- Page 1 User Manual...
-
Page 2: Table Of Contents
Wireless Remote Control ......................... 14 5. Technical Information ....................15 Fogger Maintenance ........................15 Storage/ Maintenance ........................15 General Troubleshooting ........................ 16 6. Technical Specifications ....................17 Returns ............................18 Contact Us .........................19 Page 2 of 19 Geyser P4. User Manual Rev. 2... -
Page 3: Before You Begin
Chauvet believes that the information contained in this manual is accurate in all respects. However, Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss, damage or disruption caused by any errors or omissions in this document, whether such errors or omissions result from negligence, accident or any other cause. -
Page 4: Safety Notes
Keep this User Manual for future use. If you sell the product to another user, be sure to give this document to the next owner. Fog Cleaner Quart (FCQ) was specifically developed by Chauvet to clean your Geyser P4 Make sure you use FCQ regularly, no longer than 90 days between cleanings, to increase the life of your fogger. -
Page 5: Introduction
Nozzle and LEDs Fluid Line In Handles Safety Eye Control Loop LED Display Buttons DMX In/Out On/Off Switch Power In Safety Eye Loop Fuse Holder Manual Fog Remote Control Button Receiver Port Geyser P4 User Manual Rev. 2 Page 5 of 19... -
Page 6: Dimensions
Dimensions 13.4 in (340 mm) 10.2 in (260 mm) 7 in (180 mm) 2.39 in (60.8 mm) Page 6 of 19 Geyser P4. User Manual Rev. 2... -
Page 7: Setup
ETUP AC Power The Geyser P4 has a fixed voltage power supply and it can work with an input voltage of either 120 VAC, 60 Hz or 230 VAC, 50 Hz, depending on the specific model. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s panel, or refer to... -
Page 8: Mounting
Notes. Orientation Primarily, the Geyser P4 is to be floor mounted in a vertical fog jet orientation. Alternatively, it may also be mounted in a floor mounting/horizontal fog jet orientation or in an overhead mounting/downward fog jet orientation; however, be sure to follow instructions closely to avoid tank spills with alternate mountings. - Page 9 (178 mm) The dimensions shown for the mounting hole positions are included here to aid in installation. Floor Mounting – Vertical Fog Output Floor Mounting Floor Mounting – Horizontal Fog Output Geyser P4 User Manual Rev. 2 Page 9 of 19...
- Page 10 Overhead Mounting – Downward Fog Jet With inverted mounting, avoid spillage of the fog fluid by setting the fluid tank in an upright position. Be sure to use a safety cable for both the Geyser P4 and the fluid tank when rigging in this manner.
-
Page 11: Tank Inversion Steps For Inverted Mounting
Attach the removable plate to the opposite side and secure the tank with the bottle lock. Secure both the bottom plate and tank cover with the screws. *Actual product may vary slightly from photo Geyser P4 User Manual Rev. 2 Page 11 of 19... -
Page 12: Operation
Address The Geyser P4 uses up to 10 DMX channels in a 10CH DMX mode, which defines the highest configurable address to 503. If you are not familiar with the DMX protocol, download the DMX Primer from www.chauvetlighting.com. - Page 13 010 ó 255 Speed, slow to fast 000 ó 009 No function Strobe 010 ó 255 Strobe, slow to fast 000 ó 002 No function Dimmer 003 ó 255 0–100% Geyser P4 User Manual Rev. 2 Page 13 of 19...
-
Page 14: Configuration (Standalone)
Plug the wireless receiver into the Remote Control Receiver port on the side of the Geyser P4 On the wireless transmitter, press the button assigned to the color program (1–4). The Geyser P4 emits fog and activates the color program for as long as you hold down the button. Page 14 of 19... -
Page 15: Technical Information
Refill with fog fluid. Run the machine briefly to clear any cleaning solution from the pump and heater. Fog Cleaner Quart (FCQ) was specifically developed by Chauvet to clean your Geyser P4 Make sure you use FCQ regularly, no longer than 90 days between cleanings, to increase the life of your fogger. Storage/ Before storing the fogger, run FCQ through the system as described in the cleaning procedure above;... -
Page 16: General Troubleshooting
Replace battery on wireless remote transmitter transmitter ran out of battery Internal problem Send the product for repair If you still experience problems after trying the above solutions, contact Chauvet Technical Support. Page 16 of 19 Geyser P4. User Manual Rev. 2... -
Page 17: Technical Specifications
Thermal Maximum External Temp. Cooling System 104 °F (40 °C) Convection Ordering Product Name Item Code UPC Number Geyser P4 (120 V) 09071156 781462215040 Geyser P4 (230 V) 09071157 781462215057 Geyser P4 User Manual Rev. 2 Page 17 of 19... -
Page 18: Returns
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. Chauvet reserves the right to use its own discretion to repair or replace returned product(s). Page 18 of 19... -
Page 19: Contact Us
Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., United Kingdom, Ireland, Mexico or Benelux, contact the dealer of record. Geyser P4 User Manual Rev. 2 Page 19 of 19...
