Page 1: User Manual
DIVIINA® LM2 Line Scan Camera DIVIINA LM2 Camera User Manual e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 2: Table Of Contents
6.3.3 Exposure and Synchronization ............................17 6.3.4 Gain and Offset ..................................21 6.3.5 Save & Restore Settings ..............................22 APPENDIX A: Test Patterns ..............23 1024 Pixels Camera .........................23 2048 Pixels Camera.........................23 4096 Pixels Camera.........................23 e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... - Page 3 APPENDIX D : Command Summary ............28 10.1 Information ..........................28 10.2 Signal Source ..........................28 10.3 Exposure & Synchronisation....................28 10.4 Gains & Offset ........................29 10.5 Save & Restore settings ......................29 APPENDIX E: Revision History............. 30 e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11...
-
Page 4: Camera Overview
LSB/(nJ/cm²) 8bits Response non linearity < 1 PRNU +/- 10 Dynamic range Functionality (Programmable via Control Interface) Gain Up to 36 dB Offset Up to 16 LSB Trigger Mode Free-run, external triggered e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 5: Description
CE and RoHS compliant Description DiViiNA is a cost efficient CCD line scan camera family with Camera Link interface. Featuring e2v’s own high performance linear CCD sensors from 1024 pixels up to 4096 pixels, as used in the world recognized AViiVA cameras;... -
Page 6: Image Sensor
® DIVIINA IMAGE SENSOR Sensor Structure The sensor has a odd/even structure in two taps as following : Response of the sensors 14µm pixel 10µm pixel 1000 1100 Wavelength e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 7: Camera Hardware Interface
X,Y plan Y axis Z axis All dimensions in millimeters Sensor size (pixels #) 1024 2048 4096 x with 14µm sensor (mm) 20.83 13.66 x with 10µm sensor (mm) 22.88 17.76 7.52 e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 8: Input/Output Connectors And Led
Power Connector : Hirose 6pts 12v to 24v 3.2.1 Power Connector Camera connector type: Hirose HR10A-7R-6PB (male) Cable connector type: Hirose HR10A-7P-6S (female) Signal Signal Power supply from 12v to 24v Camera side description e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 9: Camera Link Output Configuration
Port A0 Port A1 Port A2 Port A3 Port A4 Port A5 Port A6 Port A7 Port B0 Port B1 Port B2 Port B3 Port B4 Port B5 Port B6 Port B7 e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 10: Standard Conformity
A shielded power supply cable A Camera Link data transfer cable ref. 14B26-SZLB-500-OLC (3M) e2v recommends using the same configuration to ensure the compliance with the following standards. CE Conformity The DIVIINA cameras comply with the requirements of the EMC (European) directive 89/336/CEE (EN 50081-2, EN 61000-6-2). -
Page 11: Getting Started
On the appropriate Camera Page (EM2 or EM4) you’ll find a download link first version of CommCam compliant is indicated in the last Chapter CommCam download requires a login/password : Login : commcam Password : chartreuse e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 12: Setting Up In The System
Line Rate = (300 /110) x 4096 = 11170 Lines/s. If you use a 60mm lens, the working distance will be : L = (60 x 110) / 40,96 = 161mm. This will certainly require a macro lens. e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 13: Camera Software Interface
CAMERA SOFTWARE INTERFACE Control and Interface As all the e2v Cameras, the DIVIINA is delivered with the friendly interface control software COMMCAM.UCL (as “Ultimate Camera Link”) which is based on the GenICam standard COMMCAM recognizes and detects automatically all the UCL Cameras connected on any transport layers (Camera Link or COM ports) of your system. -
Page 14: Serial Protocol And Command Format
Error: communication failure. >129 Error: protocol failure. >130 Error: parameters are out of range. >131 Error: access failure. >132 Error: access denied. >133 Error: initialization failure. >134 Error : Parameters conflict. >135 e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 15: Camera Commands
All these values are fixed in factory except the Camera User ID which can be fixed by the Customer: Vendor name “e2v” • Read function: “r vdnm”; Return by the camera: “e2v” (string) Can not be written Model Name: Camera model name •... -
Page 16: Setup
The filter has to be disabled if the inspection is done at Nyquist frequency : Then the tap balance has to be performed by using odd and even Tap Gains. The Camera is delivered with the Auto Tap Balance enabled by default. e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 17: Exposure And Synchronization
CC1 rising to integration period start delay 350ns Integration period stop to readout 1,8µs CC1 hold time (pulse high duration) 1,1µs CC1/CC2 falling/rising to integration period start delay 350ns CC1/CC2 rising to integration period stop delay 1,3µs e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... - Page 18 Ext Trig with integration time set in the camera This mode requires an external trigger ( via CC1) but the exposure time is the one defined in the Camera. tint tper EXPOSURE N+1 EXPOSURE N READOUT N-1 READOUT N e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11...
- Page 19 CC2 controls the starting of the exposure time CC1 controls the end of the exposure time. The line period is defined by the one of the CC2 Trig signal. tper tint EXPOSURE N EXPOSURE N+1 READOUT N-1 READOUT N e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11...
- Page 20 Note that if the exposure time is increased and set at a lower value than the line period, this last one will be automatically adjusted at the value of the exposure time : This modification won’t appear in CommCam without disconnect/reconnect e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11...
-
Page 21: Gain And Offset
: You have to refresh them individually with a right click on the value. Analog odd Gain Set the Amplification Gain on the odd Tap • The value set also copied in the Analog Global Gain parameter. e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 22: Save & Restore Settings
“w lcfg 0” : Load settings from the Factory default settings “w lcfg 1” : Load settings from the User Bank “w scfg 1” : Save the current settings in the User bank e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 23: Appendix A: Test Patterns
The test pattern is composed of 8 successive ramps from 0 to 255 LSB gray values : 4096 Pixels Camera The test pattern is composed of 16 successive ramps from 0 to 255 LSB gray values : e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 24: Appendix B: Optical Mounts Available
® DIVIINA APPENDIX B: Optical Mounts available F-Mount F Mount: (Part number EV50-MOUNT-F) Drawing for the additional part (except Nikon BR3) : e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 25: C-Mount
® DIVIINA C-Mount C Mount : (Part number EV50-MOUNT-C) e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 26: Appendix C : Troubleshooting
Camera Power up LED Color Fixed No LED Green If CommCam Camera ready connection possible : then the LED is HS, else : Check power supply And its characteristics Contact Hotline for e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 27: Commcam Connection
• The Frame Grabber is compliant with CameraLink standard 1.1 Contact the hotline : hotline-cam@e2v.com An e2v Camera is detected but not • The version of CommCam used is too old : You identified : have to use the version 1.2.x and after. -
Page 28: Appendix D : Command Summary
Set line period synchronisation (start and period) and integration time controlled by 1 signal (ITC) w sync 3 Set line period synchronisation (start and period) and integration time controlled by 2 signals r sync Get current synchronisation mode e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 29: Gains & Offset
Command Features Save & Restore w lcfg 0 Load current configuration from factory bank w lcfg 1 Load current configuration from User bank w scfg 1 Save current configuration into User bank e2v semiconductors SAS 2011 0994G -Diviina LM2 04/11... -
Page 30: Appendix E: Revision History
