Owner's Manual
This manual contains important safety, assembly, operation and
maintenance information.
Please read and fully understand this manual before operation.
Save this manual for future reference.
STOP-ALTO-ARRET
See back page for Customer Service Information
Consulte el reverso para Servicio de Información al Cliente
Voir les pages verso pour des renseignements sur le service à la clientèle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GREEN MACHINE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Huffy GREEN MACHINE

Summary of Contents for Huffy GREEN MACHINE

  • Page 1 HGM-Mini EN-AU 091516 © Copyright Huffy Corporation 2016 Owner’s Manual This manual contains important safety, assembly, operation and maintenance information. Please read and fully understand this manual before operation. Save this manual for future reference. STOP-ALTO-ARRET See back page for Customer Service Information Consulte el reverso para Servicio de Información al Cliente...

  • Page 2: Table Of Contents

    • Owner’s Model Identification Record ............. 3 • Warning and Safety Information ............4-5 • Assembly Notes - Tools Needed............6 • Operating Your Green Machine ............. 7 Model Assembly • Parts Assembly List ................8 • Assemble the Fork and Steering Arms ..........9 •...

  • Page 3: Owner's Model Identification Record

    Owner’s Model Identification Record NOTE: This information is only available with model itself. It is not available from Huffy. Model number is on the packaging and instruction manual. Write the model number below to keep it for future reference. If the model is stolen, give this number and a description of the model to the police. This will help them find the model.

  • Page 4: Warning And Safety Information

    Warning and Safety Information PLEASE READ AND FULLY UNDERSTAND THIS OWNERS MANUAL BEFORE OPERATING THE PRODUCT This symbol is important. See the word “CAUTION” or “WARNING” which follows it. The word “CAUTION” is before mechanical instructions. If you do not obey these instruc- tions, mechanical damage or failure of a part of the product can occur.

  • Page 5: Warning And Safety Information

    Warning and Safety Information - continued • Understand all operating procedures before riding. • Do not add a motor to the product. • Do not modify the product. • Before each ride check all screws, fasteners and brakes; re-tighten any that are loose. Replace any fasteners that are damaged.

  • Page 6: Assembly Notes - Tools Needed

    Assembly Notes The instructions in this manual refer to the right and left side of the product, these are defined from the rider position. Do not discard any parts until the unit is completely as- sembled. Required Tools Phillips Screwdriver Metric Allen Wrench (supplied) Torque Wrench (recommended)

  • Page 7: Operating Your Green Machine

    Steering your Green Machine Steering Function: • Pulling back on the left lever, and pushing forward on the right lever will turn the product towards the left. • Pulling back on the right lever, and pushing forward on the left lever will turn the product towards the right.

  • Page 8: Parts Assembly List

    Parts Assembly 10 11 12 13 14 Description Description Front Wheel Assembly Rear Wheels (x2) Pedal Set Rear Axle Cover Front Fork Axle Pivot Bolt and Stop Fork/Frame Bushing Axle Pivot Support Fork Mounting Hardware Rear Axle Steering Handlebar Hardware Axle Bushing (x2) Front Cowling Axle Cap and Screw (x2)

  • Page 9: Assemble The Fork And Steering Arms

    Assemble the Fork and Steering Arms NOTE: Remove and set aside Bolt from mounting hole STEPS: NOTE: Make sure Seat Bracket is pointing UP before starting. Insert Fork Tube fully into the Frame Tube so that both Mount Holes line Insert Pivot Shaft through Frame.

  • Page 10: Assemble Front Cowling

    Assemble the Front Cowling TIP: Rotate Wheel/Fork assembly over so that mounting hole Dimple is on TOP. NOTE: If needed, loosen Steering Arm screws during assembly, then retighten. See Torque Chart for recommended torque. Attach the Cowling by sliding it down and back on the Fork so that the Cutouts fit around the fork legs.

  • Page 11: Attaching Steering Linkage

    Attaching Steering Linkage - Front NOTE: Make sure the curve of Steering Arms are pointing backwards! STEP ONE: Insert the front end of Right Steering Linkage into right Steering Arm End shown. Make sure rear end pointing UP Make sure Steering Linkage is on the OUTSIDE (view ) of the Steering Arms as shown.

  • Page 12: Assemble Rear Axle And Steering Linkage

    Assemble the Rear Axle and Steering Linkage NOTE: Shoulder Screw set ( ) are pre-installed. Remove before starting. Fold Steering Arms forward as shown with Frame Tube pointing back. Turn Rear Axle 90° UP as shown. Make sure Steering Stop is on TOP as shown in View Insert each Steering Linkage End...

  • Page 13: Assemble The Rear Wheels

    Assemble the Rear Wheels Install rear Wheels by placing wheel over Axle Bushings with axle cap recess facing OUTWARDS. Install Axle Cap with Screw . Tighten securely. Do not over-tighten. Repeat for opposite side. WARNING: • Ensure Wheels turn smoothly. •...

  • Page 14: Installing The Seat

    Installing the Seat NOTE: Remove Screws if they are pre-installed. Position Seat over Mounting Plate so that the correct holes align for the child’s size. Install 2 Screws and Washers through Seat and Mounting Plate. Tighten securely. Do not over-tighten. This can damage the seat. WARNING: •...

  • Page 15: Installing Rear Axle Cover

    Installing Rear Axle Cover IMPORTANT: Make sure Stop Screw is fully tightened before starting. NOTE: Remove Screws if they are pre-installed. Position Axle Cover over Axle Plate so that the holes align. Install 2 Screws through Axle Cover and Axle Plate. Tighten securely.

  • Page 16: Repair And Service

    Repair and Service WARNING: • Inspect the model frequently. Failure to inspect the model and to make repairs or adjustments, as necessary, can result in injury to the rider or to others. Make sure all parts are correctly assembled and adjusted as written in this manual and any “Special Instructions”.

  • Page 17: Torque Chart

    Torque Chart Recommended Torque: Use of a torque wrench is recommended. Recommended torque for each fastener is listed below. In addition to tightening to the recommended torque, please ensure the parts of the product are sufficiently tightened by performing the functional tests (in the compo- nent assembly sections of the owner’s manual) on each component as it is tightened.
  • Page 18 Limited Warranty General: • Part or model specifi cations are subject to Huff y will not be liable for incidental or change without notice. consequential loss or damage, due directly or • This Limited Warranty is the only warranty for indirectly from use of this product.
  • Page 19 WARNING / ADVERTENCIA / AVERTISSEMENT : ALWAYS WEAR YOUR HELMET WHEN RIDING THIS PRODUCT! USE SIEMPRE EL CASCO AL MONTAR ESTE PRODUCTO! TOUJOURS PORTER VOTRE CASQUE LORSQUE CIRCONSCRIPTION CE PRODUIT ! • Helmet should sit level on • El nivel del casco se debe ajustar •...
  • Page 20 ANTES DE DEVOLVER EL RETOURNER AU MAGASIN, PRODUCTO A LA TIENDA, COMMUNIQUEZ AVEC LE COMUNÍQUESE CON SERVICIO SERVICE À LA CLIENTÈLE DE AL CLIENTE DE HUFFY. NOS HUFFY. NOUS VOUS AIDERONS COMPLACE AYUDARLO VOLONTIERS AVEC TOUT CON CUALQUIER PARTE O PROBLÈME CONCERNANT LES PROBLEMA DE ENSAMBLADO PIÈCES OU LE MONTAGE!
