Viglen Vig711W Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Vig711W
Motherboard
Manual
.
.
C O M P U T E R S
N E T W O R K S
S O L U T I O N S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vig711W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Viglen Vig711W

Summary of Contents for Viglen Vig711W

  • Page 1 Vig711W Motherboard Manual C O M P U T E R S N E T W O R K S S O L U T I O N S...
  • Page 2 Viglen’s Environment laboratory To gain a 'CE' mark, the Viglen computer range has had to undergo many difficult tests to ensure it is Electromagnetically Compatible. These are carried out in the in-house 'Environment lab' at Viglen Headquarters. We have made every effort to guarantee that each computer leaving our factory complies fully with the correct standards.
  • Page 3 PS/2 are trademarks of International Business Machines Corporation. Core i3/i5/i7 Pentium® are registered trademarks of Intel® Corporation. All other trademarks are acknowledged. Genie, Vig, Viglen, and Omnino are trademarks of Viglen Limited. Copyright and Patents This manual and all accompanying software and documentation are copyrighted and all rights reserved.

  • Page 4: Table Of Contents

    Replacing the Clock/CMOS RAM Battery Chapter 3: Solving Problems Resetting the System Troubleshooting Procedures Problems & Suggestions Chapter 4: System BIOS What is the BIOS? The Power-On Sequence BIOS Upgrades BIOS Setup Windows 8/8.1 BIOS Setting Chapter 5: Suggestions V1.0 Vig711W Motherboard Manual...

  • Page 5: Chapter 1: Motherboard Overview

    Chapter 1: Motherboard Overview Introduction This manual describes the Viglen Vig710W motherboard inside your computer. The motherboard is the most important part of your computer. It contains the CPU, memory and graphics circuitry that make the computer work in the correct manner.

  • Page 6: Feature Summary

    Gigabit Ethernet Controller Rear I/O Ports  1 x 19V Power Port  1x HDMI  1x Gigabit LAN (Realtek® RTL8111F)  1x Microphone  1x Headphone/Speaker  2x USB 3.0 Ports  2x USB 2.0 Ports V1.0 Vig711W Motherboard Manual...
  • Page 7 1 x TPM Connector (2 x8 pin) Expansion Capabilities  1 x Half Mini PCI Express slot supports PCIe signal  1 x Full Mini PCI Express slot supports PCIe signal (Default) BIOS  AMI EFI BIOS V1.0 Vig711W Motherboard Manual...
  • Page 8 If non-SPD memory is installed, the BIOS will attempt to correctly configure the memory settings, but performance and reliability may be impacted or the SO-DIMMs may not function under the determined frequency. V1.0 Vig711W Motherboard Manual...
  • Page 9 8 full range channels at 24-bit/96kHz audio of lossless audio formats such as Dolby TrueHD or DTS HD Master Audio. The maximum supported resolution is 1920 x 1200 at 60 Hz refresh (WUXGA). The HDMI port is compliant with the HDMI 1.3 specification. V1.0 Vig711W Motherboard Manual...
  • Page 10 Figure 1: Audio Connectors  Line-Out (Green) - Line Out, is a connector for speakers or headphones.  Mic (Pink) - Mic, is a connector for microphones. V1.0 Vig711W Motherboard Manual...
  • Page 11 Link Green LAN activity is occurring. LAN link is established. Blinking LAN activity is occurring. Data Green/yellow 10 Mb/s data rate is selected. rate 100 Mb/s data rate is selected. 1000 Mb/s data rate is selected. V1.0 Vig711W Motherboard Manual...
  • Page 12 POST. When the voltage drops below a certain level, the BIOS Setup program settings stored in CMOS RAM (for example, the date and time) might not be accurate. Replace the battery with an equivalent one. V1.0 Vig711W Motherboard Manual...
  • Page 13 If only the supervisor password is set, the computer boots without asking for a password. If both passwords are set, you can enter either password to boot the computer. V1.0 Vig711W Motherboard Manual...

  • Page 14: System Board Components

    Mini PCI-E Full-card Slot SATA Ports TPM Connector Header SoDIMM Slots Mini PCI-E Half-card Slot SATA Power_HDD Clear_CMOS SATA Power_ODD DMIC Header System Fan Header CPU Fan Header LCD Voltage Selector Chassis Speaker Connector Front Panel Header Battery Connector V1.0 Vig711W Motherboard Manual...

  • Page 15: Back Panel Connectors

    These audio connectors are used for audio devices (MIC-IN, LINE-OUT). Note: The back panel audio line out connectors is designed to power headphones or amplified speakers only. Poor audio quality occurs if passive (non-amplified) speakers are connected to this output. V1.0 Vig711W Motherboard Manual...

  • Page 16: Chapter 2: System Board Options

    The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red. CAUTION! The Viglen Vig710W motherboard and associated components are sensitive electronic devices. A small static shock from your body can cause expensive damage to your equipment.

  • Page 17: Before You Begin

    BEFORE YOU BEGIN Make sure you are earthed and free of static charge before you open the computer case. If you are unsure about upgrading your computer, return it to Viglen so a qualified engineer can perform the upgrade. STEPS TO TAKE TO PREVENT STATIC DISCHARGE: 1.

  • Page 18: System Board Jumper Settings

    RAM onboard has a power supply from an external battery to keep the data of the system configuration. The CMOS RAM allows the system to automatically boot OS every time it is turned on. Status Normal Clear CMOS Figure 5: Clear CMOS jumper V1.0 Vig711W Motherboard Manual...

  • Page 19: Motherboard Connectors

    50 ms to signal the power supply to switch on or off. (The time Power Switch Header requirement is due to internal debounce circuitry on the board.) At least two seconds must pass before the power supply will recognize another on/off signal. V1.0 Vig711W Motherboard Manual...
  • Page 20 Note: DC Power connector supports 19V power Adapter. The back panel DC connector is compatible with a 7.4 mm/OD (outer diameter) and 5.1 mm/ID (inner diameter) plug, where the inner contact is +19 (±10%) V DC and the shell is GND. The maximum current rating is 12 A. V1.0 Vig711W Motherboard Manual...
  • Page 21 Signal Name Signal Name [Port 1] Left channel Ground [Port 1] Right channel PRESENCE# (Dongle present) [Port 2] Right channel [Port 1] SENSE_RETURN SENSE_SEND (Jack detection) Key (no pin) [Port 2] Left channel [Port 2] SENSE_RETURN V1.0 Vig711W Motherboard Manual...
  • Page 22 USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Figure 9: Front USB connectors Front USB Connector: USB20_5 Figure 10: Front USB connector - single    V1.0 Vig711W Motherboard Manual...
  • Page 23 CPU fan control. Figure 11: Fan Power connectors Table 5: System FAN header, CPU FAN header 4-Wire support 3-Wire support +12V power +12V power FAN_FB FAN_PWM Control V1.0 Vig711W Motherboard Manual...
  • Page 24 This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device. Figure 12: Serial ATA Connector NOTE: Please do not fold the serial ATA cable into 90-degree angle. Otherwise, data loss may occur during transmission. V1.0 Vig711W Motherboard Manual...

  • Page 25: Upgrading The Cpu

    2. Rotate the socket lever to lift the load plate away from the socket (Figure 14, A). Make sure that the load plate is in the fully open position (Figure 13, B) while being careful not to damage adjacent components. Do not touch the socket contacts. Figure 14: Lift the load plate V1.0 Vig711W Motherboard Manual...
  • Page 26 B) and that the notches on the processor align with the posts on the socket (Figure 16, C). Lower the processor straight down without tilting or sliding it in the socket (Figure 16, A). Figure 16: Install the processor V1.0 Vig711W Motherboard Manual...
  • Page 27 (Figure 17, C, and D). The socket cover (Figure 17, B) will pop off as shown. Figure 17: Secure the load plate in place 6. Pick up the socket cover and remove it from the desktop board. V1.0 Vig711W Motherboard Manual...
  • Page 28 Make sure the four hooks are in the proper position before you install the cooler. If the heatsink is held in by screws, position heatsink correctly and screw into place. Figure 18: Connecting the processor fan heat sink power cable to the processor fan header V1.0 Vig711W Motherboard Manual...

  • Page 29: Installing & Removing Memory Modules

    5. When the SO-DIMM is seated, push down until the retaining arms at either ends of the socket snap into place. Make sure the clips are firmly in place. 6. Replace the computer cover. Figure 19: Memory Installation V1.0 Vig711W Motherboard Manual...
  • Page 30 Hold the SO-DIMM by the edges, lift it away from the socket, and store it in an antistatic package. 5. Reinstall and reconnect any parts you removed or disconnected to reach the SO- DIMM sockets. Figure 20: Removing Memory Modules V1.0 Vig711W Motherboard Manual...

  • Page 31: Replacing The Clock/Cmos Ram Battery

    CAUTION! Danger of explosion if the battery is incorrectly replaced. Replace only with the same or equivalent type recommended by Viglen. Discard used batteries according to manufacturer’s instructions. To replace the battery, carry out the following: 1.

  • Page 32: Chapter 3: Solving Problems

    The second part lists error code messages that might be displayed. Please remember that if you cannot solve the problem by yourself then you should contact Viglen Technical Support for further assistance. Viglen Technical Support can be reached in the following ways: Telephone: 01727 201 850 Fax:...

  • Page 33: Troubleshooting Procedures

    Errors that prevent the boot process from continuing (fatal errors), are communicated by a series of audible beeps. If this type of error occurs, refer to the error codes and messages listed at the end of this chapter. 6. Confirm that the operating system has loaded. V1.0 Vig711W Motherboard Manual...

  • Page 34: Problems & Suggestions

    Check that the brightness and contrast controls are properly adjusted. Check that the video signal cable is properly installed. Make sure a video board is installed, enabled, and the jumpers are positioned correctly. Reboot the system. V1.0 Vig711W Motherboard Manual...
  • Page 35 System halts before This indicates a fatal system error that requires immediate service attention. Note the screen display and write down any beep code completing POST emitted. Provide this information to your dealer service department / Technical Support. V1.0 Vig711W Motherboard Manual...

  • Page 36: Chapter 4: System Bios

    (also known as the CMOS RAM) and provides a special Setup program to change this information. The BIOS in your Viglen computer is guaranteed to be fully compatible with the IBM BIOS. It has been written by American Megatrends Inc, an industrial leader in the field of BIOS software.

  • Page 37: Bios Upgrades

    AMIDEDOS.EXE utility or in Windows using the AEFUWIN utility that is available from the Viglen FTP site. This utility does BIOS upgrades as follows:  Updates the flash BIOS from a file on a disk or within the location of the utility.

  • Page 38: Bios Setup

    Select Screen ↑↓ Select Item <Enter> Select Change Opt General help Previous values Optimized Defaults Save & Exit ESC: Exit Getting Help After entering the Setup menu, the first menu you will see is the Main Menu. V1.0 Vig711W Motherboard Manual...
  • Page 39  Boot - Use this menu to specify the priority of boot devices.  Security - Use this menu to set supervisor and user passwords.  Save & Exit - This menu allows you to load the BIOS default values or factory V1.0 Vig711W Motherboard Manual...
  • Page 40 3. Save & Exit Setup: Use the arrow keys (←, →, ↑, ↓) to select the [Save Changes & Reset] in [Save & Exit] menu, and press <Enter>. A pop-up message will appear, please select [Yes] and press<Enter> to save the configurations and exit BIOS setup utility. Figure 25: Save & Exit Setup V1.0 Vig711W Motherboard Manual...

  • Page 41: Windows 8/8.1 Bios Setting

    To access the BIOS, Press the F7 key during POST for the boot menu to appear and then select ‘Enter Setup’ Enabling/Disabling Windows 8/10 Features 1. From the BIOS main menu select the ‘Boot’ tab. Figure 26: Main menu V1.0 Vig711W Motherboard Manual...
  • Page 42 Figure 27: Boot Configuration Menu – Windows 7 settings For Windows 8.1 and 10 following settings should be set: OS Boot Mode [UEFI OS] Network Stack [Enabled] Figure 28: Boot Configuration Menu – Windows 8/10 settings V1.0 Vig711W Motherboard Manual...
  • Page 43 In the Boot configuration menu ensure OS boot Mode is set to [UEFI OS]. 1. From the BIOS tab options select the ‘Security’ tab and select the ‘Secure Boot menu’ option. Figure 29: Boot Configuration Menu – Windows 8/10 settings V1.0 Vig711W Motherboard Manual...
  • Page 44 2. Once Secure Boot is set to ‘Enabled’ set the Secure Boot Mode to ‘Custom’ Figure 30: Secure Boot Enabled/Disabled option 3. In Custom mode scroll down the active options in the Security Tab option list and Select the ‘Key Management’ Option. Figure 31: Secure Boot V1.0 Vig711W Motherboard Manual...
  • Page 45 Figure 32: Default Key Provisioning 5. In the Key management options select the ‘Install default Secure Boot Keys’ option and confirm Installation in the pop up to install the default secure Boot Keys. Figure 33: Default Secure Boot Keys V1.0 Vig711W Motherboard Manual...
  • Page 46 5. Once the Default Secure Boot keys are installed it will state ‘Installed’ as shown in below image Figure 34: Default Secure boot keys V1.0 Vig711W Motherboard Manual...
  • Page 47 1. In the Key management options select ‘Default Key Provisioning’ and Set the option to ‘Disabled’ Figure 35: Default Key Provisioning 2. Select ‘Clear Secure Boot Keys’ and confirm Installation in the prompt pop up to clear the default secure Boot Keys. Figure 36: Reset platform V1.0 Vig711W Motherboard Manual...
  • Page 48 Once all BIOS settings have been configured press F4 key to Save and Exit the BIOS Setup. For Non UEFI OS support (Windows 7) secure boot keys must be set to default and secure boot disabled. Otherwise system will not detect SATA hard disk drive under boot menu. V1.0 Vig711W Motherboard Manual...

  • Page 49: Chapter 5: Suggestions

    Viglen is interested in continuing to improve the quality and information provided in their manuals. Viglen has listed some questions that you may like to answer and return to Viglen. This will help Viglen to keep and improve the standard of their manuals.
  • Page 50 Are there any technological improvements that could be made to the system? 7. Other points you would like to mention? Please return this slip to: Product Development Dept. XMA Ltd. 7 Handley Page Way Colney Street St Albans Hertfordshire AL2 2DQ V1.0 Vig711W Motherboard Manual...
