Clearances - Carrier 24AHA4 Service Manual

CLEARANCES - - INDOOR
4 in.
(101.6 mm)
min.
CLEARANCES - - OUTDOOR
D
UNIT
A
B
C
D
E
8 in.
4 in.
(203.2 mm)
(101.6 mm)
min.
min.
80 in
(2032 mm)
min.
Fig. 5 – Indoor Unit Clearance
A
B
Fig. 6 – Outdoor Unit Clearance
Table 6—Outdoor Clearances
Coil Facing Wall - - in. (mm)
24 (610)
24 (610)
20 (508)
6 (152)
6 (152)
C
Air-inlet
6
A08357
Air-outlet
E
A08436
Fan Facing Wall - - in. (mm)
24 (610)
24 (610)
6 (152)
8 (203)
20 (508)
