Summary of Contents for Viglen Vig550B
- Page 1 Vig550B Motherboard Manual C O M P U T E R S N E T W O R K S S O L U T I O N S...
- Page 2 Viglen’s Environment laboratory To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters.
- Page 3 Intel® Corporation. AMI BIOS is a registered trademark of American Megatrends. All other trademarks are acknowledged. JAC-UP, Genie, Contender, Dossier, Vig, Viglen, and Envy are trademarks of Viglen Limited. Copyright and Patents This manual and all accompanying software and documentation are copyrighted and all rights reserved.
-
Page 4: Table Of Contents
Main Menu items Standard CMOS Features 43 - 45 Advanced BIOS Features 46 - 47 Advanced Chipset Features DRAM Timing Control AGP & P2P Bridge Control On Chip AGP Control VGA Share Memory Size Vig550B Motherboard Manual – Ver 1.0... - Page 5 Main Menu Additional Options Chapter 5: Technical Information Enhanced IDE Operating Systems and Hard Drives 63 - 64 Power Supply Connector Useful Connector Information 66 - 68 Reliability Temperature Chapter 6: Glossary Notes Chapter 7: Suggestions Vig550B Motherboard Manual – Ver 1.0...
-
Page 6: Chapter 1: Motherboard Overview
Chapter 1: Motherboard Overview Introduction This manual describes the Viglen VIG550B motherboard inside your computer. The motherboard is the most important part of your computer. It contains all of the CPU, memory and graphics circuitry that make the computer work. -
Page 7: Feature Summary
Feature Summary The Vig550B motherboard supports Intel® Pentium® 4 and Celeron® processors with up to 1MB of second-level cache integrated in a micro PGA 775 Socket package operating at speeds up to 3.6GHz. The motherboard features: Form factor: • Micro ATX Form Factor: 243mm by 230mm Processor: •... - Page 8 775 connector. The package consists of: • Processor card including the processor core and the second-level cache burst pipelined synchronous static RAM (BSRAM) and tag RAM. • Thermal plate. • Back cover. Vig550B Motherboard Manual – Ver 1.0...
- Page 9 The motherboard can be upgraded with a Pentium 4 processor that runs at higher speeds. Memory Main Memory The Vig550B Motherboard has Two DDR DIMM sockets. Minimum memory size is 128MB; Maximum memory size is 2GB. The BIOS automatically detects memory type, size, and speed. The motherboard supports the following memory features: •...
- Page 10 Accelerated Graphics Port (AGP) The Vig550B features both integrated graphics and an AGP port. When using the integrated graphics then a dynamic portion of the main system memory is used as video memory. There is an optional GPA (Graphics Performance Accelerator) modules which has a dedicated 4MB of video memory.
- Page 11 1.44MB and 720KB DOS-formatted diskette and is supported by Windows 95 and Windows NT operating system. The Vig550B board allows connection of an LS-120 compatible drive and a standard 3½” floppy drive. The LS-120 drive can be configured as a boot device before a floppy drive, if selected in the BIOS setup utility.
- Page 12 One 9-pin D-Sub serial port connector is located on the back panel and is compatible with NS16C550 UARTs. NOTE: If a dual serial port card is installed in a PCI slot, wake on LAN needs to be disabled, otherwise the system will not shutdown and stay off. Vig550B Motherboard Manual – Ver 1.0...
-
Page 13: Audio Subsystem
This key sequence resets the computer’s software by jumping to the beginning of the BIOS code and running the Power-On Self Test (POST). Audio Subsystem The Vig550B board has multiple AC ’97 V 1.03 compliant audio features including an Analog Devices ALC 655 codec. The audio subsystem includes these features: •... - Page 14 This utility eliminates the need to enter the Set-up program after you install an IDE drive. Expansion Slots The system has Three PCI bus add-in card connectors and One AGP universal connector. Vig550B Motherboard Manual – Ver 1.0...
-
Page 15: System Board Components
K: Dimm 1 and 2 AA: PCI Slots L: ATX Power BB: AGP Slot M: CMOS Battery CC: Buzzer / Speaker N: Jumper 1 DD: Floppy Drive Connector O: IDE 1 / IDE 2 P: Power Fan Header Vig550B Motherboard Manual – Ver 1.0... -
Page 16: Overview Of System Board Components
266MHz operation, and 1.5V AGP interface that supports AGP 2.0 specification including 8x Fast Write protocol. I - 775 Intel CPU socket This the socket in which the CPU is installed into. J – CPU fan connector Allows a CPU fan to be connected. Vig550B Motherboard Manual – Ver 1.0... - Page 17 This allows an additional 2 USB ports to be added with the use of a cable. T – Internal USB4 header This allows an additional 2 USB ports to be added with the use of a cable. Vig550B Motherboard Manual – Ver 1.0...
- Page 18 CC – Onboard Speaker / Buzzer Output Audio Errors or Beeps. DD – Floppy drive connector This allows a floppy drive to be added to the motherboard. The port is slotted to ensure correct installation. Vig550B Motherboard Manual – Ver 1.0...
-
Page 19: Back Panel Connectors
Back Panel Connectors The Vig550B Motherboard external IO connectors are attached to a metallic I/O shield. This shield serves several purposes: • It protects the sensitive motherboard from any external EMC interference. • It stops the computer from interfering with other electrical devices. - Page 20 Table 3: Audio 2, 4 or 6-channel configuration Headphone/2-Speaker 4-Speaker 6-Speaker Light Blue Line In Rear Speaker Out Rear Speaker Out Lime Line Out Front Speaker Out Front Speaker Out Pink Mic In Mic In Bass/Center Vig550B Motherboard Manual – Ver 1.0...
-
Page 21: Chapter 2: System Board Options
Chapter 2: System Board Options The VIG550B motherboard is capable of accepting Pentium® 4 CPU’s. RAM can be upgraded to a maximum of 2GB using DDR400 SDRAM DIMMs Non ECC Unbuffered memory. WARNING! Unplug the system before carrying out the procedures described in this chapter. - Page 22 Make sure you are earthed and free of static charge before you open the computer case. If you are unsure about upgrading your computer, return it to Viglen so a qualified engineer can perform the upgrade. STEPS TO TAKE TO PREVENT STATIC DISCHARGE: 1.
-
Page 23: Overview Of Jumper Settings
Overview of Jumper Settings The Vig550B motherboard contains the latest technology to offer an almost jumper less configuration. All Pentium® 4 CPUs are automatically detected and the Speed is automatically set from the information provided by the CPU. The only jumper present on the motherboard is for clearing all the CMOS settings. In the unlikely event of the CMOS becoming corrupted then jumper JP1 can be set to clear the contents of the CMOS. -
Page 24: System Board Jumper Settings
The BIOS uses current configuration information and passwords for booting. Clear Turn off the system and unplug the power cord. Move the jumper from pins 1-2 (default) to pins 2-3 for about 5~10 seconds. Then move the jumper back to pins 1-2. Vig550B Motherboard Manual – Ver 1.0... - Page 25 Do not move the jumper with the power on. Always turn off the power and unplug the power cord from the computer before changing the jumper Note: There is no jumper setting for configuring the processor speed or bus frequency. Vig550B Motherboard Manual – Ver 1.0...
-
Page 26: Motherboard Connectors
Motherboard Connectors There are connectors on the motherboard for FAN, IDE, Power supply, CD audio, Floppy, IDE, & Front Panel Connectors. The location and/or details of these connections are shown below. Figure 4: Motherboard Connectors Vig550B Motherboard Manual – Ver 1.0... -
Page 27: Front Panel Connectors
Power L.E.D. This attaches to the power L.E.D on the front panel, to display if the computer is active or not. Power On/Off When these pins are shorted it turns the computer on and off. Vig550B Motherboard Manual – Ver 1.0... -
Page 28: Upgrading The Cpu
The Pentium® 4 processor together with Level 2 cache chips are housed in a protective package. The design of the Vig550B computer makes it a simple job to replace or upgrade the processor. To do so please refer to figure 6 and follow the instructions below: 1. -
Page 29: Installing & Removing Memory Modules
Hold the DIMM by the edges, lift it away from the socket, and store it in an antistatic package. 5. Reinstall and reconnect any parts you removed or disconnected to reach the DIMM sockets. Vig550B Motherboard Manual – Ver 1.0... -
Page 30: Expansion Slots (Pci & Agp)
IRQ Holder for PCI steering Advanced AC’97 CODEC Standard PCI Graphics Adapter (VGA) PS/2 Compatible Mouse Port Numeric Data Processor Primary IDE Channel Secondary IDE Channel * These IRQs are usually available for ISA or PCI devices Vig550B Motherboard Manual – Ver 1.0... -
Page 31: Pci Slots
This motherboard has an Accelerated Graphics Port (AGP) slot that supports AGP 8X (3.3V/1.5V) cards. Note: The notches on the card golden fingers to ensure that they fit the AGP slot on your motherboard. Figure 9: Install an AGP card Vig550B Motherboard Manual – Ver 1.0... -
Page 32: Replacing The Clock/Cmos Ram Battery
CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by Viglen. Discard used batteries according to manufacturer’s instructions. The battery is listed as board component ‘E’ on the diagram on Figure 1. -
Page 33: Chapter 3: Solving Problems
Please remember that if you cannot solve the problem by yourself then you should contact your suppliers Technical Support for further assistance. Viglen Technical Support can be reached in the following ways: Telephone: 020 8758 7000 Fax: 020 8758 7080 Email: techsupport@viglen.co.uk... -
Page 34: Troubleshooting Procedures
If this type of error occurs, refer to the error codes and messages listed at the end of this chapter. 6. Confirm that the operating system has loaded. Vig550B Motherboard Manual – Ver 1.0... -
Page 35: Problems Operating Add-In Boards
• If the PCI/ISA legacy board uses memory space between 80000H - 9FFFFH, run Set-up and set conventional memory to 256 K. • If the PCI/ISA legacy board uses shared memory between C8000H - DFFFH, run Set-up and enable shared memory for the appropriate memory space. Vig550B Motherboard Manual – Ver 1.0... -
Page 36: Problems & Suggestions
Make sure the power and signal cables for the drive are properly not go on when drive is installed. in use or is tested by Check that the drive is properly configured and enabled in Setup. POST Vig550B Motherboard Manual – Ver 1.0... -
Page 37: Problems & Suggestions
This indicates a fatal system error that requires immediate service completing POST attention. Note the screen display and write down any beep code emitted. Provide this information to your dealer service department / Technical Support. Vig550B Motherboard Manual – Ver 1.0... -
Page 38: Chapter 4: System Bios
RAM (also known as the CMOS RAM) and provides a special Setup program to change this information. The BIOS in your Viglen computer is guaranteed to be fully compatible with the IBM BIOS. It has been written by American MegaTrends Inc. (AMI), an industrial leader in the field of BIOS software. -
Page 39: Phoenix Bios - Introduction
BIOS Upgrades A new version of the BIOS can be upgraded from a diskette using the AFUDOS.EXE utility that is available from the Viglen FTP site. This utility does BIOS upgrades as follows: • Updates the flash BIOS from a file on a disk. -
Page 40: Configuring The Motherboard Using Bios Setup
Configuring the Vig550B Motherboard using BIOS Setup Before You Begin CAUTION! • Always follow the steps in each procedure in the correct order. • Set up a log to record information about your computer, such as model, serial numbers, installed options, and configuration information. -
Page 41: Bios Setup Program
Note: If the system becomes unstable after changing any BIOS settings, load the default settings to ensure system stability. Select the Load Default Settings item under the Exit Menu. Vig550B Motherboard Manual – Ver 1.0... -
Page 42: Main Menu
At the bottom right corner of a menu screen are the navigation keys for that particular menu. Use the navigation keys to select items in the menu and change the settings. Some of the navigation keys differ from one screen to another. Vig550B Motherboard Manual – Ver 1.0... -
Page 43: Main Menu Items
A scroll bar appears on the right side of a menu screen when there are items that do not fit on the screen. Press Up/Down arrow keys or PageUp/PageDown keys to display the other items on the screen. General Help Vig550B Motherboard Manual – Ver 1.0... -
Page 44: Standard Cmos Features
Sets the type of floppy drive installed. Configuration options: [Disabled] [360K, 5.25 in.] [1.2M , 5.25 in.] [720K , 3.5 in.] [1.44M, 3.5 in.] [2.88M, 3.5 in.] Floppy 3 Mode Support This feature is not supported. Vig550B Motherboard Manual – Ver 1.0... - Page 45 This displays the amount of base memory installed on the system, typically 640K. Extended Memory This displays the amount of extended memory detected during system boot-up. Total Memory This displays the total amount of memory available in the system. Vig550B Motherboard Manual – Ver 1.0...
- Page 46 The approximate size of the disk drive. The size is normally slightly greater then the formatted disk given in the disk-checking program. Cylinder This item configures the number of cylinders Head This item configures the number of read/write heads. Vig550B Motherboard Manual – Ver 1.0...
-
Page 47: Advanced Bios Features
Figure 15: Advanced BIOS features Sub-Menu CPU Feature This item is used to manage the thermal state for certain CPU. Hard Disk Boot Priority Use this option to select the hard disk boot priority Vig550B Motherboard Manual – Ver 1.0... - Page 48 NOTE: Don’t forget your password. If you forget the password, you will have to open the computer case and clear all information in the CMOS before you can start up the system. But by doing this, you will have to reset all previously set options. Vig550B Motherboard Manual – Ver 1.0...
-
Page 49: Advanced Chipset Features
[Yes]: The system automatically detects the unused DIMM and PCI slot and stops sending the clock signal to them. [No]: The clock signal is sent to all PCI slots. Advanced Chipset Features Figure 16: Advanced Chipset Features Vig550B Motherboard Manual – Ver 1.0... -
Page 50: Dram Timing Control
DRAM installed. DO NOT change the values in this field unless you have changed the DRAM or CPU. AGP & P2P Bridge Control Figure 18: AGP & P2P Bridge Control Vig550B Motherboard Manual – Ver 1.0... -
Page 51: On Chip Agp Control
VGA. In the case above the memory being used for the VGA is 64MB; this also means that 64MB will be lost from the main memory. System BIOS Cacheable This allows the BIOS to be cached in the memory for faster execution. Enable for better performance. Vig550B Motherboard Manual – Ver 1.0... -
Page 52: Integrated Peripherals
Enable for better performance. Integrated Peripherals Figure 20: Integrated Peripherals Init Display First This specifies whether your graphics card in installed in one of the PCI slots or is integrated on the motherboard. On Chip IDE Device Vig550B Motherboard Manual – Ver 1.0... -
Page 53: On Chip Ide Device
When enabled every write instruction sent by the system, will be sent to the write buffer. Burst able transactions then burst on the PCI bus in one go and non-burst able transactions do not. Vig550B Motherboard Manual – Ver 1.0... -
Page 54: On Chip Pci Device
This allows a USB mouse to be used in a DOS environment by selecting [BIOS] or in the OS by selecting [OS]. Audio Controller This allows you to control the onboard AC97 audio. Disable this item if you are going to install a PCI audio add-on card. Vig550B Motherboard Manual – Ver 1.0... -
Page 55: Onboard Super Io Device
Onboard Serial Port 1 This assigns the I/O address and interrupt request (IRQ) for the onboard serial port1 (COM1) Onboard Parallel Port This assigns the I/O address and interrupt request (IRQ) for the onboard parallel port. Vig550B Motherboard Manual – Ver 1.0... -
Page 56: Onboard Pci Device
Figure 24: Onboard PCI Device Onboard LAN Device Enables and disables the onboard LAN LAN Boot ROM Enables and disables booting from the onboard LAN or a network add-in card with a remote boot ROM installed. Vig550B Motherboard Manual – Ver 1.0... -
Page 57: Power Management Setup
[Power Off] When the AC power returns the system remains off. You must press the power button to turn the system on. [Power On] When the AC power returns the system will be powered on automatically. Vig550B Motherboard Manual – Ver 1.0... -
Page 58: Pm Wakeup Events
The default is [Move & Click]. Wakeup by Alarm Allows the system to be woken from an alarm. Once enabled options for Month Alarm, Day Alarm and time alarm are available to be selected and edited. Vig550B Motherboard Manual – Ver 1.0... -
Page 59: Pnp/Pci Configurations
Note: The ESCD (Extended System Configuration Data) contains the IRQ, DMA, I/O port and memory information of the system. This is a specification and feature of the Plug & Play BIOS. Vig550B Motherboard Manual – Ver 1.0... -
Page 60: Irq Resources
[Enable] MPEG ISA/VESA VGA card work with PCI/VGA. [Disable] MPEG ISA/VESA VGA card do not work with PCI/VGA. PIRQ_0 Use No. ~ PIRQ_7 Use IRQ No. This allows IRQ numbers to be specified manually or automatically for installed PCI devices. Vig550B Motherboard Manual – Ver 1.0... -
Page 61: Pc Health Status
This item allows a temperature to be set at which the system will shut down automatically to prevent over heating. All Voltages, Fans Speed and Thermal Monitoring These are unchangeable as they give the current statues of the CPU, environment temperatures, fan speeds and the system power voltage. Vig550B Motherboard Manual – Ver 1.0... -
Page 62: Frequency/Voltage Control
Allows the CPU clock ratio to be changed if it isn’t locked. Spread Spectrum If enabled, could reduce the EMI (Electro-Magnetic Interference) generated by the system. Clock Control By Allows control over Async, CPU Frequency, DRAM Ratio and DRAM frequency. Vig550B Motherboard Manual – Ver 1.0... -
Page 63: Main Menu Additional Options
Allows the settings that have been changed to be saved and exits the BIOS setup menu. This also reboots the machine. Exit Without Saving Exits the BIOS setup menu without saving any setting that have been changed. This also reboots the machine. Vig550B Motherboard Manual – Ver 1.0... -
Page 64: Chapter 5: Technical Information
Block Addressing), and the OS supports LBA, or uses the BIOS to access the disk. Extended CHS mode also overcomes the 528MB maximum size limitation imposed by Standard CHS mode. It can be used with drives which are larger than 528MB that do not support LBA. Vig550B Motherboard Manual – Ver 1.0... - Page 65 If this driver is not installed and the drive fitted to the system supports Type F DMA on the ISA interface or Mode 3 on the PCI interface then higher performance will be achieved by NOT using '32-bit Disk Access'. Vig550B Motherboard Manual – Ver 1.0...
-
Page 66: Power Supply Connector
+5 V Ground +5 V Ground PWRGD (Power Good) +5 VSB (Standby) +12 V +3.3 V -12 V Ground PS-ON# (power supply remote on/off control) Ground Ground Ground -5 V +5 V +5 V Vig550B Motherboard Manual – Ver 1.0... -
Page 67: Useful Connector Information
Audio Right Out Table 17: Audio Line In Connector Signal Name Sleeve Ground Audio Left In Ring Audio Right In Table 18: Audio Mic In Connector Signal Name Sleeve Ground Mono In Ring Electric Bias Voltage Vig550B Motherboard Manual – Ver 1.0... - Page 68 +5 V (I/O) AD20 AD21 REQ64C# ACK64C# Ground AD19 +5 V +5 V AD18 +3.3 V +5 V +5 V These signals (in parentheses) are optional in the PCI specification and are not currently implemented. Vig550B Motherboard Manual – Ver 1.0...
- Page 69 Table 21: Front Panel USB Pin Assignment Pin Assignment Data0 - Data1 - Data0 + Data1 + Ground Ground Table 22: Internal Speaker Pin Assignment Signal Ground Vig550B Motherboard Manual – Ver 1.0...
-
Page 70: Reliability
MTBF data is calculated from predicted data @ 55 °C. The MTBF prediction for the motherboard is 112,977. 7547 hours. Temperature Table 23: Temperature Temperature Specification Non-operating -40°C to +70°C Operating 0°C to +55°C Vig550B Motherboard Manual – Ver 1.0... -
Page 71: Chapter 6: Glossary
Much of the circuitry previously required on hard disk controller cards is now integrated on the hard disk itself. Interface The electronics providing a connection between two pieces of equipment. For example, a printer interface connects a computer to a printer. Vig550B Motherboard Manual – Ver 1.0... - Page 72 BIOS is responsible for this copying. Super VGA Additional screen modes and capabilities provided over and above the standard VGA defined by IBM. Video Graphics Array - the graphics standard defined by IBM and provided on IBM's PS/2 machines. Vig550B Motherboard Manual – Ver 1.0...
-
Page 73: Notes
Notes Vig550B Motherboard Manual – Ver 1.0... -
Page 74: Chapter 7: Suggestions
Viglen is interested in continuing to improve the quality and information provided in their manuals. Viglen has listed some questions that you may like to answer and return to Viglen. This will help Viglen help to keep and improve the standard of their manuals. - Page 75 5. How do you rate the Viglen Technical support and Service Departments? Are there any technological improvements that could be made to the system? 7. Other points you would like to mention? Please return this slip to: Product Development Dept.
