OWNER'S MANUAL

Operation

Maintenance

Specifications

All information in this Owner's Manual is current at the time of publica-

tion. However, HYUNDAI reserves the right to make changes at any

time so that our policy of continual product improvement may be car-

ried out.

This manual applies to all models of this vehicle and includes descrip-

tions and explanations of optional as well as standard equipment.

As a result, you may find material in this manual that does not apply to

your specific vehicle.

Table of Contents

Chapters

Table of Contents

Need help?

Do you have a question about the Sonata LF and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyundai Sonata LF

Page 1: Specifications
Maintenance Specifications All information in this Owner's Manual is current at the time of publica- tion. However, HYUNDAI reserves the right to make changes at any time so that our policy of continual product improvement may be car- ried out.
Page 2 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your HYUNDAI should not be modified in any way. Such modifications may adversely affect the performance, safety or durability of your HYUNDAI and may, in addition, violate condi- tions of the limited warranties covering the vehicle. Certain modifications may also be in vio- lation of regulations established by the Department of Transportation and other government agencies in your country.
Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as DANGER, WARNING, CAUTION and NOTICE. These titles indicate the following: DANGER CAUTION DANGER indicates a hazardous situa- CAUTION indicates a hazardous situa- tion which, if not avoided, will result tion which, if not avoided, could result in death or serious injury.
Page 4 Your Owner's Manual will introduce you to the features and operation of your new HYUNDAI. It is suggested that you read it carefully because the information it contains can contribute greatly to the satisfaction you receive from your new car.
Page 5 Introduction HOW TO USE THIS MANUAL We want to help you get the greatest Your safety, and the safety of others, Throughout this manual DANGER, possible driving pleasure from your is very important. This Owner's WARNING, CAUTION, NOTICE and vehicle. Your Owner’s Manual can Manual provides you with many safe- the SAFETY ALERT SYMBOL will assist you in many ways.
Page 6 (Do fied (We recommend that you not use methanol blended fuels) consult an authorized HYUNDAI dealer for details.) Except Europe Your new vehicle is designed to use WARNING...
Page 7 Discontinue gasoline, we recommend that you hol), and gasoline or gasohol con- use of any gasohol product ask an authorized HYUNDAI dealer. taining methanol (also known as which impairs drivability. wood alcohol) are being marketed Octane rating of leaded gasoline is along with or instead of leaded or same with unleaded one.
Page 8: Ron (Research Octane Number)
Do not use methanol Fuel Additives HYUNDAI recommends avoiding Fuels containing methanol (wood HYUNDAI recommends that you use fuels containing MTBE (Methyl alcohol) should not be used in your unleaded gasoline which has an Tertiary Butyl Ether) over 15.0% vol.
Page 9 Introduction VEHICLE BREAK-IN PROCESS Operation in foreign countries If you are going to drive your vehicle No special break-in period is needed. in another country, be sure to: By following a few simple precautions for the first 1,000 km (600 miles) you •...
Page 11: Table Of Contents
Your vehicle at a glance Safety system of your vehicle Convenient features of your vehicle Multimedia System TABLE OF CONTENTS Driving your vehicle What to do in an emergency Maintenance Specifications & Consumer information Index...
Page 12 Seat belts .............2-25 Your vehicle at a glance Seat belt safety precautions........2-25 Seat belt warning light ..........2-26 Exterior overview (I) ..........1-2 Seat belt restraint system ...........2-27 Exterior overview (II) ..........1-3 Additional seat belt safety precautions ....2-32 Interior overview (I) ..........1-4 Care of seat belts ............2-35 Interior overview (II) ..........1-5 Child restraint system (CRS) ......2-36...
Page 13 Mirrors..............3-29 Convenient features of your vehicle Inside rearview mirror............3-29 Outside rearview mirror ..........3-30 Accessing your vehicle .........3-4 Reverse parking aid function........3-33 Remote key ...............3-4 Windows ..............3-35 Remote key precautions..........3-6 Power windows..............3-35 Smart key ................3-8 Panorama sunroof ..........3-41 Smart key precautions...........3-11 Sunshade................3-42 Battery replacement .............3-12 Sliding the sunroof ............3-42...
Page 14 LCD display ............3-66 Driver assist system ..........3-115 LCD modes ................3-66 Rear view camera ............3-115 Trip computer mode ............3-67 Rear parking assist system ........3-116 Turn By Turn (TBT) mode ..........3-68 Parking assist system ..........3-119 A/V mode ................3-68 Defroster.............3-122 Information mode............3-68 Rear window defroster ..........3-122 User settings mode............3-70 Manual climate control system......3-124 Warning messages ............3-75...
Page 15 Climate control additional features....3-150 Multimedia system Cluster ionizer..............3-150 Sunroof inside air recirculation.........3-150 Multimedia system ..........4-2 Storage compartment........3-151 AUX, USB and iPod port ..........4-2 ® Center console storage ..........3-151 Antenna ................4-3 Glove box ................3-152 Steering wheel audio control ........4-4 Sunglass holder .............3-152 Audio / Video / Navigation system (AVN) ....4-5 Bluetooth Wireless Technology hands-free....4-5...
Page 16 iPod ® mode ...............4-72 System controllers and functions AUX mode ................4-75 - 4.3 inch COLOR TFT LCD (For Europe)..4-139 My music mode..............4-76 Radio mode..............4-143 Bluetooth ® Wireless Technology audio mode ..4-79 Media mode..............4-145 Voice recognition ............4-99 Audio CD mode ..............4-146 Ending voice recognition ..........4-100 MP3 CD mode ..............4-148 Setup (for RDS, Bluetooth...
Page 17 Hill-Start Assist Control (HAC) ........5-49 Driving your vehicle Emergency Stop Signal (ESS) ........5-50 Good braking practices..........5-51 Before driving............5-3 Drive mode integrated control system .....5-52 Before entering the vehicle ...........5-3 Cruise control ............5-54 Before starting..............5-3 Cruise Control operation ..........5-54 Ignition switch ............5-4 Blind spot detection system (BSD) ....5-60 Key ignition switch............5-5 BSD (Blind Spot Detection) /...
Page 18 Vehicle weight ............5-85 What to do in an emergency Overloading...............5-85 Hazard warning flasher ........6-2 In case of an emergency while driving ....6-2 If the engine stalls while driving ........6-2 If the engine stalls at a crossroad or crossing ..6-3 If you have a flat tire while driving......6-3 If the engine will not start ........6-4 If the engine doesn't turn over or turns over slowly..................6-4...
Page 19 Emergency commodity ........6-23 Maintenance Fire extinguisher .............6-23 First aid kit ..............6-23 Engine compartment ..........7-3 Triangle reflector ............6-23 Maintenance services ...........7-6 Tire pressure gauge ............6-23 Owner's responsibility............7-6 Owner maintenance precautions ........7-6 Owner maintenance..........7-7 Owner maintenance schedule........7-8 Scheduled maintenance services ......7-10 Normal maintenance schedule (for Europe) ....7-11 Maintenance under severe usage and low mileage conditions (for Europe)......7-15 Normal maintenance schedule (except Europe) ..7-17...
Page 20 Washer fluid ............7-35 Tire traction..............7-52 Tire maintenance ............7-52 Checking the washer fluid level .......7-35 Tire sidewall labeling............7-52 Parking brake ............7-36 Low aspect ratio tire ............7-57 Checking the parking brake .........7-36 Fuses..............7-58 Air cleaner ............7-37 Fuse/Relay panel description ........7-64 Filter replacement............7-37 Light bulbs.............7-72 Climate control air filter ........7-39 Headlamp, position lamp, turn signal lamp and...
Page 21 Specifications & Consumer information Dimensions ..............8-2 Engine ..............8-2 Bulb wattage............8-3 Tires and wheels ............8-4 Air conditioning system ........8-4 Tire load and speed capacity ......8-5 Volume and weight ..........8-5 Recommended lubricants and capacities ...8-6 Recommended SAE viscosity number ......8-8 Vehicle identification number (VIN)....8-9 Vehicle certification label ........8-9 TIRE specification and pressure label ....8-10 Engine number .............8-10...
Page 22: Your Vehicle At A Glance
Your vehicle at a glance Exterior overview (I) ..........1-2 Exterior overview (II) ..........1-3 Interior overview (I) ..........1-4 Interior overview (II) ..........1-5 Instrument panel overview (I)......1-6 Instrument panel overview (II)......1-7 Engine compartment ..........1-8...
Page 23: Your Vehicle At A Glance
Your vehicle at a glance EXTERIOR OVERVIEW (I) ■ Front view 1. Hood ..........3-46 2. Headlamp ..........7-73 3. DRL/Position lamp or fog lamp..7-73 4. Tires and wheels .......7-46 5. Outside rearview mirror .....3-30 6. Panoramic sunroof* ......3-41 7. Front windshield wiper blades ...7-40 8.
Page 24: Exterior Overview (Ii)
EXTERIOR OVERVIEW (II) ■ Rear view 1. Antenna ..........4-3 2. Doors ..........3-14 3. Fuel filler door........3-53 4. Rear parking assist system*.....3-116 5. Rear combination lamp ......7-81 6. High mounted stop lamp ....7-85 7. Rearview camera* ......3-115 8. Trunk ...........3-48 * : if equipped The actual shape may differ from the illustration.
Page 25: Interior Overview (I)
Your vehicle at a glance INTERIOR OVERVIEW (I) ■ Left-hand drive 1. Door lock/unlock button ....3-14 2. Driver position memory system ..3-24 3. Outside rearview mirror folding switch ..........3-32 4. Outside rearview mirror control switch ..........3-31 5. Central door lock switch ....3-17 6.
Page 26: Interior Overview (Ii)
INTERIOR OVERVIEW (II) ■ Right-hand drive 1. Door lock/unlock button ....3-14 2. Driver position memory system ..3-24 3. Outside rearview mirror folding switch ..........3-32 4. Outside rearview mirror control switch ..........3-31 5. Central door lock switch ....3-17 6. Power window switches ....3-35 7.
Page 27: Instrument Panel Overview (I)
Your vehicle at a glance INSTRUMENT PANEL OVERVIEW (I) ■ Left-hand drive 1. Light control/Turn signals ....3-98 2. Steering wheel audio controls*/ ® Bluetooth wireless technology hands-free controls* ......4-4 3. Instrument cluster......3-57 4. Horn ..........3-28 5. Driver's front air bag ......2-47 6.
Page 28: Instrument Panel Overview (Ii)
INSTRUMENT PANEL OVERVIEW (II) ■ Right-hand drive 1. Light control/Turn signals ....3-98 2. Steering wheel audio controls*/ ® Bluetooth wireless technology hands-free controls* ......4-4 3. Instrument cluster......3-57 4. Horn ..........3-28 5. Driver's front air bag ......2-47 6. Wiper/Washer ........3-111 7. Cruise controls* ........5-54 ■...
Page 29: Engine Compartment
Your vehicle at a glance ENGINE COMPARTMENT ■ Gasoline Engine (Theta II 2.4L MPI) 1. Engine coolant reservoir....7-31 2. Radiator cap ........7-30 /clutch 3. Brake fluid reservoir ....7-33 4. Air cleaner ........7-37 5. Engine oil dipstick......7-27 6. Engine oil filler cap ......7-28 7.
Page 30: Safety System Of Your Vehicle
Safety system of your vehicle This chapter provides you with important information about how to protect yourself and your passengers. It explains how to properly use your seats and seat belts, and how your air bags work. Additionally, this chapter explains how to properly restrain infants and children in your vehicle. Important safety precautions.......2-2 Child restraint system (CRS) ......2-36 Always wear your seat belt..........2-2...
Page 31: Important Safety Precautions
Safety system of your vehicle IMPORTANT SAFETY PRECAUTIONS You will find many safety precautions Restrain all children Driver distraction and recommendations throughout All children under age 13 should ride Driver distraction presents a serious this section, and throughout this man- in your vehicle properly restrained in and potentially deadly danger, espe- ual.
Page 32: Control Your Speed
• NEVER let the use of a mobile Keep your vehicle in safe condi- device distract you from driving. You tion have a responsibility to your passen- Having a tire blowout or a mechanical gers and others on the road to failure can be extremely hazardous.
Page 33: Seats
Safety system of your vehicle SEATS Front seats 1. Forward and rearward 2. Seatback angle 3. Seat cushion height 4. Lumbar support* Manual seat 5. Seat warmer / Air ventilation seat* 6. Headrest Rear seats 7. Seat warmer* Power seat 8.
Page 34: Safety Precautions
Air bags Safety precautions (Continued) You can take steps to reduce the risk Adjusting the seats so that you are sit- • Hold the steering wheel by the of being injured by an inflating air ting in a safe, comfortable position rim with hands at the 9 o’clock bag.
Page 35: Front Seats
Safety system of your vehicle Seat belts Front seats (Continued) Always fasten your seat belt before The front seat can be adjusted by • Do not route the seat belt starting any trip. using the control switches located on across your neck, across sharp the outside of the seat cushion.
Page 36 Manual adjustment (Continued) CAUTION • Do not allow anything to inter- To prevent injury: fere with the normal position and proper locking of the seat- • Do not adjust your seat while back. wearing your seat belt. • Do not place a cigarette lighter Moving the seat cushion for- on the floor or seat.
Page 37 Safety system of your vehicle Reclining seatback Seat belts must be snug against your hips and chest to work properly. Sitting in a reclined position when When the seatback is reclined, the the vehicle is in motion can be dan- shoulder belt cannot do its job gerous.
Page 38 Power adjustment CAUTION The front seat can be adjusted by using the control switches located on To prevent damage to the seats: the outside of the seat cushion. Before • Always stop adjusting the driving, adjust the seat to the proper seats when the seat has been position so that you can easily control adjusted as far forward or...
Page 39 Safety system of your vehicle Reclining seatback Sitting in a reclined position when the vehicle is in motion can be dan- gerous. Even when buckled up, the protections of your restraint system (seat belts and air bags) is greatly reduced by reclining your seatback. WARNING NEVER ride with a reclined seat- OLF034005...
Page 40 Seat belts must be snug against your hips and chest to work properly. When the seatback is reclined, the shoulder belt cannot do its job because it will not be snug against your chest. Instead, it will be in front of you.
Page 41: Rear Seats
Safety system of your vehicle Seatback pocket Rear seats Folding the rear seat (if equipped) The rear seatbacks can be folded to facilitate carrying long items or to increase the luggage capacity of the vehicle. WARNING • Never allow passengers to sit OLF034025 on top of the folded down To fold down the rear seatback:...
Page 42 WARNING When returning the rear seat- back from a folded to an upright position, hold the seatback and return it slowly. Ensure that the seatback is completely locked into its upright position by pushing on the top of the seat- back.
Page 43 Safety system of your vehicle Armrest WARNING Make sure the engine is off, the shift lever is in P (Park), and the parking brake is securely applied whenever loading or unloading cargo. Failure to take these steps may allow the vehicle to move if the shift lever is inadvertently moved to another position.
Page 44 Carrying long/narrow cargo WARNING CAUTION (if equipped) • careful when loading Cargo loading cargo through the rear pas- Make sure the engine is off, the senger seats to prevent dam- automatic transmission is in P age to the vehicle interior. (Park) and the parking brake is •...
Page 45: Headrest
Safety system of your vehicle Headrest NOTICE (Continued) The vehicle’s front and rear seats • To prevent damage, NEVER hit or have adjustable headrests. The head- pull on the headrests. rests provide comfort for passengers, but more importantly they are CAUTION designed to help protect passengers from whiplash and other neck and...
Page 46 Front seat headrests OLF034009 OLF034010 Forward and rearward adjustment Adjusting the height up and down ODH033105L The headrest may be adjusted for- To raise the headrest: The driver’s and front passenger’s ward to 3 different positions by 1. Pull it up to the desired position (1). seats are equipped with adjustable pulling the headrest forward to the headrests for the passengers safety...
Page 47 Safety system of your vehicle ■ Type A WARNING NEVER allow anyone to travel in a seat with the headrest removed. OLF034011 ■ Type B OLF034015 NOTICE If you recline the seatback towards the front with the head restraint and seat cushion raised, the head restraint may come in contact with the sunvisor or other parts of the vehicle.
Page 48 ■ Type A Rear seat headrests 4. Recline the seatback (4) with the seatback angle switch (3). WARNING Always make sure the headrest locks into position after rein- stalling and adjusting it properly. OLF034013 ■ Type B * : if equipped ODH033106L The rear seats are equipped with headrests in all the seating positions...
Page 49: Seat Warmers And Air Ventilation Seats
Safety system of your vehicle Seat warmers and air ventila- (Continued) tion seats • People taking medication that Front seat warmers (if equipped) can cause drowsiness or sleepiness. Seat warmers are provided to warm the seats during cold weather. WARNING WARNING The seat warmers can cause a NEVER place anything on the...
Page 50 ■ Type A While the engine is running, push Information either of the switches to warm the dri- With the seat warmer switch in the ver's seat or front passenger's seat. ON position, the heating system in the During mild weather or under condi- seat turns off or on automatically tions where the operation of the seat depending on the seat temperature.
Page 51 Safety system of your vehicle Seat warmers and air ventilation ■ Air ventilation seat The seat warmers and air ventilation seats are provided to warm or cool seats (if equipped) • Type A the front seats by blowing air through ■...
Page 52 If the air vents do not operate, paint thinner, benzene, alco- restart the vehicle. If there is hol or gasoline to clean the no change, we recommend seats. that you have your vehicle (Continued) inspected by an authorized HYUNDAI dealer. 2-23...
Page 53 Safety system of your vehicle Rear seat warmers (if equipped) Each time you push the switch, the temperature setting of the seat is changed as follows : OFF → HIGH ( ) → LOW ( The seat warmer defaults to the OFF position whenever the ignition switch is placed in the ON position.
Page 54: Seat Belts
SEAT BELTS This section describes how to use the (Continued) WARNING seat belts properly. It also describes • Do not wear the shoulder belt some of the things not to do when Seat belts must be used by ALL under your arm or behind your using seat belts.
Page 55: Seat Belt Warning Light
Safety system of your vehicle Seat belt warning light If you continue not to fasten the seat (Continued) belt and you drive over 9 km/h (5 Seat belt warning • No modifications or additions mph), the illuminated warning light should be made by the user ■...
Page 56: Seat Belt Restraint System
Seat belt restraint system NOTICE WARNING Lap/shoulder belt If you are not able to smoothly pull Riding in an improper position enough of the seat belt out from adversely affects the front pas- the retractor, firmly pull the seat senger's seat belt warning sys- belt out and release it.
Page 57 Safety system of your vehicle ■ Front seat (Continued) • Position one arm under the shoulder belt and the other over the belt, as shown in the illus- tration. • Always position the shoulder belt anchor into locked posi- tion at the appropriate height. •...
Page 58 ■ Type A ■ Type B When using the rear center seat belt, the buckle with the “CENTER” mark must be used. WARNING Always have the metal tab (A) inserted into the buckle (A'). OLF034063 Information OLF034062 If you are not able to pull out the safe- Type A ty belt from the retractor, firmly pull When using the rear center seat belt,...
Page 59 • NEVER inspect, service, repair or replace the pre-tensioners yourself. This must be done by an authorized HYUNDAI dealer. (Continued) 2-30...
Page 60 SRS air bags be inspected (2) Retractor pre-tensioner CAUTION by an authorized HYUNDAI dealer (3) SRS control module as soon as possible. Body work on the front area of the vehicle may damage the pre-tensioner seat belt system.
Page 61: Additional Seat Belt Safety Precautions
Safety system of your vehicle Seat belt use and children Additional seat belt safety pre- NOTICE cautions Infant and small children • Both the driver's and front pas- Seat belt use during pregnancy Most countries have child restraint senger's pre-tensioner seat laws which require children to travel belts may be activated in certain...
Page 62 Small children are best protected Larger children WARNING from injury in an accident when prop- Children under age 13 and who are erly restrained in the rear seat by a too large for a booster seat must ALWAYS properly restrain infants child restraint system that meets the always occupy the rear seat and use and small children in a child...
Page 63 Safety system of your vehicle Seat belt use and injured people The more the seatback is reclined, WARNING the greater chance the passenger’s A seat belt should be used when an hips will slide under the lap belt or injured person is being transported. •...
Page 64: Care Of Seat Belts
We recommend not damaged by seat hinges, doors that you consult an authorized or other abuse. HYUNDAI dealer. Periodic inspection All seat belts should be inspected periodically for wear or damage of any kind. Any damaged parts should be replaced as soon as possible.
Page 65: Child Restraint System (Crs)
Safety system of your vehicle CHILD RESTRAINT SYSTEM (CRS) Child Restraint System (CRS) Children always in the rear Most countries have child restraint laws which require children to travel always in the rear in approved child restraint devices. WARNING Infants and younger children must be The laws governing the age or restrained in an appropriate rear-fac- height/weight restrictions at which...
Page 66: Selecting A Child Restraint System (Crs)
• Select a child restraint that fits the • After an accident, we recom- ger’s seat. vehicle seating position where it mend HYUNDAI dealer Placing a rear-facing child will be used. check the child restraint sys- restraint in the front seat can tem, seat belts, ISOFIX lower •...
Page 67 Safety system of your vehicle Keep using restraints in the rear-fac- ing position as long as children fit within the height and weight limits allowed by the child restraint’s manu- facturer. It’s the best way to keep them safe. Once your child has outgrown the rear-facing child restraint, your child is ready for a forward-facing child restraint with a harness.
Page 68: Installing A Child Restraint System (Crs)
Booster seats Installing a Child Restraint After selecting a proper child restraint and checking that the child restraint System (CRS) A booster seat is a restraint designed fits properly in the rear of this vehicle, to improve the fit of the vehicle’s seat you are ready to install the child belt system.
Page 69 Safety system of your vehicle ISOFIX lower anchorage and • Secure the child in the child The child restraint manufacturer will restraint. Make sure the child is provide you with instructions on how top-tether anchorage (ISOFIX properly strapped in the child to use the child restraint with its anchorages system) for children restraint according to the child...
Page 70 WARNING Do not attempt to install a child restraint system using ISOFIX ISOFIX Lower Anchorage lower anchorages in the rear cen- Position Indicator ter seating position. There are no ISOFIX lower anchorages provid- ed for this seat. Using the out- board seat anchorages can dam- age the anchorages which may break or fail in a collision result-...
Page 71 Safety system of your vehicle Securing a child restraint with ISOFIX lower anchorages are locat- WARNING ed between the seatback and the the “ISOFIX Anchorages System” seat cushion of the rear seat left and To install a ISOFIX-compatible child Take the following precautions right outboard seating positions.
Page 72 Securing a child restraint seat WARNING with “Tether Anchor” system (if equipped) Take the following precautions when installing the top-tether strap: • Read and follow all installation instructions provided with your child restraint system. • NEVER attach more than one child restraint to a single ISOFIX top-tether anchorage.
Page 73 Safety system of your vehicle Child Seat Restraint for Vehicle ISOFIX Positions – For Europe Vehicle ISOFIX Positions Mass Group Size Class Fixture Rear Outboard Rear Outboard Front Passenger Rear Center (Driver side) (Passenger side) ISO/L1 Carrycot ISO/L2 0 : UP to 10kg ISO/R1 ISO/R1 0+ : UP to 13kg...
Page 74 Securing a child restraint with NOTICE a lap/shoulder belt When using the rear center seat When not using the ISOFIX anchor- belt, you should also refer to the “3- ages system, all child restraints must point Rear Center Seat Belt” sec- be secured to a vehicle rear seat with tion in this chapter.
Page 75 Safety system of your vehicle To remove the child restraint, press the release button on the buckle and then pull the lap/shoulder belt out of the restraint and allow the seat belt to retract fully. OLMB033045 OLMB033046 2. Fasten the lap/shoulder belt latch 3.
Page 76 Child Seat Restraint Suitability for Seat Position using the Seat Belt - For Europe Use child safety seats that have been officially approved and are appropriate for your children. When using the child safety seats, refer to the following table. Seating position Age group Front passenger...
Page 77 (2 Points) CRS MAKE, U/SU B I L S Exempt Pass Exempt Pass MODEL B : Belted I : ISOFIX L : Support leg S : Strap/Top-tether For more detailed, we recommend that you contact an authorized HYUNDAI dealer. 2-48...
Page 78: Air Bag Supplemental Restraint System
AIR BAG - SUPPLEMENTAL RESTRAINT SYSTEM 1. Driver’s front air bag 2. Passenger’s front air bag 3. Side air bag 4. Curtain air bag The actual air bags in the vehicle may differ from the illustration. OLF034038L 2-49...
Page 79 Safety system of your vehicle Vehicles equipped with WARNING Supplemental Air Bag System for the driver’s seat and front passenger’s AIR BAG SAFETY PRECAUTIONS seats. ALWAYS use seat belts and child restraints - every trip, every time, The front air bags are designed to everyone! Even with air bags, you can be seriously injured or killed in supplement the three-point seat a collision if you are improperly belted or not wearing your seat belt...
Page 80: Supplemental Restraint System
Where are the air bags? ■ Driver’s front air bag WARNING Driver’s and passenger’s front air bags To reduce the risk of serious injury or death from an inflating Your vehicle is equipped with a front air bags, take the following Supplemental Restraint System...
Page 81 The purpose of the system be serviced by an o’clock and 3 o’clock positions, the air bag is to provide the vehicle’s authorized HYUNDAI dealer. to minimize the risk of injuries driver and the front passenger with to your hands and arms.
Page 82 Curtain air bags (if equipped) They are designed to help protect the WARNING heads of the front seat occupants and the rear outboard seat occupants To reduce the risk of serious in certain side impact collisions. injury or death from an inflating The curtain air bags are designed to curtain air bags, take the follow- deploy only during certain side...
Page 83: How Does The Air Bags System Operate
Safety system of your vehicle How does the air bags system (10) Side pressure sensors SRS warning light operate? (11) Driver’s and front passenger’s seat belt buckle sensors. (if equipped) The SRSCM continually monitors SRS components except for buckle The SRS air bag warning light on the sensor while the ignition switch is in instrument panel will illuminate for the ON position to determine if a...
Page 84 We recommend that an author- adequate restraint. When needed, virtually impossible for you to see ized HYUNDAI dealer inspect the the side air bags help provide protec- the air bags inflate during an acci- SRS as soon as possible if any tion in the event of a side impact.
Page 85 Safety system of your vehicle • To help provide protection, the air You can take steps to reduce the risk ■ Driver’s front air bag (1) bags must inflate rapidly. The of being injured by an inflating air speed of air bag inflation is a con- bag.
Page 86 ■ ■ Driver’s front air bag (2) Driver’s front air bag (3) WARNING To prevent objects from becom- ing dangerous projectiles when the passenger's air bag inflates: • Do not install or place any objects (drink holder, CD holder, stickers, etc.) on the front passenger's panel above the glove box where the pas- OLMB033056...
Page 87: What To Expect After An Air Bag Inflates
• We recommend that an author- from seeing out of the windshield or doors as soon as possible ized HYUNDAI dealer replace being able to steer. Curtain air bags after impact to reduce pro- the air bag immediately after may remain partially inflated for longed exposure to the smoke deployment.
Page 88: Do Not Install A Child Restraint On The Front Passenger Seat
Noise and smoke from inflating Do not install a child restraint WARNING air bag on the front passenger seat When the air bags inflate, they make ■ Type A • Extreme hazard! Do not use a a loud noise and may produce rearward facing child restraint smoke and powder in the air inside of on a seat protected by an air...
Page 89: Why Didn't My Air Bag Go Off In A Collision
• Do not hit or allow any objects ond or third collisions in multiple authorized HYUNDAI dealer. to impact the locations where impact accidents, as well as low air bags or sensors are speed impacts. Damage to the vehicle installed.
Page 90 1. SRS control module 2. Front impact sensor 3. Side pressure sensor (front) 4. Side impact sensor (rear) OLF034046N/OLF034047/OLF034048/OLF034049/OLF034068 2-61...
Page 91 Safety system of your vehicle Air bag inflation conditions Although the driver’s and front pas- senger’s air bags are designed to inflate only in frontal collisions, they also may inflate in other types of col- lisions if the front impact sensors detect a sufficient impact.
Page 92 Air bag non-inflation conditions OLF034054 OLF034055 Front air bags are not designed to Front air bags may not inflate in side OLF034053 inflate in rear collisions, because impact collisions, because occupants In certain low-speed collisions the air occupants are moved backward by move in the direction of the collision, bags may not deploy.
Page 93 Safety system of your vehicle ODH033076 OLF034056 OLF034057 In an angled collision, the force of Just before impact, drivers often Front air bags may not inflate in impact may direct the occupants in a brake heavily. Such heavy braking rollover accidents because front air direction where the air bags would lowers the front portion of the vehicle bag deployment would not provide...
Page 94: Srs Care
HYUNDAI dealer. Improper handling box. cle structure. of the SRS system may result in seri- •...
Page 95: Additional Safety Precautions
Consult an your vehicle's air bag system. against the inside of the vehicle, authorized HYUNDAI dealer for against other occupants, or be ejected the necessary information. from the vehicle. Failure to follow these precau-...
Page 96: Air Bag Warning Labels
Air bag warning labels Be sure to read all of the information about the air bags that are installed on (if equipped) your vehicle in this Owner’s Manual. ■ Type A OLF034060 ■ Type B OLF034060N Air bag warning labels are attached to alert the driver and passengers of potential risks of the air bag system.
Page 97: Convenient Features Of Your Vehicle
Convenient features of your vehicle Accessing your vehicle .........3-4 Reverse parking aid function........3-33 Remote key ...............3-4 Windows ..............3-35 Remote key precautions..........3-6 Power windows..............3-35 Smart key ................3-8 Panorama sunroof ..........3-41 Smart key precautions...........3-11 Sunshade................3-42 Battery replacement .............3-12 Sliding the sunroof ............3-42 Immobilizer system ............3-13 Tilting the sunroof ............3-43 Door locks .............3-14...
Page 98 A/V mode ................3-68 Manual climate control system......3-124 Information mode............3-68 Heating and air conditioning........3-125 User settings mode............3-70 System operation............3-130 Warning messages ............3-75 System maintenance ............3-132 Trip computer ............3-83 Checking the amount of air conditioner refrigerant and compressor lubricant ...........3-133 Overview................3-83 Trip modes ................3-83 Automatic climate control system....3-134 Trip A/B ................3-83 Automatic heating and air conditioning....3-135...
Page 99 Interior features..........3-154 Ashtray ................3-154 Cup holder...............3-154 Sunvisor................3-156 Power outlet..............3-156 Cigarette lighter ............3-158 Clock.................3-158 Clothes hanger ..............3-160 Floor mat anchor(s)............3-161 Rear curtain..............3-161 Side curtain..............3-162...
Page 100: Accessing Your Vehicle
4. Make sure the doors are locked by After unlocking the doors, the doors checking the position of the door Your HYUNDAI uses a remote key, will lock automatically after 30 sec- lock button inside the vehicle. which you can use to lock or unlock onds unless a door is opened.
Page 101 Trunk unlocking Start-up Mechanical key To unlock: For detailed information refer to “Key ■ Type A ■ Type B Ignition Switch” in chapter 5. 1. Press the Trunk Unlock button (3) on the remote key for more than one second. NOTICE 2.
Page 102: Remote Key Precautions
When the remote key does not work correctly, open and close the door with the mechanical key. If you have a problem with the remote key, it is recommended that you contact an authorized HYUNDAI dealer. (Continue)
Page 103 HYUNDAI authority to operate the equipment. If dealer. the keyless entry system is inoperative due to changes or modifications not...
Page 104: Smart Key
4. Make sure the doors are locked by ■ Right-hand drive OBA043222IN checking the position of the door lock button inside the vehicle. Your HYUNDAI uses a Smart Key, which you can use to lock or unlock a door (and trunk) and even start the Information engine.
Page 105 Unlocking Even though you press the outside 3. The doors will unlock. The hazard door handle button, the doors will not warning lights will blink two times. ■ Left-hand drive lock and the chime will sound for Also, the outside rearview mirror three seconds if any of the following will unfold, if the outside rearview occur:...
Page 106 Convenient features of your vehicle Trunk unlocking Start-up Mechanical key To unlock: You can start the engine without If the Smart Key does not operate inserting the key. For detailed infor- normally, you can lock or unlock the 1. Carry the smart key. mation refer Engine...
Page 107: Smart Key Precautions
HYUNDAI dealer or tow the vehicle, mitter. Avoid placing the smart key and your if necessary. • The smart key is near a mobile two...
Page 108: Battery Replacement
HYUNDAI authority to operate the equipment. If dealer. the keyless entry system is inoperative...
Page 109: Immobilizer System
The transponder in your key is an recommended that you contact your The immobilizer system protects your important part of the immobilizer HYUNDAI dealer. vehicle from theft. If an improperly system. It is designed to give Do not attempt to alter this system or...
Page 110: Door Locks
Convenient features of your vehicle DOOR LOCKS Remote key Operating door locks from If you lock/unlock the driver's door with a key, all vehicle doors will outside the vehicle lock/unlock automatically. (if equipped Mechanical key with the central door lock system) ■...
Page 111 Smart key To lock the doors, press the button on Information the outside door handle while carry- ■ Left-hand drive • In cold and wet climates, door lock ing the smart key with you or press and door mechanisms may not work the door lock button on the smart key.
Page 112: Operating Door Locks From Inside The Vehicle
Convenient features of your vehicle Operating door locks from • To unlock a door, push the door Information lock button (1) to the “Unlock” posi- inside the vehicle If a power door lock ever fails to func- tion. The red mark (2) on the door With the door lock button tion while you are in the vehicle try lock button will be visible.
Page 113: Central Door Lock Switch
With the central door lock • If the key is in the ignition switch WARNING and any door is opened, the doors switch (if equipped) will not lock even though the lock ■ Left-hand drive The doors should always be button (1) of the central door lock fully closed and locked while switch is pressed.
Page 114: Auto Door Lock/Unlock Features
Convenient features of your vehicle Auto door lock/unlock features WARNING WARNING Impact sensing door unlock system (if equipped) Always secure your vehicle Opening a door when something is approaching may cause dam- All doors will be automatically Leaving your vehicle unlocked age or injury.
Page 115: Child-Protector Rear Door Locks
Child-protector rear door locks To lock the child safety lock, insert a key (or screwdriver) into the hole and turn it to the lock position. To allow a rear door to be opened from inside the vehicle, unlock the child safety lock. WARNING If children accidently open the rear doors while the vehicle is...
Page 116: Theft-Alarm System
Convenient features of your vehicle THEFT-ALARM SYSTEM This system helps to protect your Once the security system is set, open- vehicle and valuables. The horn will ing any door, the trunk, or the hood sound and the hazard warning lights without using the remote key or smart will blink continuously if any of the key will cause the alarm to activate.
Page 117: Theft-Alarm System (For Brazil)
Theft-alarm system (For Brazil) • If you press the button again or turn Information the ignition switch or Engine Intrusion/tilt sensor ON/OFF con- • Make sure all windows are close Start/Stop button to the ON position, dition (For Brazil, if equipped) while the sensor operates.
Page 118 (or smart key). switch to the ON position and wait for 30 seconds. Then the system will be disarmed. • If you lose your keys, we recom- mend that you consult with an authorized HYUNDAI dealer. 3-22...
Page 119 If the hazard warning light blink and mend that the system be serviced the horn sounds 3 times when you by an authorized HYUNDAI dealer. lock the doors by using the transmit- Malfunctions caused by improper ter, it means the intrusion/tilt sensor alterations, adjustments or modifi- is not working normally.
Page 120: Driver Position Memory System
- Outside rearview mirror position ory has been successfully stored. system checked by an authorized - Instrument panel illumination intensity HYUNDAI dealer. OLF044403L/OLF044404L "Driver 1 (or 2) settings saved" will appear on the LCD display. 3-24...
Page 121: Easy Access Function
Recalling memory position Easy access function Information (if equipped) 1. Move the shift lever into P (for • While recalling the "1" memory Automatic transaxle) or Neutral (for The system will move the driver's position, pressing the SET or 1 but- manual transaxle) while the ignition seat automatically as follows: ton temporarily stops the adjust-...
Page 122: Steering Wheel
Also, the steering effort becomes your vehicle to an authorized (With Smart key system) heavier as the vehicle’s speed HYUNDAI dealer and have the sys- increases and becomes lighter as tem checked as soon as possible. • Motor noise may be heard when the the vehicle’s speed decreases for...
Page 123: Tilt Steering / Telescope Steering
Tilt steering / Telescope steering After adjusting, pull up the lock- release lever (1) to lock the steering wheel in place. Push the steering WARNING wheel both up and down to be cer- tain it is locked in position. Always Never adjust the steering wheel adjust the position of the steering while driving.
Page 124: Heated Steering Wheel
Convenient features of your vehicle Heated steering wheel To turn the heated steering wheel off, Horn press the button again. The indicator (if equipped) on the button will turn off. ■ Type A Information The heated steering wheel will turn off automatically approximately 30 min- utes after the heated steering wheel is turned on.
Page 125: Mirrors
MIRRORS Day/night rearview mirror Inside rearview mirror WARNING Before you start driving, adjust the rearview mirror to the center on the NEVER adjust the mirror while view through the rear window. driving. This may cause loss of vehicle control resulting in an WARNING accident.
Page 126: Outside Rearview Mirror
Convenient features of your vehicle Electric Chromic Mirror (ECM) Outside rearview mirror (if equipped) The electric rearview mirror automati- cally controls the glare from the head- lamp of the car behind you in night- time or low light driving conditions. When the engine is running, the glare is automatically controlled by the sensor mounted in the rearview...
Page 127 ■ Left-hand drive WARNING CAUTION • • The right outside rearview mir- Do not scrape ice off the mir- ror is convex. In some coun- ror face; this may damage the tries, the left outside rearview surface of the glass. mirror is also convex.
Page 128 Convenient features of your vehicle Folding the outside rearview After adjustment, move the lever (1) ■ Left-hand drive to the middle to prevent inadvertent mirror adjustment. NOTICE • The mirrors stop moving when they reach the maximum adjust- ing angles, but the motor contin- ues to operate while the switch is pressed.
Page 129: Reverse Parking Aid Function
Center (AUTO) : Reverse parking aid function NOTICE (if equipped) The mirror will fold or unfold auto- The electric type outside rearview matically as follows: mirror operates even though the • Without smart key system ignition switch is in the OFF posi- - The mirror will fold or unfold when tion.
Page 130 Convenient features of your vehicle The outside rearview mirrors will automatically revert to their original positions if any of the following occur: The ignition switch is pressed to either the LOCK/OFF position or the ACC position. • The shift lever is moved to any position except R (Reverse).
Page 131: Windows
WINDOWS Power windows (1) Driver’s door power window ■ Left-hand drive switch (2) Front passenger’s door power window switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window* (7) Power window lock switch * : if equipped OLF044030...
Page 132 Convenient features of your vehicle ■ Right-hand drive (1) Driver’s door power window switch (2) Front passenger’s door power window switch (3) Rear door (right) power window switch (4) Rear door (left) power window switch (5) Window opening and closing (6) Automatic power window* (7) Power window lock switch * : if equipped...
Page 133 Window opening and closing The ignition switch must be in the ON Information position to be able to raise or lower • In cold and wet climates, power win- the windows. Each door has a Power dows may not work properly due to Window switch to control that door's freezing conditions.
Page 134 If the power windows do not operate properly after resetting, it is recom- mended that the system be checked by an authorized HYUNDAI dealer. OLF044032 If a window senses any obstacle while it is closing automatically, it will...
Page 135: Power Window Lock Switch
Power window lock switch When the power window lock switch Information is pressed: ■ Left-hand drive The automatic reverse feature is only • The driver's master control can active when the “Auto Up” feature is operate all the power windows. used by fully pulling up the switch to •...
Page 136 Convenient features of your vehicle NOTICE (Continued) WARNING • • To prevent possible damage to Do not allow children to play • the power window system, do NEVER leave the keys in your with the power windows. Keep vehicle with unsupervised not open or close two windows the driver’s door power window children, when the engine is...
Page 137: Panorama Sunroof
PANORAMA SUNROOF (IF EQUIPPED) Information WARNING • In cold and wet climates, the sun- • Make sure heads, other body roof may not work properly due to parts or objects are out of the freezing conditions. way before using the sunroof. •...
Page 138: Sunshade
Convenient features of your vehicle When the sunshade is opened Sunshade Sliding the sunroof If you pull the sunroof control lever When the sunshade is closed backward, the sunroof glass will slide all the way open. To stop the sunroof movement at any point, pull or push the sunroof control lever momentarily.
Page 139: Tilting The Sunroof
When the sunshade is opened Tilting the sunroof Closing the sunroof If you push the sunroof control lever When the sunshade is closed upward, the sunroof glass will tilt. To stop the sunroof movement at any point, pull or push the sunroof control lever momentarily.
Page 140 Convenient features of your vehicle Automatic reversal NOTICE WARNING • Periodically remove any dirt that • Make sure heads, other body may accumulate on the sunroof parts or other objects are safe- guide rail or between the sun- ly out of the way before closing roof and roof panel, which can the sunroof to avoid injuries or make a noise.
Page 141: Resetting The Sunroof
For more details, contact an author- - The one-touch sliding function of the ized HYUNDAI dealer. sunroof does not normally operate 1. Turn the engine on and close the sunroof glass and sunshade com- pletely.
Page 142: Exterior Features
Convenient features of your vehicle EXTERIOR FEATURES Closing the hood Hood 1. Before closing the hood, check the Opening the hood following: ■ Left-hand drive • All filler caps in engine compart- ment must be correctly installed. • Gloves, rags or any other com- bustible material must be removed from the engine compartment.
Page 143: Trunk
Trunk ■ Inside WARNING • Left-hand drive Opening the trunk • ■ Outside Before closing the hood, ensure all obstructions are removed from around hood opening. • Always double check to be sure that the hood is firmly latched before driving away. If it is not latched, the hood OLF044044 could open while the vehicle...
Page 144: Emergency Trunk Safety Release
Convenient features of your vehicle Closing the trunk Emergency trunk safety Information release (if equipped) Lower the trunk lid and press down To prevent damage to the trunk lift until it locks. cylinders and the attached hardware, always close the trunk before driving. WARNING NOTICE Always keep the trunk lid com-...
Page 145: Trunk Lid Control Switch
Trunk lid control switch (Continued) WARNING (if equipped) • Your vehicle should be kept • You and your passengers locked and keys should be must be aware of the location kept out of the reach of chil- Emergency Trunk dren. Parents should teach Safety Release lever in this their children about the dan- vehicle and how to open the...
Page 146: Smart Trunk
Convenient features of your vehicle How to use the Smart Trunk Smart trunk (if equipped) 1. Setting The trunk can be opened with no- To activate the Smart Trunk, go to touch activation satisfying all the User Settings Mode and select Smart Trunk on the LCD display.
Page 147 WARNING • Make sure you close the trunk before driving your vehicle. • Make sure there are no people or objects around the trunk before opening or closing the trunk. • Make sure objects in the trunk do not come out when open- ing the trunk on a slope.
Page 148 Convenient features of your vehicle How to deactivate the Smart Detecting area Information Trunk function using the smart • If you press the door unlock button (2), the Smart Trunk function will be deactivated temporarily. But, if you do not open any door for 30 sec- onds, the smart trunk function will be activated again.
Page 149: Fuel Filler Door
Fuel filler door Information Opening the fuel filler door • The Smart Trunk function will not ■ Left-hand drive work if any of the following occurs: - The smart key is close to a radio transmitter such as a radio station or an airport which can interfere with normal operation of the transmitter.
Page 150 Convenient features of your vehicle Closing the fuel filler door Information (Continued) 1. To install the fuel tank cap, turn it • Do not use cellular phones If the fuel filler door does not open clockwise until it “clicks” one time. while refueling.
Page 151 (Continued) (Continued) (Continued) • • • When refueling, always move Use only approved portable If pressurized fuel sprays out, the shift lever to the P (Park) plastic fuel containers designed it can cover your clothes or position (for automatic to carry and store gasoline. skin and thus subject you to transaxle) or first gear or R the risk of fire and burns.
Page 152: Emergency Fuel Filler Lid Release
• If the fuel filler cap requires replacement, use only a genuine HYUNDAI cap or the equivalent OLF044054 specified for your vehicle. An If the fuel filler lid does not open...
Page 153: Instrument Cluster
INSTRUMENT CLUSTER ■ Type A 1. Tachometer 2. Speedometer 3. Engine coolant temperature gauge 4. Fuel gauge 5. Warning and indicator lights 6. LCD display (including Trip computer) ■ Type B ❈ The actual cluster in the vehicle may differ from the illustration.
Page 154: Instrument Cluster Control
Convenient features of your vehicle Instrument cluster control When pressing the illumination con- ■ Type A trol button, the interior switch illumi- Instrument panel illumination nation intensity is also adjusted. The ■ Type A selected brightness of illumination can be saved in the Driver position memory system(if equipped).
Page 155: Lcd Display Control
Tachometer LCD display control Gauges Speedometer ■ km/h ■ MPH, km/h ■ Type A ■ Type B OLF044201L OLF044105L OLF044103L/OLF044103N tachometer indicates The LCD display modes can be approximate number of engine revo- The speedometer indicates the changed by using the control buttons. lutions per minute (rpm).
Page 156 Convenient features of your vehicle Engine Coolant Temperature Fuel Gauge NOTICE gauge ■ Except Europe gauge pointer moves ■ Except Europe • Type A • Type B beyond the normal range area • Type A • Type B toward the "130 or H" position, it indicates overheating that may damage the engine.
Page 157 Outside Temperature Gauge Information WARNING ■ Type A ■ Type B • The fuel tank capacity is given in Fuel Gauge chapter 8. • The fuel gauge is supplemented by a Running out of fuel can expose low fuel warning light, which will vehicle occupants to danger.
Page 158 Convenient features of your vehicle Icy Road Warning Light - User Settings Mode in the Cluster : Information You can change the temperature (if equipped) If the icy road warning light appears unit in the “Other Features - while driving, you should drive more Temperature unit”...
Page 159 Transaxle Shift Indicator For example : Indicates that shifting up to the ■ Type A ■ Type B 3rd gear is desired (currently the shift lever is in the 2nd or 1st gear). : Indicates that shifting down to the 3rd gear is desired (current- ly the shift lever is in the 4th, 5th, or 6th gear).
Page 160 Convenient features of your vehicle For example ■ Type A ■ Type B : Indicates that shifting up to the 3rd gear is desired (currently the shift lever is in the 2nd or 1st gear). : Indicates that shifting down to the 3rd gear is desired (current- ly the shift lever is in the 4th, 5th, or 6th gear).
Page 161 Odometer ■ Type A ■ Type B OLF044114/OLF044115 The odometer indicates the total dis- tance that the vehicle has been driv- en and should be used to determine when periodic maintenance should be performed. 3-65...
Page 162: Lcd Display
Convenient features of your vehicle LCD DISPLAY LCD modes Modes Symbol Explanation This mode displays driving information like the tripmeter, fuel economy, and so on. Trip Computer For more details, refer to "Trip Computer" in this chapter. Turn By Turn (TBT) This mode displays the state of the navigation.
Page 163: Trip Computer Mode
Cannot edit settings while driving Quick guide (Help, if equipped) Trip computer mode ■ Type A ■ Type B OLF044168L OLF044169L OLF044422L/OLF044423L This warning message illuminates if If you press and hold the OK button This mode displays driving informa- you try to select the other User in the User Settings Mode, explana- tion like the tripmeter, fuel economy,...
Page 164: Turn By Turn (Tbt) Mode
Convenient features of your vehicle Turn By Turn (TBT) mode A/V mode (if equipped) Information mode (if equipped) Service Interval ■ Type A ■ Type B ■ Type A ■ Type B ■ Type A ■ Type B OLF044175/OLF044176 OLF044172/OLF044173 OLF044179N/OLF044180N This mode displays the state of the A/V system.
Page 165 Warning Message ■ Type A ■ Type B ■ Type A ■ Type B If one of followings occurs, warning messages will be displayed on the information mode for several seconds. - Malfunction of below systems • Blind Spot Detection (BSD), and so on.
Page 166: User Settings Mode
Convenient features of your vehicle User settings mode On this mode, you can change setting of the instrument cluster, doors, lamps, and so on. Driving Assist (if equipped) Items Explanation To activate or deactivate the RCTA system. RCTA (Rear Cross Traffic Alert) For more details, refer to "Rear Cross Traffic Alert (RCTA)"...
Page 167 Door/Trunk Items Explanation • Off : The auto door lock operation will be deactivated. • Enable on Speed: All doors will be automatically locked when the vehicle speed exceeds 9.3mph Automatically Lock (15km/h). • Enable on Shift: All doors will be automatically locked if the automatic transaxle shift lever is shift- ed from the P (Park) position to the R (Reverse), N (Neutral), or D (Drive) position.
Page 168 Convenient features of your vehicle Light Items Explanation • Off: The one touch turn signal function will be deactivated. • 3, 5, 7 Flashes : The lane change signals will blink 3, 5, or 7 times when the turn signal lever is One Touch Turn Signal moved slightly.
Page 169 Seat/Steering Items Explanation • None: The seat easy access function will be deactivated. • Normal/Extended: - When you turn off the engine, the driver’s seat will automatically move rearward short (Normal) Seat Easy Access or long (Extended) for you to enter or exit the vehicle more comfortably. - If you change the Engine Start/Stop button from OFF position to the ACC, ON, or START posi- tion, the driver’s seat will return to the original position.
Page 170 Convenient features of your vehicle Other features Items Explanation • Off : The average fuel economy will not reset automatically whenever refueling. Fuel Economy Auto Reset • On (Auto Reset) : The average fuel economy will reset automatically when refueling. For more details, refer to “Trip Computer”...
Page 171: Warning Messages
Low Key Battery Press start button while turning Warning messages (if equipped) (for smart key system) wheel (for smart key system) Shift to "P" position (for smart key system and auto- matic transaxle) OLF044122L OLF044415L • This warning message illuminates •...
Page 172 Convenient features of your vehicle Steering wheel unlocked Check steering wheel lock Press brake pedal to start engine (for smart key system) system (for smart key system) (for smart key system and auto- matic transaxle) OLF044416L OLF044417L OLF044124L • This warning message illuminates •...
Page 173 Press clutch pedal to start Key not in vehicle Key not detected engine (for smart key system (for smart key system) (for smart key system) and manual transaxle) OLF044116L OLF044118L OLF044134L • This warning message illuminates • This warning message illuminates if if the smart key is not in the vehicle the smart key is not detected when This warning message illuminates if...
Page 174 Start/Stop button once more. Start/Stop button for 10 seconds in • If the warning illuminates each time the ACC position. you press the Engine Start/Stop but- ton, we recommend that you have the vehicle inspected by an author- ized HYUNDAI dealer. 3-78...
Page 175 Shift to "P" or "N" to start engine Door, Hood, Trunk Open Sunroof Open (if equipped) (for smart key system and auto- matic transaxle) OLF044136 OLF054446 • It means that any door, hood, or This warning message illuminates if OLF044130L trunk is open.
Page 176 Convenient features of your vehicle Turn on "FUSE SWITCH" Align steering wheel (if equipped) Steering wheel aligning is com- pleted (if equipped) OLF044148L OLF044150L/OLF044152L OLF044154L • This warning message illuminates • This warning message illuminates if the fuse switch located on the if you start the engine when the •...
Page 177 Low Washer Fluid Low Fuel Engine has overheated OLF044156L OLF044160L OLF044158L • This warning message illuminates • This warning message illuminates • This warning message illuminates on the service reminder mode if if the fuel tank is nearly empty. when the engine coolant tempera- the washer fluid level in the reser- ture is above 120°C (248°F).
Page 178 OLF044166L ■ Type B OLF044167L This warning message illuminates if there is a malfunction (burned-out bulb except LED lamp or circuit mal- function) with the headlamp. In this case, have your vehicle inspected by an authorized HYUNDAI dealer. 3-82...
Page 179: Trip Computer
TRIP COMPUTER Overview Trip modes Trip A/B (km or mile, km/h or MPH) Description To change the trip mode, rotate the MOVE switch “▲, ▼” on the steering ■ Type A ■ Type B The trip computer is a microcomput- wheel.
Page 180: Fuel Economy
Convenient features of your vehicle Average Vehicle Speed (2) Elapsed Time (3) Fuel economy (km or mile, L/100km, • The average vehicle speed is cal- • The elapsed time is the total driv- km/L or MPG) culated by the total driving dis- ing time since the last elapsed time tance and driving time since the reset.
Page 181 Average Fuel Economy (2) Automatic reset Information • The average fuel economy is calcu- To make the average fuel economy • If the vehicle is not on level ground lated by the total driving distance be reset automatically whenever refu- or the battery power has been inter- eling, select the “Auto Reset”...
Page 182 Convenient features of your vehicle Digital Speedometer One time driving information Information (km/h or MPH) mode (km or mile, L/100km or If “Sunroof Open” warning message MPG) ■ Type A ■ Type B is displayed in the cluster, this display ■...
Page 183: Warning And Indicator Lights
- It illuminates for approximately 6 Belts” in chapter 2. seconds and then goes off. • When there is a malfunction with the SRS. In this case, we recommend that you have the vehicle inspected by an authorized HYUNDAI dealer. 3-87...
Page 184 HYUNDAI dealer and cle as soon as it is safe to do so. - If the warning light illuminates inspected.
Page 185 ABS (The normal braking sys- you have the vehicle inspected by that you have the vehicle tem will still be operational without an authorized HYUNDAI dealer. inspected by an authorized the assistance of the anti-lock HYUNDAI dealer. brake system).
Page 186 • When there is a malfunction with the vehicle inspected by an authorized sudden braking. the EPB. HYUNDAI dealer as soon as possible. In this case, avoid high speed In this case, we recommend that driving and abrupt braking. you have the vehicle inspected by We recommend you have the an authorized HYUNDAI dealer.
Page 187 In this case, we recommend that ON position. ON position. you have the vehicle inspected by an authorized HYUNDAI dealer as - This indicator light comes on after - It remains on until the engine is soon as possible. the ignition key is turned to the started.
Page 188 In this case, we recommend that either the alternator or electrical you have the vehicle inspected by charging system. an authorized HYUNDAI dealer as If the engine oil pressure is low: soon as possible. 1. Drive carefully to the nearest safe location and stop your vehicle.
Page 189 Blind Spot Detection (BSD), and so engine off immediately. In this case, we recommend that you To identify the details of the warn- have the vehicle inspected by ing, look at the LCD display. an authorized HYUNDAI dealer. 3-93...
Page 190: Indicator Lights
When there is a malfunction with the immobilizer system. an authorized HYUNDAI dealer. For more details, refer to “Electronic Stability Control (ESC)” in chapter 5. In this case, we recommend that you...
Page 191 In this case, we recommend that • When the vehicle detects the you have the vehicle inspected by smart key in the vehicle properly an authorized HYUNDAI dealer. while the Engine Start/Stop button If any of the following occurs, there is ACC or ON.
Page 192 Convenient features of your vehicle ■ Low Beam Indicator Light ON Indicator Cruise ■ Type A Type B Light (if equipped) Light Indicator Light CRUISE (if equipped) This indicator light illuminates: This indicator light illuminates: This indicator light illuminates: • When the tail lights or headlights •...
Page 193 In this case, we recommend that Do not watch the ECO indicator you have the vehicle inspected by light while driving. This will dis- an authorized HYUNDAI dealer. tract you and may cause an accident that results in severe personal injury.
Page 194: Light
Convenient features of your vehicle LIGHT Exterior lights NOTICE Lighting control • Do not cover or spill anything on the sensor (1) located on the instrument panel. • Do not clean the sensor using a window cleaner, the cleanser may leave a light film which could interfere with sensor oper- ation.
Page 195 High beam operation OLF044086L OLF044087L Parking lamp position ( Headlamp position ( ) OLF044192L The headlamp, parking lamp, license The parking lamp, license plate lamp To turn on the high beam headlamp, and instrument panel lamp are turned plate lamp and instrument panel push the lever away from you.
Page 196 Convenient features of your vehicle Turn signals and lane change One-touch turn signal function signals (if equipped) To activate an one-touch turn signal function, move the turn signal lever slightly and then release it. The lane change signals will blink 3, 5 or 7 times.
Page 197 Front fog lamp (if equipped) Rear fog lamp (if equipped) 3. To turn off the front fog lamp, turn the light switch to the front fog ■ Type A lamp position again or turn off the parking lamp. NOTICE When in operation, the fog lamps consume large amounts of vehicle electrical power.
Page 198 Convenient features of your vehicle Battery saver function Headlamp delay function (if equipped) The purpose of this feature is to pre- vent the battery from being dis- If you place the ignition switch in to charged. The system automatically the ACC or OFF position with the turns off the parking lamp when the headlamps ON, the headlamps driver turns the engine off and opens...
Page 199: Headlight Leveling Device*
Daytime running light (DRL) Headlight leveling device NOTICE (if equipped) (if equipped) If the driver gets out of the vehicle The Daytime Running Lights (DRL) through other doors (except dri- can make it easier for others to see ver's door), the battery saver func- the front of your vehicle during the tion does not operate and the day, especially after dawn and before...
Page 200 • The headlamp washer can be oper- Driver + Maximum permissible that the system be inspected by ated 15 minutes after the last opera- loading an authorized HYUNDAI dealer. tion. Do not attempt to inspect or replace the wiring yourself. 3-104...
Page 201: Welcome System
Welcome system (if equipped) Also, if the outside rearview mirror Headlamp and Parking lamp folding switch is in the AUTO posi- When the headlamp (lamp switch in Welcome light (if equipped) tion, the outside rearview mirror will the headlamp or AUTO position) is on unfold automatically.
Page 202: Interior Lights
Convenient features of your vehicle Interior lamp Interior lamp AUTO cut Interior lights When the interior lamp switch is in The interior lamps will automatically NOTICE the DOOR position and all doors (and go off approximately 20 minutes after Do not use the interior lights for trunk) are closed and locked, the the engine is turned off and the extended periods when the engine...
Page 203 Front lamps Front Map Lamp : Front Room Lamp ( Press either of these lens to turn the Press this button to turn the front and ■ Type A map lamp on or off. This light pro- rear room lamps on and off. duces a spot beam for convenient use as a map lamp at night or as a personal lamp for the driver and the...
Page 204 Convenient features of your vehicle Rear lamps Trunk room lamp (if equipped) NOTICE ■ Type A Do not leave the lamp switches on for an extended period of time when the engine is turned off. OLF044098 ■ Type B OLF044255 The trunk room lamp comes on when the trunk is opened.
Page 205 Door courtesy lamp Glove box lamp Vanity mirror lamp OLF044256 OLF044257 OLF044258 The door courtesy lamp comes ON The glove box lamp comes on when Opening the lid of the vanity mirror will when the door is opened to assist the glove box is opened.
Page 206 Convenient features of your vehicle Puddle lamp (if equipped) Escort light When the ignition switch is in the OFF position and the driver's door is opened, the puddle lamp will come on for 30 seconds. If the driver's door is closed within the 30 seconds, the puddle lamp will turn off after 15 sec- onds.
Page 207: Wipers And Washers
WIPERS AND WASHERS ■ Type A A : Wiper speed control Windshield wipers · MIST (V) – Single wipe Operates as follows when the igni- tion switch is in the ON position. · OFF (O) – Off MIST (V) : For a single wiping cycle, ·...
Page 208 Convenient features of your vehicle AUTO (Automatic) control LO (1) : The wiper runs at a lower If the wiper switch is set in AUTO speed. mode when the ignition switch is in (if equipped) the ON position, the wiper will oper- HI (2) : The wiper runs at a higher ate once to perform a self-check of speed.
Page 209: Windshield Washers
Windshield washers If equipped with the Headlamp NOTICE Washer, washer fluid will be sprayed • When washing the vehicle, set on the headlamp at the same time you the wiper switch in the OFF (O) operate the windshield washer when: position to stop the auto wiper 1.
Page 210 Convenient features of your vehicle CAUTION • To prevent possible damage to the washer pump, do not operate the washer when the fluid reservoir is empty. • To prevent possible damage to the wipers or windshield, do not operate the wipers when the windshield is dry.
Page 211: Driver Assist System
DRIVER ASSIST SYSTEM Rear view camera Whenever the vehicle ignition is WARNING cycled off and on, the rear view cam- (if equipped) era will turn on when the shift lever is • Never rely solely on the rear put into R (Reverse). camera display when backing- This is a supplemental system that shows behind the vehicle through the...
Page 212: Rear Parking Assist System
Convenient features of your vehicle Rear parking assist system NOTICE Information (if equipped ) Do not push, scratch or strike the The system may not recognize objects sensor with any hard objects that less than 30 cm (12 in.) from the sensor, could damage the surface of the or it may sense an incorrect distance.
Page 213 Operation of the rear parking Operation condition Types of warning indicator and sound assist system • This system will activate when the Distance from Warning Warning indicator on the rear parking assist ■ Type A object indicator sound OFF button is not illuminated. If you desire to deactivate the rear parking assist system, press the 120cm ~ 61cm...
Page 214 • The sensor is covered with snow. • Objects, which tend to absorb sen- ized HYUNDAI dealer. • Any non-factory equipment or sor frequency such as clothes, accessories have been installed, or spongy material or snow.
Page 215: Parking Assist System
Operation of the Parking Assist Parking Assist System This system is a supplemental sys- tem that senses objects within the (if equipped) System range and location of the sensors, it ■ Type A ■ Type A cannot detect objects in other areas where sensors are not installed.
Page 216 • The indicator may differ from the illustration as objects or sensors status. If the indicator blinks, we recommend that the system be checked by an authorized HYUNDAI dealer. • If the audible warning does not sound or if the buzzer sounds inter- mittently when shifting into R (Reverse) position, this may indicate a malfunction with the Parking Assist System.
Page 217 Non-operational conditions of Detecting range may decrease when: Information Parking Assist System • Outside temperature Sensor may not recognize objects less extremely hot or cold. Parking Assist System may not than 30 cm from the sensor, or it may operate normally when: •...
Page 218: Defroster
Convenient features of your vehicle DEFROSTER Rear window defroster • To activate the rear window NOTICE defroster, press the rear window ■ Manual climate control system To prevent damage to the conduc- defroster button located in the cen- • Type A tors bonded to the inside surface ter facia switch panel.
Page 219 Outside mirror defroster Front wiper deicer (if equipped) (if equipped) If your vehicle is equipped with the wiper deicer, it will operate at the If your vehicle is equipped with the same time you turn on the rear win- outside mirror defrosters, they will operate at the same time you turn on dow defroster.
Page 220: Manual Climate Control System
Convenient features of your vehicle MANUAL CLIMATE CONTROL SYSTEM (IF EQUIPPED) ■ Type A 1. Fan speed control knob 2. Temperature control knob 3. Mode selection buttons 4. Front windshield defroster button 5. Rear window defroster button 6. Air intake control button 7.
Page 221: Heating And Air Conditioning
Heating and air conditioning 1. Start the engine. 2. Set the mode to the desired posi- tion. To improve the effectiveness of heating and cooling : - Heating: - Cooling: 3. Set the temperature control to the desired position. 4. Set the air intake control to the outside (fresh) air position.
Page 222 Convenient features of your vehicle Mode selection Floor/Defrost-Level (A, C, E, D) Face-Level (B, D, F) Most of the air flow is directed to the Air flow is directed toward the upper floor and the windshield with a small body and face. Additionally, each amount directed to the side window outlet can be controlled to direct the defrosters.
Page 223 Temperature control OLF044208 OLF044209 MAX A/C-Level (B, D, F) Instrument panel vents OLF044210 To operate the MAX A/C, turn the The outlet vents can be opened or The temperature control knob allows mode selection knob to extreme left. closed separately using the thumb- you to control the temperature of the Air flow is directed toward the upper wheel.
Page 224 Convenient features of your vehicle Air intake control Recirculated air position Information With the recirculated air It should be noted that prolonged position selected, air operation of the heater in the recircu- from passenger lated air position (without air condi- compartment will tioning selected) will cause fogging of...
Page 225 Fan speed control To turn off the fan WARNING • Continuous operation of the climate control system in the recirculated air position may allow humidity to increase inside the vehicle which may fog the glass and obscure vis- ibility. • Do not sleep in a vehicle with air conditioning or heating system on.
Page 226: System Operation
Convenient features of your vehicle Air conditioning (A/C) System operation Operation Tips • To keep dust or unpleasant fumes Ventilation from entering the car through the 1. Set the mode to the position. ventilation system, temporarily set 2. Set the air intake control to the the air intake control to the recircu- outside (fresh) air position.
Page 227 Air conditioning Air conditioning system operation Information tips HYUNDAI Air Conditioning Systems • When using the air conditioning sys- are filled with R-134a refrigerant. • If the vehicle has been parked in tem, monitor the temperature gauge direct sunlight during hot weather, 1.
Page 228: System Maintenance
We recommend that the air con- decrease, resulting in moisture accu- ditioning system be serviced by mulation on the inside of the wind- an authorized HYUNDAI dealer. shield even when the outside (fresh) air position is selected. If this hap- Improper service may cause...
Page 229: Checking The Amount Of Air Conditioner Refrigerant And Compressor Lubricant
It is important that tem be inspected by an authorized the correct type and amount of HYUNDAI dealer. oil and refrigerant is used. Otherwise, it may cause damage to the vehicle and personal injury.
Page 230: Automatic Climate Control System
Convenient features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM (IF EQUIPPED) ■ Type A 1. Driver’s temperature control knob 2. Passenger’s temperature control knob 3. AUTO (automatic control) button 4. OFF button 5. Fan speed control button 6. Air conditioning button 7.
Page 231: Automatic Heating And Air Conditioning
Automatic heating and air con- ditioning OLF044217 OLF044218 2. Turn the temperature control knob Information to set the desired temperature. OLF044216 Never place anything near the sensor 1. Press the AUTO button. to ensure better control of the heating Information and cooling system.
Page 232: Manual Heating And Air Conditioning
Convenient features of your vehicle Manual heating and air condi- tioning The heating and cooling system can be controlled manually by pushing buttons other than the AUTO button. In this case, the system works sequentially according to the order of buttons select- ed.
Page 233 Mode selection Face-Level (B, D, F) Floor & Defrost (A, C, D, E) ■ Type A Air flow is directed toward the upper Most of the air flow is directed to the body and face. Additionally, each floor and the windshield with a small outlet can be controlled to direct the amount directed to the side window air discharged from the outlet.
Page 234 Convenient features of your vehicle ■ Type A ■ Front Also, you can adjust the direction of air delivery from these vents using the vent control lever as shown. OLF044220 OLF044209 ■ Type B ■ Rear OLF044221 OLF044222 Defrost-Level (A) Instrument panel vents Most of the air flow is directed to the The outlet vents can be opened or...
Page 235 Temperature control Adjusting the driver and passenger side temperature individually • Press the “SYNC” button again to adjust the driver and passenger side temperature individually. The illumination of button turns off. • Operate the driver side tempera- ture control knob to adjust the driv- er side temperature.
Page 236 Convenient features of your vehicle Air intake control Temperature conversion Recirculated air position If the battery has been discharged or ■ Type A With the recirculated air disconnected, the temperature mode position selected, air display will reset to Centigrade. from passenger This is a normal condition.
Page 237 Fan speed control Information WARNING Prolonged operation of the heater in • Continued climate control the recirculated air position (without system operation in the recir- air conditioning selected) may cause culated air position may allow fogging of the windshield and side win- humidity to increase inside dows and the air within the passenger the vehicle which may fog the...
Page 238: System Operation
Convenient features of your vehicle Air conditioning OFF mode System operation Ventilation 1. Set the mode to the position. 2. Set the air intake control to the outside (fresh) air position. 3. Set the temperature control to the desired position. 4.
Page 239 Air conditioning Operation Tips NOTICE • To keep dust or unpleasant fumes HYUNDAI Air Conditioning Systems • The refrigerant system should from entering the vehicle through are filled with R-134a refrigerant. only be serviced by trained and the ventilation system, temporarily 1.
Page 240 Convenient features of your vehicle Air conditioning system operation • Operating the air conditioning sys- Information tem in the recirculated air position tips • When using the air conditioning sys- provides maximum cooling, how- • If the vehicle has been parked in tem, monitor the temperature gauge ever, continual operation in this direct sunlight during hot weather,...
Page 241: System Maintenance
If this hap- pens, we recommend that the cli- Otherwise, it may cause damage mate control air filter be replaced by to the vehicle and personal injury. an authorized HYUNDAI dealer. 3-145...
Page 242: Windshield Defrosting And Defogging
Convenient features of your vehicle W W INDSHIELD DEFROSTING AND DEFOGGING • For maximum defrosting, set the Manual climate control system WARNING temperature control to the extreme To defog inside windshield right/hot position and the fan speed Windshield heating control to the highest speed. Do not use the posi- •...
Page 243: Automatic Climate Control System
To defrost outside windshield Automatic climate control If the air-conditioning, outside (fresh) air position and higher fan speed are system not selected automatically, adjust the To defog inside windshield corresponding button or knob manu- ally. If the position is selected, lower fan speed is controlled to higher fan speed.
Page 244: Defogging Logic
Convenient features of your vehicle To defrost outside windshield Automatic climate control sys- Defogging logic (if equipped) To reduce the probability of fogging 1. Turn the ignition switch to the ON up the inside of the windshield, the position. air intake or air conditioning are con- trolled automatically according to 2.
Page 245 Auto defogging system When the Auto Defogging To cancel or reset the Auto System operates, the indi- (only for automatic climate Defogging System cator will illuminate. control system, if equipped) Press the front windshield defroster button for 3 seconds when the igni- tion switch is in the ON position.
Page 246: Climate Control Additional Features
Convenient features of your vehicle CLIMATE CONTROL ADDITIONAL FEATURES Cluster ionizer (if equipped) Sunroof inside air recirculation (if equipped) When the ignition switch is in the ON position, the clean air function turns If the sunroof opens while the heater on automatically.
Page 247: Storage Compartment
STORAGE COMPARTMENT Center console storage NOTICE WARNING To avoid possible theft, do not Never store cigarette lighters, leave valuables in the storage propane cylinders, or other compartments. flammable/explosive materials in the vehicle. These items may catch fire and/or explode if the vehicle is exposed to hot tem- peratures for extended periods.
Page 248: Glove Box
Convenient features of your vehicle Glove box To open: Sunglass holder (if equipped) Pull the lever (2). ■ Left-hand drive WARNING ALWAYS close the glove box door after use. An open glove box door can cause serious injury to the pas- senger in an accident, even if the passenger is wearing a seat belt.
Page 249: Multi Box
Multi box (if equipped) WARNING • Do not keep objects except sunglasses inside the sun- glass holder. Such objects can be thrown from the holder in the event of a sudden stop or an accident, possibly injuring the passengers in the vehicle. •...
Page 250: Interior Features
Convenient features of your vehicle INTERIOR FEATURES Ashtray (if equipped) Cup holder WARNING ■ Front • Type A Ashtray use Putting lit cigarettes or matches in an ashtray with other com- bustible materials may cause a fire. OLF044280 • Type B OLF044264 To use the ashtray, open the cover.
Page 251 Front WARNING WARNING To open the cover: Push the cover. • Keep cans or bottles out of Avoid abrupt starting and direct sun light and do not put braking when the cup holder them in a hot vehicle. It may is in use to prevent spilling Rear explode.
Page 252: Sunvisor
Convenient features of your vehicle Sunvisor Power outlet (if equipped) WARNING ■ Front For your safety, do not block your view when using the sunvisor. NOTICE • Do not put several tickets in the ticket holder at one time. This could cause damage to the tick- et holder.
Page 253 (Continued) NOTICE WARNING • Some electronic devices can To prevent damage to the Power cause electronic interference Avoid electrical shocks. Do not Outlets : when plugged into a vehicle’s place your fingers or foreign • Use the power outlet only when power outlet.
Page 254: Cigarette Lighter
To use the cigarette lighter, the igni- NOTICE tion switch must be in the ACC or ON position. Only a genuine HYUNDAI lighter should be used in the cigarette Push the cigarette lighter all the way lighter socket. The use of plug-in into its socket.
Page 255 With Audio system With AVN system (if equipped) To set the time : The ignition switch must be in the ACC position or the ON position. • H (Hour) Press the "H" button to advance the time displayed by one hour. •...
Page 256: Clothes Hanger
Convenient features of your vehicle GPS Time check Clothes hanger (if equipped) WARNING The clock is automatically updated ■ Type A through the navigation system. Do not hang other objects except clothes. In an accident it may cause vehicle damage or GPS Time non-check personal injury.
Page 257: Floor Mat Anchor(S)
To avoid any To raise and lower the rear curtain, interference with pedal operation, press the button. HYUNDAI recommends that the HYUNDAI floor mat designed for use in your vehicle be installed. 3-161...
Page 258: Side Curtain
Convenient features of your vehicle The rear curtain will be lowered auto- Side curtain (if equipped) NOTICE matically when you shift the shift • Always hang both sides of the lever into R (Reverse) and raised curtain on the hook. This could automatically when you shift the shift cause damage to the side cur- lever from R (Reverse) into P (Park).
Page 259: Multimedia System
Multimedia System Multimedia system ..........4-2 Voice recognition ............4-99 Ending voice recognition ..........4-100 AUX, USB and iPod port ..........4-2 ® Setup (for RDS, Bluetooth ® Wireless Technology Antenna ................4-3 equipped model) ............4-107 Steering wheel audio control ........4-4 Setup (for Bluetooth ® WirelessTechnology equipped Audio / Video / Navigation system (AVN) ....4-5 model) ................4-114...
Page 260: Multimedia System
Multimedia System MULTIMEDIA SYSTEM AUX, USB and iPod ® port Information Information • If you install an aftermarket HID When using a portable audio device headlamp, your vehicle’s audio and connected to the power outlet, noise electronic device may malfunction. may occur during playback.
Page 261: Antenna
Antenna NOTICE NOTICE • Do not clean the inside of the • To prevent damage to the rear rear window glass with a cleaner glass antenna, never use sharp or use a scraper to remove for- instruments or window cleaner eign deposits as this may cause containing abrasives to clean damage to the antenna elements.
Page 262: Steering Wheel Audio Control
Multimedia System VOLUME (VOL + / - ) (1) Steering wheel audio control MODE ( ) (3) (if equipped) • Move the VOLUME lever up to Press the MODE button to select increase volume. Radio, Disc, or AUX. ■ ■ ■...
Page 263: Audio / Video / Navigation System (Avn)
Bluetooth Audio / Video / Navigation sys- ® Wireless Technology (1) Call / Answer button tem (AVN) (if equipped) hands-free (if equipped) (2) Call end button (3) Microphone Detailed information for the AVN sys- tem is described in a separately sup- plied manual.
Page 264: How Vehicle Audio Works
Multimedia System How vehicle audio works This can be due to factors, such as AM reception the distance from the radio station, FM reception closeness of other strong radio sta- tions or the presence of buildings, bridges or other large obstructions in the area.
Page 265 FM radio station JBM003 JBM004 JBM005 FM broadcasts are transmitted at • Fading - As your vehicle moves • Station Swapping - As an FM signal high frequencies and do not bend to away from the radio station, the weakens, another more powerful follow the earth's surface.
Page 266 Multimedia System Caring for disc • Depending on the type of CD- MP3 File Information R/CD-RW CDs, certain CDs may • If the temperature inside the car is too not operate normally according to • Supported Audio Formats high, open the car windows to venti- the manufacturing companies.
Page 267 • Support for Compressed Files • For MP3/WMA compression files, • Language Support differences in sound quality will (Unicode Support) 1. Supported Bitrates (Kbps) occur depending on the bitrate. 1. English: 94 characters (Higher sound quality can be expe- MPEG1 MPEG2 MPEG2.5 2.
Page 268 Multimedia System • Compatibility by Disc Type • Precautions upon Writing CDs 5. Prolonged use of CD-R/CD-RW discs that do not satisfy related 1. Playing MIXED CDs: First plays 1. In all cases except when creating standards and/or specifications the audio CD, then plays the com- multisession discs, check the could result in product malfunc- pressed file(s).
Page 269 Using a cellular phone or a two- NOTE: way radio Order of playing files (folders) : When a cellular phone is used inside 1. Song playing order : the vehicle, noise may be produced sequentially. from the audio system. This does not 2.
Page 270 Multimedia System (Continued) NOTICE WARNING • Do not place beverages close to Operating the device while driving the audio system. Spilling bever- • Do not stare at the screen while could lead to accidents due to a ages may lead to system mal- driving.
Page 271 (Continued) (Continued) Information • Clean fingerprints and dust off the • Do not use abnormally shaped discs Using the discs disc surface (coated side) with a soft (8cm, heart-shaped, octagon- • This device has been manufactured cloth. shaped) as such discs could lead to to be compatible with software malfunctions.
Page 272 Multimedia System (Continued) (Continued) Information • Only products formatted with • The amount of time required to rec- Using the USB device byte/sectors under 64Kbyte will be ognize the USB device may differ • Connect the USB device after turn- recognized.
Page 273 (Continued) (Continued) (Continued) • When using mass storage USB • The device may not support normal • Avoid use of USB mem- devices with separate logical drives, operation when using formats such ory products that can only files saved to the root drive can as HDD Type, CF, or SD Memory.
Page 274 Multimedia System (Continued) (Continued) Information • When the EQ features of an exter- • If your iPhone ® is connected to both ® Using the iPod device the Bluetooth ® nal device, such as the iPod ® , and Wireless Technology •...
Page 275 (Continued) (Continued) Information • Some iPod ® s may not sync with the • When the external device power is Using the AUX device System depending on its version. If connected to the power jack, play- • If an external device connector is the Media is removed before the ing the external device may output connected with the AUX terminal,...
Page 276 Multimedia System Information Information Information ® Before using the Bluetooth Precautions for safe driving When connecting a ® handsfree Bluetooth phone • Bluetooth ® Handsfree is a feature What is Bluetooth ® that enables drivers to practice safe • Before connecting the head unit •...
Page 277 (Continued) • Park the vehicle when connecting the head unit with the mobile phone. • Bluetooth ® connection may become intermittently disconnected in some mobile phones. Follow these steps to try again. 1.Within the mobile phone, turn the Bluetooth ® function off/on and try again.
Page 278: System Controllers And Functions - 3.8 Inch Mono Tft (Except Europe)
Multimedia System SYSTEM CONTROLLERS AND FUNCTIONS - 3.8 INCH MONO TFT (EXCEPT EUROPE) ❈ Display and settings may differ depending on the Name Description selected audio. • Each time the key is pressed, the mode is MEDIA ® changed in order of CD, USB, iPod , AUX, My Audio Head Unit Music, BT Audio modes.
Page 279 Name Description DISP • Each time the button is shortly pressed, it sets the screen Off ➟ Screen On ➟ Screen Off ❈ Audio operation is maintained and only the screen will be turned Off. In the screen Off state, press any key to turn the screen On again.
Page 280 Multimedia System Audio Head Unit (For RDS model) Name Description DISP • Each time the button is shortly pressed, it sets the screen Off ➟ Screen On ➟ Screen Off ❈ Audio operation is maintained and only the screen will be turned Off. In the screen Off state, press any key to turn the screen On again.
Page 281 Name Description Audio Head Unit MEDIA • Each time the key is pressed, the mode is (For Bluetooth equipped model) changed in order of CD, USB, iPod, AUX, My Music, BT Audio modes. ❈ In Setup>Display, the media pop up screen will be displayed when [Mode Pop up] is turned When the pop up screen is displayed, use the TUNE knob or keys...
Page 282 Multimedia System Name Description • Radio Mode SCAN - Shortly press the key : Previews each broad cast for 5 seconds each - Press and hold the key : Previews the broad casts saved in Preset for 5 sec- onds each. ❈...
Page 283 Audio Head Unit Name Description MEDIA • Each time the key is pressed, the mode is changed in order of CD, USB, iPod, AUX, My Music, BT Audio modes. ❈ In Setup>Display, the media pop up screen will be displayed when [Mode Pop up] is turned When the pop up screen is displayed, use the TUNE knob or keys to select...
Page 284: Setup (For Rds Model)
Multimedia System Mode Pop up Song Info SETUP (for RDS model) [Mode Pop up] Changes When playing an MP3 file, select the selection mode desired display info from ‘Folder/File’ Display Settings or ‘Album/Artist/Song’. • During On state, press the RADIO key to display the mode MEDIA change pop up screen.
Page 285 Audio Settings Speed Dependent Volume Control This menu allows you to set the This feature is used to automatically ‘Bass, Middle, Treble’ and the Sound control the volume level according to Fader and Balance. the speed of the vehicle. Select [Audio Settings] Select menu Select [Speed Dependent Vol.] Turn through TUNE knob...
Page 286: Phone Setup (For Rds, Bluetooth ® Wireless Technology Equipped Model)
Multimedia System ➂ Pairing completion is displayed. Pair Phone Phone Setup ❈ In some mobile phones, pairing NOTICE (for RDS , Bluetooth ® Wireless will automatically be followed by Technology equipped model) To pair a Bluetooth ® Wireless connection. Technology enabled mobile ❈...
Page 287 ➁ Connect the selected mobile Phone List Changing connection sequence • (Priority) phone. The names of up to 5 paired phones ➂ Connection completion is dis- This is used to change the order (pri- will be displayed. ority) of automatic connection for the played.
Page 288 Multimedia System Delete Phone book Download Auto Download • Select [Phone List] Select mobile This feature is used to download When connecting a mobile phone, it phone through TUNE knob phone book and call histories into is possible to automatically download Select [Delete] the audio system.
Page 289 ❈ If the Bluetooth Using the Bluetooth ® ® Outgoing Volume Wireless Wireless Technology system is turned on, the system will Technology System This is used to set the volume of your automatically try to connect the voice as heard by the other party To use Bluetooth Wireless Technology ®...
Page 290 Multimedia System Memory Information Language System Settings (if equipped) This menu is used to set the display and voice recognition language. Press the key Select [System] SETUP Select [Language] Set through TUNE Displays currently used memory and through tune knob or key Select knob total system memory.
Page 291: Setup
Media Display SETUP Mode Pop up [Mode Pop up] Changes When playing an MP3 file, select the selection mode desired display info from ‘Folder/File’ Display Settings or ‘Album/Artist/Song’. • During On state, press the RADIO key to display the mode MEDIA Press key Select...
Page 292 Multimedia System Sound Settings Audio Settings Speed Dependent Volume SETUP This menu allows you to set the Control Press key Select ‘Bass, Middle, Treble’ and the Sound [Sound] through TUNE knob or This feature is used to automatically Fader and Balance. control the volume level according to Select [Audio Settings] Select menu the speed of the vehicle.
Page 293: Phone Setup (For Rds, Bluetooth ® Wireless Technology Equipped Model)
➂ Pairing completion is displayed. Phone Setup Pair Phone (for Bluetooth ® Wireless ❈ In some mobile phones, pairing Technology equipped model) will automatically be followed by NOTICE connection. To pair a Bluetooth ® Wireless ❈ It is possible to pair up to five Press key Select SETUP...
Page 294 Multimedia System ➁ Connect the selected mobile Phone List • Changing connection sequence phone. (Priority) The names of up to 5 paired phones ➂ Connection completion is dis- This is used to change the order (pri- will be displayed. played. ority) of automatic connection for the A [ ] is displayed in front of the cur- ❈...
Page 295 - The connected phone will auto- Contacts Download Audio Streaming matically be changed to No. 1 pri- This feature is used to download Songs (files) saved your ority. contacts and call histories into the Bluetooth Wireless Technology ® audio system. enabled mobile phone can be played Delete through the audio system.
Page 296 Multimedia System ❈ If Bluetooth Using the Bluetooth ® Bluetooth ® ® Wireless Wireless Wireless Technology System Off Technology System Technology system is turned on, the system will automatically try to To use Bluetooth ® This feature is used when you do not Wireless Technology connect the most recently con- wish to use the Bluetooth...
Page 297: System Settings
System Settings Memory Information Displays currently used memory and total system memory. Press the key Select [System] SETUP Select [Memory Information] OK through tune knob or The currently used memory is dis- played on the left side while the total system memory is displayed on the right side.
Page 298: Radio (For Rds Model)
Multimedia System Preset SEEK Traffic Announcement (TA) RADIO (FOR RDS MODEL) : Shortly pressing the FM, AM SCAN Press the (under 0.8 seconds): Set • Shortly pressing the key (under 0.8 TA Traffic Announcement) mode. seconds): Plays the frequency Changing RADIO mode saved in the corresponding key.
Page 299 AST (Auto Store) AF (Alternative Frequency) Info Volume Press the key Set [ AST] Info Volume refers to the sound vol- Press the key Set [ MENU MENU ume upon receiving News or Traffic through TUNE knob or key. through TUNE knob or key.
Page 300: Radio
Multimedia System Preset SEEK Selecting through manual RADIO : FM, AM search Press the Turn the TUNE knob left/right to • Shortly pressing the key : Plays the adjust the frequency. frequency saved in the correspon- • FM : Changes by 200KHz ding key.
Page 301 MENU : Audio CD Repeat MENU : MP3 CD / USB In CD mode, press key. MENU In MP3 CD / USB mode, press Set [ RPT] through the TUNE key. knob or key to repeat the cur- MENU rent song. ❈...
Page 302 Multimedia System Folder Repeat Copy MENU : iPod ® In iPod mode, press key. Set [ F.RPT] through the TUNE Set [ Copy] through the TUNE MENU knob or key to repeat songs knob or key. within the current folder. ❈This is used to copy the current ❈...
Page 303 Information MENU : My Music Mode Information Set [ Info] through the TUNE In My Music mode, press key. MENU Set [ Info] through the TUNE knob knob or key. key. Displays information of the current Displays information of the current song.
Page 304 Multimedia System Delete All Delete Selection AUX is used to play external MEDIA Set [ Del.All] through the TUNE Press the key Set [ Del.Sel] MENU currently connected with the AUX knob or key. through the TUNE knob or key. terminal.
Page 305 Making a call using the Steering wheel remote controller Name Description MODE • Each time this key is pressed, the mode is changed in order of FM1 ➟ FM2 ➟ FMA ➟ AM ➟ AMA ➟ CD ➟ USB or iPod ➟ AUX ➟ My Music ➟ BT Audio •...
Page 306 Multimedia System Phone MENU (for RDS model) Phone Book Phone Setup Press the key to display three Press the key Set [ P. Press the key Set [ Setup] PHONE PHONE PHONE menus (Call History, Phone Book, Book] through the TUNE knob or through the TUNE knob or...
Page 307 Phone MENU Contacts Phone Setup Press the key to display three PHONE Press key Set Press the key Set [ Setup] PHONE PHONE menus (Call History, Contacts, Contacts] through the TUNE knob or through the TUNE knob or Phone Setup). key.
Page 308 Multimedia System (Continued) (Continued) Information ® • You will not be able to use the • Some cellular phones or other - Using the Bluetooth hands-free feature when your phone devices may cause interference noise Wireless Technology cellular (in the car) is outside of the cellular or malfunction to audio system.
Page 309 (Continued) (Continued) (Continued) • Pairing and connecting a Bluetooth ® • Bluetooth ® • The hands-free call volume and Wireless Technology quality may differ depending on the Wireless Technology enabled mobile enabled operation may be unstable mobile phone type. phone will work only when the depending on the communication Bluetooth ®...
Page 310: Radio
Multimedia System SYSTEM CONTROLLERS AND FUNCTIONS - 4.3 INCH COLOR TFT LCD (EXCEPT EUROPE) ❈ Display and settings may differ depending on the selected audio Name Description MEDIA • Each time the key is pressed, the mode is changed in order of CD, USB, iPod , AUX, ®...
Page 311 Name Description DISP • Each time the button is shortly pressed, it sets the screen Off ➟ Screen On ➟ Screen Off ❈ Audio operation is maintained and only the screen will be turned Off. In the screen Off state, press any key to turn the screen On again.
Page 312 Multimedia System Steering-wheel mounted controls Name Description MODE • Each time this key is pressed, the mode is ➟ ➟ ➟ changed in order of FM1 ➟ ➟ ➟ ➟ ➟ ® USB or iPod ➟ Music BT Audio. • If the media is not connected or a disc is not inserted, corresponding modes will be disabled.
Page 313 Name Description • When pressed shortly - When pressed in the phone screen, displays call history screen - When pressed in the dial screen, makes a call - When pressed in the incoming call screen, answers the call - When pressed during call waiting, switches to waiting call (Call Waiting) •...
Page 314: Radio Mode(For Rds Model)
Multimedia System 1. Mode Display 5. Autostore RADIO MODE Displays currently operating mode Automatically saves frequencies with (for RDS model) superior reception to Preset buttons 2. Frequency Basic Mode Screen 6. RDS Info Displays the current frequency Displays RDS broadcast information 3.
Page 315 Switching to Radio Mode Searching Radio Frequencies Using TUNE Turn the TUNE knob to select the desired frequency. Using Seek Pressing the key will change RADIO • FM : Increases/decreased by SEEK the operating mode in order of FM1 Press the key to play the TRACK 50kHz...
Page 316 Multimedia System Auto Store Using Radio Mode Information Press the button to automati- While listening to a frequency you cally save receivable frequencies to want to save as a preset, press and Selecting /Saving Presets Preset buttons. hold one of the [1] ~ [6] preset buttons Press the buttons to play (over 0.8 seconds) to save the current...
Page 317 RDS Menu Scan TA (Traffic Announcement) Press the button to set the AF Press and hold the key (over (Alternative Frequency), Region and 0.8 seconds) to preview frequencies Press the key to turn the TA News features. with superior reception for 5 seconds (Traffic Announcement) feature...
Page 318: Radio Mode
Multimedia System 1. Mode Display Switching to Radio Mode RADIO MODE Displays currently operating mode. Pressing the key will change RADIO Basic Mode Screen 2. Frequency the operating mode in order of FM1 ➟ ➟ Displays the current frequency. If [Mode Pop up] is turned on within 3.
Page 319 Searching Radio Frequencies Using Radio Mode Auto Store Press the button to auto- Auto store matically save receivable frequen- Using Seek Selecting Presets/Saving Presets cies to Preset buttons. SEEK Press the key to play the Press the button to display Preset TRACK previous/next frequency.
Page 320: Media Mode
Multimedia System Title Icon MEDIA MODE ® When Bluetooth Wireless Technology, iPod ® , USB, or AUX Pressing the key will change MEDIA device is connected or a CD is ➟ the operating mode in order of CD inserted, the corresponding mode USB(iPod ®...
Page 321: Audio Cd Mode
Changing Tracks AUDIO CD MODE While playing, press the button to pause and press button to SEEK Press the key to move to TRACK play. the previous or next track. Using Audio CD Mode Information Playing/Pausing CD Tracks Information Once an audio CD is inserted, the •...
Page 322 Multimedia System Selecting from the List Rewinding / Fast-forwarding Audio CD Mode Menu Tracks Turn the TUNE knob left/right to Within this mode, you will have search for the desired track. While playing, press and hold the access to the Info, Random(Shuffle), SEEK key to rewind or fast-for- Repeat and List features.
Page 323 Info Repeat List Press the ) button to Press the ) button to Press the ) button to Info Repeat List display details about the current disc. repeat the current track. Press the display the track list screen. button again to turn the repeat fea- ture off.
Page 324: Mp3 Cd Mode
Multimedia System Selecting from the List While playing, press the button MP3 CD MODE to pause and press button to Turn the TUNE knob left/right to play. search for the desired file. Using MP3 CD Mode Information Playing/Pausing MP3 Files If there are numerous files and folders within the disc, reading time could Once an MP3 disc is inserted the...
Page 325 Rewinding / Fast-forwarding Files Info MP3 CD Mode Menu While playing, press and hold the Within this mode, you will have Press the ) button to Info SEEK access to the Info, Random(Shuffle), key (over 0.8 seconds) to display details about the current file. TRACK Repeat, Copy and List features.
Page 326 Multimedia System Random(Shuffle) Copying Files List Press the ) button to Press the ) button to Press the ) button to Shuffle Copy List play files in random(Shuffle) order. copy the current file into My Music. display the file list screen. Each time the button is pressed, the Information feature changes in order of Random...
Page 327: Usb Mode
Changing Files USB MODE While playing, press the button SEEK to pause and press button to Press the keys to move to TRACK play. the previous or next file. Using USB Mode Information Information Playing/Pausing USB Files SEEK • Loading may require additional time •...
Page 328 Multimedia System Selecting from the List Searching Folders USB Mode Menu Turn the TUNE knob left/right to Press the key to select FOLDER Within this mode, you will have search for the desired file. and search folders. access to the Info, Random(Shuffle), Repeat, Copy and List features.
Page 329 Info Random (Shuffle) Copying Files Press the ) button to Press the ) button to Press the ) button to Info Shuffle Copy display details about the current file. play files in random(Shuffle) order. copy the current file into My Music. Each time the button is pressed, the feature changes...
Page 330: Ipod ® Mode
Multimedia System Changing Songs While playing, press the button iPod MODE ® to pause and press button to SEEK Press the key to move to play. TRACK the previous or next song. Using iPod Mode ® Information Information ® iPod s with unsupported communica- Playing/Pausing iPod ®...
Page 331 Searching Categories Category Menu Information Turn the TUNE knob left/right to Within the iPod ® Category menu, There are eight categories that can be search for the desired category. you will have access to the searched, including Playlists, Artists, , and features.
Page 332 Multimedia System Random(Shuffle) iPod ® Mode Menu Information Press the ) button to Shuffle Within this mode, you will have • If the search mode is accessed while play songs in random(Shuffle) order. access to the Random(Shuffle), playing a song, the most recently Repeat and List features.
Page 333: Aux Mode
List Connecting an External Device AUX MODE Press the ) button to List External audio players (Camcorders, display the Category Menu. car VCR, etc.) can be played through Using AUX Mode a dedicated cable. Press the key Select [AUX] MEDIA <For RDS model>...
Page 334: My Music Mode
Multimedia System Selecting from the List MY MUSIC MODE Information Turn the TUNE knob left/right to If there are no files saved within My search for the desired file. Using My Music Mode Music, the button will be My Music disabled.
Page 335 Rewinding / Fast-forwarding Info My Music Mode Menu Files Press the ) button to Info Within this mode, you will have display details about the current file. While playing, press and hold the access to the Info, Random(Shuffle), SEEK key to rewind or fast-for- Repeat, Delete and List features.
Page 336 Multimedia System List List Menu Press the ) button or Select All Press the button to display the List individually select the files you want to From the List screen, it is possible to file list screen. delete files you previously saved into delete.
Page 337: Bluetooth ® Wireless Technology Audio Mode
® Bluetooth Wireless Information Information Technology AUDIO MODE • If the Bluetooth ® The play/pause feature may operate Wireless Technology ® (for Bluetooth Wireless differently depending on the mobile audio is not operating properly, check Technology equipped model) phone. whether the feature is turned off at SETUP [Phone] [Audio stream-...
Page 338 Multimedia System Bluetooth ® Wireless Technology NOTICE Information (for RDS, Bluetooth Wireless ® - Using upon connecting • Bluetooth Wireless Technology ® Technology equipped model) ® Bluetooth Wireless Handsfree is a feature that Technology phone enables drivers to practice safe Using Bluetooth Wireless driving.
Page 339 (Continued) (Continued) (Continued) • Bluetooth • Bluetooth ® ® • If you do not want to automatically Wireless Technology con- Wireless Technology fea- connect your Bluetooth ® Wireless nection may become intermittently tures supported within the vehicle Technology phone, try the following. disconnected in some mobile phones.
Page 340: Multimedia System
Multimedia System (Continued) (Continued) (Continued) Bluetooth ® • Only Wireless • Only one function can be used at a • Placing the audio system within an time between the Bluetooth ® Technology device can be connected Wireless electromagnetic environment may Technology Handsfree and Bluetooth ®...
Page 341 Pairing a Bluetooth ® Wireless 1) Device : Name of device as shown Pairing Key / PHONE Technology wireless technolo- on the Steering Remote when searching from your gy Device Controller Bluetooth Wireless Technology ® device 2) Passkey : Passkey used to pair the What is Bluetooth Wireless ®...
Page 342 Multimedia System Pairing through [PHONE] Information Information Setup • The waiting period during phone Press the Select SETUP pairing will last for one minute. The [Phone] Select [Pair Phone] pairing process will fail if the device Select TUNE knob is not paired within the given time. If the pairing process fails, you must start the process from the beginning.
Page 343 Connecting a Device From the paired phone list, select the Changing Priority device you want to connect and Press key Select SETUP press the button. [Phone] Select [Paired Phone List] What is Priority? It is possible to pair up to five Bluetooth ®...
Page 344 Multimedia System From the paired phone list, select Disconnecting a Device Deleting a Device the phone you want to change to the Press key Select SETUP highest priority, then press the [Phone] Select [Paired Phone List] Press key Select SETUP button from the Menu.
Page 345 1) Dial Number : Displays the dial Information USING Bluetooth Wireless ® screen where numbers can be Technology • If you press the [Call History] button dialed to make calls but there is no call history data, a 2) Call History : Displays the call his- prompt is displayed which asks tory list screen whether to download call history...
Page 346 Multimedia System Calling by Dialing a Number Answering Calls Information • When the incoming call pop-up is displayed, most Audio and SETUP Answering a Call Press the key Select [Dial PHONE mode features will not operate. Only Number] Answering a call with a Bluetooth ®...
Page 347 During a Handsfree Call Call History Information Press the Select [Call PHONE • The call history list will display up History] to 30 outgoing, incoming, and missed calls. • Upon downloading call histories, previously saved histories are delet- • Incoming calls with hidden caller IDs will not be saved in the call his- tory list.
Page 348 Multimedia System Phone Book (Continued) Information • The download feature may not be Press key Select PHONE • Up to 1,000 phone book entries can supported in some mobile phones. [Phone book] be copied into car phone book. Check to see that the Bluetooth ®...
Page 349: Wireless Technology
Bluetooth ® Wireless Technology 1) Device : Name of device as shown Pairing Key / Key on PHONE when searching from your the Steering Remote Controller (for Bluetooth Wireless ® Bluetooth ® Wireless Technology Technology equipped model) device When No Devices have been Paired 2) Passkey : Passkey used to pair the Pairing a Bluetooth Wireless...
Page 350 Multimedia System Pairing through [PHONE] Information Information Setup • The waiting period during phone Press the Select SETUP pairing will last for one minute. The [Phone] Select [Pair Phone] pairing process will fail if the device Select TUNE knob is not paired within the given time. If the pairing process fails, you must start the process from the begin- ning.
Page 351 Connecting a Device From the paired phone list, select the Changing Priority device you want to connect and Press key Select SETUP press the button. Connect [Phone] Select [Paired Phone List] What is Priority? It is possible to pair up to five Bluetooth ®...
Page 352 Multimedia System From the paired phone list, select the Disconnecting a Device Deleting a Device phone you want to change to the highest priority, then press the Press key Select Press key Select SETUP SETUP button from the Menu. Change priority [Phone] Select [Paired Phone List] [Phone] Select [Paired Phone List] The selected device will be changed...
Page 353 4) Setup : Displays Phone related Calling by Dialing a Number USING Bluetooth Wireless ® settings Technology Press the key Select [Dial PHONE Information Number] Phone Menu Screen • If you press the [Call History] but- ton but there is no call history data, Phone Menus a prompt is displayed which asks With a Bluetooth...
Page 354 Multimedia System Answering Calls During a Handsfree Call Information • When the incoming call pop-up is Answering a Call displayed, most Audio and SETUP mode features will not operate. Only Answering a call with a Bluetooth ® the call volume can be operated. Wireless Technology device connect- •...
Page 355 Contacts Call History Information Press key Select PHONE Press the Select [Call PHONE • Up to 1,000 contacts entries can be [Contacts] History] copied into car contacts. • Upon downloading contacts data, previously saved contacts data will be deleted. • Downloading is not possible if the contacts download feature is turned off within the Bluetooth ®...
Page 356 Multimedia System (Continued) (Continued) Information • After downloading the Bluetooth ® • Within the following situations, - Using the Voice Recognition voice recognition may not function Wireless Technology phone book, it • When using the voice recognition properly due to external sound. takes some times to convert the feature, only commands listed with- phone book data into voice informa-...
Page 357: Voice Recognition
Skipping Prompt Messages If voice recognition is in [Normal VOICE RECOGNITION Mode], then the system will say While prompt message is being stat- (if equipped) “Please say a command. Beep~” ed Shortly press the key on the • If voice recognition is in [Expert steering remote controller (under 0.8 Using Voice Recognition Mode], then the system will only...
Page 358: Ending Voice Recognition
Multimedia System ENDING VOICE RECOGNITION While Voice Recognition is operating Press and hold the key on the steering remote controller (over 0.8 seconds) Information • While using voice command, press- ing a steering wheel remote control or a different key will end voice command.
Page 359 ❈ • End voice command. Illustration on using voice commands Shortly pressing the key (under 0.8 seconds): • Starting voice command. Please say a command Ding~ Shortly pressing the key (under 0.8 seconds): Please say a command Ding~ Phone book More Help Phone book.
Page 360 Multimedia System Voice Command List • Common Commands: These are commands that can be used in all situations. (However, some commands may not be supported in special circumstances.) Command Function Command Function • More Help Provides guidance on commands that can be When currently listening to the FM radio, used anywhere in the system.
Page 361 Command Function Command Function Media Moves to the most recently played media AUX (Auxiliary) Plays the connected external device. screen. Bluetooth Audio Plays music saved connected Play Track 1~30 If a music CD has been inserted, plays the Bluetooth ® Wireless Technology device.
Page 362 Multimedia System • FM/AM radio commands: Commands that can be • Audio CD commands: Commands that can be used used while listening to FM, AM radio. while listening to Audio CD. Command Function Command Function Preset 1~6 Plays the broadcast saved in Preset 1~6. Region off Disable Region feature Auto Store...
Page 363 • MP3 CD / USB commands: Commands that can be • iPod Commands: Commands that can be used while used while listening to music files saved in CD and playing iPod. USB. Command Function Command Function Random Randomly plays the files within the current All Random Randomly plays all saved songs.
Page 364 Multimedia System • Bluetooth • My Music Commands: Commands that can be used Wireless Technology Audio Commands: ® while playing My Music. Commands that can be used while playing Phone Music. Command Function Command Function Random Randomly plays all saved files. Play Plays the currently paused song.
Page 365: Setup (For Rds, Bluetooth ® Wireless Technology Equipped Model)
Pop-up Mode Display Settings SETUP Press key Select SETUP (for RDS, Bluetooth ® Wireless [Display] Select [Pop-up Mode] Adjusting the Brightness Technology equipped model) Press key Select SETUP [Display] Select [Brightness] Starting Mode Press the key to display the SETUP Setup screen.
Page 366 Multimedia System Scroll Text MP3 Information Display Sound Settings Press key Select Press key Select SETUP SETUP [Display] Select [Song Info] [Display] Select [Scroll text] Audio Settings Press key Select SETUP [Sound] Select [Audio Setting] This feature is used to change the This feature is used to scroll text dis- information displayed within USB played on the screen when it is too...
Page 367 SDVC (Speed Dependent Volume Touch Screen Beep Bluetooth ® Wireless Technology Setting Control) Press key Select SETUP [Sound] Select [Touch Screen Press key Select SETUP Beep] [Sound] Select [Speed Dependent Pairing a New Device Vol.] Press key Select SETUP [Phone] Select [Pair Phone] This feature is used to turn the touch The volume level is controlled auto- screen beep on/off.
Page 368 Multimedia System Viewing Paired Phone List : Moves to the previous Information Press key Select SETUP screen - BEFORE DOWNLOADING [Phone] Select [Paired Phone List] PHONE BOOKS : Connect/disconnects cur- rently selected phone • Only phone books within connected phones can be downloaded. Also : Deletes currently check to see that your mobile phone...
Page 369 Downloading Phone books Auto Download (Phone Book) Audio Streaming Press key Select Press key Select Press key Select SETUP SETUP SETUP [Phone] Select [Phone book [Phone] Select [Auto Download] [Phone] Select [Audio Streaming] Download] This feature is used to automatically When Audio Streaming is turned on, The Phone book is downloaded from download mobile phone book entries...
Page 370 Multimedia System Outgoing Volume Turning Bluetooth System Off Information Press key Select SETUP To turn Bluetooth ® Press key Select SETUP Wireless Technology [Phone] Select [Outgoing Volume] [Phone] Select [Bluetooth System back on, go to [Phone] and SETUP Off] press “Yes”. ®...
Page 371 Language System Setting Press key Select SETUP [System] Select [Language] Memory Information Press key Select SETUP [System] Select [Memory Information] This feature is used to change the system and voice recognition lan- guage. This feature displays information If the language is changed, the sys- related to system memory.
Page 372: Setup (For Bluetooth Wirelesstechnology Equipped Model)
Multimedia System Display Settings 1) Automatic : Adjusts the brightness SETUP automatically (for Bluetooth ® Wireless 2 Day : Always maintains the bright- Adjusting the Brightness Technology equipped model) ness on high Press key Select SETUP 3) Night : Always maintains the [Display] Select [Brightness] brightness on low Starting Mode...
Page 373 Mode Pop up Text Scroll MP3 Information Display Press key Select Press key Select Press key Select SETUP SETUP SETUP [Display] Select [Mode Pop up] [Display] Select [Text Scroll] [Display] Select [Media Display] This feature is used to display the This feature is used to scroll text dis- This feature is used to change the Mode Pop up screen when entering...
Page 374 Multimedia System SDVC (Speed Dependent Sound Settings Use the buttons to Volume Control) adjust the Fader/Balance settings. Use the buttons to adjust the Press key Select SETUP Sound Settings [Sound] Select [Speed Dependent Bass/Middle/Treble settings. Press key Select SETUP Vol.] Press the button to reset.
Page 375 Bluetooth Viewing Paired Phone List ® Wireless : Moves to the previous Technology Setting screen Press key Select SETUP [Phone] Select [Paired Phone List] 2) Connect/Disconnect Phone : Connect/disconnects currently Pairing a New Device selected phone Press key Select SETUP 3) Delete : Deletes the currently [Phone] Select [Pair Phone] selected phone...
Page 376 Multimedia System Downloading Contacts Auto Download (Contacts) Streaming Audio Press key Select Press key Select Press key Select SETUP SETUP SETUP [Phone] Select [Contacts Download] [Phone] Select [Auto Download] [Phone] Select [Streaming Audio] The contacts is downloaded from the This feature is used to automatically When Streaming Audio is turned on, mobile phone and the download download mobile contacts entries...
Page 377 Outgoing Volume System Setting Press key Select SETUP [Phone] Select [Outgoing Volume] Memory Information Press key Select SETUP [System] Select [Memory Information] Use the buttons to adjust the outgoing volume level. This feature displays information Turning Bluetooth System Off related to system memory. Press key Select SETUP...
Page 378: Rear View Camera
Multimedia System REAR VIEW CAMERA NOTICE (if equipped) The rear view camera has been equipped with an optical lens to provide a wider range of vision and • The system has been equipped may appear different from the actu- with a rear view camera for user al distance.
Page 379 APPENDIX Name Description Name Description "Playlists" is filtering keyword for Monday Monday Playlists searching mode of playlists for iPod Tuesday Tuesday "Songs" is filtering keyword for Wednesday Wednesday Songs searching mode of playlists for iPod Thursday Thursday "Audiobooks" is filtering keyword for Audiobooks Friday Friday...
Page 380 Multimedia System Name Description Name Description Ejecting CD Ejecting CD Battery discharge Battery discharge Start the engine Start the engine Audio CD Audio CD Setup Setup Track Audio CD song order Display Setup display mode Reading Media Reading Media Not supported Not supported file format This function is used to select Mode Pop up...
Page 381 Name Description Name Description Treble is sound of high frequency. This function is used to select user Treble Language It can be adjusted sound by user language Fader is sound positon between Deutsch Deutsch Fader FRONT and REAR. It can be adjusted English(UK) English(UK) sound by user...
Page 382 Multimedia System Name Description Name Description Incoming Call Receivng phone After pairing phone, audio system Auto Download automatically download phone book Call Ended Call Ended When there is unwanted call, you After pairing phone, audio system can Call Rejected push the button on the steering support Bluetooth ®...
Page 383 Name Description Changed priority about the regis- Priority changed tered phones Overwrite previous phone book Overwrite previous information Phone does not support Phone does not support Phone book download Phone book download There are phone in the connection No connected Bluetooth device list But it was actually not connected BT...
Page 384: System Controllers And Functions - 3.8 Inch Mono Tft (For Europe)
Multimedia System SYSTEM CONTROLLERS AND FUNCTIONS - 3.8 INCH MONO TFT (FOR EUROPE) Audio Head Unit Name Description MEDIA • Each time the key is pressed, the mode is changed in order of CD, USB, iPod , AUX, ® My Music. ❈...
Page 385 Name Description • Radio Mode SCAN - Shortly press the key : Previews each broad cast for 5 seconds each - Press and hold the key : Previews the broad casts saved in Preset for 5 seconds each. ❈ Press the SCAN key again to continue listen- ing to the current frequency.
Page 386: Setup
Multimedia System Sound Settings SETUP Mode Pop up [Mode Pop up] Changes selection mode Press key Select Display Settings • During On state, press the RADIO [Sound] through TUNE knob or key to display the mode MEDIA Press key Select change pop up screen.
Page 387 Audio Settings Speed Dependent Volume Control This menu allows you to set the ‘Bass, Middle, Treble’ and the Sound This feature is used to automatically Fader and Balance. control the volume level according to the speed of the vehicle. Select [Audio Settings] Select menu through TUNE knob Turn Select [Speed Dependent Vol.] Turn...
Page 388 Multimedia System System Settings Memory Information Language Displays currently used memory and This menu is used to set the display total my music memory. and voice recognition language. Press the key Select [System] Select [Memory Information] OK Select [Language] Set through TUNE through tune knob or knob...
Page 389: Radio
Preset SEEK Selecting through manual RADIO : FM, AM search Press the Turn the TUNE knob left/right to • Shortly pressing the key : Plays the adjust the frequency. frequency saved in the correspon- • FM : Changes by 50KHz ding key.
Page 390 Multimedia System BASIC METHOD OF USE : AUDIO CD / MP3 ® CD / USB / IPOD / MY MUSIC Name Description Repeat While song (file) is playing key Audio CD, MP3 CD, USB, iPod®, My Music mode: • Repeats the current song MP3 CD, USB mode: •...
Page 391: Basic Method Of Use : Audio Cd / Mp3 Cd / Usb / Ipod ® / My Music
Name Description Scan SCAN While song (file) is playing Scans all songs for 10 seconds starting from the next song. ❈ Press the SCAN key again to turn off. ❈ The SCAN function is not supported in iPod ® mode. Folder Search : While file is playing FOLDER...
Page 392 Multimedia System MENU : Audio CD Information MENU : MP3 CD / USB In CD mode, press key. MENU In MP3 CD / USB mode, press Set [ Info] through the TUNE key. MENU knob or key to display informa- tion of the current song.
Page 393 Folder Repeat Copy MENU : iPod ® In iPod mode, press key. Set [ F.RPT] through the TUNE Set [ Copy] through the TUNE MENU knob or key to repeat songs knob or key. within the current folder. ❈This is used to copy the current ❈...
Page 394 Multimedia System Information MENU : My Music Mode Random Set [ Info] through the TUNE In My Music mode, press key. MENU Set [ RDM] through the TUNE knob knob or key. key. Displays information of the current Plays all songs within the currently song.
Page 395 Delete Delete All AUX is used to play external MEDIA Set [ Delete] through the TUNE Set [ Del.All] through the TUNE currently connected with the AUX knob or key. knob or key. terminal. Deletes all songs of My Music. •...
Page 396 Multimedia System Making a call using the Steering wheel remote controller Name Description MODE • Each time this key is pressed, the mode is ➟ ➟ ➟ changed in order of FM1 ➟ ➟ ➟ ® USB or iPod My Music •...
Page 397: System Controllers And Functions - 4.3 Inch Color Tft Lcd (For Europe)
SYSTEM CONTROLLERS AND FUNCTIONS - 4.3 INCH COLOR TFT LCD (FOR EUROPE) Audio Head Unit Name Description MEDIA • Each time the key is pressed, the mode is ®) changed in order of CD, USB(iPod , AUX, My Music, BT Audio modes. (for Bluetooth Wireless Technology equipped ®...
Page 398 Multimedia System Name Description • Each time the button is shortly pressed, it sets the screen Off ➟ Screen On ➟ Screen Off ❈ Audio operation is maintained and only the screen will be turned Off. In the screen Off state, press any key to turn the screen On again.
Page 399 Steering-wheel mounted controls Name Description • When pressed shortly - Starts voice recognition - When selecting during a voice prompt, stops the prompt and converts to voice command waiting state • When pressed and held (over 0.8 seconds) - Ends voice recognition MODE •...
Page 400 Multimedia System Name Description • When pressed shortly - When pressed in the phone screen, displays call history screen - When pressed in the dial screen, makes a call - When pressed in the incoming call screen, answers the call - When pressed during call waiting, switches to waiting call (Call Waiting) •...
Page 401: Radio Mode
1. Mode Display Switching to Radio Mode RADIO MODE Displays currently operating mode. Pressing the key will change RADIO Basic Mode Screen 2. Frequency the operating mode in order of FM1 ➟ ➟ Displays the current frequency. If [Pop up Mode] is turned on within 3.
Page 402 Multimedia System Searching Radio Frequencies Using Radio Mode Auto Store Press the button to automati- cally save receivable frequencies to Using Seek Selecting Presets/Saving Presets Preset buttons. SEEK Press the key to play the Press the button to display the TRACK previous/next frequency.
Page 403: Media Mode
Title Icon MEDIA MODE ® When Bluetooth Wireless Technology, iPod ® , USB, or AUX Pressing the key will change MEDIA device is connected or a CD is ➟ the operating mode in order of CD inserted, the corresponding mode USB(iPod ®...
Page 404: Audio Cd Mode
Multimedia System Changing Tracks AUDIO CD MODE Information SEEK Press the key to move to TRACK • Only genuine audio CDs are sup- the previous or next track. ported. Other discs may result in Using Audio CD Mode recognition failure (e.g. copy CD-R, Playing/Pausing CD Tracks Information CDs with labels)
Page 405 Selecting from the List Repeat Audio CD Mode Menu Turn the TUNE knob left/right to Press the button to repeat the Within this mode, you will have search for the desired track. current track. Press the button again access to the Info, Random(Shuffle), to turn the repeat feature off.
Page 406: Mp3 Cd Mode
Multimedia System Selecting from the List MP3 CD MODE Information Turn the TUNE knob left/right to If there are numerous files and folders search for the desired file. within the disc, reading time could Using MP3 CD Mode take more than 10 seconds and the list may not be displayed or song searches Playing/Pausing MP3 Files may not operate.
Page 407 Scan Info MP3 CD Mode Menu Press the key to play the first Press the button to display SCAN Within this mode, you will have 10 seconds of each file. details about the current file. access to the Info, Random(Shuffle), Repeat, Copy and List features.
Page 408 Multimedia System Random(Shuffle) Copying Files List Press the button to play files in Press the button to copy the Press the button to display the random(Shuffle) order. current file into My Music. file list screen. Each time the button is pressed, the feature changes in order of Random Information ➟...
Page 409: Usb Mode
Selecting from the List USB MODE Information Turn the TUNE knob left/right to • Loading may require additional time search for the desired file. if there are many files and folders Using USB Mode within the USB and result in faulty list display or file searching.
Page 410: Usb Mode
Multimedia System Searching Folders Info USB Mode Menu Press the button to display Press the key to select FOLDER Within this mode, you will have details about the current file. and search folders. access to the Info, Random(Shuffle), Repeat, Copy and List features. Information •...
Page 411 Random (Shuffle) Repeat List Press the button to play files in Press the button to repeat the Press the button to display the Random(Shuffle) order. current file or folder. file list screen. Each time the button is pressed, the Each time the button is pressed, the feature changes in order of Random feature changes in order of Repeat➟...
Page 412: Ipod ® Mode
Multimedia System Changing Songs Searching Categories iPod MODE ® Turn the TUNE knob left/right to SEEK Press the key to move to TRACK search for the desired category. the previous or next song. Using iPod Mode ® Information Playing/Pausing iPod ®...
Page 413 Category Menu iPod ® Mode Menu Information Within the iPod ® Category menu, Within this mode, you will have • If the search mode is accessed while you will have access to the access to the Random(Shuffle), playing a song, the most recently Home, and features.
Page 414: Aux Mode
Multimedia System Repeat Connecting an External Device AUX MODE Press the button to repeat the External audio players (Camcorders, current song. Press the button again car VCR, etc.) can be played through Using AUX Mode to turn the repeat feature off. a dedicated cable.
Page 415: My Music Mode
Changing Files Selecting from the List MY MUSIC MODE SEEK Press the key to move to Turn the TUNE knob left/right to TRACK the previous or next file. search for the desired file. Using My Music Mode Information Playing/Pausing My Music Files SEEK •...
Page 416 Multimedia System Random List My Music Mode Menu Press the button to play files in Press the button to display the Within this mode, you will have random order. Press the button again file list screen. access to the Info, Random(Shuffle), to turn the Random feature off.
Page 417 List Menu After selecting the files you want to Information delete, press the button to From the List screen, it is possible to • If there is memory available, up to delete the selected files. delete files you previously saved into 6,000 files can be saved.
Page 418: Bluetooth ® Wireless Technology Audio Mode
Multimedia System Bluetooth Wireless ® Information Information Technology Audio Mode • If the Bluetooth ® The play/pause feature may operate Wireless Technology (for Bluetooth Wireless ® differently depending on the mobile audio is not operating properly, check phone. whether the feature is turned off at Technology equipped model) [Phone] [Audio stream-...
Page 419 Bluetooth ® Wireless Technology (Continued) NOTICE (for Bluetooth Wireless ® • Viewing the screen for pro- • Bluetooth Wireless Technology ® Technology equipped model) longed periods of time is dan- Handsfree is a feature that gerous and may lead to acci- enables drivers to practice safe dents.
Page 420 Multimedia System (Continued) (Continued) Information • Bluetooth ® • If you do not want to automatically Wireless Technology - Using upon connecting connect your Bluetooth ® Wireless connection may become intermit- ® Bluetooth Wireless Technology phone, try the following. tently disconnected in some mobile Technology phone 1.
Page 421 (Continued) (Continued) (Continued) • Bluetooth ® Wireless Technology fea- • If a connected Bluetooth ® • Other devices cannot be paired Wireless tures supported within the vehicle are Bluetooth ® while Wireless Technology device becomes discon- as follows. Some features may not be Technologydevice is already con- nected for various reasons, such as supported...
Page 422 Multimedia System Pairing a Bluetooth ® Wireless 1) Device : Name of device as shown Pairing Key / Technology wireless technolo- on the Steering Remote when searching from your gy Device Controller Bluetooth Wireless Technology ® device When No Devices have been Paired 2) Passkey : Passkey used to pair the What is Bluetooth Wireless...
Page 423 Pairing through [PHONE] Information Information Setup • The waiting period during phone Press the Select pairing will last for one minute. The [Phone] Select [Pair Phone] pairing process will fail if the device Select TUNE knob is not paired within the given time. If the pairing process fails, you must start the process from the beginning.
Page 424 Multimedia System Connecting a Device From the paired phone list, select the Changing Priority device you want to connect and Press key Select press the button. [Phone] Select [Paired Phone List] What is Priority? It is possible to pair up to five Bluetooth ®...
Page 425 From the paired phone list, select Disconnecting a Device Deleting a Device the phone you want to change to the Press key Select highest priority, then press the [Phone] Select [Paired Phone List] Press key Select button from the Menu. The selected [Phone] Select [Paired Phone List] device will be changed to the high- est priority.
Page 426 Multimedia System 1) Dial Number : Displays the dial Information USING Bluetooth Wireless ® screen where numbers can be Technology • If you press the [Call History] but- dialed to make calls ton but there is no call history data, 2) Call History : Displays the call his- a prompt is displayed which asks tory list screen...
Page 427 Calling by Dialing a Number Answering Calls Information • When the incoming call pop-up is displayed, most Audio and SETUP Answering a Call Press the key Select [Dial mode features will not operate. Only Number] Answering a call with a Bluetooth ®...
Page 428 Multimedia System During a Handsfree Call Call History Phone book Press the Select [Call Press key Select History] [Phone book] 1) Caller : Displays the other party’s name if the incoming caller is A list of incoming, outgoing and The list of saved phone book entries saved within your phone book missed calls is displayed.
Page 429 (Continued) Information Information - When driving on rugged and Using the Voice Recognition • Up to 1,000 phone book entries can uneven roads be copied into car phone book. • When using the voice recognition - During severe rain (heavy rains, feature, only commands listed with- •...
Page 430: Voice Recognition
Multimedia System Skipping Prompt Messages • If voice recognition is in [Expert VOICE RECOGNITION Mode], then the system will only While prompt message is being stat- (if equipped) say a “Beep~” ed Shortly press the key on the • To change the Normal Mode/Expert steering remote controller (under 0.8 Mode setting, go to seconds)
Page 431 ENDING VOICE RECOGNITION While Voice Recognition is operating Press and hold the key on the steering remote controller (over 0.8 seconds) Information • While using voice command, press- ing a steering wheel remote control or a different key will end voice command.
Page 432 Multimedia System ❈ • End voice command. Illustration on using voice commands Shortly pressing the key (under 0.8 seconds): • Starting voice command. Please say a command Ding~ Shortly pressing the key (under 0.8 seconds): Please say a command Ding~ Phone book More Help Phone book.
Page 433 Voice Command List • Common Commands: These are commands that can be used in all situations. (However, some commands may not be supported in special circumstances.) Command Function Command Function • More Help Provides guidance on commands that can be When currently listening to the FM radio, used anywhere in the system.
Page 434 Multimedia System Command Function Command Function Media Moves to the most recently played media AUX (Auxiliary) Plays the connected external device. screen. Bluetooth Audio Plays music saved connected Play Track 1~30 If a music CD has been inserted, plays the Bluetooth ®...
Page 435 • FM/AM radio commands: Commands that can be • Audio CD commands: Commands that can be used used while listening to FM, AM radio. while listening to Audio CD. Command Function Command Function Preset 1~6 Plays the broadcast saved in Preset 1~6. Region off Disable Region feature Auto Store...
Page 436 Multimedia System • MP3 CD / USB commands: Commands that can be • iPod Commands: Commands that can be used while used while listening to music files saved in CD and playing iPod. USB. Command Function Command Function Random Randomly plays the files within the current All Random Randomly plays all saved songs.
Page 437 ® • My Music Commands: Commands that can be used • Bluetooth Wireless Technology Audio Commands: while playing My Music. Commands that can be used while playing Phone Music. Command Function Command Function Random Randomly plays all saved files. Play Plays the currently paused song.
Page 438: Setup (For Bluetooth Wireless Technology Equipped Model)
Multimedia System Pop-up Mode Display Settings SETUP Press key Select (for Bluetooth ® Wireless [Display] Select [Pop-up Mode] Adjusting the Brightness Technology equipped model) Press key Select [Display] Select [Brightness] Starting Mode Press the key to display the Setup screen. This feature is used to display the Pop-up Mode screen when entering radio and media modes.
Page 439 Scroll text MP3 Information Display Sound Settings Press key Select Press key Select Audio Settings [Display] Select [Scroll text] [Display] Select [Song Info] Press key Select [Sound] Select [Audio Setting] This feature is used to scroll text dis- This feature is used to change the played on the screen when it is too information displayed within USB long to be displayed at once.
Page 440 Multimedia System SDVC (Speed Dependent Volume Dialogue Touch Screen Beep Volume Control) Press key Select Press key Select Press key Select [Sound] Select [Volume Dialogue] [Sound] Select [Touch Screen [Sound] Select [Speed Dependent Beep] Vol.] This feature is used to turn the touch The volume level is controlled auto- screen beep on/off.
Page 441 Bluetooth Viewing Paired Phone List ® Wireless : Moves to the previous Technology Setting screen Press key Select [Phone] Select [Paired Phone List] 2) Connect/Disconnect Phone : Connect/disconnects currently Pairing a New Device selected phone Press key Select 3) Delete : Deletes the currently [Phone] Select [Pair Phone] selected phone 4) Change Priority : Sets currently...
Page 442 Multimedia System Downloading Phone books Auto Download (Phone books) Audio Streaming Press key Select Press key Select Press key Select [Phone] Select [Phonebooks Download] [Phone] Select [Auto Download] [Phone] Select [Audio Streaming] The Phone books is downloaded This feature is used to automatically When Streaming Audio is turned on, from the mobile phone and the download mobile contacts entries...
Page 443 System Setting Outgoing Volume Press key Select Memory Information [Phone] Select [Outgoing Volume] Press key Select [System] Select [Memory Information] Use the buttons to adjust the outgoing volume level. This feature displays information related to system memory. Turning Bluetooth System Off Press key Select Information...
Page 444: Rear View Camera
Multimedia System Voice Recognition Mode Setting Language REAR VIEW CAMERA (if equipped) Press key Select (if equipped) [System] Select [Language] Press key Select [System] Select [Voice Recognition • The system has been equipped System] with a rear view camera for user safety by allowing a wider rear range of vision.
Page 445 APPENDIX Name Description Name Description "Playlists" is filtering keyword for Monday Monday Playlists searching mode of playlists for iPod Tuesday Tuesday "Songs" is filtering keyword for Wednesday Wednesday Songs searching mode of playlists for iPod Thursday Thursday "Audiobooks" is filtering keyword for Audiobooks Friday Friday...
Page 446 Multimedia System Name Description Name Description Ejecting CD Ejecting CD Battery discharge Battery discharge Start the engine Start the engine Audio CD Audio CD Setup Setup Track Audio CD song order Display Setup display mode Reading Media Reading Media Not supported Not supported file format This function is used to select Mode Pop up...
Page 447 Name Description Name Description Treble is sound of high frequency. This function is used to select user Treble Language It can be adjusted sound by user language Fader is sound positon between Deutsch Deutsch Fader FRONT and REAR. It can be adjusted English(UK) English(UK) sound by user...
Page 448 Multimedia System Name Description Name Description Incoming Call Receivng phone After pairing phone, audio system Auto Download automatically download phone book Call Ended Call Ended When there is unwanted call, you After pairing phone, audio system can Call Rejected push the button on the steering support Bluetooth ®...
Page 449 Name Description Changed priority about the regis- Priority changed tered phones Overwrite previous phone book Overwrite previous information Phone does not support Phone does not support Phone book download Phone book download There are phone in the connection No connected Bluetooth device list But it was actually not connected BT...
Page 450: Driving Your Vehicle
Driving your vehicle Before driving............5-3 Drive mode integrated control system .....5-52 Before entering the vehicle ...........5-3 Cruise control ............5-54 Before starting..............5-3 Cruise Control operation ..........5-54 Ignition switch ............5-4 Blind spot detection system (BSD) ....5-60 Key ignition switch............5-5 BSD (Blind Spot Detection) / Engine Start/Stop button..........5-8 LCA (Lane Change Assist)..........5-61 Manual transaxle ..........5-17...
Page 451 HYUNDAI dealer.
Page 452: Before Driving
BEFORE DRIVING Before entering the vehicle Before starting WARNING • Be sure all windows, outside mir- • Make sure the hood, the trunk, and ror(s), and outside lights are clean the doors are securely closed and To reduce the risk of SERIOUS and unobstructed.
Page 453: Ignition Switch
Driving your vehicle IGNITION SWITCH (Continued) WARNING WARNING You are much more likely to NEVER drink or take drugs and To reduce the risk of SERIOUS have a serious accident if you drive. INJURY or DEATH, take the fol- drink or take drugs and drive. If lowing precautions: you are drinking or taking Drinking or taking drugs and...
Page 454: Key Ignition Switch
Key ignition switch (Continued) • Before leaving the driver’s seat, always make sure the shift lever is in 1st gear (for manual transaxle vehicle) or P (Park, for automatic transaxle vehicle) position, apply the parking brake, and turn igni- tion switch to the LOCK posi- tion.
Page 455 Driving your vehicle Key ignition switch positions Switch Action Notes Position To turn the ignition switch to the LOCK position, push the key in The steering wheel locks to protect the vehi- slightly at the ACC position and turn the key towards the LOCK cle from theft.
Page 456 Starting the engine Starting the gasoline engine Vehicle with automatic transaxle: Vehicle with manual transaxle: 1. Make sure the parking brake is WARNING applied. 1. Make sure the parking brake is applied. 2. Make sure the shift lever is in P •...
Page 457: Engine Start/Stop Button
Driving your vehicle Engine Start/Stop button NOTICE Information To prevent damage to the vehicle: • Do not wait for the engine to warm up while the vehicle remains station- • Do not hold the ignition key in ary. the START position for more than 10 seconds.
Page 458 WARNING WARNING To turn the engine off in an • NEVER press the Engine emergency: Start/Stop button while the vehicle is in motion except in Press and hold the Engine an emergency. This will result Start/Stop button for more than in the engine turning off and two seconds OR Rapidly press loss of power assist for the...
Page 459 Driving your vehicle Engine Stop/Start button positions - Vehicle with manual transaxle Button Position Action Notice • To turn off the engine, stop the vehicle and If the steering wheel is not locked properly then press the Engine Start/Stop button. when you open the driver's door, the warning chime will sound.
Page 460 - Vehicle with manual transaxle Button Position Action Notice • Press the Engine Start/Stop button while it Do not leave the Engine Start/Stop button in is in the ACC position without depressing the ON position when the engine is not run- the clutch pedal.
Page 461 Driving your vehicle Engine Stop/Start button positions - Vehicle with automatic transaxle Button Position Action Notice To turn off the engine, press the Engine If the steering wheel is not locked properly Start/Stop button with shift lever in P (Park). when you open the driver's door, the warning chime will sound.
Page 462 - Vehicle with automatic transaxle Button Position Action Notice Press the Engine Start/Stop button while it Do not leave the Engine Start/Stop button in is in the ACC position without depressing the ON position when the engine is not run- the brake pedal.
Page 463 Driving your vehicle Starting the engine Vehicle with manual transaxle: Information 1. Always carry the smart key with • The engine will start by pressing the WARNING you. Engine Start/Stop button, only when 2. Make sure the parking brake is the smart key is in the vehicle.
Page 464 NOTICE NOTICE Information To prevent damage to the vehicle: To prevent damage to the vehicle: • Do not wait for the engine to warm up while the vehicle remains station- • If the engine stalls while you are press Engine ary.
Page 465 Driving your vehicle OLF054009 Information If the smart key battery is weak or the smart key does not work correctly, you can start the engine by pressing the Engine Start/Stop button with the smart key in the direction of the pic- ture above.
Page 466: Manual Transaxle
MANUAL TRANSAXLE (IF EQUIPPED) Manual transaxle operation To shift to R (Reverse), make sure the vehicle has completely stopped, The manual transaxle has 6 forward and then move the shift lever to neu- gears. The transaxle is fully synchro- tral before moving into R (Reverse). nized in all forward gears so shifting to either a higher or a lower gear is easily accomplished.
Page 467 Driving your vehicle Using the clutch Downshifting NOTICE clutch pedal should Downshift when you must slow down To prevent unnecessary wear or depressed all the way to the floor in heavy traffic or drive up a steep hill damage to the clutch: before: to prevent engine load.
Page 468: Good Driving Practices
Good driving practices • Exercise extreme caution when NOTICE driving on a slippery surface. Be • Never take the vehicle out of gear To prevent damage to the engine, especially careful when braking, and coast down a hill. This is clutch and transaxle: accelerating or shifting gears.
Page 469 • ALWAYS wear your seatbelt. the travel lanes. In a collision, an unbelted occupant is significantly more • HYUNDAI recommends you likely to be seriously injured follow all posted speed limits. or killed than a properly belt- ed occupant. •...
Page 470: Automatic Transaxle
AUTOMATIC TRANSAXLE (IF EQUIPPED) ■ Left-hand drive ■ Right-hand drive Sports mode Sports mode Depress the brake pedal, press the shift button, and then move shift lever. Press the shift button, then move shift lever. Move shift lever. OLF054012/OLF054012R 5-21...
Page 471: Automatic Transaxle Operation
Driving your vehicle P (Park) Automatic transaxle operation (Continued) Always come to a complete stop The automatic transaxle has six for- • Do not use the engine brake before shifting into P (Park). ward speeds and one reverse speed. (shifting from a high gear to To shift from P (Park), you must The individual speeds are selected lower gear) rapidly on slip-...
Page 472 R (Reverse) N (Neutral) D (Drive) Use this position to drive the vehicle The wheels and transaxle are not This is the normal driving position. backward. engaged. The transaxle will automatically shift through a 6-gear sequence, provid- Use N (Neutral) if you need to restart ing the best fuel economy and NOTICE a stalled engine, or if it is necessary...
Page 473 Driving your vehicle Sports mode In Sports Mode, moving the shift (Continued) lever backwards and forwards will • If the driver presses the lever to allow you to select the desired range + (Up) or - (Down) position, the of gears for the current driving condi- transaxle may not make the request- tions.
Page 474 For your safety, the automatic tem be inspected by an authorized transaxle has a shift-lock system HYUNDAI dealer immediately. which prevents shifting the transaxle from P (Park) into R (Reverse) unless the brake pedal is depressed.
Page 475: Parking
Driving your vehicle Ignition key interlock system Parking Good driving practices (if equipped) Always come to a complete stop and • Never move the shift lever from P The ignition key cannot be removed continue to depress the brake pedal. (Park) or N (Neutral) to any other unless the shift lever is in the P Move the shift lever into the P (Park)
Page 476 In a collision, an unbelted driving on a slippery surface. Be occupant is significantly more • HYUNDAI recommends you especially careful when braking, likely to be seriously injured follow all posted speed limits. accelerating or shifting gears. On a...
Page 477: Braking System
Driving your vehicle BRAKING SYSTEM Power brakes (Continued) WARNING Your vehicle has power-assisted • Wet brakes may impair the brakes that adjust automatically Take the following precautions: vehicle’s ability to safely slow through normal usage. down; the vehicle may also •...
Page 478: Disc Brakes Wear Indicator
Disc brakes wear indicator Parking brake When your brake pads are worn and Applying the parking brake new pads are required, you will hear a high pitched warning sound from your front or rear brakes. You may hear this sound come and go or it may occur whenever you depress the brake pedal.
Page 479 (1), lower the parking brake (2). or does not release all the way, we touch the parking brake. If the recommend that the system be parking brake is released checked by an authorized HYUNDAI unintentionally, serious injury dealer. may occur. •...
Page 480 Check Parking If the Parking Brake Warning Light NOTICE Brake Warning Light remains on after the parking brake is • Do not apply the accelerator by placing the ignition released while engine is running, pedal while the parking brake is switch to the ON posi- there may be a malfunction in the engaged.
Page 481: Electric Parking Brake (Epb)
Driving your vehicle Releasing the parking brake Electric Parking Brake (EPB) Also, the EPB is applied automatical- ly if the [AUTO HOLD] switch is on (if equipped) when the engine is turned off. Applying the parking brake However, if you press the EPB switch within one second after the engine is turned off, the EPB will not be applied.
Page 482 To release EPB (Electric Parking • Automatic transaxle vehicle Information - Manual Brake) automatically: 1. Start the engine. transaxle • Shift lever in P (Park) 2. Fasten the driver's seat belt. A vehicle towing a trailer on a hill or With the engine running depress 3.
Page 483 • If the parking brake warning We recommend that you contact an light is still on even though the authorized HYUNDAI dealer by load- EPB has been released, we rec- ing the vehicle on a flatbed tow truck ommend that the system be and have the system checked.
Page 484 NOTICE Information WARNING • Do not apply the accelerator • A clicking sound may be heard • Whenever leaving the vehicle pedal while the parking brake is while operating or releasing the or parking, always come to a engaged. If you depress the EPB.
Page 485 Driving your vehicle ■ Type A ■ Type B ■ Type A ■ Type B EPB malfunction indicator (if equipped) OLF054128N/OLF044408N OLF054131N/OLF044411N AUTO HOLD deactivating. Parking brake automatically locked Press brake pedal If the EPB is applied while Auto Hold OLF054022 When the conversion from Auto Hold is activated, a warning will sound and...
Page 486 If there is a problem with the brake • If the EPB warning light is still ized HYUNDAI dealer. pedal while driving, emergency brak- on, we recommend that the sys- The EPB malfunction indicator may...
Page 487: Auto Hold
Brake) does not release If the EPB does not release normal- ly, we recommend that you contact OLF054018 an authorized HYUNDAI dealer by 1. With the driver's door, engine loading the vehicle on a flatbed tow hood and trunk closed, fasten the truck and have the system checked.
Page 488 To cancel : To release : If you press the accelerator pedal with the shift lever in R (Reverse), D (Drive) or sports mode, the Auto Hold will be released automatically and the vehicle will start to move. The indicator changes from green to white.
Page 489 - The driver's seat belt is unbuckled mend that you contact an author- and driver's door is opened ized HYUNDAI dealer. - The engine hood is opened while • While operating Auto Hold, you may the shift lever is in D (Drive) hear mechanical noise.
Page 490 Hold, a warning will sound and a warning will sound and a message We recommend that you contact message will appear. will appear. an authorized HYUNDAI dealer. NOTICE Depress the brake pedal when the above message appears for the Auto Hold and EPB may not acti- vate.
Page 491: Auto Hold
Driving your vehicle ■ Type A ■ Type B Anti-lock Brake System (ABS) WARNING An Anti-Lock Braking System (ABS) or an Electronic Stability Control (ESC) system will not prevent accidents improper or dangerous driving maneuvers. Even though vehi- cle control is improved during emergency braking, always...
Page 492 ABS will not prevent a skid that recommend that you contact an results from sudden changes in authorized HYUNDAI dealer as soon direction, such as trying to take a as possible. corner too fast or making a sudden lane change.
Page 493: Electronic Stability Control (Esc)
It does not ly. To reduce the risk of serious mean your ABS is malfunctioning. injury or death, we recommend Have the battery recharged before that you contact your HYUNDAI driving the vehicle. dealer as soon as possible. NOTICE OLF054448 ■...
Page 494 ESC operation ESC checks where you are steering When operating and where the vehicle is actually When the ESC is in opera- ESC ON condition going. ESC applies braking pressure tion, the ESC indicator light When the ignition switch is in the ON to any one of the vehicle’s brakes blinks: position, the ESC and the ESC OFF...
Page 495: Esc Off Button
Driving your vehicle • When moving out of the mud or ESC OFF condition • State 2 driving on a slippery road, the To cancel ESC operation : ■ Type A ■ Type B engine rpm (revolutions per minute) may not increase even if you press the accelerator pedal deeply.
Page 496 ESC system. When this warning tires, make sure they are the same light illuminates we recommend that size as your original tires for this vehicle. the vehicle be checked by an author- ized HYUNDAI dealer as soon as possible. 5-47...
Page 497: Vehicle Stability Management
Driving your vehicle VSM operation Vehicle Stability Management NOTICE (if equipped) VSM ON condition prevent damage Vehicle Stability Management (VSM) The VSM operates when: transaxle: helps ensure the vehicle stays stable • The Electronic Stability Control • Do not allow wheel(s) of one when accelerating or braking sud- (ESC) is on.
Page 498: Hill-Start Assist Control (Hac)
The HAC acti- vehicle be checked by an vates only for approximately 2 authorized HYUNDAI dealer as seconds. soon as possible. NOTICE Driving with varying tire or wheel sizes may cause the ESC system to malfunction.
Page 499: Emergency Stop Signal (Ess)
Driving your vehicle Emergency Stop Signal (ESS) Information Information (if equipped) • The HAC does not operate when the The Emergency Stop Signal (ESS) sys- The Emergency Stop Signal system shift lever is in P (Park) or N tem will not work if the hazard warn- alerts the driver behind by blinking (Neutral) ing flasher is already on.
Page 500: Good Braking Practices
Vehicles with the parking brake call an authorized HYUNDAI dealer not fully engaged are at risk for for assistance. moving inadvertently and caus- ing injury to yourself or others.
Page 501: Drive Mode Integrated Control System
Driving your vehicle DRIVE MODE INTEGRATED CONTROL SYSTEM (IF EQUIPPED) ECO mode (Active ECO) ■ Type A The drive mode may be selected according to the driver’s preference Active ECO helps improve or road condition. fuel efficiency by control- The system initializes to the NOR- ling certain engine and MAL mode (except for ECO mode) transaxle system operating...
Page 502 SPORT mode When Active ECO is activated: Limitation of Active ECO opera- tion: • The acceleration response may be SPORT mode focuses on SPORT slightly reduced as the accelerator If the following conditions occur while dynamic driving by auto- pedal is depressed moderately. Active ECO is operating, the system matically controlling the operation is limited even though...
Page 503: Cruise Control
Driving your vehicle CRUISE CONTROL (IF EQUIPPED) Cruise Control operation The Cruise Control system allows (Continued) you to drive at speeds above 40 ■ Type A • Do not use the Cruise Control km/h (25 mph) without depressing when it may not be safe to the accelerator pedal.
Page 504 To set Cruise Control speed 2. Accelerate to the desired speed, Information which must be more than 40 km/h ■ Type A • During normal cruise control opera- (25 mph). tion, when the SET switch is activat- ed or reactivated after applying the Information - Manual brakes, the cruise control will ener-...
Page 505 Driving your vehicle ■ Type A To increase Cruise Control Information speed The vehicle may slow down or speed ■ Type A up slightly while going uphill or down- hill. OLF054042/Q ■ Type B OLF054043/Q ■ Type B OLF054042L 3. Push the lever (1) down (SET-) , and release it.
Page 506 To decrease Cruise Control Release the lever when the • Push the lever (1) down (SET-) and desired speed is shown and the release it immediately. The cruising speed vehicle will accelerate to that speed will decrease 2.0 km/h (1.2 ■...
Page 507 Driving your vehicle To temporarily accelerate with Cruise Control will be canceled • Pressing the CANCEL / O switch located on the steering wheel. the Cruise Control ON when: • Pushing the CRUISE button. Both Depress the accelerator pedal. When ■...
Page 508 To resume preset Cruising To turn Cruise Control off Information speed ■ Type A Each of the above actions will cancel ■ Type A Cruise Control operation (the SET indicator light in the instrument clus- ter will go off), but only pressing the CRUISE button will turn the system off.
Page 509: Blind Spot Detection System (Bsd)
Driving your vehicle BLIND SPOT DETECTION SYSTEM (BSD) (IF EQUIPPED) (1) BSD (Blind Spot Detection) (Continued) The warning range depends on • The Blind Spot Detection your vehicle speed. However, if System (BSD) is a supplemen- your vehicle is much faster than Blind spot area tal system to assist you.
Page 510: Bsd (Blind Spot Detection)
Warning type BSD (Blind Spot Detection) / To operate: LCA (Lane Change Assist) Press the BSD switch with the The system will activate when: Ignition switch in the ON position. Operating conditions 1.The system is on. The indicator illuminates on the 2.Vehicle speed is above about 30 ■...
Page 511 Driving your vehicle ■ Left side ■ Left side ■ Right side ■ Right side OLF054051N OLF054052N OLF054053N Second stage alert First stage alert If a vehicle is detected within the The second stage alarm will activate when: boundary of the system, a warning 1.
Page 512 10 minutes, the sys- tem will work normally. If the system does not work normally even though the foreign substance is removed, we recommend that you take your vehicle to an authorized HYUNDAI dealer and have the sys- tem checked. 5-63...
Page 513: Rcta (Rear Cross Traffic Alert)
Driving your vehicle Warning type RCTA (Rear Cross Traffic Alert) Information Operating conditions ■ Left • If the detected vehicle is out of the • Type A • Type B To operate: sensing range of your vehicle, move the vehicle away from the detected Go to the User Settings Mode object slowly;...
Page 514 NOTICE (Continued) WARNING • The Blind Spot Detection • The system may not work prop- • The warning light on the out- System (BSD) and Rear Cross erly if the bumper has been side rearview mirror will illu- Traffic Alert (RCTA) are not a replaced or if repair work has minate whenever a vehicle is substitute for proper and safe...
Page 515 Driving your vehicle Non-operating condition DRIVER'S ATTENTION (Continued) - Metal substances are near the Outside rearview mirror may not The driver must be cautious in the vehicles such as in a construc- alert the driver when: below situations for the system tion area.
Page 516 (Continued) - When your vehicle is backing up, if the detected vehicle also backs - Small objects like shopping carts and strollers. - If there vehicle with decreased ride height (lowered). - When the vehicle is close to another vehicle. - When the vehicle in the next lane moves two lanes away from you OR when the vehicle two lanes...
Page 517: Special Driving Conditions
Driving your vehicle SPECIAL DRIVING CONDITIONS Hazardous driving conditions Rocking the vehicle WARNING When hazardous driving conditions If it is necessary to rock the vehicle are encountered such as water, to free it from snow, sand, or mud, If the tires spin at high speed snow, ice, mud or sand: first turn the steering wheel right and the tires can explode, and you...
Page 518: Smooth Cornering
Smooth cornering Driving at night NOTICE Avoid braking or gear changing in Night driving presents more hazards If you are still stuck after rocking corners, especially when roads are than driving in the daylight. Here are the vehicle a few times, have the wet.
Page 519: Driving In The Rain
Driving your vehicle Driving in the rain • If you believe your brakes may be Driving in flooded areas wet, apply them lightly while driv- Rain and wet roads can make driving Avoid driving through flooded areas ing until normal braking operation dangerous.
Page 520: Winter Driving
WINTER DRIVING Snow tires Snow or icy conditions If you mount snow tires on your vehi- cle, make sure to use radial tires of You need to keep sufficient distance the same size and load range as the between your vehicle and the vehicle WARNING original tires.
Page 521 If tire chains must be used, use gen- uine HYUNDAI parts and install the tire chain after reviewing the instruc- tions provided with the tire chains. Damage to your vehicle caused by improper tire chain use is not cov- ered by your vehicle manufacturer’s...
Page 522: Winter Precautions
Chain Installation Winter Precautions NOTICE When installing tire chains, follow the Use high quality ethylene glycol When using tire chains: manufacturer's instructions coolant • Wrong size chains or improperly mount them as tightly possible. Drive Your vehicle is delivered with high installed chains can damage slowly (less than 30 km/h (20 mph)) quality ethylene glycol coolant in the...
Page 523 Window wash- HYUNDAI dealer. damaged in any way. er anti-freeze is available from an authorized HYUNDAI dealer and most auto parts outlets. Do not use Change to "winter weight" oil if To keep locks from freezing...
Page 524 Don't let your parking brake freeze Don't let ice and snow accumulate Don't place foreign objects or underneath materials in the engine compart- Under some conditions your parking ment brake can freeze in the engaged Under some conditions, snow and position.
Page 525: Trailer Towing (For Europe)
Ask an authorized 10% or 100 kg (220.4 lbs), whichev- are pulling a trailer. For exam- HYUNDAI dealer for further details er value is lower. In this case, do not before towing. ple, if the trailer is too heavy, exceed 100 km/h (62.1 mph) for...
Page 526: If You Decide To Pull A Trailer
• When towing a trailer, be sure to What is the maximum safe weight of The tongue load is an important consult an authorized HYUNDAI a trailer? It should never weigh more weight to measure because it affects dealer for further information on...
Page 527 Driving your vehicle Reference weight and distance when trailer towing a trailer WARNING Engine Gasoline Engine Take the following precautions: • Never load a trailer with more 2.0L MPI 2.4L MPI 2.4L GDI weight in the rear than in the Item front.
Page 528: Trailer Towing Equipment
• Install a trailer after removing the under cover on the left side of the • A HYUNDAI trailer hitch accessory vehicle. After using the trailer, rein- is available at an authorized stall the under cover to its original HYUNDAI dealer.
Page 529: Driving With A Trailer
Driving your vehicle Trailer brakes Distance Driving with a trailer If your trailer is equipped with a brak- Stay at least twice as far behind the Towing a trailer requires a certain ing system, make sure it conforms vehicle ahead as you would when amount of experience.
Page 530 Consult authorized Making turns When towing a trailer, the green HYUNDAI dealer for assistance. When you’re turning with a trailer, arrows on your instrument panel will make wider turns than normal. Do flash for turns even if the bulbs on this so your trailer won’t strike soft...
Page 531 Driving your vehicle Driving on hills Parking on hills NOTICE Reduce speed and shift to a lower Generally, if you have a trailer prevent engine and/or gear before you start down a long or attached to your vehicle, you should transaxle overheating: steep downgrade.
Page 532: Maintenance When Towing A Trailer
Ready to leave after parking on 6. Reapply the brakes and parking Maintenance when towing a brakes. a hill trailer 7. Move the shift lever to P (Park, for 1. With the shift lever to P (Park, for Your vehicle will need service more automatic transaxle vehicle) or 1st automatic transaxle vehicle) or often when you regularly pull a trail-...
Page 533 Driving your vehicle NOTICE To prevent vehicle damage: • Due to higher load during trailer usage, overheating might occur on hot days or during uphill driv- ing. If the coolant gauge indi- cates over-heating, switch off the air conditioner and stop the vehicle in a safe area to cool down the engine.
Page 534: Vehicle Weight
VEHICLE WEIGHT Two labels on your driver’s door sill GAW (Gross Axle Weight) Overloading show how much weight your vehicle This is the total weight placed on was designed to carry: the Tire and WARNING each axle (front and rear) - including Loading Information Label and the vehicle curb weight and all payload.
Page 535: What To Do In An Emergency
What to do in an emergency Hazard warning flasher ........6-2 Emergency commodity ........6-23 Fire extinguisher .............6-23 In case of an emergency while driving ....6-2 First aid kit ..............6-23 If the engine stalls while driving ........6-2 Triangle reflector ............6-23 If the engine stalls at a crossroad or crossing ..6-3 Tire pressure gauge ............6-23 If you have a flat tire while driving......6-3 If the engine will not start ........6-4...
Page 536: Hazard Warning Flasher
• The turn signals do not work when mend that you contact an author- ■ Type B the hazard flasher is on. ized HYUNDAI dealer. OLF064002 The hazard warning flasher serves as a warning to other drivers to exercise extreme caution when approaching, overtaking, or passing your vehicle.
Page 537: If The Engine Stalls At A Crossroad Or Crossing
If the engine stalls at a cross- If you have a flat tire while • When the vehicle is stopped, press the hazard warning flasher button, road or crossing driving move the shift lever into P (Park, If the engine stalls at a crossroad or If a tire goes flat while you are driv- for automatic transaxle vehicle) or crossing, if safe to do so, move the...
Page 538: If The Engine Will Not Start
N (Neutral) or P (Park). ized HYUNDAI dealer for assistance. service technician or towing service • Check the battery connections to do it for you.
Page 539 (Continued) (Continued) WARNING • Batteries contain sulfu- NEVER attempt to recharge To prevent SERIOUS INJURY or ric acid which is highly the battery when the vehicle’s DEATH to you or bystanders, corrosive. Do not allow battery cables are connected always follow these precautions acid to contact your to the battery.
Page 540 What to do in an emergency Jump starting procedure NOTICE Information 1. Position the vehicles close enough To prevent damage to your vehi- An inappropriately disposed that the jumper cables will reach, cle: battery can be harmful to the but do not allow the vehicles to environment human •...
Page 541 5. Connect the other end of the apparent, have your vehicle checked jumper cable to the red, positive by an authorized HYUNDAI dealer. (+) battery/jumper terminal of the assisting vehicle (2). 6. Connect the second jumper cable...
Page 542: If The Engine Overheats
HYUNDAI dealer for cap, using a thick towel, and sure the engine cooling fan is assistance.
Page 543: If You Have A Flat Tire
If overheating happens again, may cause cracks in the we recommend that you call an engine. To prevent damage, authorized HYUNDAI dealer for add engine coolant slowly in assistance. small quantities.
Page 544: Jack And Tools
What to do in an emergency Jack and tools OLF064031N OLF064005 Turn the winged hold down bolt If it is hard to loosen the tire hold- OLF064004N counterclockwise to remove the down wing bolt by hand, you can (1) Jack handle spare tire.
Page 545: Changing Tires
Changing tires Follow these steps to change your (Continued) vehicle’s tire: • ALWAYS place the jack on the WARNING 1. Park on a level, firm surface. designated jacking positions 2. Move the shift lever into P (Park, on the vehicle and NEVER on A vehicle can slip or roll off of a for automatic transaxle vehicle) or the bumpers or any other part...
Page 546 What to do in an emergency ■ ■ Type A Type B OLF064007 OLF064009 OLF064008 5. Block both the front and rear of the 6. • Type A • Type B tire diagonally opposite of the tire Insert the wheel cap remover into the Insert the screwdriver into the groove you are changing.
Page 547 ■ ■ Front Rear OLF064010 OLF064011 OLF064012 7. Loosen the wheel lug nuts coun- 8. Place the jack at the designated 9. Insert the jack handle into the jack terclockwise one turn each in the jacking position under the frame and turn it clockwise, raising the order shown above, but do not closest to the tire you are chang-...
Page 548 NOTICE that an authorized HYUNDAI dealer tighten the lug nuts to their Check the tire pressure as soon proper torque as soon as possi- as possible after installing a spare ble.
Page 549 We load carrying capacity shown recommend that you consult an on the sidewall of the com- authorized HYUNDAI dealer for pact spare tire. assistance. • Do not use the compact spare tire continuously.
Page 550 What to do in an emergency When driving with the compact spare NOTICE CAUTION tire mounted to your vehicle: When the original tire and wheel • Check the tire pressure after To prevent damaging the com- are repaired and reinstalled on the installing the compact spare tire.
Page 551: Jack Label
Jack label 1. Model Name ■ Example 2. Maximum allowable load • Type A 3. When using the jack, set your parking brake. 4. When using the jack, stop the engine. 5. Do not get under a vehicle that is OHYK064001 supported by a jack.
Page 552: Ec Declaration Of Conformity For Jack
What to do in an emergency EC Declaration of conformity for Jack JACKDOC14S 6-18...
Page 553: Towing
Dolly OLF064021N OLF064022 If emergency towing is necessary, we recommend having it done by an CAUTION authorized HYUNDAI dealer or a commercial tow-truck service. • Do not tow the vehicle with the Proper lifting and towing procedures...
Page 554: Removable Towing Hook
What to do in an emergency When towing your vehicle in an Removable towing hook 1. Open the trunk, and remove the emergency without wheel dollies: towing hook from the tool case. ■ Front 1. Place the ignition switch in the 2.
Page 555: Emergency Towing
• Fasten the towing cable or chain securely to the hook. mend you have it done by an author- ized HYUNDAI dealer or a commer- • Do not jerk the hook. Apply steady cial tow truck service. and even force.
Page 556 What to do in an emergency CAUTION To avoid damage to your vehicle and vehicle components when towing: • Always pull straight ahead when using the towing hooks. Do not pull from the side or at a vertical angle. • Do not use the towing hooks to pull a vehicle out of mud, ODH063025...
Page 557: Emergency Commodity
EMERGENCY COMMODITY (IF EQUIPPED) Your vehicle is equipped with emer- First aid kit To check the tire pressure, take the gency commodities to help you following steps: Supplies for use in giving first aid respond to emergency situation. 1. Unscrew the inflation valve cap such as scissors, bandage and that is located on the rim of the adhesive tape, etc.
Page 558: Maintenance
Maintenance Engine compartment ..........7-3 Parking brake ............7-36 Checking the parking brake .........7-36 Maintenance services ...........7-6 Air cleaner ............7-37 Owner's responsibility............7-6 Owner maintenance precautions ........7-6 Filter replacement............7-37 Owner maintenance..........7-7 Climate control air filter ........7-39 Owner maintenance schedule........7-8 Filter inspection...............7-39 Filter replacement............7-39 Scheduled maintenance services ......7-10 Wiper blades ............7-40 Normal maintenance schedule (for Europe) ....7-11...
Page 559 Tire sidewall labeling............7-52 Low aspect ratio tire ............7-57 Fuses..............7-58 Fuse/Relay panel description ........7-64 Light bulbs.............7-72 Headlamp, position lamp, turn signal lamp and side marker light bulb replacement......7-73 Side repeater lamp replacement .........7-75 Headlamp and front fog lamp aiming (for Europe) ...7-76 Rear combination light bulb replacement ....7-81 High mounted stop lamp replacement.......7-85 License plate light bulb replacement ......7-85...
Page 560: Engine Compartment
ENGINE COMPARTMENT ■ Gasoline Engine (Nu 2.0L MPI) 1. Engine coolant reservoir 2. Radiator cap 3. Brake/clutch fluid reservoir 4. Air cleaner 5. Engine oil dipstick 6. Engine oil filler cap 7. Windshield washer fluid reservoir 8. Fuse box 9. Battery The actual engine room in the vehicle may differ from the illustration.
Page 561 Maintenance ■ Gasoline Engine (Theta II 2.0L T-GDI) 1. Engine coolant reservoir 2. Radiator cap 3. Brake/clutch fluid reservoir 4. Air cleaner 5. Engine oil dipstick 6. Engine oil filler cap 7. Windshield washer fluid reservoir 8. Fuse box 9. Battery The actual engine room in the vehicle may differ from the illustration.
Page 562 ■ Gasoline Engine (Theta II 2.4L MPI) 1. Engine coolant reservoir 2. Radiator cap 3. Brake/clutch fluid reservoir 4. Air cleaner 5. Engine oil dipstick ■ Gasoline Engine (Theta II 2.4L GDI) 6. Engine oil filler cap 7. Windshield washer fluid reservoir 8.
Page 563: Maintenance Services
HYUNDAI cient servicing may result in opera- standards and receives technical dealer. support from HYUNDAI in order to tional problems with your vehicle that provide you with a high level of serv- could lead to vehicle damage, an ice satisfaction.
Page 564: Owner Maintenance
If you must run the engine formed by the owner or an authorized Performing maintenance work during maintenance, do so HYUNDAI dealer at the frequencies on a vehicle can be dangerous. out doors or in an area with indicated to help ensure safe, If you lack sufficient knowledge plenty of ventilation.
Page 565: Owner Maintenance Schedule
Maintenance While operating your vehicle: At least monthly: Owner maintenance schedule • Note any changes in the sound of • Check coolant level in the engine When you stop for fuel: the exhaust or any smell of exhaust coolant reservoir. •...
Page 566 At least twice a year: At least once a year: (i.e., every Spring and Fall) • Clean body and door drain holes. • Check radiator, heater and air condi- • Lubricate door hinges and hood tioning hoses for leaks or damage. hinges.
Page 567: Scheduled Maintenance Services
Maintenance SCHEDULED MAINTENANCE SERVICES Follow Normal Maintenance Schedule if the vehicle is usually operated where none of the following conditions apply. If any of the following conditions apply, you must follow the Maintenance Under Severe Usage Conditions. • Repeated short distance driving. •...
Page 568: Normal Maintenance Schedule (For Europe)
NORMAL MAINTENANCE SCHEDULE (FOR EUROPE) MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Months Miles×1,000 MAINTENANCE Km×1,000 ITEM At first, inspect at 90,000 km (60,000 miles) or 72 months Drive belts * after that, inspect every 30,000 km (20,000 miles) or 24 months 2.0 MPI 2.4 MPI Engine oil and...
Page 569 : Inspect for excessive valve noise and/or engine vibration and adjust if necessary. We recommend that the system be checked by an authorized HYUNDAI dealer. : The fuel filter is considered to be maintenance free but periodic inspection is recommended for this maintenance schedule depends on fuel quality.
Page 570 NORMAL MAINTENANCE SCHEDULE (CONT.) (FOR EUROPE) MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Months Miles×1,000 MAINTENANCE Km×1,000 ITEM At first, replace at 210,000 km (120,000 miles) or 10 years: Engine coolant * after that, replace every 30,000 km (20,000 miles) or 24 months * Battery condition Brake lines, hoses and connections Brake pedal, Clutch pedal (if equipped)
Page 571 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) (FOR EUROPE) MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Months Miles×1,000 MAINTENANCE ITEM Km×1,000 Steering gear rack, linkage and boots Driveshaft and boots Tire (pressure & tread wear) Front suspension ball joints Bolt and nuts on chassis and body Air conditioner refrigerant (if equipped) Air conditioner compressor (if equipped)
Page 572: Maintenance Under Severe Usage And Low Mileage Conditions (For Europe)
MAINTENANCE UNDER SEVERE USAGE AND LOW MILEAGE CONDITIONS (FOR EUROPE) The following items must be serviced more frequently on cars mainly used under severe and low mileage driving con- ditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance...
Page 573 Maintenance Maintenance Maintenance item Maintenance intervals Driving condition operation Inspect more frequently Driveshaft and boots C, D, E, F, G, H, I depending on the condition Manual transaxle fluid (if equipped) Every 120,000 km (80,000 miles) C, F, G, I, K Automatic transaxle fluid (if equipped) Every 90,000 km (60,000 miles) A, C, F, G, I...
Page 574: Normal Maintenance Schedule (Except Europe)
: If good quality gasolines meet Europe Fuel standards (EN228) or equivalents including fuel additives is not available, one bottle of additive is recommended. Additives are available from your authorized HYUNDAI dealer along with information on how to use them.
Page 575 : Inspect for excessive valve noise and/or engine vibration and adjust if necessary. We recommend that the system be checked by an authorized HYUNDAI dealer. : The fuel filter is considered to be maintenance free but periodic inspection is recommended for this maintenance schedule depends on fuel quality.
Page 576 NORMAL MAINTENANCE SCHEDULE (CONT.) (EXCEPT EUROPE) MAINTENANCE Number of months or driving distance, whichever comes first INTERVALS Months Miles×1,000 MAINTENANCE Km×1,000 ITEM Inspect “Coolant level adjustment and leak” every day Cooling system At first, inspect 60,000 km (40,000 miles) or 48 months after that, inspect every 30,000 km (20,000 miles) or 24 months At first replace at 200,000 km (120,000 miles) or 10 years: Engine coolant *...
Page 577 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) (EXCEPT EUROPE) Number of months or driving distance, whichever comes first MAINTENANCE INTERVALS Months Miles×1,000 MAINTENANCE ITEM Km×1,000 Steering gear rack, linkage and boots Driveshaft and boots Tire (pressure & tread wear) Front suspension ball joints Bolt and nuts on chassis and body Air conditioner refrigerant (if equipped) Air conditioner compressor (if equipped)
Page 578: Maintenance Under Severe Usage Conditions
MAINTENANCE UNDER SEVERE USAGE CONDITIONS (EXCEPT EUROPE) The following items must be serviced more frequently on cars mainly used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and if necessary, adjust, correct, clean or replace Maintenance Maintenance item Maintenance intervals...
Page 579 Maintenance Maintenance Maintenance item Maintenance intervals Driving condition operation Inspect more frequently Disc brakes and pads, calipers and rotors C, D, E, G, H depending on the condition Inspect more frequently Parking brake C, D, G, H depending on the condition Inspect more frequently Driveshaft and boots C, D, E, F, G, H, I...
Page 580: Explanation Of Scheduled Maintenance Items
If an excessive amount of lines, fuel hoses and connections be are required. foreign matter accumulates in the replaced by an authorized HYUNDAI fuel tank, the filter may require dealer. Drive belts replacement more frequently.
Page 581 Inspect the surface of hoses for evi- dence of heat and/or mechanical HYUNDAI dealer. sary. We recommend that the system be serviced by an authorized damage. Hard and brittle rubber, HYUNDAI dealer.
Page 582 We recommend that the automatic ed or damaged parts immediately. function and failure. transaxle fluid changed by an author- Use only specified automatic ized HYUNDAI dealer according to transaxle fluid. (Refer Brake fluid the maintenance schedule.
Page 583 For more information on checking Check the linkage for bends or dam- the pads or lining wear limit, refer to age. Check the dust boots and ball the HYUNDAI web site. joints for deterioration, cracks, or damage. Replace any damaged (http://brakemanual.hmc.co.kr) parts.
Page 584: Engine Oil
ENGINE OIL ■ Nu 2.0 MPI ■ Theta 2.4 MPI Checking the engine oil level 1. Be sure the vehicle is on level ground. 2. Start the engine and allow it to reach normal operating tempera- ture. 3. Turn the engine off and wait for a few minutes (about 5 minutes) for the oil to return to the oil pan.
Page 585 Maintenance ■ Nu 2.0 MPI ■ Theta 2.4 MPI 5. Pull the dipstick out again and check the level. The level should be between F and L. CAUTION • Do not overfill the engine oil. It may damage the engine. •...
Page 586: Checking The Engine Oil And Filter
Always protect your skin by washing your hands thoroughly with soap and warm water as soon as pos- sible after handling used oil. We recommend that the engine oil and filter be replaced by an author- ized HYUNDAI dealer. 7-29...
Page 587: Engine Coolant
Maintenance ENGINE COOLANT The high-pressure cooling system Checking the coolant level (Continued) has a reservoir filled with year-round • Turn the engine off and wait antifreeze coolant. The reservoir is until it cools down. Use filled at the factory. extreme care when removing Check the antifreeze protection and the radiator cap.
Page 588 If the coolant level is low, add enough distilled (deionized) or soft water. Bring the level to F (MAX), but do not overfill. If frequent additions are required, we recommend that the system be inspected by an authorized HYUNDAI dealer. 7-31...
Page 589: Changing The Coolant
Maintenance For mixture percentage, refer to the Changing the coolant WARNING following table. We recommend that the coolant be replaced by an authorized HYUNDAI Coolant Mixture Percentage Ambient dealer. (volume) Temperature • Do not use radiator coolant or Antifreeze Water...
Page 590: Brake/Clutch Fluid
Checking the brake/clutch If the fluid level is excessively low, we NOTICE recommend that the system be fluid level Before removing the brake/clutch checked by an authorized HYUNDAI filler cap, read the warning on the dealer. cap. Information WARNING Use only the specified brake/clutch fluid.
Page 591 Maintenance WARNING CAUTION When changing and adding Do not allow brake/clutch fluid brake/clutch fluid, handle it to contact the vehicle's body carefully. Do not let it come in paint, as paint damage will contact with your eyes. If brake/ result. Brake/clutch fluid, which clutch fluid should come in con- has been exposed to open air tact with your eyes, immediately...
Page 592: Washer Fluid
WASHER FLUID Checking the washer fluid CAUTION level Coolant • Do not use radiator coolant or antifreeze in the washer fluid reservoir. • Radiator coolant can severely obscure visibility when sprayed on the windshield and may cause loss of vehicle control or damage to paint and body trim.
Page 593: Parking Brake
HYUNDAI dealer. serviced by an authorized HYUNDAI dealer. Stroke : 5~6 “clicks’’ at a force of 20 kg (44 lbs, 196 N).
Page 594: Air Cleaner
AIR CLEANER Filter replacement OLF074011 OLF074012 1. Remove the air cleaner filter cover. 3. Pull down the lever to the UNLOCK OLF074010 position. 2. Wipe the inside of the air cleaner. The air cleaner filter can be cleaned for inspection using compressed air. Do not attempt to wash or to rinse it, as water will damage the filter.
Page 595 7. Check if the cover is firmly installed. • Use HYUNDAI genuine parts, use of non-genuine parts could damage the air flow sensor. 7-38...
Page 596: Climate Control Air Filter
CLIMATE CONTROL AIR FILTER Filter inspection Filter replacement If the vehicle is operated in the severely air-polluted cities or on dusty rough roads for a long period, it should be inspected more fre- quently and replaced earlier. When you, the owner, replace the climate control air filter, replace it performing the following procedure, and be care- ful to avoid damaging other compo-...
Page 597: Wiper Blades
Maintenance WIPER BLADES Blade inspection Contamination of either the wind- Blade replacement shield or the wiper blades with for- When the wipers no longer clean eign matter can reduce the effective- adequately, the blades may be worn ness of the windshield wipers. or cracked, and require replacement.
Page 598 OLF074017 OLF074018 OLF074019 1. Raise the wiper arm. 2. Lift up the wiper blade clip. Then 3. Install the new blade assembly in pull down the blade assembly and the reverse order of removal. remove it. 4. Return the wiper arm on the wind- shield.
Page 599: Battery
Keep batteries out of the tions clean, tight, and coated with cell caps. We recommend that you reach of children because petroleum jelly or terminal grease. contact an authorized HYUNDAI batteries contain highly • Rinse any spilled electrolyte from dealer. corrosive...
Page 600 (Continued) (Continued) CAUTION • If any electrolyte gets When lifting a plastic-cased If you connect unauthorized into your eyes, flush battery, excessive pressure electronic devices to the bat- your eyes with clean on the case may cause battery tery, the battery may be dis- water for at least 15 min- acid to leak, resulting in per- charged.
Page 601: Battery Capacity Label
❈ The actual battery label in the vehicle cells begin gassing (boiling) may differ from the illustration. violently or if the temperature of the electrolyte of any cell 1. CMF60L-BCI : The HYUNDAI exceeds 49°C (120°F). model name of battery • Wear eye protection when 2.
Page 602: Reset Items
Reset items (Continued) Items should be reset after the bat- • Disconnect the battery charg- tery has been discharged or the bat- er in the following order. tery has been disconnected. 1. Turn off the battery charger • Auto up/down window main switch.
Page 603: Tires And Wheels
Maintenance TIRES AND WHEELS Tire care WARNING For proper maintenance, safety, and maximum fuel economy, you must Tire underinflation always maintain recommended tire Severe underinflation (70 kPa inflation pressures and stay within (10 psi) or more) can lead to the load limits and weight distribution severe heat build-up, causing recommended for your vehicle.
Page 604 • Be sure to reinstall the tire since startup.) tem be checked by an author- inflation valve caps. Without ized HYUNDAI dealer. • Check the pressure of your the valve cap, dirt or moisture spare tire each time you check •...
Page 605: Checking Tire Inflation Pressure
1.6 km (1 mile). worn, show uneven wear, or are damaged. • Remember to check the pres- sure your spare tire. HYUNDAI recommends that you check the spare every time you check the pressure of the other tires on your vehi- cle. 7-48...
Page 606: Tire Rotation
■ without a spare tire Tire rotation Information To equalize tread wear, it is recom- The outside and inside of the mended that the tires be rotated unsymmetrical tire is distinguish- every 12,000 km (7,500 miles) or able. When installing an unsym- sooner if irregular wear develops.
Page 607: Wheel Alignment And Tire Balance
If the problem is not wear or your vehicle pulling one way solved, we recommend that you or the other, the alignment may need contact an authorized HYUNDAI to be reset. dealer. If you notice your vehicle vibrating OLMB073027...
Page 608 Compact spare tire replacement (Continued) WARNING (if equipped) • The use of any other tire size A compact spare tire has a shorter • Driving on worn-out tires is or type may seriously affect tread life than a regular size tire. very hazardous will...
Page 609: Wheel Replacement
Maintenance Wheel replacement Tire traction Tire sidewall labeling When replacing the metal wheels for Tire traction can be reduced if you any reason, make sure the new drive on worn tires, tires that are wheels are equivalent to the original improperly inflated or on slippery factory units in diameter, rim width road surfaces.
Page 610 2. Tire size designation 205/65R16 95H Wheel size designation A tire’s sidewall is marked with a tire 205 - Tire width in millimeters. Wheels are also marked with impor- size designation. You will need this tant information that you need if you 65 - Aspect ratio.
Page 611 Maintenance 3. Checking tire life Tire speed ratings WARNING (TIN : Tire Identification The chart below lists many of the dif- Number) ferent speed ratings currently being Tire age used for passenger car tires. The Any tires that are over 6 years old, Tires degrade over time, even speed rating is part of the tire size based on the manufacturing date,...
Page 612 4. Tire ply composition and 6. Maximum load rating Tread wear material This number indicates the maximum The tread wear grade is a compara- load in kilograms and pounds that tive rating based on the wear rate of The number of layers or plies of rub- the tire when tested under controlled can be carried by the tire.
Page 613 Maintenance Traction - AA, A, B & C Temperature -A, B & C WARNING The traction grades, from highest to The temperature grades are A (the lowest, are AA, A, B and C. Those highest), B and C representing the Tire temperature grades represent the tires ability to tire’s resistance to the generation of...
Page 614: Low Aspect Ratio Tire
- If the tire is impacted, we rec- ommend that you inspect the tire condition or contact an authorized HYUNDAI dealer. - To prevent damage to the tire, inspect the tire condition and pressure every 3,000km.
Page 615: Fuses
Always replace a blown fuse with one of the same rating. Normal Blown If the replacement fuse blows, this indi- cates an electrical problem. Avoid using the system involved and immedi- ately consult an authorized HYUNDAI dealer. Blown Normal OLF074075 7-58...
Page 616 If fuses, relays and terminals fastened with bolts or nuts are blown, we recommend that you consult an authorized HYUNDAI dealer. • Do not input any other objects except fuses or relays into fuse/relay terminals such as a driver or wiring.
Page 617 4. Check the removed fuse; replace it if it is blown. 5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, we recommend that you consult an authorized HYUNDAI dealer. 7-60...
Page 618 Fuse switch Information CAUTION • Always place the fuse switch in the ON position while driv- ing the vehicle. • Place the fuse switch in the OFF position when the vehicle is parked more than a month to prevent battery discharge. •...
Page 619: Fuse Box
5. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If it fits loosely, we rec- ommend that you consult an authorized HYUNDAI dealer. CAUTION After checking the fuse box in OLF074025...
Page 620 If the multi fuse is blown, we rec- though the engine compartment ommend that you consult an panel fuse and inner fuse are not authorized HYUNDAI dealer. blown, if the electrical system is not operated, the main fuse may be blown. The main fuse is connected with other parts and system.
Page 621: Fuse/Relay Panel Description
Maintenance Fuse/Relay panel description Driver’s side fuse panel OLF074027 Inside the fuse/relay box covers, you can find the fuse/relay label describ- ing fuse/relay name and capacity. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the OLF074058L time of printing.
Page 622 Driver’s side fuse panel Fuse Name Symbol Fuse rating Circuit Protected SAFETY Driver Safety Power Window Module WINDOW LH P/SEAT PASS Passenger Seat Manual Switch P/WDW LH Power Window Main Switch, Rear Power Window Module LH Power Window Main Switch, Rear Power Window Module RH Passenger Door Module, P/WDW RH Passenger Power Window Switch DR LOCK...
Page 623 Maintenance Driver’s side fuse panel Fuse Name Symbol Fuse rating Circuit Protected Glove Box Lamp, Ignition Key Ill. & Door Warning Switch, Front Vanity Lamp Switch LH/RH, INTERIOR LAMP Overhead Console Lamp, Room Lamp, Rear Personal Lamp LH/RH, Trunk Room Lamp, Driver/Passenger Smart Key Outside Handle Driver/Passenger Door Lamp MEMORY 2 7.5A...
Page 624 Driver’s side fuse panel Fuse Name Symbol Fuse rating Circuit Protected MDPS 7.5A MDPS Unit MODULE 3 BCM, Sport Mode Switch, Stop Lamp Switch STOP LAMP Stop Signal Electronic Module MODULE 1 7.5A Key Solenoid, Driver/Passenger Door Module MODULE SUN ROOF 1 Panorama Sunroof Motor A/CON 7.5A...
Page 625 Maintenance Driver’s side fuse panel Fuse Name Symbol Fuse rating Circuit Protected Front Console Switch, Blind Spot Detection Radar, Fuel Filler Door & Trunk Lid Switch, MODULE Front Parking Assist Sensor, Rear Parking Assist Sensor, PCB Block (Fuse - F1/F2/F7/F8) Rear Fog Lamp ICM Relay Box (Rear Fog Lamp Relay) WASHER...
Page 626 Engine compartment fuse panel OLF074028 Inside the fuse/relay box covers, you can find the fuse/relay label describ- ing fuse/relay name and capacity. Information Not all fuse panel descriptions in this manual may be applicable to your vehicle. It is accurate at the time of printing.
Page 627 Maintenance Engine compartment main fuse panel Fuse Name Symbol Fuse rating Circuit Protected [W/O Smart Key] RLY. 8 (Start Relay), Ignition Switch, [With Smart Key] RLY. 8 (Start Relay), PCB Block (IG2 Relay) BLOWER RLY. 3 (Blower Relay) ABS 1 ABS Control Module, ESP Control Module REAR RLY.
Page 628 Engine compartment main fuse panel Fuse Name Symbol Fuse rating Circuit Protected Smart Junction Block B+ 1 (Power Window Relay, Fuse -F1/F2/F3/F4/F10/F13/F17/F18/F23/F24/F30) E-CVVT 3 [G4KJ/G4KH] PCM E-CVVT 2 [G4KJ/G4KH] PCM DEICER RLY. 7 (Deicer Relay) DRL Lamp RLY. 2 (DRL Lamp Relay) H/LAMP HI [With HID] RLY.
Page 629: Light Bulbs
This condi- Prior to working on the light, firm- expertise, consult an authorized tion is caused by the temperature ly apply the parking brake, HYUNDAI dealer. In many cases, difference between lamp ensure that the Engine Start/Stop it is difficult to replace vehicle inside and outside.
Page 630: Headlamp, Position Lamp, Turn Signal Lamp And
Type B Headlamp, position lamp, turn signal lamp and fog lamp light bulb replacement Type A OLMB073042L Headlamp (Halogen bulb) OLF074050 (1) Headlamp (Low) WARNING (2) Headlamp (High) • (3) Turn signal lamp Handle halogen bulbs with OLF074051N care. Halogen bulbs contain (4) Position lamp (1) Headlamp (Low) pressurized gas that will pro-...
Page 631 Information The headlamp aiming should be adjusted after an accident or after the headlamp assembly is reinstalled at an authorized HYUNDAI dealer. OLF074085N 1. Open the hood. 2. Disconnect the negative battery cable. 3. Remove the headlamp bulb cover by turning it counterclockwise.
Page 632: Side Repeater Lamp Replacement
If the LED lamp does not operate, Turn signal lamp have the vehicle checked by an 1. Open the hood. OLF074053N authorized HYUNDAI dealer. 2. Disconnect the negative battery If the LED lamp does not operate, cable. have the vehicle checked by an 3.Remove the socket from the...
Page 633: Headlamp And Front Fog Lamp Aiming (For Europe)
Maintenance Front fog lamp aiming Headlamp and front fog lamp 4. With the headlamp and battery in normal condition, aim the head- aiming (For Europe) The front fog lamp can be aimed as lamps so the brightest portion falls the same manner of the headlamps Headlamp aiming on the horizontal and vertical aiming.
Page 634 Aiming point H1 : Height between the head lamp bulb center and ground (Low beam) H2 : Height between the head lamp bulb center and ground (High beam) H3 : Height between the fog lamp bulb center and ground W1 : Distance between the two head lamp bulbs centers (Low beam) W2 : Distance between the two head lamp bulbs centers (High beam) W3 : Distance between the two fog lamp bulbs centers OLF074099L...
Page 635 Maintenance Headlamp low beam (LHD side) ■ Based on 10m screen OLF074090L 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3. When aiming the low beam, vertical aiming should be adjusted after adjusting the horizontal aiming. 4.
Page 636 Headlamp low beam (RHD side) ■ Based on 10m screen OLF074091L 1. Turn the low beam on without driver aboard. 2. The cut-off line should be projected in the cut-off line shown in the picture. 3. When aiming the low beam, vertical aiming should be adjusted after adjusting the horizontal aiming. 4.
Page 637 Maintenance Front fog lamp ■ Based on 10m screen OLF074093L 1. Turn the front fog lamp on without the driver aboard. 2. The cut-off line should be projected in the allowable range (shaded region). 7-80...
Page 638: Rear Combination Light Bulb Replacement
Rear combination light bulb replacement Stop/Tail lamp Type A Turn Signal lamp OLF074062 OLF074063 3. Remove the socket from the Stop/Tail lamp and Turn signal lamp assembly by turning the socket 1. Open the trunk lid. counterclockwise until the tabs on 2.
Page 639 Maintenance 6. Install the socket in the assembly by aligning the tabs on the socket with the slots in the assembly. Push the socket into the assembly and turn the socket clockwise. Back up lamp Tail lamp OLF074064 OLF074065 4. Remove the bulb by pulling it Backup lamp and Tail lamp straight out.
Page 640 Type B Stop/Tail lamp If the LED lamp does not operate, have the vehicle checked by an authorized HYUNDAI dealer. OLF074062 Turn signal lamp OLF074054 1.Open the trunk lid. (1) Stop/Tail lamp 2.Remove the service cover by turn- (2) Turn signal lamp...
Page 641 Maintenance Back up lamp Turn Signal lamp OLF074063N OLF074064 OLF074065N 4. Remove the bulb by pulling it 3. Remove the socket from the Backup lamp straight out. assembly by turning the socket 1. Open the trunk. counterclockwise until the tabs on 5.
Page 642: High Mounted Stop Lamp Replacement
■ Room lamp - with sunroof If the high mounted stop lamp does If the license plate lamp does not not operate, we recommend that you operate, we recommend that you contact an authorized HYUNDAI contact an authorized HYUNDAI dealer. dealer. OLF074068...
Page 643 4. Align the lens tabs with the interior light housing notches and snap the lens into place. If the lamps do not operating, have the vehicle checked by an authorized HYUNDAI dealer. OLF074081N OLF074069 ■ Room lamp - without sunroof ■ Luggage room lamp...
Page 644: Appearance Care
APPEARANCE CARE Finish maintenance Exterior care CAUTION Washing Exterior general caution To help protect your vehicle’s finish • It is very important to follow the label Do not use strong soap, from rust and deterioration, wash it chemical detergents or hot directions when using any chemical thoroughly and frequently at least water, and do not wash the...
Page 645 Maintenance Waxing WARNING Wax the vehicle when water will no longer bead on the paint. Wet brakes Always wash and dry the vehicle After washing the vehicle, test before waxing. Use a good quality the brakes while driving slowly liquid or paste wax, and follow the to see if they have been affected manufacturer’s instructions.
Page 646 Finish damage repair Bright-metal maintenance Underbody maintenance Deep scratches or stone chips in the • To remove road tar and insects, Corrosive materials used for ice and painted surface must be repaired use a tar remover, not a scraper or snow removal and dust control may promptly.
Page 647 Maintenance Aluminum wheel maintenance Corrosion protection WARNING The aluminum wheels are coated with Protecting your vehicle from corro- a clear protective finish. sion After washing the vehicle, test By using the most advanced design the brakes while driving slowly and construction practices to combat CAUTION to see if they have been affected corrosion, we produces cars of the...
Page 648 High-corrosion areas High temperatures can also acceler- Keep your car clean ate corrosion of parts that are not If you live in an area where your car The best way to prevent corrosion is properly ventilated so the moisture is regularly exposed to corrosive to keep your car clean and free of can be dispersed.
Page 649 Maintenance • When cleaning lower door panels, Keep paint and trim in good con- Don't neglect the interior rocker panels and frame mem- dition Moisture can collect under the floor bers, be sure that drain holes are Scratches or chips in the finish mats and carpeting to cause corro- kept open so that moisture can should be covered with "touch-up"...
Page 650: Interior Care
Cleaning the upholstery and Interior care CAUTION interior trim Interior general precautions Vinyl When cleaning leather products Prevent chemicals such as perfume, Remove dust and loose dirt from (steering wheel, seats etc.), use cosmetic oil, sun cream, hand clean- vinyl with a whisk broom or vacuum neutral detergents or low alco- er and air freshener from contacting cleaner.
Page 651 Maintenance Cleaning the lap/shoulder belt webbing Clean the belt webbing with any mild soap solution recommended for cleaning upholstery or carpet. Follow the instructions provided with the soap. Do not bleach or re-dye the webbing because this may weaken it. Cleaning the interior window glass If the interior glass surfaces of the...
Page 652: Emission Control System
In order to assure the proper function phere. of the emission control systems, it is recommended that you have your car inspected and maintained by an authorized HYUNDAI dealer in accordance with the maintenance schedule in this manual. 7-95...
Page 653: Exhaust Emission Control System
Maintenance Canister Engine exhaust gas precautions 3. Exhaust emission control system (carbon monoxide) Fuel vapors generated inside the fuel tank are absorbed and stored in the • Carbon monoxide can be present Exhaust Emission Control onboard canister. When the engine is with other exhaust...
Page 654 Operating precautions for cat- • Do not operate the engine in con- WARNING fined or closed areas (such as alytic converters (if equipped) garages) any more than what is Exhaust necessary to move the vehicle in or WARNING out of the area. Engine exhaust gases contain carbon monoxide (CO).
Page 655 • Use only UNLEADED FUEL for made authorized gasoline engine. HYUNDAI dealer. • Do not operate the vehicle when • Avoid driving with a very low there are signs of engine mal- fuel level. If you run out of...
Page 656: Specifications & Consumer Information
Specifications & Consumer information Dimensions ..............8-2 Engine ..............8-2 Bulb wattage............8-3 Tires and wheels ............8-4 Air conditioning system ........8-4 Tire load and speed capacity ......8-5 Volume and weight ..........8-5 Recommended lubricants and capacities ...8-6 Recommended SAE viscosity number ......8-8 Vehicle identification number (VIN)....8-9 Vehicle certification label ........8-9 TIRE specification and pressure label ....8-10 Engine number .............8-10...
Page 657: Dimensions
Specifications & Consumer information DIMENSIONS Items mm (in) Overall length 4,885 (192.3) Overall width 1,865 (73.4) Overall height 1,475 (58.1) 205/65R16 1,614 (63.5) Front tread 215/55R17 1,602 (63.0) 235/45R18 1,597 (62.8) 205/65R16 1,621 (63.8) Rear tread 215/55R17 1,609 (63.3) 235/45R18 1,604 (63.1) Wheelbase 2,805 (110.4)
Page 658: Bulb Wattage
BULB WATTAGE Light Bulb Bulb type Wattage H7LL Headlamps Low/High High 9005HL+ Turn signal lamps PY21W Front Type A Position lamps Type B Daytime running light Fog lamps Static bending lamps H7LL Stop lamps P21/5W Type A P21/5W Stop/ Tail lamps Type B Rear combination lamp Type A...
Page 659: Tires And Wheels
550 ± 25g (19.5 ± 0.8) Refrigerant Theta 2.4 R-134a 650 ± 25g (22.9 ± 0.8) g (oz.) Nu 2.0 Compressor lubricant 100 ± 10 (3.52 ± 3.5) PAG (FD46 X G) g (oz.) Contact an authorized HYUNDAI dealer for more details.
Page 660: Tire Load And Speed Capacity
TIRE LOAD AND SPEED CAPACITY Load Capacity Speed Capacity Item Tire size Wheel size LI * SS * km/h 205/65R16 6.5JX16 Full size tire 215/55R17 7.0JX17 235/45R18 7.5JX18 T125/80D16 4.0TX16 Compact spare tire (if equipped) T135/80D17 4.0TX17 LI : LOAD INDEX SS : SPEED SYMBOL VOLUME AND WEIGHT Theta 2.0...
Page 661: Recommended Lubricants And Capacities
API SM * & ILSAC GF-4 or above MICHANG ATF SP-IV, SK ATF SP-IV Automatic transaxle fluid 7.1 l (7.5 US qt.) NOCA ATF SP-IV, HYUNDAI genuine ATF & SP-IV Manual transaxle fluid 1.9 l (2.0 US qt.) API GL-4, SAE 75W/85 Theta 2.0...
Page 662 Lubricant Volume Classification Brake/clutch fluid 0.7~0.8 l (0.74~0.85 US qt.) FMVSS116 DOT-3 or DOT-4 Fuel 70 l (18.49 US gal.) Refer to “Fuel Requirements” in the Foreword chapter. : Refer to the recommended SAE viscosity numbers on the next page. : Engine oils labeled Energy Conserving Oil are now available.
Page 663: Recommended Sae Viscosity Number
Specifications & Consumer information Recommended SAE viscosity When choosing an oil, consider the range of temperature your vehicle will be number operated in before the next oil change. Proceed to select the recommended oil viscosity from the chart. CAUTION Temperature Range for SAE Viscosity Numbers °C Always be sure to clean the area Temperature...
Page 664: Vehicle Identification Number (Vin)
VEHICLE IDENTIFICATION NUMBER (VIN) VEHICLE CERTIFICATION LABEL ■ Frame number ■ VIN label (if equipped) OLF084001 OLF084006N The vehicle identification number The VIN is also on a plate attached OLF084002 (VIN) is the number used in register- to the top of the dashboard. The vehicle certification label...
Page 665: Tire Specification And Pressure Label
Specifications & Consumer information TIRE SPECIFICATION AND ENGINE NUMBER PRESSURE LABEL ■ Nu 2.0 MPI ■ Theta 2.4 MPI OLF084011L OLF084010L ■ Theta 2.0 T-GDI ■ Theta 2.4 GDI OLF084007N The tires supplied on your new vehi- cle are chosen to provide the best performance for normal driving.
Page 666: Air Conditioner Compressor Label
Directive 1995/5/EC. refrigerant (1) and refrigerant oil (2). Further information including the manufacturer's declaration of con- formity is available on HYUNDAI web site as follows: http://service.hyundai-motor.com 8-11...

Hyundai Sonata LF Owner's Manual

Table of Contents

Interior Overview (II)

2 Safety System of Your Vehicle

3 Convenient Features of Your Vehicle

Multimedia System

4 Multimedia System

Multimedia System

System Controllers and Functions - 3.8 Inch MONO TFT (for Europe)

System Controllers and Functions - 4.3 Inch COLOR TFT LCD (for Europe)

Driving Your Vehicle

Before Driving

Ignition Switch

Manual Transaxle

Automatic Transaxle

Braking System

Drive Mode Integrated Control System

Cruise Control

Special Driving Conditions

Winter Driving

Trailer Towing (for Europe)

Vehicle Weight

What to Do in an Emergency

Hazard Warning Flasher

In Case of an Emergency While Driving

If the Engine will Not Start

Jump Starting

If the Engine Overheats

If You Have a Flat Tire

Towing

Emergency Commodity

Maintenance

Engine Compartment

Maintenance Services

Owner Maintenance

Scheduled Maintenance Services

Explanation of Scheduled Maintenance Items

Engine Oil

Engine Coolant

Brake/Clutch Fluid

Washer Fluid

Parking Brake

Air Cleaner

Climate Control Air Filter

Wiper Blades

Battery

Tires and Wheels

Fuses

Light Bulbs

Appearance Care

Emission Control System

Quick Links

Specifications

Chapters

Need help?

Questions and answers

Related Manuals for Hyundai Sonata LF

Summary of Contents for Hyundai Sonata LF
