Hyundai 2017 Sonata Quick Reference Manual

WALK THE CUSTOMER THROUGH EACH OF
THE FOLLOWING KEY DELIVERY FEATURES
☐
How to Defrost - page 26
Press the front defrost button.
1
Set to the warmest temperature setting.
2
Set to the highest fan speed.
3
☐
Tire Pressure Monitoring System (TPMS) - page 43
LOW TIRE PRESSURE INDICATOR /
TPMS MALFUNCTION INDICATOR
NOTE: Tire pressure may vary in colder temperatures causing the
low tire pressure indicator to illuminate. Inflate tires according to
the Tire Pressure Label located on the driver's side door pillar.
☐
Windshield Wiper / Washer - page 12
To activate wipers, move the switch
•
MIST
down to one of the three positions
OFF
(INT, LO, HI)
INT
• To adjust "INT" speed, move switch
LO
• To spray the washer fluid pull lever
HI
toward you
• Push the lever up for a single wiper
pass
☐
Unlocking Vehicle - page 02
LOCK
UNLOCK
TRUNK OPEN
ALARM
☐
Blue Link - pages 31-33
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
- Show Blue Link Users Manual & tear out Voice
Commands/Quick Tip Card
- Encourage customers to press the Blue link button
MAINTENANCE
Scheduled Maintenance Normal Usage
Engine Oil and Filter* Replace 7,500 or 12 mos.
Fuel Additive Add 7,500 or 12 mos.
Tire Rotation Perform 7,500
Inspect 7,500
Air Cleaner Filter
Replace 30,000
Vacuum Hose Inspect 7,500
Climate Control Air Filter
Replace 15,000
(for Evaporator and Blower Unit)
Air Conditioning Refrigerant Inspect 15,000
Brake Hoses & Lines Inspect 15,000
Drive Shafts & Boots Inspect 15,000
Exhaust Pipe & Muffler Inspect 15,000
Front Disc Brake / Pads, Calipers & Rotors Inspect 15,000
Rear Brake Disc / Pads Inspect 15,000
Steering Gear Box, Linkage & Boots /
Inspect 15,000
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts Inspect 15,000
Brake Fluid Inspect 30,000
Crankcase Ventilation Hose Inspect 30,000
Fuel Filter Inspect 30,000
Fuel Lines, Fuel Hoses and Connections Inspect 30,000
Fuel Tank Air Filter Inspect 30,000
Parking Brake Inspect 30,000
Vapor Hose, Fuel Tank & Fuel Filler Cap Inspect 30,000
Spark Plugs Replace 105,000
1st Replace 120,000 or 120 mos.
Engine Coolant
Add'l Replace 30,000 or 24 mos.
1st Replace 120,000 or 120 mos.
Inverter Coolant
Add'l Replace 30,000 or 24 mos.
Inspect 7,500 or 12 mos
Hybrid Starter Generator (HSG) Belt
Replace 60,000 or 48 mos
Automatic Transmission Fluid No check, No service required
*Check the engine oil regularly between recommended oil change. Hyundai recommends Quaker State oil.
*See Owner's Manual for details.
Looking For more detailed information? This Quick Reference Guide does not replace your vehicle's Owner's Manual. If
you require additional information or are unsure of a specific issue, we recommend that you always refer to the
vehicle's Owner's Manual or contact your authorized Hyundai dealer. The information contained in this Quick
Reference Guide is correct at the time of printing; however, specifications and equipment can change without
notice. No warranty or guarantee is being extended in this Quick Reference Guide, and Hyundai reserves the right
to change product specifications and equipment at any time without incurring obligations. Some vehicles are
shown with optional equipment.
Severe Usage*
Replace 3,750 or 6 mos.
Add Same as Normal
HYUNDAI
Perform 7,500
Inspect Same As Normal
Replace More Frequently
Inspect Same As Normal
Quick Reference Guide
Replace More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect 7,500
Inspect Same As Normal
Inspect More Frequently
Inspect More Frequently
Inspect More Frequently
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Inspect Same As Normal
Replace More Frequently
Replace Same As Normal
Replace More Frequently
Replace Same As Normal
Replace Same As Normal
Inspect 3,750 or 6 mos
Replace 30,000 or 24 mos
Replace 60,000
NP150-C2017-A
(Rev 08/02/16)
Printing 08/05/16
www.hyundai.com
Roadside Assistance: 1-800-243-7766
Consumer Affairs: 1-800-633-5151
®
XM Radio: 1-800-967-2346
Blue Link: 1-855-2BLUELINK
(1-855-225-8354)
