Hyundai SONATA 2016 Quick Reference Manual

WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
HOW TO DEFROST - page 22- 25
1 Press the front defrost button.
2 Set to warmest temperature setting.
3 Set to highest fan speed.
☐
TIRE PRESSURE MONITORING SYSTEM (TPMS) - page 35
LOW TIRE PRESSURE INDICATOR /
TPMS MALFUNCTION INDICATOR
NOTE
☐
WINDSHIELD WIPER / WASHER - page 09
MIST
OFF
INT
LO
HI
☐
UNLOCKING VEHICLE - page 02
☐
BLUE LINK - pages 29-31
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
- Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button
MAINTENANCE
Scheduled Maintenance Normal Usage
Engine Oil and Filter (2.4 GDI)* Replace 7,500 or 12 mos.
1st Replace 3,000 or 6 mos.
Engine Oil and Filter (1.6TGDI/2.0TGDI)*
Add'l Replace 5,000 or 6 mos.
Fuel Additive (2.4 GDI) *1 Add 7,500 or 12 mos.
1st Add 3,000 or 6 mos.
Fuel Additive (2.0 TGDI) *1
Add'l Add 5,000 or 6 mos.
Tire Rotation Perform 7,500
Inspect 7,500
Air Cleaner Filter
Replace 30,000
Vacuum Hose Inspect 7,500
Climate Control Air Filter
Replace 15,000
(for Evaporator and Blower Unit)
Air Conditioning Refrigerant Inspect 15,000
Brake Hoses & Lines Inspect 15,000
Drive Shafts & Boots Inspect 15,000
Exhaust Pipe & Muffler Inspect 15,000
Front Disc Brake/Pads, Calipers & Rotors Inspect 15,000
Steering Gear Box, Linkage & Boots/
Inspect 15,000
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts Inspect 15,000
Brake fluid Inspect 30,000
Crankcase Ventilation Hose Inspect 30,000
Fuel Filter Inspect 30,000
Fuel Lines, Fuel Hoses and Connections Inspect 30,000
Fuel Tank Air Filter Inspect 30,000
Rear Disc Brake/Pads, Parking Brake Inspect 30,000
Vapor Hose, Fuel Tank & Fuel Filler Cap Inspect 30,000
Valve Clearance (if equipped) Inspect 60,000
Spark Plugs (2.4GDI) Replace 105,000
Spark Plugs (1.6TGDI/2.0TGDI) Replace 45,000
1st Inspect 60,000 or 72 mos.
Drive Belt (Alt, A/C)
Add'l Inspect 15,000 or 24 mos.
1st Replace 60,000 or 60 mos.
Coolant
Add'l Replace 30,000 or 24 mos.
Automatic Transmission Fluid No check, No service required
Dual Clutch Transmission Fluid Inspect 37,500
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*1 If TOP TIER Detergent Gasoline is not available, one bottle of additive is recommended. Additives are available
from your authorized Hyundai dearler along with information on how to use them. Do not mix other additives.
*See Owner's Manual for details.
Severe Usage*
Replace 3,750 or 6 mos.
Replace 3,000 or 3 mos.
SONATA
HYUNDAI
Add Same as Normal
Quick Reference Guide
Add Same as Normal
Perform 7,500
Inspect Same As Normal
Replace More Frequently
Inspect Same As Normal
Replace More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect 7,500
Inspect Same As Normal
Inspect More Frequently
Inspect More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Replace More Frequently
Replace Same As Normal
Inspect Same As Normal
Replace More Frequently
Replace More Frequently
Inspect Same As Normal
Replace Same As Normal
Replace 60,000
Replace 75,000
NP150-F2016-B
(Rev 07/16/15)
Printing 07/19/15
www.hyundai.com
1-800-243-7766
Roadside Assistance:
1-800-633-5151
Consumer Affairs:
XM ® Radio: 1-800-967-2346
Sirius
1-855-2BLUELINK
Blue Link:
(1-855-225-8354)
