8.2.

Connections

Caution:
• When you operate this product, the power outlet should
be near the product and easily accessible.
Telephone line cord
•Connect to a single telephone line jack (RJ11).
Power cord
•Connect to a power outlet (120 V, 60 Hz).
Using surge protectors
The warranty does not cover damage due to power line
surges or lightning. For additional protection, we
recommend using surge protectors (
If the fax machine shares a single telephone line with a
DSL service
Fax transmission/reception may be disturbed, noise
interference may be heard during telephone conversations,
or Caller ID may not function properly. A filter to prevent this
is provided by your provider. Please attach the filter (
the telephone line cord of the unit.
8.3.
1. Open the front cover.
2. Release the back cover by pushing the green button (
3. Open the back cover.
).
) to
4. Insert the blue gear of the ink film roll into the front left slot
53

Installing the Ink Film

of the unit ( ) and the white gear of the ink film roll into
the rear left slot of the unit (
• The ink film is safe to touch and will not rub off on your
hands like carbon paper.
KX-FP215
).
).
