Technical Manual 1.00, PNM-200 Series V1
Analog camera interface
PNM-210 offers connection for up to two analog cameras using the BNC connector
available at the PNM device interface cable. Analog camera #1 must be connected to the
cable labeled with BNC-1 and analog camera #2 must be connected to BNC-2.
The use of the cameras is under full control of the VPL application. Please consult the
RTCU IDE on-line help for additional information.
Note: BNC-2 may not be available on all variants of the PNM-210.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Page 13 of 19
Ph: (+45) 7625 0210
Fax: (+45) 7625 0211
Email: info@logicio.com
www.logicio.com / www.rtcu.dk
