Page 1: Installation Guide
Dome Network Camera Installation Guide Before attempting to set up or operate this camera, please read this quick installation guide and retain it for future reference. Model No. TN3230 QR-code for camera installation in the C4Home app. V1-140620 P/N: 3GA0310961... - Page 2 The information in this document is subject to change without notice. COMPRO reserves the right to make revisions to this publication without obligation to notify any person or entity of any such changes.
-
Page 3: Table Of Contents
Technical Specifications ........17 TN3230 Technical Specifications ......17 Technical Support Information . -
Page 4: Important Notices
Important Notices Regulatory Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 5: Product Overview
If anything is missing, please don’t hesitate to contact your local distributor. Item Description Network camera Compro TN3230 dome network camera Hex cap screw For use with the hexagon nuts to mount the camera on a rack rail Spring washer... -
Page 6: Hardware Overview
Hardware Overview Camera Layout Name Description IR LEDs Provides additional lighting in low light conditions Ambient light sensor Feeds information on environmental lighting condition to the camera Lens Vari-focal, f 3~9 mm, F1.2~2.1, auto iris, megapixel, IR- corrected Lens hood For eliminating unnecessary light; direction adjustable All-in- one ter minal Intergrating power, IO, Ethernet, and audio in/out... -
Page 7: Power Connector Pinout
Name Description Rotation adjustment Loosen the screw to rotate the lens screw Tilt adjustment screw For holding the tilting position of the camera Screw holes (on the For installing the wall mount bracket (resvered) bottom) for wall mount bracket Power connector A 3-pin power connector I/O connector For connection with various I/O devices... -
Page 8: Digital I/O Connector Block
The following output scenario is where the siren will only sound when the input has been triggered. Should you wish to use the other way around in which the output de- vice keeps staying on until the input has been triggered, please use NC. TN3230 TN3230 Product Overview... -
Page 9: Installation
Installation Mounting on a Dropped Ceiling Before you mount the camera on a dropped ceiling, you must first ensure that the ceil- ing is robust enough to hold the weight of the camera. Then refer to the following steps. 1. Use the supplied drill template to drill three mounting holes on the ceiling. Then drill a hole for the camera’s protective cap. -
Page 10: Connect The Cables
Connect the Cables Connect Camera Using PoE This camera supports PoE (Power-over-Ethernet), which allows electrical power and IP data to be both delivered on a single Ethernet cable. The following instructions explain how to connect your network camera using PoE. PoE Switch Wireless Router/Hub... - Page 11 Internet Wireless Router/Hub Using Ethernet Cable and Power Adapter The figure below shows the basic cabling of your IP camera. Internet Connect an Ethernet cable (not supplied in the package) between IP camera with your wireless switch/router. Connect the power adapter/power cable (optional accessary, not supplied in the package) to the IP camera and plug to the power outlet Make sure your smartphone is able to access the internet via your wireless switch/router.
-
Page 12: Install C4Home App And Add Camera
Install C4Home App and Add Camera Make sure your smartphone is able to go to internet via your wireless router. Then download the C4Home app from Apple store or Google Play and install to your smart- phone. Start C4Home app and register your personal C4Home account. (You can scan the QR-code below on your smartphone to add C4home app.) Login to the C4Home account and click “+”... -
Page 13: Adjust The Image
Adjust the Image Follow the instructions below to adjust the camera's varifocal lens. Adjust Zoom and Focus 1. To adjust the zoom and focus, first remove the protection sheet from the top cover, and then loosen the fixing screw on the top cover to remove the top cover. 2. - Page 14 60° 60° 180° 180° 3. Loosen the tilt adjustment screw (labeled in below figure) on both sides and then tilt the lens holder (labeled in below figure) to adjust the camera's tilting position. The tilt adjustment range is between +60 degrees to -60 degrees. 4.
-
Page 15: Change Sd Memory Card
7. Having obtained the optimal result, re-install the top cover to complete the op- eration. Change SD Memory Card The camera comes with a 4GB microSD card pre-installed inside the housing. The SD memory card is user-upgradeable. And if you like to replace it, refer to the steps below that explain the procedure. -
Page 16: Operation
From C4Home iPhone/Android App When you enable and register the C4Home service, you can use the C4Home app on your iPhone, Android phone or tablet to manage and watch live video of Compro cloud network cameras. The C4Home app is a safe and easy way to monitor your home, office and your valuable possessions from anywhere in the world. - Page 17 tures. Icon Name Description Click here to remove the installed network camera Edit from list. Add Camera Click here to add camera to the list. Here you can setup more details for each camera: Camera • Camera Settings: Setup the camera name Setup and password •...
- Page 18 Icon Name Description Click here for basic settings of C4Home app: Setup • Language: Select the display language for Page C4Home app. • Stream Buffer Size: Setup the stream buffer size for low, median or high. • Auto Login: Enable/Disable auto login for C4Home app.
-
Page 19: Technical Specifications
Technical Specifications TN3230 Technical Specifications Sensor 1/3" Progressive scan CMOS 2-megapixel sensor HD Vari-focal, f 3~9 mm, F1.2~2.1, auto iris, IR- Lens corrected Zoom 3X optical (manual adjust), 10x digital (total 30x) Angle of View 31.7° ~ 93° CAMERA Camera Angle 360°... - Page 20 (Live view in M-JPEG mode) • PoE switch/router or PoE injector (IEEE 802.3af class 3 Type B ) for PoE connection Dimensions Ø 160 x 135 mm Weight (Net) 1140 g (2.52 lb.) Optional • Compro PF-100, PF-200 PoE Injector Accessories • Power Adapter (DC 12V / 2A) * Specifications are subject to change without prior notice. Technical Specifications...
-
Page 21: Technical Support Information
Technical Support Information Contact Compro Technical Support If you need any technical support, fill out the online form (http://comprousa.com/en/ form.htm) or directly email to support@comprousa.com. Compro Technology, Inc. www.comprousa.com Tel. +886 2 2918 0169, Fax +886 2 2915 2389 4F, No.12, Alley 6, Lane 45, Pao Shin Road,... - Page 22 Technical Specifications...
- Page 24 . c o m p r o u s a . c o m Compro Technology Head Office 4F, No.12, Alley 6, Lane 45, Pao Shin Road, Hsintien District, New Taipei City 231, Taiwan Tel. +886 2 29180169 Fax. +886 2 29152389...
