Fun Generation ClubFX-1 Beam Flower40W Quad User Manual page 28

Operating
DMX address
28
The display shows 'DMX Addr' . Press [ENTER] to then select with [UP] and [DOWN] the first DMX
channel to be used by the device (DMX address) in a range between 001 to max. 509.
When the display shows the desired value press [ENTER] to save the setting and then [DOWN]
to change to the next menu item. To change the menu item without making changes, press
[MODE].
Make sure that this number matches the configuration of your DMX controller. The following
table shows the highest possible DMX address for the various DMX modes
Mode
4 channels
6 channels
10 channels
LED flower effect
Highest possible DMX address
509
507
503
