Sensor alignment
Z = -10.3 mm
X = 19.76 mm (4k 5µm)
X = 19.76 mm (2k 10µm)
X = 24.88 mm (1k 10µm)
X = 27.44 mm (0.5k 10µm)
Y = 30 mm
Die flatness
Rotation (X,Y plan)
Parallelism
3.2

Input/output Connectors and LED

USB Connector
For Firmware
upgrade
CameraLink
Connector CL2
(High Speed ver.
only)
U M UNIIQA+ C
SER ANUAL OLOR
±100µm
±100 µm
±100 µm
50 µm
±0.3°
50µm
– R I – 09/2016
EV
Power Connector :
10-15V DC
Multi-Colored LED
for Status and
diagnostic
CameraLink
Connector CL1
P
(PoCL)
