PNM-200 Series Overview

Speaker
LEDs
Interface
Power
SET
Key 1
Key 2
Key 3
Key 4
Led's
Touch Screen
Please note that all the keys and the LED's on the PNM-200 series device can be
configured by the VPL application. Please refer to the RTCU IDE online-help for further
information.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Set Key1 Key2
Description
No built-in functionality. May be used for power by the application.
User-defined key.
User-defined key.
User-defined key.
User-defined key.
User-defined key.
Status LED's
To interact with the application using finger touch or attached stylus
Touch
Screen
Key3
Power
Speaker
Key4
