Description; Typical Applications - e2v UNIIQA User Manual

Functionality (Programmable via Control Interface)
Analog Gain
Offset
Trigger Mode
Mechanical and Electrical Interface
Size (w x h x l)
Weight
Lens Mount
Sensor alignment ( see chapter 2.1 )
Sensor flatness
Power supply
Power dissipation
General Features
Operating temperature
Relative Humidity for Operation
Storage temperature
Regulatory
1.2

Description

e2v's UNiiQA+ line scan cameras family has been specifically designed to overcome the limitations of your
current inspection system: make cost savings, improve your throughput, inspect larger areas or identify
smaller defects.
Three UNiiQA+ product ranges are offered:

UNiiQA+ Essential: low speed cameras for cost effective equipment or with modest speed requirement

UNiiQA+ High-Speed: high speed cameras to help improve the performance of your system
The UNiiQA+ family has also been designed to be highly modular to enable engineers to reuse the same
camera in multiple equipment, simplify logistics and reduce development cycle time. All UNiiQA+ cameras
feature e2v's proprietary CMOS sensors : a single line of highly sensitive pixels of either 5µm or 10µm size.
1.3

Typical Applications


On-line quality control

Raw material inspection (plastic film, glass, wood...)

Print and paper inspection

Sorting

Food sorting (Belt sorting, Lane sorting, Free fall sorting)

Parcel and postal sorting

Barcode reading
U M UNIIQA+ C
SER ANUAL OLOR
Timed (Free run) and triggered (Ext Trig, Ext ITC) modes
F, C and M42x1 (on the Front Face)
0 to 50 (front face), 70 (internal)
– R I – 09/2016
EV
Up to 12 (x4)
-4096 to +4096
60 x 60 x 33.65
<150
±100
50
Single 10 DC to 15 DC
< 3,6 (PoCL compliant)
85%
-40 to 70
CE, FCC , Reach, RoHS and Chinese RoHs compliant
dB
LSB
mm
g
-
µm
µm
V
W
°C
%
°C
