Operating the Unit

Replacing the Battery

Open the battery compartment on the back of the unit and take out the battery.
Disconnect the battery from the unit by opening the black connector. To do so, hold both sides of the
connector firmly to avoid damaging the connecting cables to the unit.
Now connect the connector of the new battery to the unit. Insert the battery in the battery compart-
ment and close the cover (see also P. 10).
If the unit was disconnected from the power supply, the date and time must be re-entered. The last
measurement time window will be saved and valid.
Note: The date should be identical to the last date saved in the unit.
Warning: Do not reuse the battery if it is clearly damaged. In this case, call the cyclotest® service hot-
line.

Charging the Battery

The battery charge state is displayed in 5 stages in the bottom left corner of the display:
100 % 70 % 40 % 15 % 5 %
