- Page 1 AR-B9629 User’s Guide AR-B9629 Half Size All-In-One 386SX CPU BOARD User’s Guide Edition: 1.1 Book Number: AR-B9629-03.0109...
-
Page 2: Table Of Contents
AR-B9629 User’s Guide Table of Contents PREFACE ................................0-3 COPYRIGHT NOTICE AND DISCLAIMER......................... 0-3 WELCOME TO THE AR-B9629 CPU BOARD........................0-3 BEFORE YOU USE THIS GUIDE ............................0-3 RETURNING YOUR BOARD FOR SERVICE ........................0-3 TECHNICAL SUPPORT AND USER COMMENTS ......................0-3 ORGANIZATION................................ -
Page 3: Preface
0.3 BEFORE YOU USE THIS GUIDE Please refer to the Chapter 3, “Setting System,” in this guide, if you have not already installed this AR-B9629. Check the packing list before you install and make sure the accessories are completely included. -
Page 4: Organization
AR-B9629 User’s Guide 0.6 ORGANIZATION This information for users covers the following topics (see the Table of Contents for a detailed listing): Chapter 1, “Overview”, provides an overview of the system features and packing list. Chapter 2, “System Controller” describes the major structure. -
Page 5: Overview
Features 1.1 INTRODUCTION The AR-B9629 is a new generation half-size, 386SX board. This card offers much greater performance than the older cards such as support for onboard 2MB DRAM. The unit also comes with a programmable watchdog timer and other typical interfaces. The 386 CPU board is excellent for embedded systems, MMI’s, workstations, medical applications or POS/POI systems. -
Page 7: System Controller
Parallel Port (AR-B9449) 2.1 MICROPROCESSOR The AR-B9629 uses the ALI M6117 CPU; it is designed to perform systems like Intel’s 386SX system with deep green features. The 386SX core is the same as M1386SX of Acer Labs. Inc. and 100% object code compatible with the Intel 386SX microprocessor. -
Page 8: Keyboard Controller
2.4 INTERRUPT CONTROLLER The equivalent of two 8259 Programmable Interrupt Controllers (PIC) are included on the AR-B9629 board. They accept requests from peripherals, resolve priorities on pending interrupts in service, issue interrupt requests to the CPU, and provide vectors which are used as acceptance indices by the CPU to determine which interrupt service routine to execute. -
Page 9: I/O Port Address Map
AR-B9629 User’s Guide 2.4.1 I/O Port Address Map Hex Range Device 000-01F DMA controller 1 020-021 Interrupt controller 1 022-023 ALI M6117 chipset address 040-04F Timer 1 050-05F Timer 2 060-06F 8042 keyboard/controller 070-071 Real-time clock (RTC), non-maskable interrupt (NMI) -
Page 10: Real-Time Clock And Non-Volatile Ram
2.4.2 Real-Time Clock and Non-Volatile RAM The AR-B9629 contains a real-time clock compartment that maintains the date and time in addition to storing configuration information about the computer system. It contains 14 bytes of clock and control registers and 114 bytes of general purpose RAM. -
Page 11: Serial Port
AR-B9629 User’s Guide 2.5 SERIAL PORT The ACEs (Asynchronous Communication Elements ACE1 to ACE4) are not only used to convert parallel data to a serial format on the transmit side but also used to convert serial data to parallel on the receiver side. In order of transmission and reception, the serial format is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits. - Page 12 AR-B9629 User’s Guide (5) Line Control Register (LCR) Bit 0: Word Length Select Bit 0 (WLS0) Bit 1: Word Length Select Bit 1 (WLS1) WLS1 WLS0 Word Length 5 Bits 6 Bits 7 Bits 8 Bits Bit 2: Number of Stop Bit (STB)
-
Page 13: Parallel Port
AR-B9629 User’s Guide (9) Divisor Latch (LS, MS) Bit 0: Bit 0 Bit 8 Bit 1: Bit 1 Bit 9 Bit 2: Bit 2 Bit 10 Bit 3: Bit 3 Bit 11 Bit 4: Bit 4 Bit 12 Bit 5:... - Page 14 AR-B9629 User’s Guide (4) Printer Status Buffer The system microprocessor can read the printer status by reading the address of the Printer Status Buffer. The bit definitions are described below: -ERROR SLCT -ACK -BUSY Figure 2-2 Printer Status Buffer NOTE: X represents not used.
- Page 15 AR-B9629 User’s Guide (5) Printer Control Latch & Printer Control Swapper The system microprocessor can read the contents of the printer control latch by reading the address of printer control swapper. Bit definitions are as follows: STROBE AUTO FD XT...
-
Page 17: Setting Up The System
Overview System Setting 3.1 OVERVIEW The AR-B9629 is an all-in-one, half-size, 386SX CPU board. This section provides hardware jumper settings, the connectors’ locations, and the pin assignment. CAUTION: The CPU board doesn’t support the SIMM-type DRAM. Figure 3-1 External System Location... -
Page 18: System Settings
Press the jumper evenly onto the pins. Be careful not to bend the pins. We will show the locations of the AR-B9629 jumper pins, and the factory-default settings. CAUTION: Do not touch any electronic component unless you are safely grounded. Wear a grounded wrist strap or touch an exposed metal part of the system unit chassis. -
Page 19: Isa Bus Connector (Cn1)
AR-B9629 User’s Guide 3.2.4 ISA Bus Connector (CN1) DIP50 /ZWS RSTDRV IRQ9 BUSCLK (+12) /MEMW /IORDY /MEMR /IOW SA13 /IOR SA12 SA19 SA11 SA18 SA10 SA17 SA16 SA15 SA14 IRQ7 IRQ6 IRQ5 IRQ4 IRQ3 CN1: ISA Bus Connector... -
Page 20: External Buzzer (J2)
AR-B9629 User’s Guide DIP50 /DACK1 DRQ1 /DACK2 DRQ2 /DACK3 DRQ3 /REFSH (-5) BALE /IOCHK (-12) /SBHE /MEM16 LA23 /IO16 LA22 IRQ10 LA21 IRQ11 LA20 IRQ12 LA19 IRQ15 LA18 IRQ14 LA17 /DACK0 /MRD16 DRQ0 /MWR16 /DACK5 DRQ5 /DACK6 SD10 DRQ6 SD11... -
Page 21: Power Connector (J3)
AR-B9629 User’s Guide 3.2.6 Power Connector (J3) Reserved JST4S J3: Power Connector 3.2.7 I/O Connector for KB/MS, serial port, parallel port (CN3) 40PIN /IDEEN /IDERST /IDECS0 /IDECS1 TXD2D DSR2V RXD2D DTR2V DCD1D RI1D TXD1D RXD1D DSR1D RTS1D DTR1D CTS1D SDCT1... -
Page 22: Bios Console
AR-B9629 User’s Guide 4. BIOS CONSOLE This chapter describes the AR-B9629 BIOS menu displays and explains how to perform common tasks needed to get up and running, and presents detailed explanations of the elements found in each of the BIOS menus. The... -
Page 23: Standard Cmos Setup
AR-B9629 User’s Guide 4.2 STANDARD CMOS SETUP The <Standard CMOS Setup> option allows you to record some basic system hardware configuration and set the system clock and error handling. If the CPU board is already installed in a working system, you will not need to select this option anymore. -
Page 24: Advanced Cmos Setup
AR-B9629 User’s Guide 4.3 ADVANCED CMOS SETUP The <Advanced CMOS SETUP> option consists of configuration entries that allow you to improve your system performance, or let you set up some system features according to your preference. Some entries here are required by the CPU board’s design to remain in their default settings. - Page 25 AR-B9629 User’s Guide System Keyboard This function specifies that a keyboard will be attached to the computer. Primary Display The option is used to set the type of video display card installed in the system. Password Check This option enables password checking every time the computer is powered on or every time the BIOS Setup is executed.
-
Page 26: Advanced Chipset Setup
AR-B9629 User’s Guide 4.4 ADVANCED CHIPSET SETUP This option controls the configuration of the board’s chipset. Control keys for this screen are the same as for the previous screen. AMIBIOS SETUP - ADVANCED CHIPSET SETUP (C) 1995 American Megatrends, Inc. All Rights Reserved AT Bus Clock 14.318 / 2... -
Page 27: Peripheral Setup
OnBoard IDE This option specifies the onboard IDE controller channels that will be used. OnBoard FDC This option enables the floppy drive controller on the AR-B9629. OnBoard Serial Port This option enables the serial port on the AR-B9629. OnBoard Parallel Port This option enables the parallel port on the AR-B9629. -
Page 28: Auto-Detect Hard Disks
AR-B9629 User’s Guide 4.6 AUTO-DETECT HARD DISKS This option detects the parameters of an IDE hard disk drive, and automatically enters them into the Standard CMOS Setup screen. 4.7 PASSWORD SETTING This BIOS Setup has an optional password feature. The system can be configured so that all users must enter a password every time the system boots or when BIOS Setup is executed. -
Page 29: Bios Exit
AR-B9629 User’s Guide 4.9 BIOS EXIT This section is used to exit the BIOS main menu in two types situation. After making your changes, you can either save them or exit the BIOS menu and without saving the new values. -
Page 30: Bios Update
The chips can be electronically reprogrammed, allowing you to upgrade your BIOS firmware without removing and installing chips. The AR-B9629 provides FLASH BIOS update function for you to easily upgrade newer BIOS version. Please follow the operating steps for updating new BIOS: Turn on your system and don’t detect the CONFIG.SYS and AUTOEXEC.BAT files. -
Page 31: Specifications
CE-Design In Add EMI components to keyboard and PS/2 mouse PC Board: 4 layers Dimensions: 82.6 mmX57.2mm Operating Temp. 0~60℃ Storage Temp. -20~80℃ Operating Humidity 0~90﹪relative humidity none-condensing Order Information: AR-B9449 is a collocation tool for writing program on AR-B9629... -
Page 33: Placement & Dimensions
AR-B9629 User’s Guide 6. PLACEMENT & DIMENSIONS 6.1 PLACEMENT... -
Page 34: Dimensions
AR-B9629 User’s Guide 6.2 DIMENSIONS Unit: mil (1 inch = 25.4 mm = 1000 mil) Note: If the content in Setting is inconsistent with CD-ROM, please refer to the Setting as priority.
