Page 1 COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE...
Page 2: Service Procedure
HT-RC180 SERVICE PROCEDURE-1 1. Replacing the fuses This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse, For fuse rating, refer to the marking adjacent to the symbol. Ce symbole indique que le fusible utilise est e lent.
Page 3 HT-RC180 SERVICE PROCEDURE-2 Replacing Power Amplifier Parts When a power amplifier of certain channel is broken and goes into Protect mode, the following parts in the channel must be replaced at the sametime, because these parts also get damage in most cases. Front L ch Front R ch Center ch...
Page 4 HT-RC180 ADJUSTMENT PROCESURE ADJUSTMENT OF IDLING CURRENT 1) Setting R6040 to R6046 to minimum position before power ON. 2) Setting the voltage at P6080 to P6086 to 3mV by adjusting R6040 to R6046, under the condition of no input signal and no load, immediately after powr ON. L/C/R SL/SR/SBL/ABR Below 4mV...
Page 5 HT-RC180 EXPLODED VIEWS-1 A611 A107 x 3 pcs. A115 A185 A607 A189 L=10mm x 2 A177 A179 x 2 pcs. A111 A089 A171 A603 A191 U003 A175 A111 x 6 pcs. A193 A613 A044 x 6 pcs. A107 x 2 pcs. A605 U0031 A183...
Page 6: Exploded Views
HT-RC180 EXPLODED VIEWS-2 Q6050A Q6050B x 2 pcs. x 6 pcs. A031 x 14 pcs. Q6056 Q6066 Q6054 Q6064 Q6051 Q6061 Q6052 Q6062 Q6050 Q6060 Q6053 Q6063 Q6055 Q6065...
Page 7: Block Diagram
HT-RC180 BLOCK DIAGRAM-1 HEADPHONES except JJ , MR TUNER ( PART-1 ) AUDIO SECTION PACK POWER AMPLIFIER for MDC only MAINR SPEAKER TERMINALS SIRIUS SL/Z3L IN12 +29dB TONE FRONT LEFT Down mix : No use R2A15220FP Tone : Use for Z3 IN10 MAINL +29dB...
Page 8 HT-RC180 BLOCK DIAGRAM-2 VIDEO SECTION D4 BOARD TC74HC4052 HDMI BOARD Scanning Line Aspect Ratio NJM2586AM U005 HDMI CIRCUIT PC BOARD MJJ ONLY TX-SA707/TX-NA807 only BAHDM-0132-1D DACV DACSC DACSY DACPR DACPB DACY VD BOARD ADCY NJW1325 ADCPB ADCPR ADCSY U0032 VIDEO CIRCUIT PC BOARD YOUT ADCSC ADCV...
Page 9 HT-RC180 BLOCK DIAGRAM-3 (PART-3) HP DET HPD0 HDMI SECTION R0PWR5V ADV7342 DDC DATA DSDA0 VOUT2 DACPY DDC CLK DSCL0 ADINPB CLKIN_A DAC_1 DCLK DACPB CERemote FSDATA31-0 CLKIN_B DAC_2 A4/AN2 DACPR FSADDR12-0 P_VSYNC DAC_3 U005 109-110 DACCV CK+/- R0XC+/- FSCLKp/n P_HSYNC DAC_4 111-112 DACSY...
Page 10 HT-RC180 BLOCK DIAGRAM-4 DSP/ ETHER/ USB SECTION Depend on Total cost of AVR. USB FS RJ-45 Reserved USB HS HOST Reserved HiSideSw DSP/Ether/USB Block SDR SDRAM(x16bit) EtherPHY 256Mb?? x2pcs HiSideSw from HDMI block EMIFB x32DataBus NAND Controles NANDFlash EMFA_A[1:2] EMIFA 24.576MHz EMFA_D[0:7] Reserved...
Page 11 HT-RC180 HT-RC180 SCHEMATIC DIAGRAM-1 U0011 AUDIO INPUT CIRCUIT PC BOARD (BAASP-0073-1L) (PART-5) except TX-SR707 ((SD-7) (SD-7) to HDMI PWB except TX-SA707JJ connect with MICON PWB(BADG-0099) connect with MICON PWB(BADG-0099) to BAVD-0101 except TX-NA807JJ P5518 JL104A JL5513A P5512 CN19 P5513 SRZ3MUT BAASP-0073 Z3MUT PRESRMUT...
Page 12: Schematic Diagram
HT-RC180 SCHEMATIC DIAGRAM-2 (1/4W) U0024 63.9V[56.6V] R5182 POWER AMP. INPUT CIRCUIT (INPUT STAGE) PC BOARD 62.1V[54.8V] BACLA-0087-1G 62.1V[54.8V] -62.4V[-55.1V] R5032 R5002 C5012 R5022 (PART-6) 1.5K 47/50 R5232 +B1C -61.3V[-54.0V] -B1C 1.2V -0.9V R5042 -58.8V[-51.5V] -1.2V TX-SR707 TX-NR807 -SA707 -NA807 -62.7V[-55.5V] DTR-40.1 DTR-50.1 Q5060 - 5066...
Page 13 HT-RC180 HT-RC180 SCHEMATIC DIAGRAM-3 U001 POWER AMPLIFIER CIRCUIT PC BOARD (BAAMP-0072-1L) (PART-7) P6901B P6902B POWER AMP(Final Stage) SECTION BAAMP-0072 64.0V[56.7V] 64.0V[56.7V] +B1L +B1SL L6000 L6003 IPRO IPRO TX-SR707 / TX-NR807 / 0.6V 0.6V DTR-40.1 DTR-50.1 1.2V 1.2V +BSL Q6050 - Q6056 2SC5242 TTC0001 R6080...
Page 14 HT-RC180 HT-RC180 SCHEMATIC DIAGRAM-4 AREA-1 SP TARMINAL DACC BATRM-0083 DACSW U002 SPEAKER TERMINAL-1 PC BOARD DACFL U0022 SPEAKER TERMINAL-2 PC BOARD DACFR BATRM-0083-1G DACSBL BATRM-0085-1G DACSBR (PART-8) DACSL AREA-4 to H/P Jack DACSR JL4103A NSCT-5P97 OTPF AD_L E6611 AD_R +12VDG +12VDG GNDDG R6691 390(1/2W)
Page 15 R4133 YIN_DVD MODEL HT-RC180 VOUT1 SYIN1 R4506 Q4700 1.2K R4230 NC P4700 Component Terminals C4230 NC P4118 Onkyo= Silver D4018 NEJITANSI_ST3 Integra= Gold D4019 C4144 104Z R4148 C4151 47/25(UTSP) C4207 C4200 3.9K (TX-SR707 DC, TX-NR807 DC ONLY) 1/50(UTSP) 1/50(UTSP) R4220 1M...
Page 16 HT-RC180 HT-RC180 SCHEMATIC DIAGRAM-6 U0031 CPU CIRCUIT PC BOARD BACPU-0100-1P (PART-11) TO DEBUGER TO FLASH WRITER NC(Debuger) NSCT-9P2243 P1001A P1004A BACPU-0100 Power_GND GND_VD AUXCV_IN -15VA +15VA AUX_R1 GND_AUX GND_AUX Digital AUX_L SRZ3MUT3.3 MICOUT GND_DG MICMUT Q1027 HPDET MICDET KRA102S HPRL OPTF VOLA C1043 105Z...
Page 17 HT-RC180 HT-RC180 SCHEMATIC DIAGRAM-7 U003 DAC/ DIR CIRCUIT PC BOARD-7 BADG-0099-1P (PART-12) SP terminal PC board (SD-15) (SD-4) TO_NAHDM-0132 TO BATRM-0083 (Part-20) (Part-10) P3605B P3607B P1008B IMSA-9142S-18A IMSA-9142S-16A IMSA-9142B-20A excptJJ excptJJ BADG-0099 R1620-1627 R1640-1647 Q1611-1614 Q1621-1624 Q1631-1634 C1630-1637 R1630-1637 R1650-1657 C1640-1647 R1680-1687 R1690-1697...
Page 18: 1 Bahdm-0132-1D
HT-RC180 HT-RC180 SCHEMATIC-DIAGRAM-8 U005 HDMI CIRCUIT PC BOARD-1 BAHDM-0132-1D HDMI IN/ HDMI RX/ HDMI TX SECTION TX_SCL (PART-13) TX_SDA TX_INT TX_RST TX2_INT GNDHD 3.3V TX2_RST +3.3VHD1 INPSEL Q205 HPLG_DET TC74VHC157FT SN74CB3Q3305PWR HPLG2_DET L251 INPSEL R268 +3.3VHD1 C8632 SELECT RX_CLK PCMLRCK_DR0_A BLM18PG181SN1 R269 0ohm...
Page 19 HT-RC180 HT-RC180 SCHEMATIC DIAGRAM-9 U005 HDMI CIRCUIT PC BOARD-2 BAHDM-0132-1D (PART-14) HDMI IN/ ENCODER/ POWER SUPPLY SECTION +3.3VHD1 VPOWER +5VHD VSW_SDET TX_SCL VSW_VDET Q8802 +3.3VEN TX_SDA Q8804 VSW_CDET TRINO PART BH18FB1WG NC_TA48033BF 122mA TX_INT VSW_SDA +1.8VEN PART-15 PART-15 TORINO TX_RST VOUT VSW_SCL ANALOG INPUT...
Page 20 HT-RC180 HT-RC180 SCHEMATIC DIAGRAM-10 HDMI CIRCUIT PC BOARD-3 U005 BAHDM-0132-1D (PART-15) TRINO SECTION +1_8V_PLL +3_3V_LVDS_PLL +1_8V_ADC +3_3V_ADC1 +1_8V_CORE +3_3V_I/O +3_3V_LBADC +2.5V_DDR FSVREF +3_3V_LVDS +3_3V_ADC2 +1_8V_DLL +3_3V_PLL +3_3V_I/O C8202 C8203 C8204 C8205 C8206 C8207 C8208 C8209 C8210 C8211 C8212 C8213 C8214 C8215 C8216 C8217...
Page 21 HT-RC180 SCHEMATIC DIAGRAM-11 HDMI CIRCUIT PC BOARD-4 U005 BAHDM-0132-1D (PART-16) TRINO BOARD MEMORY SECTION HDMI INPUT1 PART PART-13 (SD-8) Trino OUTPUT TRINO PART OCMADDR[0..21] PART-15 Trino INPUT FSDQS[0..3], FSDQM[0..3] 2OE2 2OE1 2OE2 2OE1 RXCB0 TXCB0 GPIO_42 TXCB2 2D10 2Q10 2D10 2Q10 FSDATA[0..31] RXCB1...
Page 22 HT-RC180 SCHEMATIC DIAGRAM-12 SPI0 & control signals U005 to 2nd DSP from HDMI Block HDMI CIRCUIT PC BOARD-5 from DIR Block BAHDM-0132-1D VDD_MPU3.3V C3202 105Z VDD_CSW3.3 (PART-17) NET/ USB SECTION TC74VHC157FT Q3202 DIG/NETUSB R3233 +3.3V SELECT TP96 BOOT3 R3208 ADSP_MCK SEL_MCK R3224 GPIO5_3/BOOT3...
Page 23 HT-RC180 SCHEMATIC DIAGRAM-13 for Debugging Boot Opt. NAND UART1 SPI0 R3115 or R3116 BOOT2 BOOT7 +5VHD BOOT1 U005 R3111 or R3112 BOOT5 TPD2E001DRLR BOOT0 R3109 or R3110 BOOT6 BOOT3 BOOT2 HDMI CIRCUIT PC BOARD-6 R3107 or R3108 BOOT7 BOOT3 is always pulled up. differencial impeadance = 90ohm SPI0 &...
Page 24 HT-RC180 SCHEMATIC DIAGRAM-14 HDMI CIRCUIT PC BOARD-7 BAHDM-0132-1D (PART-19) U005 DSP MEMORY SECTION GND_ARM VDD_MPU3.3V GND_ARM PA_12 MB_A12 C3001 105Z +3.3V R3009 L3001 PBA_0 MB_BA0 BLM18PG121SN1D PA_0 MB_A0 GND_ARM PA_1 MB_A1 C3002 105Z VDD_NAND3.3V C3003 106K/6.3 33x4 R3010 MB_A0 EMA_D0 +3.3V EMB_A0 EMA_D0/GPIO0_0/BOOT12...
Page 25 HT-RC180 SCHEMATIC DIAGRAM-15 HDMI CIRCUIT PC BOARD-8 U005 BAHDM-0132-1D (PART-20) DSP CONNECT SECTION (SD-7) (SD-6) TO_BAETC-0246 TO_BADG-0099 (Part-18) TO_BACPU-0101 (Part-19) (Part-17) NSCT-5P97 IMSA-9142B-18A IMSA-9142B-8A IMSA-9142B-16A JL3889B P3608A IMSA-9142B-18A P3605A P3606A P3607A GND_ARM from HDMI Block from HDMI Block SPI0 & control signals from DIR Block Host communication R3680...
Page 26 HT-RC180 SCHEMATIC DIAGRAM-16 U005 HDMI CIRCUIT PC BOARD-9 BAHDM-0132-1D (PART-21) DSP 2ND SECTION SPI0 & control signals GND_ARM TX-SR707/ DTR-40.1 from1stDSP TX-NR807/ DTR-50.1 R3411 R3410 EM2_A14 EM2_A15 to 2nd DSP R3416 EM2_A13 +3.3V BYTE EM2_A12 EM2_A11 EM2_D15 Q15/A-1 +1.2V EM2_A10 EM2_D7 EM2_A9 EM2_D14...
Page 27 HT-RC180 SCHEMATIC DIAGRAM-17 U005 HDMI CIRCUIT PC BOARD-10 BAHDM-0132-1D SPI0 & control signals (PART-22) DSP 3RD SECTION GND_ARM TX-SR707/ DTR-40.1 TX-NR807/ DTR-50.1 from 2nd DSP R3511 R3510 EM3_A14 EM3_A15 R3516 from 3rd DSP EM3_A13 +3.3V BYTE EM3_A12 EM3_A11 EM3_D15 Q15/A-1 +1.2V EM3_A10 EM3_D7...
Page 28 HT-RC180 HT-RC180 SCHEMATIC DIAGRAM-18 DISPLAY CIRCUIT PC BOARD-1 BADIS-0135-1A U004 (PART-26) BADIS-0135 NSCT-5P876 FLAC1 JL9303A FLAC2 JL9303 Q7500 5J300606B15 HNA-16SL05T Q7500A +3.3VMPU FL HOLDER GNDDG P7501:2009991154UL GNDVD AUX2CV_IN -15VA +15VA AUX2_R GNDAUX2 GNDAUX2 SEG2 SEG2 AUX2_L SEG1 SEG19 SEG20 SEG1 SEG19 SEG20 SEG0...
Page 29 HT-RC180 SCHEMATIC DIAGRAM-19 (PART-27) U0043 FRONT DIGITAL INPUT PC BOARD U0041 STANDBY SWITCH PC BOARD BASW-0136-1A BAETC-0138-1A D7590 D7589 D7592 D7593 JL7560A SCB3318E-D2 SLR-342MGTE7P SLR-342MGTE7P SLR-342MGTE7P R7520 U7520 NSCT-3P874 L7520 LEDSTBY D7595 LBC2518T2R2M SCB3318E-D2 LEDZ2 ZONE4 ZONE3 ZONE2 SLI-343URC-TE7 D7591 PURE AUDIO GREEN GREEN...
Page 30: Printed Circuit Board View
HT-RC180 PRINTED CIRCUIT BOARD VIEW-1 U001 Q6036 R6706 R6716 AMPLIFIRE CIRCUIT R6006 D6703 D6713 Q6006 R6721 R6016 Q6046 C6714 C6704 PC BOARD R6316 R6036 R6046 BAAMP-0072 R6704 R6714 D6701 C6701 Q6703 Q6713 D6702 C6703 C6713 Q6701 R6702 R6712 J6037 R6701 Q6702 L6016 R6708...
Page 31 HT-RC180 PRINTED CIRCUIT BOARD VIEW-2 E5519 U0011 AUDIO INPUT CIRCUIT PC BOARD BAASP-0073 J5515 J5563 Q5670A Q5670 Q5671 DHC-40.1 BCASP-0073 C5543 25140073 JL104A C5542 C5671 P5510D P5514B P5510B J5620 C5540 C5541 J5619 R5679 P5509B JL5514B C5660 R5660 R5688 C5684 C5685 R5687 R5678 D5501...
Page 32: Batrm
HT-RC180 PRINTED CIRCUIT BOARD VIEW-3 U002 SPEAKER TERMINAL-1 PC BOARD BATRM-0083 J6667 J6680 J6691 J6662 GNDA J6692 GNDA J6663 J6693 J6668 -15V +15V J6636 C6635 GNDDG GNDA R6635 JL6606A J6669 J6666 GND_C J6664 GNDDG GNDA J6689 J6631 GNDDG -15V C6634 GND_SL J6638 R6634...
Page 33 HT-RC180 PRINTED CIRCUIT BOARD VIEW-4 U0024 POWER AMP. INPUT CIRCUIT PC BOARD BACLA-0087 R5105 R5103 R5100 R5101 R5104 R5106 R5172 R5173 R5170 R5174 R5176 R5175 R5171 R5102 C5025 C5022 D5002 R5143 R5145 R5085 R5083 R5140 R5080 R5082 R5141 R5081 R5144 R5084 R5086 R5142...
Page 34 HT-RC180 PRINTED CIRCUIT BOARD VIEW-5 U0021 PRIMARY POWER SUPPLY PC BOARD BAPS-0084 RISK OF FIRE -REPLACE FUSE BCPS-0084 D912 AS MARKED 25140084 D911 C911 C901 E902 10A 125V F901 D923 D924 F901D F901C D933 D935 C903 D934 D931 AC SW AC CORD D930 P911...
Page 35 HT-RC180 PRINTED CIRCUIT BOARD VIEW-6 U003 DAC/DIR CIRCUIT PC BOARD BADG-0099 R1317 Q1322 R1325 R1323 R1321 R1320 P3605B R1318 C1403 C1402 C1401 C1407 C1311 C1405 R1811 L1301 C1404 P3607B Q1311 R1322 R1801 C1406 C1377 C1454 C1374 R1575 C1373 C1376 R1525 R1800 L1407 R1579...
Page 36: Bacpu
HT-RC180 PRINTED CIRCUIT BOARD VIEW-7 CPU CIRCUIT PC BOARD BACPU-0100 U0031 R1217 R1242 HPDET P1001A R1179 R1060 R1149 JL1015B R1153 R1218 R1156 R1165 P3608B R1057 R1167 Q1009 Q1008 R1026 Q1007 Q1020 D1005 APOWER_W C1040 R1069 R1176 R1196 GND_DG C1022 LEDSTBY R1008 R1189 LEDREADY...
Page 37 HT-RC180 PRINTED CIRCUIT BOARD VIEW-8 U0032 VIDEO CIRCUIT PC BOARD D4002 BAVD-0101 Q4000 D4016 POWERD +SUB R4024 D4001 R4178 R4179 R4180 R4186 GND_TU _MPU 12VRL C107 POFF C110 C105 Q102 R4507 PLLSCL FANCTRL PLLSDA STEREO STEREO RDSCLK Q4003 DATA C4006 PLLSDA C4134 PLLSCL...
Page 38: Baetc
HT-RC180 PRINTED CIRCUIT BOARD VIEW-9 U0033 UNIVERSAL PORT PC BOARD BAETC-0103 R1961 R1962 R1952 R1951 R1971 R1954 C1975 R1974 L1900 R1965 C1965 R1964 C1943 R1902 R1908 C1915 C1906 R1910 R1913 R1912 L1917 L1921 L1920 L1919 B side view C1923 C1977 L1905 C1913 L1902...
Page 39 HT-RC180 PRINTED CIRCUIT BOARD VIEW-10 P7591A P7501B C7506 JL9303A BCDIS-0135 25140135C J7642 LEDSTBY GNDDG U004 LEDZ2 LEDZ3 LEDZ4 LEDPURE KEY0 REMIN REMO_IN LED_REMO DISPLAY CIRCUIT BOARD FLD1CS FLD2CS Q7500 FLDRST GNDDG DIGCLK DIGSDO BADIS-0135 GNDDG GNDDG +3.3VST U7560 +3.3VMPU œ J7633 œ...
Page 40 HT-RC180 PRINTED CIRCUIT BOARD VIEW-11 U0041 STANDBY SWITCH PC BOARD BASW-0136 œ œ BCSW-0136 25140136 JL7590B LEDSTBY LEDZ2 D7595 LEDZ3 LEDZ4 LEDPURE œ KEY0 R7599 +5VMPU STANDBY GNDDG œ JL7590B KEY0_1 D7593 LEDSTBY LEDZ2 LEDZ3 R7597 LEDZ4 LEDPURE œ D7592 KEY0 R7596 +5VMPU...
Page 41 HT-RC180 PRINTED CIRCUIT BOARD VIEW-12 U0045 FUSE PC BOARD BAPS-0140 BCPS-0140 25140140 œ FLAC1 C9305 FLAC2 C9304 +3.3VMPU L9350 FLAC2 N.C. U0043 Q9301 FLAC1 -VP_AC1 -VP_AC1 F9301 FRONT DIGITAL INPUT DSP_AC2 œ œ 3.15A/125V DSP_AC1 +9VDG GNDDG PC BOARD BAETC-0138 GNDDG J7645 +5.9V...
Page 42 HT-RC180 PRINTED CIRCUIT BOARD VIEW-13 U005 HDMI CIRCUIT PC BOARD BAHDM-0132-1B R3116 R3603 P4104A 19P SOCKET AD IN DAC OUT R8278 R8079 R8065 R8622 R3115 R8279 R3510 P8641B R8066 R8277 C8077 R3604 Q3406 C8062 R8000 R3113 R3516 R3606 R3518 C8000 R8001 R3520 C8002...
Page 43 HT-RC180 PRINTED CIRCUIT BOARD VIEW-14 U005 HDMI CIRCUIT PC BOARD BAHDM-0132-1B C8291 R8048 C3509 C3507 C3523 R8275 R8274 R3468 C3454 R3466 R8049 C8041 C3556 R8276 C3460 Q8041 R8050 C3508 C3506 C8044 C8252 R8046 C3462 R8072 C8253 R8272 C8251 R8045 R8071 R8273 C8254 L8022...
Page 44: Packing Procedure
HT-RC180 PACKING PROCEDURE Procedure of door section A882 A861 A890 1. Open the Door. 2. Cushion (A616) on Front panel and fixed with the Fixlon tape (A615). A851 A883 A801 A870 A810 A616 A615 A876 A812 L=50mm A871 A616 A615 A877 L=50mm A875...
Page 45: Exploded View Parts List
1/113 PAGE HT-RC180 <Note> Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.
Page 46 2/113 PAGE P103 NCFC7-111012 2047111012 EXPLODED P4104 NCFC7-191012 2047191012 EXPLODED P500 WIRE TIE BSK-1 260208 EXPLODED P691 D05X-12TL 24502317 EXPLODED P693 D09A-12PG13 24502328 EXPLODED P7501 SOCKET AS NSAS-80P1788 2009991154UL EXPLODED P9008 SOCKET AS NSAS-3P1760 2009991127UL EXPLODED [CHASSIS SCREW] EXPLODED A001 CHASSIS 27100539 EXPLODED...
Page 47 3/113 PAGE A071 CLAMP WS-2NS 27300833 EXPLODED A075 HOLDER HOLDER KGLS-8S 27190480 EXPLODED A077 HOLDER KGPS-14RF 27190802 EXPLODED A079 HOLDER KGLS-14S 27190164 EXPLODED A081 HOLDER HOLDER KGLS-18S 27190470 EXPLODED A085 HOLDER KGLS-12RT 27190266 EXPLODED A087 HOLDER KGLS-10RT 27190428A EXPLODED A089 HOLDER KGLS-22RT 27190772...
Page 48 EXPLODED A545 E-WASHER ES-3S 8930301S EXPLODED A603 COVER (B) (Bent) 28210037 EXPLODED A603 COVER (B) (Not Bent) 28210037Z EXPLODED A605 LABEL HOOKUP-ONKYO 29363194 EXPLODED A607 LABEL (COVER) 29364123 EXPLODED A611 SCREW 3TTB+8B(3BC) 838430088GR EXPLODED A613 SCREW 4TTB+8C(3BC) 838440089GR EXPLODED [TUNER UNIT]...
Page 49: U003 Dac/ Dir Circuit Pc Board
5/113 PAGE U0022 Speaker terminal-2 PC board a'ssy BATRM-0085-1G EXPLODED 1B2345085-1G U0023 Center speaker terminal PC board a'ssy BATRM-0086-1G EXPLODED 1B2345086-1G U0024 Power amp. Input circuit PC board a'ssy BACLA-0087-1G EXPLODED 1B2345087-1G U003 DAC/ DIR circuit PC board a'ssy BADG-0099-1P * EXPLODED 1B2345099-1P U0031...
Page 50 6/113 PAGE D5507 or C-DIODE 1SS355 ( 1) 223269R2 PCB1 D5507 or C-DIODE KDS4148U ( 1) 223283R2 PCB1 D5507 or C-DIODE MA2J1110GL ( 1) 223302R2 PCB1 D5508 C-DIODE 1SS352 223234R2 PCB1 D5508 or C-DIODE 1SS355 ( 1) 223269R2 PCB1 D5508 or C-DIODE KDS4148U ( 1)
Page 51 7/113 PAGE D6004 C-DIODE 1SS352 223234R2 PCB1 D6004 or C-DIODE 1SS355 ( 1) 223269R2 PCB1 D6004 or C-DIODE KDS4148U ( 1) 223283R2 PCB1 D6004 or C-DIODE MA2J1110GL ( 1) 223302R2 PCB1 D6005 C-DIODE 1SS352 223234R2 PCB1 D6005 or C-DIODE 1SS355 ( 1) 223269R2 PCB1...
Page 52 8/113 PAGE Q5601 RN1441 2215410R2 PCB1 Q5602 RN1441 2215410R2 PCB1 Q5603 RN1441 2215410R2 PCB1 Q5604 RN1441 2215410R2 PCB1 Q5605 RN1441 2215410R2 PCB1 Q5606 RN1441 2215410R2 PCB1 Q5607 RN1441 2215410R2 PCB1 Q5610 RN1441 2215410R2 PCB1 Q5611 RN1441 2215410R2 PCB1 Q5612 RN1441 2215410R2 PCB1 Q5613...
Page 53 9/113 PAGE Q6001 2SC1740S-S 2213285T PCB1 Q6002 2SC1740S-S 2213285T PCB1 Q6003 2SC1740S-S 2213285T PCB1 Q6004 2SC1740S-S 2213285T PCB1 Q6005 2SC1740S-S 2213285T PCB1 Q6006 2SC1740S-S 2213285T PCB1 Q6010 2SC1740S-S 2213285T PCB1 Q6011 2SC1740S-S 2213285T PCB1 Q6012 2SC1740S-S 2213285T PCB1 Q6013 2SC1740S-S 2213285T PCB1 Q6014...
Page 54 10/113 PAGE Q6046 or 2SA949-Y(TPE6_F) ( 1) 2211354T PCB1 Q6070 2SC2229-O(TPE6_F) 2211633T PCB1 Q6070 or 2SC2229-Y(TPE6_F) ( 1) 2211634T PCB1 Q6071 2SC2229-O(TPE6_F) 2211633T PCB1 Q6071 or 2SC2229-Y(TPE6_F) ( 1) 2211634T PCB1 Q6072 2SC2229-O(TPE6_F) 2211633T PCB1 Q6072 or 2SC2229-Y(TPE6_F) ( 1) 2211634T PCB1 Q6073...
Page 55 11/113 PAGE Q6115 or 2SC5993-Q_P ( 1) 2217161 PCB1 Q6116 2SC5171(ONK_Q) 2203010 PCB1 Q6116 or 2SC5993-Q_P ( 1) 2217161 PCB1 Q6380 LM61CIZ 22242212 PCB1 Q6380A RETAINER (PTH) 27141884-1 PCB1 Q6701 2SC2712-GR 2213145R2 PCB1 Q6701 or KTC3875-GR ( 1) 2216175R2 PCB1 Q6702 2SC2712-GR 2213145R2...
Page 56 12/113 PAGE C5510 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5511 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5512 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5513 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5514 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5515 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5516 C-CERA C CC725CH1H-221J1 342102214R1 PCB1...
Page 57 13/113 PAGE C5573 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5574 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5575 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5576 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5579 C-CERA C CC725CH1H-102J1 342101024R1 PCB1 C5580 UTSP C CE04W10V-470M(UTSP) 397534717T PCB1 C5581...
Page 58 14/113 PAGE C5630 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5631 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5632 TF C ECQ-V50V-103J 374721034T PCB1 C5660 MMT C MMT50V-334J 375523344T PCB1 C5661 VR C CE04W50V-470M(VR) 394684717S PCB1 C5662 VR C CE04W50V-1000M(VR) 394681027S PCB1 C5666 UTSP C CE04W25V-220M(UTSP) 397552217T...
Page 59 15/113 PAGE C5739 UTSP C CE04W25V-220M(UTSP) 397552217T PCB1 C5905 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5906 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5907 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5908 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5910 C-CERA C CK725B1H-152K1 332101525R1 PCB1 C5911 C-CERA C CK725B1H-152K1...
Page 60 16/113 PAGE R4605 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R4606 C-CARBON R RN72K1J-102JE 435031024R1 PCB1 R4608 C-CARBON R RN72K1J-101JE 435031014R1 PCB1 R4612 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R4614 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R4616 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R4622 C-CARBON R RN72K1J-000JE 435030004R1 PCB1...
Page 61 17/113 PAGE R5545 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5546 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5547 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5548 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5549 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5550 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5551 C-CARBON R RN72K1J-224JE 435032244R1 PCB1...
Page 62 18/113 PAGE R5588 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R5590 C-CARBON R RN72K1J-223JE 435032234R1 PCB1 R5591 C-CARBON R RN72K1J-223JE 435032234R1 PCB1 R5592 C-CARBON R RN72K1J-332JE 435033324R1 PCB1 R5593 C-CARBON R RN72K1J-332JE 435033324R1 PCB1 R5594 C-CARBON R RN72K1J-331JE 435033314R1 PCB1 R5595 C-CARBON R RN72K1J-331JE 435033314R1 PCB1...
Page 63 19/113 PAGE R5633 C-CARBON R RN72K1J-122JE 435031224R1 PCB1 R5634 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R5635 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5636 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5637 METAL O R RS1/2WBJ-10 443521004T PCB1 R5638 METAL O R RS1/2WBJ-10 443521004T PCB1 R5639 C-CARBON R RN72K1J-331JE...
Page 64 20/113 PAGE R5681 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5682 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5683 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5684 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5685 CARBON R R16J-1.2K 417341224T PCB1 R5692 C-CARBON R RN72K1J-104JE 435031044R1 PCB1 R5693 C-CARBON R RN72K1J-472JE 435034724R1 PCB1...
Page 65 21/113 PAGE R5791 C-CARBON R RN72K1J-223JE 435032234R1 PCB1 R5792 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R5793 C-CARBON R RN72K1J-333JE 435033334R1 PCB1 R5794 C-CARBON R RN72K1J-333JE 435033334R1 PCB1 R5795 C-CARBON R RN72K1J-333JE 435033334R1 PCB1 R5796 C-CARBON R RN72K1J-682JE 435036824R1 PCB1 R5797 C-CARBON R RN72K1J-104JE 435031044R1 PCB1...
Page 66 22/113 PAGE R5846 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5847 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5848 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5849 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5850 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5851 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5852 C-CARBON R RN72K1J-000JE 435030004R1 PCB1...
Page 67 23/113 PAGE R5892 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5893 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5902 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5904 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5905 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5906 C-CARBON R RN72K1J-000JE 435030004R1 PCB1 R5907 C-CARBON R RN72K1J-000JE 435030004R1 PCB1...
Page 68 24/113 PAGE R6001 CARBON R R16J-4.7K 417344724T PCB1 R6002 CARBON R R16J-4.7K 417344724T PCB1 R6003 CARBON R R16J-4.7K 417344724T PCB1 R6004 CARBON R R16J-4.7K 417344724T PCB1 R6005 CARBON R R16J-4.7K 417344724T PCB1 R6006 CARBON R R16J-4.7K 417344724T PCB1 R6010 CARBON R R16J-3.3K 417343324T PCB1...
Page 69 25/113 PAGE R6076 NF CARBON R R25J-82 415478204T PCB1 R6080 CARBON R R16J-10 417341004T PCB1 R6081 CARBON R R16J-10 417341004T PCB1 R6082 CARBON R R16J-10 417341004T PCB1 R6083 CARBON R R16J-10 417341004T PCB1 R6084 CARBON R R16J-10 417341004T PCB1 R6085 CARBON R R16J-10 417341004T...
Page 70 26/113 PAGE R6154 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R6155 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R6156 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R6160 CARBON R R16J-33K 417343334T PCB1 R6161 CARBON R R16J-33K 417343334T PCB1 R6162 CARBON R R16J-33K 417343334T PCB1 R6163 CARBON R R16J-33K 417343334T PCB1...
Page 71 27/113 PAGE R6271 NF CARBON R R25J-18 415471804T PCB1 R6272 NF CARBON R R25J-18 415471804T PCB1 R6273 NF CARBON R R25J-18 415471804T PCB1 R6274 NF CARBON R R25J-18 415471804T PCB1 R6275 NF CARBON R R25J-18 415471804T PCB1 R6276 NF CARBON R R25J-18 415471804T PCB1...
Page 72 28/113 PAGE R6710 C-CARBON R RN72K1J-123JE 435031234R1 PCB1 R6712 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R6714 C-CARBON R RN72K1J-333JE 435033334R1 PCB1 R6716 C-CARBON R RN72K1J-563JE 435035634R1 PCB1 R6902 C-CARBON R RN72K1J-102JE 435031024R1 PCB1 R6903 C-CARBON R RN72K1J-473JE 435034734R1 PCB1 R6907 C-CARBON R RN72K1J-000JE 435030004R1 PCB1...
Page 73 29/113 PAGE P5509 CRIMP AS CRIMP AS 2069925170UL PCB1 P5510A SOCKET AS NSAS-26P1742 2009991118UL PCB1 P5510B PLUG NPLG-13P360 25055377 PCB1 P5510C CRIMP AS CRIMP SR805_2 20799170UL PCB1 P5510D CRIMP AS CRIMP SR805_1 20799169UL PCB1 P5512 SOCKET NSCT-15P2195 25052298 PCB1 P5513 SOCKET NSCT-19P2199 25052302...
Page 74 30/113 PAGE CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS PCB2 [SEMI CONDUCTOR] PCB2 D5000 ZENER D MTZJ5.6B 224470562T PCB2 D5001 ZENER D MTZJ5.6B 224470562T PCB2 D5002 ZENER D MTZJ5.6B 224470562T PCB2 D5003 ZENER D MTZJ5.6B 224470562T PCB2 D5004 ZENER D MTZJ5.6B...
Page 75 31/113 PAGE Q5016 2SC2240-BL(TPE2_F) 2211406T PCB2 Q5030 2SA949-Y(TPE6_F) 2211354T PCB2 Q5031 2SA949-Y(TPE6_F) 2211354T PCB2 Q5032 2SA949-Y(TPE6_F) 2211354T PCB2 Q5033 2SA949-Y(TPE6_F) 2211354T PCB2 Q5034 2SA949-Y(TPE6_F) 2211354T PCB2 Q5035 2SA949-Y(TPE6_F) 2211354T PCB2 Q5036 2SA949-Y(TPE6_F) 2211354T PCB2 Q5040 2SA949-Y(TPE6_F) 2211354T PCB2 Q5041 2SA949-Y(TPE6_F) 2211354T PCB2 Q5042...
Page 76 32/113 PAGE Q5065 or 2SA1360-O ( 1) 2202093 PCB2 Q5066 2SA1360-Y 2202094 PCB2 Q5066 or 2SA1360-O ( 1) 2202093 PCB2 Q5070 2SC3423-Y 2202104 PCB2 Q5070 or 2SC3423-O ( 1) 2202103 PCB2 Q5071 2SC3423-Y 2202104 PCB2 Q5071 or 2SC3423-O ( 1) 2202103 PCB2 Q5072...
Page 77 33/113 PAGE C5010 UTSJ C CE04W25V-47M(UTSJ) 398054707T PCB2 C5011 UTSJ C CE04W25V-47M(UTSJ) 398054707T PCB2 C5012 UTSJ C CE04W25V-47M(UTSJ) 398054707T PCB2 C5013 UTSJ C CE04W25V-47M(UTSJ) 398054707T PCB2 C5014 UTSJ C CE04W25V-47M(UTSJ) 398054707T PCB2 C5015 UTSJ C CE04W25V-47M(UTSJ) 398054707T PCB2 C5016 UTSJ C CE04W25V-47M(UTSJ) 398054707T PCB2...
Page 78 34/113 PAGE C5095 UPZ C 2AUPZTF101JE 376331014T PCB2 C5096 UPZ C 2AUPZTF101JE 376331014T PCB2 C5100 VR C CE04W100V-22M(VR) 394692207T PCB2 C5101 VR C CE04W100V-22M(VR) 394692207T PCB2 C5102 VR C CE04W100V-22M(VR) 394692207T PCB2 C5103 VR C CE04W100V-22M(VR) 394692207T PCB2 C5104 VR C CE04W100V-22M(VR) 394692207T PCB2...
Page 79 35/113 PAGE C901 IS C ECQU2A103MLC 3800039S PCB2 C901 or IS C RE275V-103M ( 1) 3500196S PCB2 C901 or IS C LE103-C3.5 ( 1) 3800042S PCB2 C902 TF C ECQ-V50V-104J 374721044T PCB2 C903 PLA C MKP R46 104M 3800041S PCB2 C911 MKT C B32529C0102J289...
Page 80 36/113 PAGE R5041 CARBON R R16J-1K 417341024T PCB2 R5042 CARBON R R16J-1K 417341024T PCB2 R5043 CARBON R R16J-1K 417341024T PCB2 R5044 CARBON R R16J-1K 417341024T PCB2 R5045 CARBON R R16J-1K 417341024T PCB2 R5046 CARBON R R16J-1K 417341024T PCB2 R5050 CARBON R R16J-5.6K 417345624T PCB2...
Page 81 37/113 PAGE R5106 CARBON R R16J-100K 417341044T PCB2 R5110 CARBON R R16J-2.2K 417342224T PCB2 R5111 CARBON R R16J-2.2K 417342224T PCB2 R5112 CARBON R R16J-2.2K 417342224T PCB2 R5113 CARBON R R16J-2.2K 417342224T PCB2 R5114 CARBON R R16J-2.2K 417342224T PCB2 R5115 CARBON R R16J-2.2K 417342224T PCB2...
Page 82 38/113 PAGE R5164 NF CARBON R R25J-820 415478214T PCB2 R5165 NF CARBON R R25J-820 415478214T PCB2 R5166 NF CARBON R R25J-820 415478214T PCB2 R5170 NF CARBON R R25J-820 415478214T PCB2 R5171 NF CARBON R R25J-820 415478214T PCB2 R5172 NF CARBON R R25J-820 415478214T PCB2...
Page 83 39/113 PAGE R5222 NF CARBON R R25J-120 415471214T PCB2 R5223 NF CARBON R R25J-120 415471214T PCB2 R5224 NF CARBON R R25J-120 415471214T PCB2 R5225 NF CARBON R R25J-120 415471214T PCB2 R5226 NF CARBON R R25J-120 415471214T PCB2 R5300 CARBON R R16J-330 417343314T PCB2...
Page 84 40/113 PAGE R6690 METAL R RNU1WCJ-8.2 453630824T PCB2 R6691 METAL O R RS1/2WBJ-390 443523914T PCB2 R6692 METAL O R RS1/2WBJ-390 443523914T PCB2 R921 METAL O R RS1/2WBJ-47 443524704T PCB2 R922 METAL O R RS1/2WBJ-68 443526804T PCB2 R934 CARBON R R16J-33K 417343334T PCB2 [SW TRM]...
Page 85: Badg
41/113 PAGE P6601 NTM-2PDMCR400 25060472 PCB2 P6602 NTM-2PDMCR400 25060472 PCB2 P6603 NTM-2PDMCR400 25060472 PCB2 P6604 NTM-2PDMCR400 25060472 PCB2 P6605 NTM-2PDMCR400 25060472 PCB2 P6606 NTM-2PDMCR400 25060472 PCB2 P6607 NTM-2PDMCR400 25060472 PCB2 P6608 NTM-2PDMCR400 25060472 PCB2 P6609 NTM-2PDMCR400 25060472 PCB2 P6610 NTM-2PDMCR400 25060472 PCB2 P6621...
Page 86 42/113 PAGE U1301 PHT CP JSR1165-001recieving 24120143 PCB3 U1302 PHT CP JSR1165-001recieving 24120143 PCB3 [SEMI CONDUCTOR] PCB3 D1001 C-DIODE 1SS352 223234R2 PCB3 D1001 or C-DIODE MA2J111 ( 1) 223279R2 PCB3 D1001 or C-DIODE KDS4148U ( 1) 223283R2 PCB3 D1002 C-DIODE 1SS352 223234R2 PCB3...
Page 87 43/113 PAGE D4501 C-DIODE 1SS352 223234R2 PCB3 D4501 or C-DIODE MA2J111 ( 1) 223279R2 PCB3 D4501 or C-DIODE KDS4148U ( 1) 223283R2 PCB3 D4606 DIODE RL1N4003 22380260T PCB3 NJM4580M-D 22241448R2 PCB3 Q1001 KRC104S 2216210R2 PCB3 Q1001 or RN1404 ( 1) 2214490R2 PCB3 Q1002...
Page 88: Cs42516-Cq
44/113 PAGE Q1028 KRC104S 2216210R2 PCB3 Q1029 KRA102S 2216220R2 PCB3 Q1030 KRC104S 2216210R2 PCB3 Q1031 KRA102S 2216220R2 PCB3 Q1032 KRC104S 2216210R2 PCB3 Q1033 KRA102S 2216220R2 PCB3 Q1034 KRC104S 2216210R2 PCB3 Q1035 KRA102S 2216220R2 PCB3 Q1036 KRC104S 2216210R2 PCB3 Q1037 KRA102S 2216220R2 PCB3 Q1038...
Page 89 45/113 PAGE Q4000 or RN1405 ( 1) 2214500R2 PCB3 Q4001 78M05(NJM78M05FA) 222780055JRC PCB3 Q4002 SI8008TM 22242323R2 PCB3 Q4003 KRC105S 2217290R2 PCB3 Q4003 or RN1405 ( 1) 2214500R2 PCB3 Q4100 NJW1325 22242596R3 PCB3 Q4101 TR ARRAY UM6K1N 226066R2 PCB3 Q4500 2SA950-Y 2211504T PCB3 Q4500 or...
Page 90 46/113 PAGE L1407 CHOKE COIL LBC2518T4R7M 231364M047R2 PCB3 L1900 CHOKE COIL BLM21PG221SN1 230949R2 PCB3 L1901 CHOKE COIL BLM21PG221SN1 230949R2 PCB3 L1902 EMIFIL BK1608LM182-T 230958R1 PCB3 L1903 EMIFIL BK1608LM182-T 230958R1 PCB3 L1904 EMIFIL BK1608LM182-T 230958R1 PCB3 L1905 EMIFIL BK1608LM182-T 230958R1 PCB3 L1906 CHOKE COIL BLM21PG221SN1...
Page 91 47/113 PAGE C1010 C-CERA C CC725CH1H-101J1 342101014R1 PCB3 C1015 UTSP C CE04W25V-100M(UTSP) 397551017T PCB3 C1017 UTSP C CE04W10V-100M(UTSP) 397531017T PCB3 C1019 UTSP C CE04W10V-100M(UTSP) 397531017T PCB3 C1020 C-CERA C CK725F1A-105Z1 332181050R1 PCB3 C1021 C-CERA C CK725B1H-102K1 332101025R1 PCB3 C1022 C-CERA C CK725B1H-102K1 332101025R1 PCB3...
Page 92 48/113 PAGE C1292 UTSP C CE04W50V-10M(UTSP) 397581007T PCB3 C1293 UTSP C CE04W50V-10M(UTSP) 397581007T PCB3 C1294 UTSP C CE04W50V-22M(UTSP) 397582207T PCB3 C1295 UTSP C CE04W50V-22M(UTSP) 397582207T PCB3 C1296 UTSP C CE04W50V-22M(UTSP) 397582207T PCB3 C1302 UTSP C CE04W10V-100M(UTSP) 397531017T PCB3 C1303 UTSP C CE04W50V 47M(UTSP) 397584707T PCB3...
Page 93 49/113 PAGE C1403 C-CERA C CC725CH1H-330J1 342103304R1 PCB3 C1404 C-CERA C CC725CH1H-330J1 342103304R1 PCB3 C1405 C-CERA C CC725CH1H-330J1 342103304R1 PCB3 C1406 C-CERA C CC725CH1H-330J1 342103304R1 PCB3 C1408 C-CERA C CC725CH1H-080D1 342100802R1 PCB3 C1409 C-CERA C CC725CH1H-080D1 342100802R1 PCB3 C1410 UTSP C CE04W10V-470M(UTSP) 397534717T PCB3...
Page 94 50/113 PAGE C1617 CERA C CC45SL50V-101J 345021014T PCB3 C1620 CERA C CC45SL50V-101J 345021014T PCB3 C1621 CERA C CC45SL50V-101J 345021014T PCB3 C1622 CERA C CC45SL50V-101J 345021014T PCB3 C1623 CERA C CC45SL50V-101J 345021014T PCB3 C1624 CERA C CC45SL50V-101J 345021014T PCB3 C1625 CERA C CC45SL50V-101J 345021014T PCB3...
Page 95 51/113 PAGE C1953 UTSP C CE04W50V-10M(UTSP) 397581007T PCB3 C1954 UTSP C CE04W10V-100M(UTSP) 397531017T PCB3 C1955 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C1956 C-CERA C CC725CH1H-470J1 342104704R1 PCB3 C1957 C-CERA C CC725CH1H-470J1 342104704R1 PCB3 C1961 VR C CE04W6.3V-470M(VR) 394624717T PCB3 C1962 VR C CE04W6.3V-470M(VR) 394624717T PCB3...
Page 96 52/113 PAGE C4111 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C4112 C-CERA C CK725B1H-102K1 332101025R1 PCB3 C4114 UTSP C CE04W50V-1M(UTSP) 397580107T PCB3 C4115 VR C CE04W6.3V-470M(VR) 394624717T PCB3 C4119 VR C CE04W6.3V-470M(VR) 394624717T PCB3 C4121 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C4122 UTSP C CE04W50V-1M(UTSP) 397580107T PCB3...
Page 97 53/113 PAGE C4175 C-CERA C CK725F1A-105Z1 332181050R1 PCB3 C4176 UTSP C CE04W50V-1M(UTSP) 397580107T PCB3 C4179 UTSP C CE04W50V-2.2M(UTSP) 397580227T PCB3 C4183 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C4184 UTSP C CE04W25V-47M(UTSP) 397554707T PCB3 C4186 UTSP C CE04W25V-47M(UTSP) 397554707T PCB3 C4187 UTSP C CE04W25V-47M(UTSP) 397554707T PCB3...
Page 98 54/113 PAGE C4254 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C4255 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C4256 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C4500 UTSP C CE04W25V-220M(UTSP) 397552217T PCB3 C4501 UTSP C CE04W25V-220M(UTSP) 397552217T PCB3 C4502 UTSP C CE04W25V-220M(UTSP) 397552217T PCB3 C4503 UTSP C CE04W25V-220M(UTSP) 397552217T PCB3...
Page 99 55/113 PAGE R1028 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R1029 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R1031 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R1032 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R1033 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R1034 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R1035 C-CARBON R RN72K1J-103JE 435031034R1 PCB3...
Page 100 56/113 PAGE R1071 C-CARBON R RN72K1J-473JE 435034734R1 PCB3 R1072 C-CARBON R RN72K1J-473JE 435034734R1 PCB3 R1073 C-CARBON R RN72K1J-473JE 435034734R1 PCB3 R1074 C-CARBON R RN72K1J-473JE 435034734R1 PCB3 R1075 C-CARBON R RN72K1J-102JE 435031024R1 PCB3 R1077 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R1078 C-CARBON R RN72K1J-221JE 435032214R1 PCB3...
Page 101 57/113 PAGE R1119 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R1120 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R1121 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R1122 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R1123 C-CARBON R RN72K1J-473JE 435034734R1 PCB3 R1124 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R1126 C-CARBON R RN72K1J-221JE 435032214R1 PCB3...
Page 102 58/113 PAGE R1166 C-CARBON R RN72K1J-472JE 435034724R1 PCB3 R1167 C-CARBON R RN72K1J-472JE 435034724R1 PCB3 R1168 C-CARBON R RN72K1J-272JE 435032724R1 PCB3 R1170 C-CARBON R RN72K1J-272JE 435032724R1 PCB3 R1171 C-CARBON R RN72K1J-272JE 435032724R1 PCB3 R1172 C-CARBON R RN72K1J-272JE 435032724R1 PCB3 R1173 C-CARBON R RN72K1J-470JE 435034704R1 PCB3...
Page 103 59/113 PAGE R1211 C-CARBON R RN72K1J-473JE 435034734R1 PCB3 R1212 C-CARBON R RN72K1J-473JE 435034734R1 PCB3 R1213 C-CARBON R RN72K1J-272JE 435032724R1 PCB3 R1214 C-CARBON R RN72K1J-272JE 435032724R1 PCB3 R1217 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R1218 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R1219 C-CARBON R RN72K1J-332JE 435033324R1 PCB3...
Page 104 60/113 PAGE R1273 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R1274 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R1275 C-CARBON R RN72K1J-823JE 435038234R1 PCB3 R1280 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R1281 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R1282 C-CARBON R RN72K1J-273JE 435032734R1 PCB3 R1283 C-CARBON R RN72K1J-470JE 435034704R1 PCB3...
Page 105 61/113 PAGE R1325 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R1485 C-CARBON R RN72K1J-100JE 435031004R1 PCB3 R1486 C-CARBON R RN72K1J-100JE 435031004R1 PCB3 R1487 C-CARBON R RN72K1J-750JE 435037504R1 PCB3 R1488 C-CARBON R RN72K1J-224JE 435032244R1 PCB3 R1490 C-CARBON R RN72K1J-750JE 435037504R1 PCB3 R1491 C-CARBON R RN72K1J-224JE 435032244R1 PCB3...
Page 106 62/113 PAGE R1567 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1568 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1569 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1570 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1571 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1572 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1573 C-CARBON R RN72K1J-221JE 435032214R1 PCB3...
Page 107 63/113 PAGE R1633 C-CARBON R RN72K1J-123JE 435031234R1 PCB3 R1634 C-CARBON R RN72K1J-123JE 435031234R1 PCB3 R1635 C-CARBON R RN72K1J-123JE 435031234R1 PCB3 R1636 C-CARBON R RN72K1J-123JE 435031234R1 PCB3 R1637 C-CARBON R RN72K1J-123JE 435031234R1 PCB3 R1640 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R1641 C-CARBON R RN72K1J-103JE 435031034R1 PCB3...
Page 108 64/113 PAGE R1773 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R1774 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R1775 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R1776 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R1777 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R1780 METAL O R RS1/2WBJ-22 443522204T PCB3 R1781 METAL O R RS1/2WBJ-22 443522204T...
Page 109 65/113 PAGE R1955 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1956 C-CARBON R RN72K1J-105JE 435031054R1 PCB3 R1961 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1962 C-CARBON R RN72K1J-220JE 435032204R1 PCB3 R1963 C-CARBON R RN72K1J-750JE 435037504R1 PCB3 R1964 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R1965 C-CARBON R RN72K1J-220JE 435032204R1 PCB3...
Page 110 66/113 PAGE R4121 C-CARBON R RN72K1J-750JE 435037504R1 PCB3 R4122 C-CARBON R RN72K1J-750JE 435037504R1 PCB3 R4123 C-CARBON R RN72K1J-104JE 435031044R1 PCB3 R4124 C-CARBON R RN72K1J-750JE 435037504R1 PCB3 R4125 C-CARBON R RN72K1J-104JE 435031044R1 PCB3 R4126 C-CARBON R RN72K1J-750JE 435037504R1 PCB3 R4127 C-CARBON R RN72K1J-104JE 435031044R1 PCB3...
Page 111 67/113 PAGE R4169 C-CARBON R RN72K1J-101JE 435031014R1 PCB3 R4170 C-CARBON R RN72K2E-022JE 435220224R1 PCB3 R4171 C-CARBON R RN72K2E-022JE 435220224R1 PCB3 R4172 C-CARBON R RN72K1J-682JE 435036824R1 PCB3 R4173 C-CARBON R RN72K1J-682JE 435036824R1 PCB3 R4174 C-CARBON R RN72K2E-022JE 435220224R1 PCB3 R4175 C-CARBON R RN72K1J-000JE 435030004R1 PCB3...
Page 112 68/113 PAGE R4229 C-CARBON R RN72K1J-331JE 435033314R1 PCB3 R4233 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R4235 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R4238 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R4258 C-CARBON R RN72K2E-022JE 435220224R1 PCB3 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 NF CARBON R R25J-10 415471004T PCB3...
Page 113 69/113 PAGE C-CARBON R RN72K1J-103JE 435031034R1 PCB3 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 [SW TRM] PCB3 E1911 TRM-423(SCREW) NEJITANSI ST3 25060495 PCB3 F4000A FUSE HOL NSCT-1P2031 25052133T PCB3 F4000B FUSE HOL NSCT-1P2031 25052133T PCB3...
Page 114 70/113 PAGE P4112 PIN JACK NPJ-10PDBY621 25045842 PCB3 P4112 or PIN JACK NPJ-10PDBY478 ( 1) 25045681 PCB3 P4113 PIN JACK NPJ-10PDBY621 25045842 PCB3 P4113 or PIN JACK NPJ-10PDBY478 ( 1) 25045681 PCB3 P4114 PIN JACK NPJ-10PDBY621 25045842 PCB3 P4114 or PIN JACK NPJ-10PDBY478 ( 1)
Page 115 71/113 PAGE D7521 or C-DIODE KDS4148U ( 1) 223283R2 PCB4 D7522 C-DIODE 1SS355 223269R2 PCB4 D7522 or C-DIODE 1SS352 ( 1) 223234R2 PCB4 D7522 or C-DIODE MA2J111 ( 1) 223279R2 PCB4 D7522 or C-DIODE KDS4148U ( 1) 223283R2 PCB4 D7523 C-DIODE 1SS355 223269R2...
Page 116 72/113 PAGE D7583 or C-DIODE 1SS352 ( 1) 223234R2 PCB4 D7583 or C-DIODE MA2J111 ( 1) 223279R2 PCB4 D7583 or C-DIODE KDS4148U ( 1) 223283R2 PCB4 D7585 SCB3318E-D2 225487 PCB4 D7590 SCB3318E-D2 225487 PCB4 D7592 SLR-342MGTE7P 225455T PCB4 D7593 SLR-342MGTE7P 225455T PCB4 D7595...
Page 117 73/113 PAGE C7501 C-CERA C CK725B1H-223K1 332102235R1 PCB4 C7502 C-CERA C CK725F1E-104Z1 332161040R1 PCB4 C7503 C-CERA C CK725F1E-104Z1 332161040R1 PCB4 C7504 C-CERA C CK725B1H-473K1 332104735R1 PCB4 C7505 C-CERA C CK725B1H-473K1 332104735R1 PCB4 C7506 ELECT C CE04W50V-33M 355783309T PCB4 C7511 C-CERA C CK725F1E-104Z1 332161040R1 PCB4...
Page 118 74/113 PAGE C9306 TF C ECQ-V50V-223J 374722234T PCB4 [RESISTOR] PCB4 R7500 C-CARBON R RN72K1J-221JE 435032214R1 PCB4 R7501 C-CARBON R RN72K1J-221JE 435032214R1 PCB4 R7502 C-CARBON R RN72K1J-273JE 435032734R1 PCB4 R7503 C-CARBON R RN72K1J-222JE 435032224R1 PCB4 R7504 C-CARBON R RN72K1J-222JE 435032224R1 PCB4 R7505 C-CARBON R RN72K1J-222JE...
Page 119 75/113 PAGE R7592 C-CARBON R RN72K1J-103JE 435031034R1 PCB4 R7593 C-CARBON R RN72K1J-103JE 435031034R1 PCB4 R7594 C-CARBON R RN72K1J-121JE 435031214R1 PCB4 R7596 C-CARBON R RN72K1J-181JE 435031814R1 PCB4 R7597 C-CARBON R RN72K1J-181JE 435031814R1 PCB4 R7599 C-CARBON R RN72K1J-102JE 435031024R1 PCB4 R7600 C-CARBON R RN72K1J-121JE 435031214R1 PCB4...
Page 120 76/113 PAGE R7647 C-CARBON R RN72K1J-222JE 435032224R1 PCB4 R7648 C-CARBON R RN72K1J-392JE 435033924R1 PCB4 R7649 C-CARBON R RN72K1J-123JE 435031234R1 PCB4 R7802 C-CARBON R RN72K1J-103JE 435031034R1 PCB4 R7939 C-CARBON R RN72K1J-104JE 435031044R1 PCB4 R7954 C-CARBON R RN72K1J-104JE 435031044R1 PCB4 R9304 METAL O R RS1/2WBJ-10 443521004T PCB4...
Page 121: U005 Hdmi Circuit Pc Board
77/113 PAGE S7613 PUSH SW NPS-111-S681 25035718T PCB4 S7614 PUSH SW NPS-111-S681 25035718T PCB4 S7615 PUSH SW NPS-111-S681 25035718T PCB4 S7616 PUSH SW NPS-111-S681 25035718T PCB4 S7618 PUSH SW NPS-111-S681 25035718T PCB4 S7619 PUSH SW NPS-111-S681 25035718T PCB4 S7620 PUSH SW NPS-111-S681 25035718T PCB4...
Page 122 78/113 PAGE PCB5 CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS PCB5 [SEMI CONDUCTOR] PCB5 D3101 C-DIODE KDS4148U 223283R2 PCB5 D3101 or C-DIODE 1SS352 ( 1) 223234R2 PCB5 D3401 C-DIODE KDS4148U 223283R2 PCB5 D3401 or C-DIODE 1SS352 ( 1) 223234R2 PCB5 D8041...
Page 123 79/113 PAGE Q3202 TC74VHC157FT 22274157ER2TO PCB5 Q3204 TC7SZU04FU 22242512R2TO PCB5 Q3205 TC7SZU04FU 22242512R2TO PCB5 Q3206 NE5532APSR 22242283R2 PCB5 Q3207 NE5532APSR 22242283R2 PCB5 Q3210 TC7WH241FU(TE12L_F) 22242076R2TO PCB5 Q3401 ES29LV160ET-70TG (0324) 222W0069R303247 PCB5 Q3401 or S29AL016D70TFI010 (0324) ( 1) 222W0063R303247 PCB5 Q3401 or S29AL016J70TFI010 (0324) ( 1) 222W0100R303247...
Page 124 80/113 PAGE Q8595 TA48018BF(TE16L_NQ) 22278018DBR2TO PCB5 Q8652 BH33FB1WG-TR 22242585R2 PCB5 Q8654 BD7820 22242300R2 PCB5 Q8701 IC (HDMI/ VIDEO) MPD70F3739GC-UEU-AX(0299) 222W0102R302995 PCB5 Q8813 TC74VCX162827 22242395R2 PCB5 Q8814 TC74VCX162827 22242395R2 PCB5 Q8817 TC74VCX162827 22242395R2 PCB5 Q8818 TC74VCX162827 22242395R2 PCB5 Q8951 MP1593DN 22242601R2 PCB5 Q8952 MP1593DN...
Page 125 81/113 PAGE L3204 CORE MMZ1608Y601BT 2350004R1 PCB5 L3205 CORE BLM18PG121SN1D 2350006R1 PCB5 L3206 CORE BLM18PG121SN1D 2350006R1 PCB5 L3207 CORE MMZ1608Y601BT 2350004R1 PCB5 L3208 CORE MMZ1608Y601BT 2350004R1 PCB5 L3209 CORE MMZ1608Y601BT 2350004R1 PCB5 L3401 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 L3402 CORE BLM18PG121SN1D 2350006R1 PCB5...
Page 126 82/113 PAGE L8408 CORE BLM18PG181SN1D 2350005R1 PCB5 L8409 C-R NET MNR12E0APJ000 43464900002R2 PCB5 L8410 C-R NET MNR12E0APJ000 43464900002R2 PCB5 L8601 CORE BLM18PG181SN1D 2350005R1 PCB5 L8602 CORE BLM18PG181SN1D 2350005R1 PCB5 L8603 CORE BLM18PG181SN1D 2350005R1 PCB5 L8604 CORE BLM18PG181SN1D 2350005R1 PCB5 L8605 CORE BLM18PG181SN1D 2350005R1...
Page 127 83/113 PAGE C3001 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3002 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3003 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3004 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3005 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3006 C-CERA C CC725CH1H-102J1 342101024R1 PCB5 C3007 C-CERA C CK725F1A-105Z1 332181050R1 PCB5...
Page 128 84/113 PAGE C3041 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3042 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3043 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3105 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3106 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3107 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3108 C-CERA C CK725F1A-105Z1 332181050R1 PCB5...
Page 129 85/113 PAGE C3145 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3146 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3147 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3148 C-CERA C CK725B1H-223K1 332102235R1 PCB5 C3149 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3150 CHIP ELECT C CEWX4V-22M 3981G2207R2 PCB5 C3151 C-CERA C CK725B1H-103K1 332101035R1...
Page 130 86/113 PAGE C3402 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3403 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3404 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3405 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3406 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3407 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3408 C-CERA C CK725F1A-105Z1 332181050R1 PCB5...
Page 131 87/113 PAGE C3443 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3444 C-CERA C CC725CH1H-102J1 342101024R1 PCB5 C3445 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C3446 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3447 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3448 C-CERA C CK725B0J-106K 332091065R2 PCB5 C3449 C-CERA C CK725F1A-105Z1 332181050R1 PCB5...
Page 132 88/113 PAGE C8016 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8017 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8018 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8021 CHIP ELECT C CEWX16V-100M 398141017R2 PCB5 C8022 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8023 CHIP ELECT C CEWX4V-100M 3981G1017R2 PCB5 C8026 CHIP ELECT C CEWX4V-220M...
Page 133 89/113 PAGE C8162 CHIP ELECT C CEWX4V-100M 3981G1017R2 PCB5 C8163 C-CERA C CK725B1H-102K1 332101025R1 PCB5 C8164 C-CERA C CK725B0J-106K 332091065R2 PCB5 C8165 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8166 C-CERA C CK725B0J-106K 332091065R2 PCB5 C8167 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8168 C-CERA C CK725B0J-106K 332091065R2...
Page 134 90/113 PAGE C8218 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8219 CHIP TANTAL TCSCS0J226MAAR 396522207R2 PCB5 C8219 or CHIP TANTAL F93-6.3V-22M ( 1) 395522207R2 PCB5 C8220 CHIP TANTAL TCSCS0J226MAAR 396522207R2 PCB5 C8220 or CHIP TANTAL F93-6.3V-22M ( 1) 395522207R2 PCB5 C8221 C-CERA C CK725B1H-103K1 332101035R1 PCB5...
Page 135 91/113 PAGE C8253 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8254 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8255 CHIP TANTAL TCSCS0J226MAAR 396522207R2 PCB5 C8255 or CHIP TANTAL F93-6.3V-22M ( 1) 395522207R2 PCB5 C8256 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8257 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8258 CHIP TANTAL...
Page 136 92/113 PAGE C8332 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8341 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 C8342 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 C8348 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 C8349 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 C8362 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8364 C-CERA C CK725B0J-106K 332091065R2 PCB5...
Page 137 93/113 PAGE C8418 CHIP ELECT C CEWX4V-22M 3981G2207R2 PCB5 C8419 C-CERA C CK725B1H-102K1 332101025R1 PCB5 C8420 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8421 C-CERA C CK725B1H-102K1 332101025R1 PCB5 C8422 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8423 C-CERA C CK725B1H-102K1 332101025R1 PCB5 C8424 C-CERA C CK725F1A-105Z1 332181050R1...
Page 138 94/113 PAGE C8517 C-CERA C CK725B1H-102K1 332101025R1 PCB5 C8518 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8519 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8521 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8522 C-CERA C CK725B0J-106K 332091065R2 PCB5 C8525 C-CERA C CK725B0J-106K 332091065R2 PCB5 C8527 C-CERA C CK725B1H-102K1 332101025R1 PCB5...
Page 139 95/113 PAGE C8584 C-CERA C CK725B0J-106K 332091065R2 PCB5 C8585 C-CERA C CK725B0J-106K 332091065R2 PCB5 C8605 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 C8608 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8609 C-CERA C CK725B0J-106K 332091065R2 PCB5 C8611 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 C8612 C-CARBON R RN72K1J-000JE 435030004R1 PCB5...
Page 140 96/113 PAGE C8869 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8870 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8951 C-CERA C CK725B1C-104K1 332121045R1 PCB5 C8952 C-CERA C CK725F1A-105Z1 332181050R1 PCB5 C8953 CD C UCD1E221MNL1GS 396652217R2 PCB5 C8954 C-CERA C CK725B1H-103K1 332101035R1 PCB5 C8955 C-CERA C CK725B1H-332K1 332103325R1 PCB5...
Page 141 97/113 PAGE R272 C-CARBON R RN72K1J-331JE 435033314R1 PCB5 R273 C-CARBON R RN72K1J-331JE 435033314R1 PCB5 R274 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R275 C-CARBON R RN72K1J-221JE 435032214R1 PCB5 R276 C-CARBON R RN72K1J-221JE 435032214R1 PCB5 R277 C-CARBON R RN72K1J-151JE 435031514R1 PCB5 R278 C-CARBON R RN72K1J-331JE 435033314R1 PCB5...
Page 142 98/113 PAGE R3043 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R3044 C-R NET RM7LJ330X04 43484733004R2 PCB5 R3045 C-R NET RM7LJ330X04 43484733004R2 PCB5 R3047 C-CARBON R RN72K1J-560JE 435035604R1 PCB5 R3048 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R3049 C-CARBON R RN72K1J-560JE 435035604R1 PCB5 R3050 C-CARBON R RN72K1J-560JE 435035604R1 PCB5...
Page 143 99/113 PAGE R3132 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3133 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3134 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3135 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3136 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R3137 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R3139 C-CARBON R RN72K1J-101JE 435031014R1 PCB5...
Page 144 100/113 PAGE R3181 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3182 C-CARBON R RN72K1J-472JE 435034724R1 PCB5 R3183 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3184 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3185 C-CARBON R RN72K1J-392FE 435033922R1 PCB5 R3186 C-CARBON R RN72K1J-472JE 435034724R1 PCB5 R3187 C-CARBON R RN72K1J-223FE 435032232R1 PCB5...
Page 145 101/113 PAGE R3236 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3237 C-CARBON R RN72K1J-221JE 435032214R1 PCB5 R3238 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3239 C-CARBON R RN72K1J-221JE 435032214R1 PCB5 R3240 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3241 C-CARBON R RN72K1J-221JE 435032214R1 PCB5 R3242 C-CARBON R RN72K1J-221JE 435032214R1 PCB5...
Page 146 102/113 PAGE R3280 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3281 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3282 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3283 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3284 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3285 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3286 C-CARBON R RN72K1J-103JE 435031034R1 PCB5...
Page 147 103/113 PAGE R3405 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3406 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3407 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3408 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3409 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3410 C-CARBON R RN72K1J-221JE 435032214R1 PCB5 R3411 C-CARBON R RN72K1J-221JE 435032214R1 PCB5...
Page 148 104/113 PAGE R3447 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3448 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3449 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3450 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R3451 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3452 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R3453 C-CARBON R RN72K1J-103JE 435031034R1 PCB5...
Page 149 105/113 PAGE R8002 C-CARBON R RN72K1J-271JE 435032714R1 PCB5 R8003 C-CARBON R RN72K1J-271JE 435032714R1 PCB5 R8010 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8011 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8012 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8013 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8014 C-CARBON R RN72K1J-103JE 435031034R1 PCB5...
Page 150 106/113 PAGE R8062 C-CARBON R RN72K1J-220JE 435032204R1 PCB5 R8063 C-CARBON R RN72K1J-220JE 435032204R1 PCB5 R8064 C-CARBON R RN72K1J-220JE 435032204R1 PCB5 R8065 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8066 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8067 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8068 C-CARBON R RN72K1J-750JE 435037504R1 PCB5...
Page 151 107/113 PAGE R8212 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8213 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8214 C-CARBON R RN72K1J-272JE 435032724R1 PCB5 R8215 C-CARBON R RN72K1J-272JE 435032724R1 PCB5 R8219 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8223 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8224 C-CARBON R RN72K1J-103JE 435031034R1 PCB5...
Page 152 108/113 PAGE R8279 C-R NET RM7LJ220X04 43484722004R2 PCB5 R8280 C-CARBON R RN72K1J-120JE 435031204R1 PCB5 R8282 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8333 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8334 C-CARBON R RN72K1J-222JE 435032224R1 PCB5 R8335 C-CARBON R RN72K1J-222JE 435032224R1 PCB5 R8336 C-CARBON R RN72K1J-472JE 435034724R1 PCB5...
Page 153 109/113 PAGE R8501 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8502 C-CARBON R RN72K1J-120JE 435031204R1 PCB5 R8503 C-R NET RM7LJ000X04 43484700004R2 PCB5 R8504 C-R NET RM7LJ330X04 43484733004R2 PCB5 R8505 C-R NET RM7LJ000X04 43484700004R2 PCB5 R8507 C-R NET RM7LJ000X04 43484700004R2 PCB5 R8508 C-R NET RM7LJ000X04 43484700004R2 PCB5...
Page 154 110/113 PAGE R8629 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8637 C-CARBON R RN72K1J-473JE 435034734R1 PCB5 R8638 C-CARBON R RN72K1J-473JE 435034734R1 PCB5 R8639 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8647 C-CARBON R RN72K1J-472JE 435034724R1 PCB5 R8648 C-CARBON R RN72K1J-472JE 435034724R1 PCB5 R8649 C-CARBON R RN72K1J-000JE 435030004R1 PCB5...
Page 155 111/113 PAGE R8750 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8751 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8752 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8823 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8824 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8937 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8951 C-CARBON R RN72K1J-103JE 435031034R1 PCB5...
Page 156 112/113 PAGE P3607A PLUG IMSA-9142B-16A 25056598 PCB5 P3608A PLUG IMSA-9142B-18A 25056599 PCB5 P3609 SOCKET 04FMN-SMT-A-TF 25052821R2 PCB5 P4104A SOCKET NSCT-19P2112 25052215 PCB5 P8005A TRM-423(SCREW) NEJITANSI ST3 25060495 PCB5 P8006 HOLDER (ｸﾗﾝﾌﾟ) UA-0 27190432 PCB5 P8302 SOCKET YKF45-7037V 25053253R3 PCB5 P8341 SOCKET YKF45-7037V 25053253R3...
Page 157 29100250A w250 x d350 PACKING A822 POLY BAG w250 x d350 29100250A PACKING A847 INST SHEET WINDOWS7 29355775 PACKING A851 WRNTY CARD (ONKYO) 29365135 PACKING A861 INS MANUAL En(TX-NR807) 29400021 PACKING A862 INS MANUAL U2FrEs(TX-NR807) 29400022 PACKING A870 INS MANUAL...
Page 158 Tel: 072-831-8023 Fax: 072-831-8163 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH (DUISBURG OFFICE) Hafennr.7602, Logport Office-Center, Bliersheimerstr.80B, 47229 Duisburg, Germany Tel: +49-2065-90198-00 Fax: +49-2065-90198-40 http://www.eu.onkyo.com/ ONKYO EUROPE UK Office...

Onkyo HT-RC180(B) Service Manual

Quick Links

Related Manuals for Onkyo HT-RC180(B)

Summary of Contents for Onkyo HT-RC180(B)

Table of Contents
