Hyundai SONATA 2018 Quick Reference Manual

WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
HOW TO DEFROST - page 18- 21
Press the front defrost button.
1
Set to warmest temperature setting.
2
Set to highest fan speed.
3
☐
TIRE PRESSURE MONITORING SYSTEM (TPMS) - page 39
LOW TIRE PRESSURE INDICATOR /
TPMS MALFUNCTION INDICATOR
NOTE: Tire pressure may vary in colder temperatures causing the low
tire pressure indicator to illuminate. Inflate tires according to the Tire
Pressure Label located on the driver's side door pillar.
☐
WINDSHIELD WIPER / WASHER - page 09
• To activate wipers move the switch down
MIST
to one of the three positions (INT, LO, HI)
OFF
• To adjust "INT" speed move switch
INT
• To spray washer fluid pull lever toward you
LO
HI
• Push lever up for a single wiper pass
☐
OPENING THE TRUNK- page 11
1. Make sure the shift lever is in P (Park).
2. Then do one of the following :
- Press the button on the trunk emblem
after unlocking the door by remote key
or smart key.
- Press the trunk unlock button of remote
key or smart key for more than 1 second.
- Press the button on the trunk itself with
the Smart Key in your possession.
- With vehicle unlocked, press the button.
☐
BLUE LINK - pages 25-27
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
- Show Blue Link Users Manual & tear out Voice Commands/Quick Tip Card
- Encourage customers to press the Blue link button
MAINTENANCE
Scheduled Maintenance
2.4 GDI
(Normal Usage)
Engine Oil and Filter Replace 7,500 or 12 mos.
Fuel Additives Add 7,500 or 12 mos.
Tire Rotation Perform 7,500
Vacuum Hose Inspect 7,500 or 12 mos.
Inspect 7,500 or 12 mos.
Air Cleaner Filter
Replace 22,500 or 36 mos.
Climate Control Air Filter
Replace 7,500 or 12 mos.
(for Evaporator and Blower Unit)
Air Conditioning Refrigerant
Brake Hoses & Lines
Drive Shafts & Boots
Front Brake Disc/Pads, Calipers
Inspect 7,500 or 12 mos.
Rear Brake Disc/Pads
Steering Gear Box, Linkage & Boots /
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
Exhaust Pipe & Muffler
Fuel Tank Air Filter
Vapor Hose & Fuel Filler Cap, Fuel Tank
Inspect 15,000 or 24 mos.
Brake Fluid
Parking Brake
Fuel Filter
Fuel Lines, Fuel Hoses and Connections Inspect 30,000 or 48 mos.
First
60,000 or 72 mos.
Drive Belt Inspect
Subsequent, every
15,000 or 24 mos.
Spark Plugs
Replace 97,500
First
120,000 or 120 mos.
Coolant Replace
Subsequent, every
30,000 or 24 mos.
Valve Clearance Inspect 60,000 or 72 mos.
Ecoshift Dual Clutch Transmission Fluid -
Automatic Transmission Fluid No checks or services required for Normal Usage driving.
*Check the engine oil regularly between recommended oil change intervals.
We recommend Quaker State oil.
*See Owner's Manual for details regarding Severe Usage maintenance recommendations.
Looking For more detailed information? This Quick Reference Guide does not replace your vehicle's
Owner's Manual. If you require additional information or are unsure of a specific issue,We
recommend that you always refer to the vehicle's Owner's Manual or contact your authorized
Hyundai dealer. The information contained in this Quick Reference Guide is correct at the time
of printing; however, specifications and equipment can change without notice. No warranty or
guarantee is being extended in this Quick Reference Guide, and Hyundai reserves the right to
change product specifications and equipment at any time without incurring obligations.
Some vehicles are shown with optional equipment.
1.6/2.0 T-GDI
HYUNDAI
Replace 6,000 or 12 mos.
Add 6,000 or 12 mos.
Perform 6,000
Inspect 6,000 or 12 mos.
SONATA
Inspect 6,000 or 12 mos.
Replace 18,000 or 36 mos.
Replace 6,000 or 12 mos.
Quick Reference Guide
Inspect 6,000 or 12 mos.
Inspect 12,000 or 24 mos.
Inspect 24,000 or 48 mos.
First
60,000 or 72 mos.
Inspect
Subsequent, every
12,000 or 24 mos.
Replace 42,000
First
120,000 or 120 mos.
Replace
Subsequent, every
30,000 or 24 mos.
Inspect 60,000 or 72 mos.
Inspect 24,000 or 48 mos.
Roadside Assistance:
Consumer Affairs:
=
XM ® Radio:
Sirius
NP150-C2018
Blue Link:
(Rev 05/25/17)
Printing 05/27//17
1-800-243-7766
1-800-633-5151
1-800-967-2346
1-855-2BLUELINK
(1-855-225-8354)
