  • Page 1: User Manual

    USER MANUAL UNIIQA+ COLOR e2v.com/imaging WE PARTNER WITH OUR CUSTOMERS TO IMPROVE, SAVE AND PROTECT PEOPLE’S LIVES...

  • Page 2: Table Of Contents

    CE Conformity ..........................15 FCC Conformity ..........................15 RoHS / Chinese RoHS ........................15 GenICam / GenCP ..........................15 Getting Started ........................16 Out of the box ..........................16 UNIIQA+ C – R I – 09/2016 ANUAL OLOR A G E...
  • Page 3 Appendix B. Timing Diagrams ....................49 B.1 Synchronization Modes with Variable Exposure Time ................49 B.2 Synchronisation Modes with Maximum Exposure Time ............... 50 B.3 Timing Values ............................51 Appendix C. CameraLink Data Cables ..................52 UNIIQA+ C – R I – 09/2016 ANUAL OLOR...
  • Page 4 C.2.2 Essential Models ..........................54 Appendix D. Lens Mounts ......................55 D.1 F-Mount..............................55 D.2 C-Mount ..............................56 Appendix E. CommCam Connection ..................57 Appendix F. Revision History ....................59 UNIIQA+ C – R I – 09/2016 ANUAL OLOR A G E...

  • Page 5: Camera Overview

    Camera Gain e-/LSB 12bits Full Well Capacity 23,7 Response non linearity (Max) Readout Noise Dynamic range SNR Max (3/4 Sat) 39.5 PRNU HF Max Values per ADC (per color) UNIIQA+ C – R I – 09/2016 ANUAL OLOR A G E...

  • Page 6: Description

    UNiiQA+ High-Speed: high speed cameras to help improve the performance of your system The UNiiQA+ family has also been designed to be highly modular to enable engineers to reuse the same camera in multiple equipment, simplify logistics and reduce development cycle time. All UNiiQA+ cameras feature e2v’s proprietary CMOS sensors : a single line of highly sensitive pixels of either 5µm or 10µm size.

  • Page 7: Models

    Measured at Max Exposure Time and Nominal Gain (No Gain)  Maximum data rate  Stabilized temperature 30/40/55 °C (Room/Front Face/Internal)  SNR Calculated at 75% Saturation with minimum Gain. UNIIQA+ C – R I – 09/2016 ANUAL OLOR A G E...

  • Page 8: Image Sensor

    Image Sensor The Uniiqa+ sensor is composed of two sensitive lines of 4096 pixels of 5µm square : One composed of Green pixels only, the second one composed alternatively of Red/Blue Pixels. Each pixel on the same column uses its own Analog to Digital Column converter (ADC Column).

  • Page 9: Column Interpolation Correction (True Color Only)

    Line Red color color Interpolations ghosting ghosting Magenta color ghosting Horizontal transition effect reduced by the “Line Interpolation” Vertical transition effect reduced by the “Column Interpolation” UNIIQA+ C – R I – 09/2016 ANUAL OLOR A G E...

  • Page 10: Response & Qe Curves

    Response & QE curves 2.3.1 Quantum Efficiency 2.3.2 Spectral Response Curve Spectral response (UNIIQA+ Color) 1060 wavelength (nm) UNIIQA+ C – R I – 09/2016 | 10 ANUAL OLOR A G E...

  • Page 11: Camera Hardware And Interface

    3 Camera Hardware and Interface Mechanical Drawings The Step file is available Essential Model High Speed Model on the web : www.e2v.com/cameras UNIIQA+ C – R I – 09/2016 | 11 ANUAL OLOR A G E...

  • Page 12: Input/Output Connectors And Led

    Power Connector : USB Connector 10-15V DC For Firmware upgrade Multi-Colored LED for Status and diagnostic CameraLink Connector CL2 (High Speed ver. only) CameraLink Connector CL1 (PoCL) UNIIQA+ C – R I – 09/2016 | 12 ANUAL OLOR A G E...

  • Page 13: Power Connector

    High Speed 3.14W 3.15W 3.21W Power Time : Max 3s (Green Light) 2nd pic at 312mA Inrush current : pic at 240mA Established current at 307mA UNIIQA+ C – R I – 09/2016 | 13 ANUAL OLOR A G E...

  • Page 14: Status Led Behaviour

    Version “High Speed” only Base : 2 Channels 24 bits RGB 2 x 85MHz 2 x 2048 2 x 1024 2 x 512 2 x 256 (60/42.5MHz) UNIIQA+ C – R I – 09/2016 | 14 ANUAL OLOR A G E...

  • Page 15: Standard Conformity

    The UNIIQA+ cameras comply with the requirements of the EMC (European) directive 2004/108/EC (EN 50081-2, EN 61000-6-2). CE 0168 FCC Conformity The UNIIQA+ cameras further comply with Part 15 of the FCC rules, which states that: Operation is subject to the following two conditions:  This device may not cause harmful interference, and ...

  • Page 16: Getting Started

    Main Camera page : www.e2v.com/cameras On the appropriate Camera Page (UNIIQA+ Monochrome) you’ll find a download link first version of CommCam compliant is indicated in the last Chapter CommCam download requires a login/password :  Login : commcam ...

  • Page 17: Camera Software Interface

    6 Camera Software Interface Control and Interface As all the e2v Cameras, the UNIIQA+ CL is delivered with the friendly interface control software COMMCAM.UCL (as “Ultimate Camera Link”) which is based on the GenICam standard COMMCAM recognizes and detects automatically all the UCL Cameras connected on any transport layers (Camera Link or COM ports) of your system.

  • Page 18: Serial Protocol And Command Format

     If the execution time of the command is greater than 300ms, the camera sends a “pending acknowledge” command which gives the duration of this command : It can’t be greater than 65536ms UNIIQA+ C – R I – 09/2016...

  • Page 19: Error Code Table

    CCD and SCD fields but not the command payload. 0x800F GENCP_WRONG_CONFIG The current receiver configuration does not allow the execution of the sent command. 0x8FFF GENCP_ERROR Generic error. UNIIQA+ C – R I – 09/2016 | 19 ANUAL OLOR A G E...

  • Page 20: Camera Commands

     Manufacturer Name (ManufacturerName) : Camera identifier set by the User in a 64Bytes String.  Read function (ASCII): “r vdnm”; Returned by the camera : “e2v”, String of 64 bytes (including “/0”)  Can’t be written  Model Name (ModelName) : Camera Model Name (GenICam) set by in factory in a 64Bytes String.

  • Page 21: Device Privilege, Standby, Status And Reboot

     Write function (ASCII): “w lock <val>” : <val> is as follow  2 : Lock the Camera in Integrator or “privilege User”  <computed value> : Unlock the Camera back in Integrator mode UNIIQA+ C – R I – 09/2016 | 21 ANUAL...

  • Page 22: Communication And Firmware Version

    The Cameras are delivered in Integrator mode. They can be locked in User mode and a specific password is required to switch back the Camera in Integrator mode. This password can be generated with a specific tool available from the hotline (hotline-cam@e2v.com) ...

  • Page 23: Image Format

     Write function (ASCII): “w smod” <value> :  “0” : 4096 pixels, 5x5µm  “1” : 2048 pixels, 10x10µm  “2” : 1024 pixels, 10x10µm  “3” : 512 pixels, 10x10µm UNIIQA+ C – R I – 09/2016 | 23 ANUAL OLOR A G E...
  • Page 24 Ch 1 Output direction for ReverseReading = 0 last  Medium Mode : 2 RGB Channels separate, outputted from Left to Right Ch 1 Ch 2 last UNIIQA+ C – R I – 09/2016 | 24 ANUAL OLOR A G E...
  • Page 25  “0” : Forward.  “1” : Reverse  “2” : Externally controlled (by CC3 of the CameraLink Sync signals) Forward/reverse information has to be set correctly For the re-ordering of the colors. UNIIQA+ C – R I – 09/2016 | 25...
  • Page 26 The definition is 4k (Full definition) with a pixel of 5x5µm.  The definition is 2k, 1k or 512 Pixel (True Color) with a pixel of 10x10µm and the Line Interpolation is enabled UNIIQA+ C – R I – 09/2016 | 26...

  • Page 27: Image Control

    The Overall size of the Memory zone is 2 x 4096 Bytes :  Read function (ASCII): “r alin” This Function is available only with the version 1.4.0 of the Firmware UNIIQA+ C – R I – 09/2016 | 27...

  • Page 28: Acquisition Control

     Write function (ASCII): “w sync” <value> The Timing diagrams associated to each Synchronization mode and the Timing values associated are detailed in the APPENDIX B of this document. UNIIQA+ C – R I – 09/2016 | 28 ANUAL OLOR...
  • Page 29 0), the Integration time is set higher than the Line Period. The Tables of the minimum Line Period (Max Line Rate) versus the Data rate and the output mode chosen are given in Appendix C (Chap. 10.2) of this document. UNIIQA+ C – R I – 09/2016 | 29 ANUAL...

  • Page 30: Gains And Offsets

    Then 3 Values are available : x1, x2 and x4. A gain x1 in a 12 bits conversion is equivalent to x4 in 10 bits. electrons Comparator Ramps at different Gains 4096 Clamp (Black 1024 Ref) UNIIQA+ C – R I – 09/2016 | 30 ANUAL OLOR A G E...
  • Page 31 CommCam “Gain & Offset” section :  Read function (ASCII): “r offs”; Returned by the camera : Value from –4096 to +4095 in LSB  Write function (ASCII): “w offs” <int> ; UNIIQA+ C – R I – 09/2016 | 31...

  • Page 32: Color Management

    Value from x-4 (-256) to x4 (256) step 0.015625 0x20220 cmbb ColorMatrixBlue(Blue) Value from x-4 (-256) to x4 (256) step 0.015625 0: Disable Color Matrix 0x20224 cmxe ColorMatrixEnable 1: Enable Color Matrix UNIIQA+ C – R I – 09/2016 | 32 ANUAL OLOR A G E...
  • Page 33 Returned by the camera : Integer value from 0 to 1548. The corresponding Gain is calculated as 20.log( 1 + <val>/1024) in dB  Write function : “w gwbg” <val> ; UNIIQA+ C – R I – 09/2016 | 33...
  • Page 34 1 : Enables the Line Interpolation Colum and Line Interpolation. Please, refer to chapter §2.2 for a detailed explanation of these two interpolations available for the User. UNIIQA+ C – R I – 09/2016 | 34 ANUAL OLOR A G E...
  • Page 35 Blue  Read function : “r cmrb”. Returns the Coefficient value from -4 (-256) to 4 (255)  Write function : “w cmrb <value>” : Set the Coefficient value UNIIQA+ C – R I – 09/2016 | 35 ANUAL OLOR...
  • Page 36  Write function : “w cmbb <value>” : Set the Coefficient value Color Matrix calculation Contact the e2v Hotline to help you about the Color Matrix calculation : hotline-cam@e2v.com By default, the Color Matrix is disabled but the coefficients are set with a Color Matrix for White LEDs Light Source.

  • Page 37: Flat Field Correction

     Read function (ASCII): “r ffcp” : Returns the FFC Status (0 if disabled, 1 if enabled)  Write function (ASCII):  “w ffcp 1” (ASCII): Enable the FFC.  “w ffcp 0” (ASCII) : Disabled the FFC UNIIQA+ C – R I – 09/2016 | 37 ANUAL OLOR...

  • Page 38: Automatic Calibration

    [-X , +X] around the pixel position. A large interval value allows filtering big defects on the paper but finally the setting of this interval depends also on the magnification in the system. UNIIQA+ C – R I – 09/2016...
  • Page 39 The Calculation result will be proposed anyway as it’s just a warning message. The Status Register is the changed and displayed in CommCam “Status” section : Register status is detailed chap §7.2. UNIIQA+ C – R I – 09/2016 | 39 ANUAL...
  • Page 40 User. When the FFC result is saved in memory, the adjust gain and target are saved in the same time in order to associate this gain value with the FFC result. UNIIQA+ C – R I – 09/2016...
  • Page 41  Remove the FFC Low Band filter (set to 0) if used during the Process. Advices The UNIIQA+ Cameras have 4 x FFC Banks to save 4 x different FFC calibrations. You can use this feature if your system needs some different conditions of lightning and/or Gain...

  • Page 42: Manual Flat Field Correction

    <val> is the concatenation of individual FPN values, without space between the values (2 Bytes per coefficient). <addr> auto increments automatically after each write command. UNIIQA+ C – R I – 09/2016 | 42...
  • Page 43 <val> is the concatenation of individual PRNU values, without space between the values (2 Bytes per coefficient). <addr> auto increments automatically after each write command. UNIIQA+ C – R I – 09/2016...

  • Page 44: Save & Restore Ffc And Configuration User Set

    - Last User Bank used is loaded in RAM Reset FPN Reset PRNU Reset a User bank : - Reset the RAM (FPN/PRNU individually) - Save in the bank to reset UNIIQA+ C – R I – 09/2016 | 44 ANUAL OLOR...

  • Page 45: Save & Restore Settings

    (Privilege level = 1). This integrator bank can be used as a « Factory default » by a system integrator. Configuration Bank Usage User Save User1 Ram Memory User2 Load User3 User4 Load Factory Integrator Save (Bank 5) UNIIQA+ C – R I – 09/2016 | 45 ANUAL OLOR A G E...

  • Page 46: Appendix

    APPENDIX UNIIQA+ C – R I – 09/2016 | 46 ANUAL OLOR A G E...

  • Page 47: Appendix A. Test Patterns

    Increment of 4 grey level at each pixels : Pixel 0 1 2 3 ….. 1020 1022 1023 Value 0 4 8 12 ….. 4084 4088 4092 UNIIQA+ C – R I – 09/2016 | 47 ANUAL OLOR A G E...

  • Page 48: Pixels, 12Bits

    A.4 1k Pixels, 12bits Increment of 8 grey level at each pixels : Pixel 0 1 2 3 ….. Value 0 8 16 24 ….. 4072 4080 4088 UNIIQA+ C – R I – 09/2016 | 48 ANUAL OLOR A G E...

  • Page 49: Appendix B. Timing Diagrams

    12 bits : 24µs This conversion is done in masked time, eventually during the next exposure period. : Delay between the Start exposure required and the real start of the exposure. UNIIQA+ C – R I – 09/2016 | 49...

  • Page 50: Synchronisation Modes With Maximum Exposure Time

    The Real exposure time (Tint ) is finally equal to the Line Period (T ) even if real it’s delayed from (T ) from the rising edge of the incoming Line Trigger. UNIIQA+ C – R I – 09/2016 | 50 ANUAL OLOR...

  • Page 51: Timing Values

    B.3 Timing Values Label Unit Tper µs Tint 1.26 µs real 0.120 µs 10µs 7.86µs µsec µs 2,06µs Tint 1,5µs 7.3µs prog UNIIQA+ C – R I – 09/2016 | 51 ANUAL OLOR A G E...

  • Page 52: Appendix C. Cameralink Data Cables

    Here is a following example of cable and the cable length limitation in accordance with the standard : DataRate Skew Cable Length 40Mhz 390ps 7,8m 66MHz 290ps 5,8m 70MHz 270ps 5,4m 80MHz 218ps 4,36m 85MHz 190ps 3,8m UNIIQA+ C – R I – 09/2016 | 52 ANUAL OLOR A G E...

  • Page 53: Choosing The Data Rate

    Line Rate Max (kHz) Tper Min (µs) 4096 Pixels 9.75 102.5 19.5 51.3 2048 Pixels 19.5 51.3 38.9 25.7 1024 Pixels 38.9 25.7 77.5 12.9 512 Pixels 77.5 12.9 UNIIQA+ C – R I – 09/2016 | 53 ANUAL OLOR A G E...

  • Page 54: Essential Models

    Data Frequency : 40MHz Base Definition Line Rate Max (kHz) Tper Min (µs) 4096 Pixels 9.75 102.5 2048 Pixels 19.5 51.3 1024 Pixels 38.9 25.7 512 Pixels UNIIQA+ C – R I – 09/2016 | 54 ANUAL OLOR A G E...

  • Page 55: Appendix D. Lens Mounts

    Appendix D. Lens Mounts D.1 F-Mount F Mount: (Part number EV71-F-MOUNT) UNIIQA+ C – R I – 09/2016 | 55 ANUAL OLOR A G E...

  • Page 56: C-Mount

    D.2 C-Mount C Mount : (Part number EV71-C-MOUNT) UNIIQA+ C – R I – 09/2016 | 56 ANUAL OLOR A G E...

  • Page 57: Appendix E. Commcam Connection

    In Windows 64bits, for a 32bits version : in the directory defined by the Register Key : CLSERIALPATH (REG_SZ) in HKEY_LOCAL_MACHINE\Wow6432Node\software\cameralink The directory should be program files(x86)\CamerLink\serial or any other specified UNIIQA+ C – R I – 09/2016 | 57...
  • Page 58 The Frame Grabber is compliant with CameraLink standard 1.1 > Contact the hotline : hotline-cam@e2v.com  An e2v Camera is detected but not  The version of CommCam used is too identified : old : You have to use the version 1.2.x and after.

  • Page 59: Appendix F. Revision History

    Interpolation in Full Definition Rev H Typo in mechanical dimensions 1.5.0 3.0.2 Rev I Typo Errors 1.5.1 3.0.2 New Mounts (C & F) references for UNIIQA+ UNIIQA+ C – R I – 09/2016 | 59 ANUAL OLOR A G E...
