Summary of Contents for Pelican PS48
- Page 1 Owner’s Manual PS48/PS80 Advantage Series Salt Based Water Softeners...
- Page 2 Pelican Water Systems shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Adding the Pelican Logo Sticker ........ -
Page 4: Product Operation And Specifications
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 4 Product Operation and Specifications Specification Description Rated Service Flow 12-18 GPM (depending on model) Minimum Working Pressure 25 PSI Maximum Working Pressure 80 PSI Maximum Vacuum 5 inch/127 mm Hg Operating Temperatures 36°F - 120°F... -
Page 5: Complete Parts List
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 5 Complete Parts List Note: Enviro Water Products supplies the parts below to accommodate a variety of water supply lines. Table 1: Parts List Part Description Qty. Part Description Qty. -
Page 6: Installation Overview
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 6 Installation Overview Wall Incoming Bypass Water Outgoing Valve Supply Water to House Overflow Barb Safety Valve Electronic Head Discharge Holding Tank Line Softener Tank Brine Tank Figure 1... -
Page 7: Installation
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 7 Installation Install Electronic Head Wall Incoming Bypass Water Outgoing Valve Supply Water to House Overflow Barb Safety Valve Electronic Head Discharge Holding Tank Line Softener Tank Brine Tank... -
Page 8: Final Setup And Installation
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 8 Final Setup and Installation Wall Incoming Bypass Water Outgoing Valve Supply Water to House Overflow Barb Safety Valve Electronic Head Discharge Holding Tank Line Softener Tank Brine Tank Figure 4 10. -
Page 9: Complete The Installation
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 9 Complete the Installation 1. Set the Bypass Valve into bypass mode. 2. Slowly turn on the main water supply until all pipes are pressurized. 3. Slowly open the bypass valves. -
Page 10: Step 2: Setting The Time
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 10 Table 2: Setting the Valve Parameter Display (Left Corner) Data Display Set To VT (Valve Type) dF2b CT (Control Type) C (Capacity) Size of system (Example: 48k or 80k) -
Page 11: Adding The Pelican Logo Sticker
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 11 Adding the Pelican Logo Sticker 1. Peel back plastic to remove it from the tank. 2. Place sticker in the desired location on the tank. © 2015 Enviro Water Solutions LLC www.pelicanwater.com... -
Page 12: Troubleshooting
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 12 Troubleshooting Problem Solution Water leaking at the top of the tank around the head. You may need to turn the head to tighten it. The tank head is pre-installed hand-tight, do not overtighten the head (just turn it snug). -
Page 13: Warranty
Pelican’s liability hereunder shall not exceed the cost of the product. Under no circumstances will Pelican be liable for any incidental or consequential damages or for any other loss, damage or expense of any kind, including loss of use, arising in connection with the installation or use or inability to use the Covered Items or any water treatment system the Covered Items are incorporated into. -
Page 14: Warranty Registration Form
PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 14 Warranty Registration Form Send in this Warranty Registration Form to validate your warranty or visit www.PelicanWater.com to complete warranty registration form online. Pelican Warranty Registration Form Date Item(s) were Received:... - Page 15 PS48/PS80 Advantage Series Salt Based Water Softeners — Rev K Page 15 !IMPORTANT! Do not use where water is microbiologically unsafe or with water of unknown quality without proper disinfection before or after the filter/softener system. © 2015 Enviro Water Solutions LLC www.pelicanwater.com...
Need help?
Do you have a question about the PS48 and is the answer not in the manual?
Questions and answers
PS48 not drawing brine, tank has been cleaned and suction tube from tank to power head cleaned and reinstalled
The Pelican PS48 may not be drawing brine after cleaning the tank and suction tube due to one or more of the following possible issues:
1. The brine line may not be fully inserted into the port on the electronic head. Ensure the grey clip is removed, the brine line is fully inserted, and the clip is replaced.
2. The tank head may not be snug, which could affect suction. Turn the head to tighten it, but do not overtighten.
3. The brine tank may not have enough water. Ensure 6 gallons of water were added to the brine tank.
4. The drain line connected to the brine tank overflow barb may be kinked or submerged. Ensure it is free of kinks and not submerged.
Check each of these areas to identify and fix the issue.
