Number (1) and the total Number of Subtitle Languages (2) displayed. If there are mul- tiple languages press ‘SUBTITLE’ again to select another subtitle lan- guage.
- Page 13 4. ZOOM During playback press ‘ZOOM’ mutiple times to enlarge the picture by 2X, 3X or 4X. 5. A-B REPEAT a. During playback press the ‘A-B’ button once to set the Starting Point A. b. Press ‘A-B’ a second time to set the Ending Point B and the player will repeatedly play the part between Point A and Point B.
-
Page 14: Playing Audio Cds
6. REPEAT a. During playback press ‘REPEAT’ repeatedly to cycle through the repeat modes. Chapter: Repeat the current chapter Title: Repeat the current title All: Repeat all chapters and titles Repeat Off: Resume normal playback K. Playing Audio CDs When playing an audio CD press the DISPLAY button constantly on the remote to view time information. -
Page 15: Playing Mp3 Discs
Total Elapsed: The current track playing and the total time that the CD has been playing. Total Remain: The current track playing and the amount of time remaining on the CD. Display Off: The CD time Information will not be displayed. USING THE1/ALL REPEAT FEATURE The default mode for the Repeat feature is OFF. -
Page 16: Using The Repeat Feature
4. Use the ( NEXT ) button to move to the next song. Press the (PREVIOUS) button to move to the beginning of the previous song. USING THE REPEAT FEATURE The default mode for the Repeat feature is OFF. Pressing REPEAT consecutively changes the repeat options: •... -
Page 17: Playing Jpeg File
M. Playing JPEG Files Load the JPEG Disc into tray. Pressing the “MENU“ button accesses the thumbnail view. Choose the picture you desire by using the “RIGHT” and “LEFT” buttons. Access the previous and next page by pressing the “PREVIOUS” or “NEXT”... -
Page 18: Connecting To Other Electronic Equipment
N. Connecting to other Electronic Equipment 1. Connecting to a TV or another monitor a. Position the AV In/Out Switch to “Out” Position. b. Connect one end of the audio/video adapter cable’s black 1/8” plug into the unit’s AV jack. Using a standard A/V cable (not supplied), connect the other end to the AUDIO/VIDEO Input jacks on your TV or Monitor (white = left audio channel, red = right audio channel, yellow=video). - Page 19 3. Headphones Wired headphones may be used with the unit. Simply plug in the headphones to either Headphone 1 jack or Headphone 2 jack on the right side of the DVD. ( Refer to Figure 6.) Figure 6 Plugging into Headphone jack 1 disables the internal speakers. 4.
-
Page 20: Setup
O. Setup 1. General Setup Page 1)With no disc inside the player, press ‘SETUP’ to display the Main screen of the Setup Menu on the screen and “General Setup Page” appears. At the same time, “ ” is highlighted. Press ‘SETUP’ again to exit the Setup Menu. - Page 21 ) Last Memory *On: The unit will return to the last position on the disc. *Off: The unit will not return to the last position on the disc. Note: The Last position memory function will only work when the disc tray is OPEN or the AV In/Out is switched. 2.Video Quality Setup 1)In Setup menu, Press the Setup”...
- Page 22 4) Press to enter the sub menu. 5) Press the button to select the desired option and press ENTER to confirm your selection. 6) Repeat steps 3-5 for other menus. Note: Press to return the previous menu. a) Audio b) Subtitle c) Disc Menu Note: Language and subtitle selection is only available for discs that are recorded in the above listed languages.
-
Page 23: Specifications
P. Specifications Compatible DISC: DVD/CD/MP3 Signal system: NTSC Panel size: 10.2 inch Frequency response: 20 Hz to 20 kHz Video output: 1 Vp-p/75 Ohm, unbalanced Audio output: 1.4V /10kOhm Audio S/N: Better than 60 dB Dynamic range : Better than 85 dB Laser: Semiconductor Laser, Wave Length: 650 nm/795 nm Power source: DC 9-12V Power consumption: 12 W... - Page 24 battery in optimum condition. Do not short the battery terminals, store the battery in a metal container, or leave the battery in a humid or damp environment. Ideally, store the battery in an airtight container with desiccant or other dehumidifying agent. Each full recharge takes approximately five-hours and one full charge can provide power to the player for at least 2.5 hours.
- Page 25 Installing the Battery Pack: 1. First, make sure the player is in “Power Off” mode and that the AC power supply has been disconnected. 2. Flip down the monitor. 3. Push the battery towards the rear of the player until it locks into position.
-
Page 26: Troubleshooting
R. Troubleshooting PROBLEM • Make sure your DVD is connected properly. No sound or Make sure all cables are securely inserted distorted sound into the appropriate jacks. • You can’t advance through the opening credits and warning information that appears Can’t advance at the beginning of movies because the disc through a movie... -
Page 27: Troubleshooting (Cont)
Troubleshooting (Cont) PROBLEM IR sensor • Verify that the batteries in the remote are inoperative fresh. • Verify that the remote sensor eye is not obstructed. • Verify that the infrared transmitter is affixed over the sensor eye of the component to be controlled. -
Page 28: Day Limited Warranty
AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within ninety (90) days from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor. - Page 29 © 2007 Audiovox Electronics Corporation 128-8038...
