INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
4300 WOOD APPLIANCE SERIES
Automatic Combustion Control (ACC)
Model:
43M-ACC-MBK
43ST-ACC-B
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may over-fire and generate
poisonous gases (i.e. carbon monoxide).
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Owner's Manual
Operation & Care
O-T L
Portland
Tested and
Oregon USA
Listed by
C
US
OMNI-Test Laboratories, Inc.
7037-171B
WARNING
If the information in these instruc-
tions is not followed exactly, a
fire could result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not over-fire - If appliance or chim-
ney connector glows, you are over-firing.
Over-firing will void your warranty.
• Comply with all minimum clearances to
combustibles as specified. Failure to
comply may cause a house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
appliance.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other flammable
materials away.
NOTE
To obtain a French translation of this manual, please contact
your dealer or visit www.quadrafire.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.quadrafire.com
December 01, 2016
Advertisement
Table of Contents
Related Manuals for Hearth & Home 43M-ACC-MBK
Summary of Contents for Hearth & Home 43M-ACC-MBK
- Page 1 Automatic Combustion Control (ACC) • Do not store or use gasoline or other flam- Model: 43M-ACC-MBK mable vapors and liquids in the vicinity of 43ST-ACC-B this or any other appliance. • Do not over-fire - If appliance or chim- ney connector glows, you are over-firing.
-
Page 2: Sample Of Serial Number / Safety Label
4300 Wood Stove Series ACC NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction A. Sample of Serial Number / Safety Label LOCATION: Back of appliance CAUTION HOT WHILE IN OPERATION DO NOT TOUCH, KEEP CHILDREN AND CLOTHING AWAY. CONTACT MAY CAUSE SKIN BURNS. KEEP FURNISHINGS AND OTHER COMBUSTIBLE MATERIAL FAR AWAY FROM THE APPLIANCE. -
Page 3: Table Of Contents
4300 Wood Stove Series ACC Safety Alert Key: DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. •... -
Page 4: Warranty Policy
4300 Wood Stove Series ACC Hearth & Home Technologies B. Warranty Policy LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance... - Page 5 4300 Wood Stove Series ACC WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • This warranty is only valid while the HHT appliance remains at the site of original installation. •...
-
Page 6: Quick Start Guide
4300 Wood Stove Series ACC C. Quick Start Guide Note: These are generic drawings and may not represent your specific model. 10 Pieces of Newspaper, 10-20 Pieces of Dry Kindling ITEMS NEEDED FOR FIRST FIRE: and a Few Pieces of Dry Split Wood. OPEN AIR CONTROLS ADD NEWSPAPER LOAD WOOD... -
Page 7: Listing And Code Approvals
4300 Wood Stove Series ACC Listing and Code Approvals A. Appliance Certification C. Mobile Home Approved • This appliance is approved for mobile home installa- Model: 4300 Millennium & Step Top (ACC) tions; when not installed in a sleeping room and when Uni-Body an outside combustion air inlet is provided. -
Page 8: Operating Instructions
4300 Wood Stove Series ACC User Guide Operating Instructions Dead wood lying on the forest floor should be considered wet, A. Over-Firing Your Appliance and requires full seasoning time. Standing dead wood can be considered to be about 2/3 seasoned. To tell if wood is WARNING dry enough to burn, check the ends of the logs. -
Page 9: Air Controls
4300 Wood Stove Series ACC very important that the flames be maintained and not allowed 2. Maximize Heat with The ACC System to go out. This will ensure the cleanest possible fire. If the To maximize heat output with the ACC timer System or also flames tend to go out, it is set too low for your burning condi- known as high burn push the ACC Air Control lever towards tions. -
Page 10: Burn Rates And Operating Efficiency
4300 Wood Stove Series ACC F. Burn Rates and Operating Efficiency WARNING For maximum operating efficiency Risk of Fire. This wood appliance has a manufacturer-set minimum low burn rate that must not be altered. It is against federal reg- When set on High Burn Rate and over-riding the Auto- ulations to alter this setting or otherwise operate this wood matic Combustion Control system an over fire situation can occur and may result in a chimney fire. -
Page 11: Building A Fire
4300 Wood Stove Series ACC G. Building A Fire Before lighting your first fire in the appliance: NOTE: • Build fire on brick firebox floor. NOTE: The special high temperature paint that your appli- • Do NOT use grates, andirons or other methods to support ance is finished with will cure as your appliance heats. -
Page 12: Correct Baffle & Blanket Placement
4300 Wood Stove Series ACC INCORRECT POSITIONS H. Correct Baffle & Blanket Placement WARNING Fire Risk Firebox damage due to improper baffle placement is not covered by warranty. Operate the wood burning appliance with the baffle in the correct po- sition only. -
Page 13: Blower Operating Instructions
4300 Wood Stove Series ACC I. Blower Operating Instructions J. Opacity (Smoke) NOTE: If your Quadra-Fire wood appliance is equipped with This is the measure of how clean your appliance is burn- an optional blower, you should follow these guidelines: ing. -
Page 14: Clear Space
4300 Wood Stove Series ACC K. Clear Space L. Negative Pressure • Do NOT place combustible objects within 4 ft (1.2 m) of the front of appliance. See Figure 14.1. WARNING • Mantel - avoid placing candles and other heat-sensitive Asphyxiation Risk. -
Page 15: Frequently Asked Questions
4300 Wood Stove Series ACC M. Frequently Asked Questions ISSUES SOLUTIONS Odor from appliance When first operated, this appliance may release an odor for the first several hours. This is caused by the curing of the paint and the burning off of any oils remaining from manufacturing. Metallic noise Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound produced by a furnace or heating duct. -
Page 16: Maintenance And Service
4300 Wood Stove Series ACC Maintenance and Service A. Quick Reference Maintenance Guide Start the first inspection after the first 2 months of use, or if performance changes, and adjust your schedule according- CAUTION! Allow the appliance to completely cool ly. -
Page 17: Cleaning And Operating The Ash Removal System
4300 Wood Stove Series ACC B. Cleaning and Operating the Ash Removal System WARNING Fire Risk Make sure Ash Removal System door is sealed tight against the gasket. Air leakage may cause: • Over-fire condition • Flame and/or smoke spillage •... -
Page 18: General Maintenance
4300 Wood Stove Series ACC C. General Maintenance Clean all the fingerprints and oils from plated surfaces BEFORE firing the appliance for the first time. If not cleaned 1. Creosote (Chimney) Cleaning properly before lighting your first fire, the oils can cause permanent markings on the plating. -
Page 19: Troubleshooting Guide
4300 Wood Stove Series ACC Troubleshooting Guide With proper installation, operation, and maintenance your wood appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist you or a qualified service person in the diagnosis of a prob- lem and the corrective action to be taken. -
Page 20: Service Part Replacement
4300 Wood Stove Series ACC Service Part Replacement A. Glass Replacement B. Firebrick Replacement Replace the firebrick if they become crumbly and/or if there Ensure that the fire is out and the appliance is cool to the is a 1/4 inch (6.35mm) gap between the bricks. touch. -
Page 21: Door Handle Assembly
4300 Wood Stove Series ACC Baffle Board even with front D. Door Handle Assembly tube & resting on all tubes 1. Slide door handle through door. 2. Install additional washer(s) as shown in Figure 21.1 3. Install key in groove. Burn Rate 4. -
Page 22: Tube Channel Assembly Replacement
4300 Wood Stove Series ACC F. Tube Channel Assembly Replacement NOTE: Service Space Removing Tube Channel Assembly In order to replace the tube channel assembly a clear- 1. Remove the right side shield by lifting up on side to ance of 19 inches (483mm) is required on the right side of remove. -
Page 23: Reference Materials
4300 Wood Stove Series ACC Reference Materials Date of Service Performed By Description of Service December 01, 2016 7037-171B... - Page 24 4300 Wood Stove Series ACC Date of Service Performed By Description of Service 7037-171B December 01, 2016...
-
Page 25: Service Parts
Service Parts 43M-ACC Service Parts Wood Stove Beginning Manufacturing Date: Oct. 2006 Ending Manufacturing Date: Active 43M-ACC-MBK 43M-ACC-GT Oct. 2006 - Jan. 2007, 43M-ACC-NT Oct. 2006 - Jan. 2007 Part number list on following page. 09/16 December 01, 2016 7037-171B... - Page 26 4300 Wood Stove Series ACC 43M-ACC Service Parts Beginning Manufacturing Date: Oct. 2006 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
-
Page 27: Pedestal Assembly
4300 Wood Stove Series ACC 43M-ACC Service Parts Beginning Manufacturing Date: Oct. 2006 Ending Manufacturing Date: Active #16 Brick Set Assembly #17 Pedestal Assembly 16.1 16.1 16.1 16.1 17.1 16.5 16.1 16.1 16.1 16.1 16.1 16.1 16.1 17.2 16.1 16.4 16.5 16.2 16.2 16.2... - Page 28 4300 Wood Stove Series ACC 43M-ACC Service Parts Beginning Manufacturing Date: Oct. 2006 Ending Manufacturing Date: Active #18 Door Assembly 18.1 18.2 18.7 18.6 18.3 18.5 18.4 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
- Page 29 4300 Wood Stove Series ACC 43M-ACC Service Parts Beginning Manufacturing Date: Oct. 2006 Ending Manufacturing Date: Active #19 Baf e Protection Channel Side view Front, looking into unit Baffle Ceramic blanket protection Fiber baffle Channel sits In between Front tube and Fiber baffle.
- Page 30 4300 Wood Stove Series ACC 43ST-ACC-B Service Parts Beginning Manufacturing Date: Sept 2016 Step Top Model - Wood Stove Ending Manufacturing Date: Active Part number list on following page. 09/16 7037-171B December 01, 2016...
- Page 31 4300 Wood Stove Series ACC 43ST-ACC-B Service Parts Beginning Manufacturing Date: Sept 2016 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
- Page 32 4300 Wood Stove Series ACC 43ST-ACC-B Service Parts Beginning Manufacturing Date: Sept 2016 Ending Manufacturing Date: Active #4 Brick Assembly Set #20 Burn Rate Controls & Associated Parts 20.1 20.10 20.9 20.2 4.2 4.2 4.2 4.2 9 in. 20.3 7-1/4 in. 2-1/2 in.
- Page 33 4300 Wood Stove Series ACC 43ST-ACC-B Service Parts Beginning Manufacturing Date: Sept 2016 Ending Manufacturing Date: Active #21 Leg, Ash Pan and Pedestal Assembly 21.1 21.4 21.5 21.3 21.2 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
- Page 34 4300 Wood Stove Series ACC 43ST-ACC-B Service Parts Beginning Manufacturing Date: Sept 2016 Ending Manufacturing Date: Active #22 Door Assembly Spring Handle Assembly Fiber Handle Assembly 22.1 22.5 22.4 22.3 22.2 IMPORTANT: THIS IS DATED INFORMATION . Parts must be ordered from a dealer or Stocked Hearth and Home Technologies does not sell directly to consumers distributor.
- Page 35 4300 Wood Stove Series ACC 43ST-ACC-B Service Parts Beginning Manufacturing Date: Sept 2016 Ending Manufacturing Date: Active Baf e Protection Channel Front, looking into unit Side view Ceramic blanket Fiber baffle Baffle protection Channel sits In between This tab sits behind the front tube. Front tube and Fiber baffle.
-
Page 36: Contact Information
CONTACT INFORMATION Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafire.com CAUTION DO NOT DISCARD THIS MANUAL Read, understand and Leave this manual with •...
