Assembly Replacement and Post-Repair Procedures

Removing the Covers

Removing the Covers

Tools Required

• T-10 TORX screwdriver
• T-15 TORX screwdriver
• T-20 TORX screwdriver

Removing the top cover

1. Remove both upper rear feet (item 1) by loosening the attaching screws (item 2).
2. Loosen the top cover screw (item 3).
3. Slide cover off.

Removing the side covers

1. Remove the top cover.
2. Remove the lower rear foot (item 4) that corresponds to the side cover you want to
remove by loosening the attaching screw (item 5).
3. Remove the handle assembly (item 6) by loosening the attaching screws (item 7).
4. Slide cover off.

Removing the bottom cover

1. Remove both lower rear feet (item 4) by loosening the attaching screws (item 5).
2. Loosen the bottom cover screw (item 8).
3. Slide cover off.
14-6
HP 8719ET/20ET/22ET
HP 8719ES/20ES/22ES
RF Network Analyzers
Service Guide
