- Page 1 Owner’s Manual Pelican PC600/PC1000 Premium Whole House Water Filter...
- Page 2 Pelican Water Systems shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 3 Table of Contents Table of Contents ............3 Product Operation and Specifications . -
Page 4: Table Of Contents
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 4 Product Operation and Specifications Specification Description PC600 PC1000 Max Flow Rate 10 GPM 15 GPM Minimum Working Pressure 25 PSI Maximum Working Pressure 80 PSI Maximum Vacuum... -
Page 5: Complete Parts List
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 5 Complete Parts List Note: Pelican supplies the parts below to accommodate a variety of water supply lines. Table 1: Parts List Part Description Qty. Part Description Qty. - Page 6 CANNO T BE REPRO DUCED O R USED TO Water Systems 1-877-842-1635 MANUFACTURE ANYTHING SHO WN O R REFERRED INSTALLATION OVERVIEW TO WITHO UT DIRECT WRITIEN PERMISSIO N FROM wm1. pe l i canwater. com SINGL E TANK SYST PELICAN WATER SYSTEMS.
-
Page 7: Installation Overview
Quick Connect Nuts. Notice: The bypass valve(s) included with this system are designed for multiple Pelican water systems. This may result in the arrows on the bypass valve(s) pointing differently than shown. If the arrows on your bypass valve(s) do not match the diagram, remove the red arrows by pulling them straight up, turn them 180°... -
Page 8: Water Filter - Carbon Soak
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 7 Water Filter - Carbon Soak !IMPORTANT! Your system will not be ready for use for a minimum of 48 hours while the Carbon Soak process takes place. Please plan your installation accordingly. -
Page 9: Water Filter - Carbon Flush
PC600-1000 Rev N — Pelican PC600/PC1000 Premium Whole House Water Filter Page 8 Water Filter - Carbon Flush !IMPORTANT! Do not perform the Carbon Flush until the Carbon Soak process is complete. Notice: Water will flow out of the outlet side of the Bypass Valve during this process. Be sure you perform this series of steps in a location suitable for water flow. -
Page 10: Installation
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 9 Installation Sediment Filter Assembly Sediment Filter Cover Sediment Filter O-Ring Blue Filter Housing Stand Pipe Figure 5 1. Unscrew the cover from the Blue Filter Housing. 2. Remove the plastic covering from the Sediment Filter. -
Page 11: Whole House Water Filter Tank Installation
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 10 Whole House Water Filter Tank Installation 1. Level the Pelican Whole House Water Filter. Notice: If the tank is not level, lift the tank straight up 6 inches and tap it on the ground until the tank stands vertical. -
Page 12: Bypass Valve Operations
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 11 Bypass Valve Operations In Service Figure A Figure A shows the system "in service" which allows water to flow in and out of the tank. In this position the system would be considered... -
Page 13: Complete The Installation
3. Peel off the protective plastic wrap from the stainless steel tank jackets. 4. Add the Pelican logo sticker in the desired location on the tank. 5. Wax stainless steel tank jacket(s) with wax provided or any other non-abrasive auto wax a minimum of 1-2 times per year or as needed based on the installed environment. -
Page 14: Maintenance
Maintenance Premium Whole House Water Filter Your Pelican PC600/PC1000 Premium Whole House Water Filter requires care and cleaning after a period of 5 years. Replacement media and instructions can be ordered on-line at www.pelicanwater.com or by calling 877-842-1635. Model numbers for replacement media are PC600-R or PC1000-R. -
Page 15: Troubleshooting
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 14 Troubleshooting Problem Solution Water leaking at the top of the tank around the head. You may need to turn the head to tighten it. The tank head is pre-installed hand-tight, do not overtighten the head (just turn it snug). -
Page 16: Warranty
Pelican's liability hereunder shall not exceed the cost of the product. Under no circumstances will Pelican be liable for any incidental or consequential damages or for any other loss, damage or expense of any kind, including loss of use, arising in connection with the installation or use or inability to use the Covered Items or any water treatment system the Covered Items are incorporated into. -
Page 17: Warranty Registration Form
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 16 Warranty Registration Form Send in this Warranty Registration Form to validate your warranty or visit www.PelicanWater.com to complete warranty registration form online. Pelican Warranty Registration Form Date Item(s) were Received:... -
Page 18: Product Certifications
PC600-1000 Rev O — Pelican PC600/PC1000 Premium Whole House Water Filter Page 17 !IMPORTANT! Do not use where water is microbiologically unsafe or with water of unknown quality without proper disinfection before or after the filter/softener system. Product Certifications Clack V3007-xx Bypass Fittings – WWQA Gold Seal Certified to NSF/ANSI Standard 44 for material safety and structural integrity only U.S.
