  • Page 1 May, 2012 HX7+ ASD Quick Start Guide...
  • Page 3 HX7+ ASD Quick Start Guide DN: 67018-000 May, 2012...
  • Page 5 The HX7+ Adjustable Speed Drive (ASD) is a solid-state AC drive that features Toshiba International Corporation’s (TIC) Vector Control algorithm. The HX7+ ASD is a very powerful tool, yet surprisingly simple to operate. The user-friendly keypad of the HX7+ ASD has an easy-to-read LCD screen. The keypad provides easy access to the many monitoring and programming features of the HX7+ ASD.
  • Page 6 The sales contract contains the entire obligation of Toshiba International Corporation. The warranty contained in the contract between the parties is the sole warranty of Toshiba International Corporation and any statements contained herein do not create new warranties or modify the existing warranty.
  • Page 7 Dimensions shown in the guide are in imperial units and/or the metric equivalent. Connection drawings within this document convey the typical topology of the HX7+ ASD system and do not include every possible connection variation. See the drawings received with the system for typeform-specific topological applicables.
  • Page 8 TOSHIBA INTERNATIONAL CORPORATION HX7+ Adjustable Speed Drive Please complete the Warranty Card supplied with the HX7+ ASD and return it to Toshiba International Corporation by prepaid mail. This will activate the 12-month warranty from the date of installation; but, shall not exceed 18 months from the shipping date.

  • Page 9: Table Of Contents

    Installation Notes ......................17 Mounting the ASD ......................19 Connecting the ASD ......................20 Power Connections ......................20 System Grounding......................23 Lead Length Specifications....................23 I/O and Control .........................24 Terminal Descriptions....................25 HX7+ ASD Control ......................29 CNU1/1A and CNU2/2A Pinout..................30 CN3 Pinout........................30 HX7+ ASD Quick Start Guide...
  • Page 10 Alarms and Trips ......................60 User Notification Codes ....................61 Alarms ..........................62 Trips/Faults ........................64 Viewing Trip Information ....................68 Clearing a Trip .......................69 Part Numbering Convention ....................70 Ordering Information ......................71 Enclosure Dimensions/Weight ....................72 Voltage/Current and Thermal Specifications ..............95 Cable/Terminal Specifications ....................96 HX7+ ASD Quick Start Guide...

  • Page 11: General Safety Information

    CAUTION The word CAUTION without the safety alert symbol indicates a potentially hazardous situation exists that, if not avoided or if instructions are not followed precisely, may result in equipment and property damage. CAUTION HX7+ ASD Quick Start Guide...

  • Page 12: Special Symbols

    DO NOT remove or cover any of these labels. If the labels are damaged or if additional labels are required, contact the Toshiba Customer Support Center. Labels attached to the equipment are there to provide useful information or to indicate an imminently hazardous situation that may result in serious injury, severe property and equipment damage, or loss of life if safe procedures or methods are not followed as outlined in this guide.

  • Page 13: Equipment Inspection

    • The storage temperature range of the HX7+ ASD is -14° to 104° F or 122° F (-10° to 40° C or 50° C). Thermal specifications are model-specific. •...

  • Page 14: Installation Precautions

    Installation and Connections on pg. 17 for further information on ventilation requirements. • The ambient operating temperature range of the HX7+ ASD is 14° to 104° F or 122° F (-10° to 40° C or 50° C) (see pg. 95 for thermal specifics).

  • Page 15: Conductor Routing And Grounding Precautions

    National and local codes should be referenced when running more than three conductors in the same conduit. • Ensure the correct phase sequence and the desired direction of motor rotation in the Bypass mode (if applicable). HX7+ ASD Quick Start Guide...

  • Page 16: Protection

    ASD unit. If EMI/RFI noise is of concern, the DBR wiring shall be three-core screened cable. The screen shall connect to the ASD enclosure and the resistor enclosure. HX7+ ASD Quick Start Guide...

  • Page 17: Residual Voltage Warning

    Ensure that the 3-phase power to the system is off and that the system is locked out and tagged out before performing maintenance or repair on the HX7+ ASD system. The relationship of MCCB1 to the total circuit is shown in Figure Figure 1. MCCB1 circuit breaker placement in the HX7+ ASD system. DANGER Always energized. Not affected by...

  • Page 18: System Integration Precautions

    • The TIC ASD is a general-purpose product. It is a system component only and the system design should take this into consideration. Please contact your Toshiba Customer Support Center for application-specific information or for training support. • The TIC ASD is part of a larger system and the safe operation of the ASD will depend upon observing certain precautions and performing proper system integration.

  • Page 19: System Setup Requirements

    When using an ASD output disconnect, the ASD and the motor must be stopped before the disconnect is either opened or closed. Closing the output disconnect while the 3-phase output of the ASD is active may result in equipment damage or injury to personnel. HX7+ ASD Quick Start Guide...

  • Page 20: Operational And Maintenance Precautions

    DO NOT open or remove the front cover or any of the enclosure panels of the ASD when the power is on. • DO NOT attempt to disassemble, modify, or repair the ASD. Contact your Toshiba Customer Support Center for repair information. •...

  • Page 21: Ce Compliance Requirements

    If the ASD is the final product, it may also be subject to machine-related directives. When required, it is the responsibility of Toshiba International Corporation to place the CE mark on qualifying ASDs. The CE Compliance section provides installation information and other required measures to satisfy the EMC Directive and the Low-Voltage Directive.

  • Page 22: Emc Directive

    EMC Directive The CE mark must be placed on every final product that includes an ASD and a motor. The HX7+ ASD complies with EMC Directive 2004/108/EC (the Toshiba-recommended EMC filter must be correctly wired and connected to the ASD for compliance).

  • Page 23: Ce Compliant Installation Guidelines

    8. Do Not connect two or more cables to the main circuit earth terminal of the ASD. If necessary, install an additional earth terminal on the noise cut plate on which the ASD is installed and connect another cable to it. HX7+ ASD Quick Start Guide...
  • Page 24 Table 2. HX7+ ASD Filter Recommendations. Filter Selection Table For HX7+ ASD FILTER MODEL FILTER MODEL FN 258-100-35 FN 3359-1000-99 FN 258-130-35 FN 3359-1000-99 FN 258-180-40 FN 3359-1600-99 FN 258-250-40 FN 3359-1600-99 FN 3359-320-99 1000 FN 3359-1600-99 FN 3359-400-99 1200...
  • Page 25 EN 60204-1: 2006: Safety of Machinery — Electrical equipment of machines – Part 1: General requirements. EN 61800-5-1: 2007: Adjustable Speed Electrical Power Drive Systems — Safety requirements – Part 5-1: Safety requirements – Electrical, thermal, and energy. HX7+ ASD Quick Start Guide...
  • Page 26 Additional Standards Toshiba International Corporation has applied the following additional standards for systems deployed in the European market. Table 4. Additional European Market Standards. Subcategory Test Standard and Level Basic and safety principles for man-machine interface, marking, and identification EN 60445...

  • Page 27: Installation And Connections

    Safety and Health Administration requirements, and to any other local and regional industry codes and standards. The Startup Wizard assists with the initial configuration of the HX7+ ASD. The Startup Wizard maybe launched from the Program menu or may be configured to start automatically upon subsequent start ups.
  • Page 28 Do not use an ASD with a motor that has a power rating that is greater than the rated output of the ASD. The ASD is designed to operate NEMA B motors. Consult with your Toshiba Customer Support Center before using the ASD for special applications such as with an explosion-proof motor or applications with a piston load.

  • Page 29: Mounting The Asd

    Install the unit securely to the floor in a well ventilated area that is out of direct sunlight. The ambient temperature rating for the HX7+ ASD is from 14° to 104° F or 122° F (-10° to 40° C or 50°...

  • Page 30: Connecting The Asd

    Charge Indicator LED is shown in Figure Ensure that the Charge Indicator LED is off before attempting to perform any maintenance on the ASD. Figure 4. Typical HX7+ ASD Charge Indicator LED. Charge Indicator LED HX7+ ASD Quick Start Guide...
  • Page 31 In the event that the motor rotates in the wrong direction when powered up, reverse any two of the three ASD output power leads (U, V, or W) connected to the motor. Figure 5. HX7+ ASD/Motor Typical Connection Diagram. HX7+ ASD Quick Start Guide...
  • Page 32 Figure 6. HX7+ ASD 3-Phase Input/Output Terminals. 3-Phase Output (U, V, and W Note: Connection shown is the typical 3-phase input connection to the HX7+ ASD. Connectivity may include a 6-, 12-, or 18-pulse input circuit 3-Phase Input (R, S, and T) which may include one or two circuit breakers on the input.

  • Page 33: System Grounding

    460 Volt  kHz 300 feet Note: Contact the Toshiba Customer Support Center for application assistance when using lead lengths in excess of those listed. Exceeding the peak voltage rating or the allowable thermal rise time of the motor insulation will reduce the life expectancy of the motor.

  • Page 34: I/O And Control

    I/O and Control The HX7+ ASD can be controlled by several input types and combinations thereof, as well as operate within a wide range of output frequency and voltage levels. This section discusses the ASD control methods and supported I/O functions.

  • Page 35: Terminal Descriptions

    The F terminal is activated by connecting CC to this terminal (Sink mode). A connection to CC provides a forward run command for the duration of the activation. This input terminal may be programmed to any of the functions listed in the HX7+ ASD Installation and Operation Manual (see F111).
  • Page 36 OUT1 — The default setting for this output terminal is the Output Low Speed. This output terminal may be programmed to provide an indication that any of the events listed in the HX7+ ASD Installation and Operation Manual has occurred or are active. This function may be used to signal the operator or to activate external equipment or a brake (see F130).
  • Page 37 FLA — One of two normally open contacts that, under user-defined conditions, connect to FLC. The FL relay is the Fault Relay by default, but may be programmed to any of the items of the HX7+ ASD Installation and Operation Manual. For further information on this terminal, see F132 and Figure FLB —...
  • Page 38 Figure 8. HX7+ ASD Terminal Board (P/N 48570). CN7A 0–1 mA 0–1 mA 4–20 mA 4–20 mA SW1 and SW2 may be switched to change the full- scale range of the FM and AM output terminals. See F670 and for more information on...

  • Page 39: Hx7+ Asd Control

    HX7+ ASD Control The Control PCB (Figure 9) serves as the primary control source for the HX7+ ASD. The Control PCB receives input from the Terminal Board (see Figure 8 on pg. 28), an Option Card, RS232/RS485 Communications, or the keypad.

  • Page 40: Cnu1/1A And Cnu2/2A Pinout

    Connect CNU1 to CNU1A and continue normally. See the 7-Series Communications Manual (P/N 53840) for more information on the HX7+ ASD communications protocol and system configuration requirements. CN3 Pinout CN3 is used for RS232/RS485 serial communications.

  • Page 41: Cn7 Pinout

    29). The CN8 Option selection may be chosen as the control input at the Frequency, Command, and Torque selections. Table 10. CN8 pinout assignments. Pin Number Pin Number Pin Number Pinout Pinout Pinout OUTLOAD RESET ENTER IOCLK OUTDAT HX7+ ASD Quick Start Guide...

  • Page 42: I/O Circuit Configurations

    Figure 11. RR input. Figure 12. RX input. Figure 13. VI/II input. Figure 14. P24 Output. Figure 15. PP Output. Figure 16. OUT1/OUT2 Output. Figure 17. FP Output. Figure 18. AM/FM Output. Figure 19. Fault Relay (during fault). HX7+ ASD Quick Start Guide...

  • Page 43: Startup And Test

    Table 11. ASD Parameter Changes by Installer/Maintenance Personnel. ASD ID__________Name:______________________Date:_______ Default or Notes Parameter Unit of Parameter Name Previous New Setting Number Measure Setting Note: Settings may also be recorded via Program  Utility Parameters  Type Reset  Save User Parameters. HX7+ ASD Quick Start Guide...

  • Page 44: Typical Connection Diagram

    Typical Connection Diagram Figure 20. HX7+ ASD Typical Connection Diagram. Note: When connecting multiple wires to the PA, PB, PC, or PO terminals, do not connect a solid wire and a stranded wire to the same terminal. Note: The VI, RX, and RR analog input terminals are referenced to CC.

  • Page 45: Hx7+ Keypad

    Figure 21 on pg. The keypad can be mounted remotely from the ASD as described in the HX7+ ASD Installation and Operation Manual. The dimensional requirements for remote mounting may also be found in this section.

  • Page 46: Keypad Operation

    Up, Down, and Enter key functions. The software used with the HX7+ ASD is menu driven; thus, making it a select and click environment. The operating parameters of a motor may be selected and viewed or changed using the keypad.

  • Page 47: System Operation

    Upon initial system powerup, the Startup Wizard may be run to assist the user with the initial configuration of the input power settings and the output parameters of the HX7+ ASD. The HX7+ ASD may also be setup by directly accessing each of the individual parameters (see the HX7+ ASD Installation and Operation Manual).

  • Page 48: Default Setting Changes

    Direct Access menu (Program  Direct Access  applicable parameter number). A listing of the Direct Access/Parameter Numbers and a description of the associated parameter may be found in the HX7+ ASD Installation and Operation Manual. A listing of all parameters that have been changed from the factory default setting may be viewed sequentially by accessing the Changed From Default screen (Program ...

  • Page 49: System Configuration And Menu Options

    System Configuration and Menu Options Root Menus The Mode key accesses the three primary screens of the HX7+ ASD: the Frequency Command screen, the Monitor screen, and the Program screen. From either screen, press the Mode key to loop through to the...
  • Page 50 V/f Group — One of four V/f profiles may be selected and run. Each V/f profile is comprised of four user settings: Base Frequency, Base Frequency Voltage, Manual Torque Boost, and Motor Overload Protection. Expanded descriptions of these parameters may be found in the HX7+ ASD Installation and Operation Manual.

  • Page 51: Startup Wizard Requirements

    ASD control settings and system operational specifications. The HX7+ ASD may also be setup by directly accessing each of the settings via the Program menu or the Direct Access Number for each item (see the HX7+ ASD Installation and Operation Manual for specifics on each parameter).
  • Page 52 This parameter allows the user to input the full-load amperage (FLA) of the motor. This value is used by the HX7+ ASD to determine the motor overload protection setting for the motor. The value is found on the nameplate of the motor.
  • Page 53 11 — Pulse Input (option) 9. Wizard Finished! This screen is the final screen of the Startup Wizard. The basic parameters of the HX7+ ASD have been set. Click Exit to load the Startup Wizard input and to return to the Frequency Command screen.

  • Page 54: Monitor Screen

    Monitor Screen Monitor Screen Monitor The Monitor mode allows the user to monitor HX7+ ASD/motor performance variables, ASD control settings, and configuration data during motor operation. The monitored parameters are listed and described below. Note: The Monitor mode is a read-only mode. The settings cannot be changed from the Monitor mode.
  • Page 55 Pattern Select — Active Group Number and Speed Number separated by a period (e.g., 2.3). Repeats Left — Number of remaining Speed cycles in the active Group. Pattern — Active Speed Number of the Group. Pattern Time Left — Time remaining in the active Speed. HX7+ ASD Quick Start Guide...

  • Page 56: Scrolling Monitor

    Seconds Between Switch user setting of the Scrolling Monitor screen. If no items are selected, No Items is displayed at the Frequency Command screen. The selected items, along with their real-time values, are displayed (and/or scrolled) on the Frequency Command screen while running. HX7+ ASD Quick Start Guide...

  • Page 57: Program Screen Menu Navigation

    Command (check box) Local|Remote Key Frequency (check box) Realtime Clock Setup Date and time setting (requires RTC option) Double Click Speed Arrow Speed Preferences Encoder Speed Encoder Action Over-Heat Alarm Alarm Popups (check box) Undervoltage Alarm HX7+ ASD Quick Start Guide...
  • Page 58 Auto Setup for 60 Hz Restore Factory Defaults Clear Trip Clear Run Timer Type Reset F007 New Base Drive Board Save User Parameters Restore User Parameters Reload EOI Flash (keypad) Reset EOI Memory (keypad) Comm. Stops During Reset HX7+ ASD Quick Start Guide...
  • Page 59 FP Terminal Meter Adjustment F677 ST Signal Selection F103 F/R Priority Selection (w/both on) F105 Input Special Input Terminal Priority (check box) F106 Extended Terminal Function F107 Line Power Switching (Commercial Power Switching) On Trip F354 HX7+ ASD Quick Start Guide...
  • Page 60 Jog Run Frequency F260 Jog Settings Jog Stop Control F261 Jog Window (check box) #1 Frequency & Characteristics F018 #2 Frequency & Characteristics F019 Preset Speeds #3 Frequency & Characteristics F020 #4 Frequency & Characteristics F021 HX7+ ASD Quick Start Guide...
  • Page 61 Emergency Off Mode Configuration F603 DC Injection Braking Time F604 Emergency Off Emergency Off Activation of the FL Output (check box) Number of Retries F303 Restart Conditions (check box) F301 Retry/Restart Scan Rate F312 Lock-on Rate F313 HX7+ ASD Quick Start Guide...
  • Page 62 Supply Voltage Compensation (check box) Base Frequency Voltage F307 Output Voltage Limitation (check box) Suppression of Inrush-Current Timing F608 Soft Start Interlock with ST (check box) F609 VI/II F205 ORQUE ETTING F214 Set Points F220 F226 F232 HX7+ ASD Quick Start Guide...
  • Page 63 F368 PG Disconnection Detection Selection F369 Electronic Gear Setting F370 PG Settings Position Loop Gain F371 Positioning Completion Range F372 Frequency Limit at Position F373 Current Control Proportional Gain F374 Current Control Integral Gain F375 HX7+ ASD Quick Start Guide...
  • Page 64 #13 Frequency & Characteristics F292 #14 Frequency & Characteristics F293 #15 Frequency & Characteristics F294 Preset Speed Mode Use Preset Speed F380 ASD Number F802 OMMUNICATION Communication Settings Logic (TTL) Baud Rate F800 RS232/RS485 Baud Rate F820 HX7+ ASD Quick Start Guide...
  • Page 65 #3 Scan Transmit F843 Scan Transmit Settings #4 Scan Transmit F844 #5 Scan Transmit F845 #6 Scan Transmit F846 Communication Error Command Request Disposition on Error F830 Optional Parameter #1 F890 Optional Parameters Optional Parameter #2 F891 HX7+ ASD Quick Start Guide...
  • Page 66 Motor Set #3 #3 Torque Boost F176 #3 Electronic Thermal Protection Level F177 #4 Base Frequency F178 #4 Max Output Voltage F179 Motor Set #4 #4 Torque Boost F180 #4 Electronic Thermal Protection Level F181 HX7+ ASD Quick Start Guide...
  • Page 67 Light-Load High-Speed Operation Heavy- F334 Load Detection Time Switching Load Torque During Forward Run F335 Heavy-Load Torque During Forward F336 Acceleration Heavy-Load Torque During Fixed Speed F337 Forward Run Switching Load Torque During Reverse Run F338 HX7+ ASD Quick Start Guide...
  • Page 68 F485 Zone Exciting Starting Rate Special Parameters Compensation Coefficient for Iron Loss F487 Voltage Compensation Coefficient for Dead Time Dead Time Compensation F489 Dead Time Compensation Bias F490 Switching Frequency Between Current and F491 Voltage HX7+ ASD Quick Start Guide...
  • Page 69 Current Differential Gain F454 Exciting Strengthening Coefficient F480 User Parameter Initialization During Typeform F709 Initialization Enable/Disable Special Parameters % Current Vector Control F482 Rocking Start F739 % Voltage Vector Control F483 % Constant Vector Control F484 HX7+ ASD Quick Start Guide...

  • Page 70: Alarms, Trips, And Troubleshooting

    Table 14 lists the Alarm codes that may be displayed during operation of the HX7+ ASD. In the event that the condition that caused the Alarm does not return to its normal operating level within a specified time, the ASD Faults and a Trip is incurred (Fault and Trip are sometimes used interchangeably).

  • Page 71: User Notification Codes

    Atn2 indicates that an Autotune retry is active for the duration of the automatic retry. This code conveys the DC Injection function being carried out. The display dbOn DC Braking shows db when braking and shows dbOn when the motor shaft stationary function is being carried out. HX7+ ASD Quick Start Guide...

  • Page 72: Alarms

    Alarms Table 14 lists the alarm codes that may be displayed during operation of the HX7+ ASD. Each alarm code listed is accompanied by a description and a possible cause. In the event that the source of the malfunction cannot be determined, contact your the...
  • Page 73 (increase the difference). each other. Undercurrent Output current of the ASD is below the level defined at F611 and remains there for the time set at F612. * Reset ignored if active. HX7+ ASD Quick Start Guide...

  • Page 74: Trips/Faults

    Reset to be recognized. In the event of multiple active trips, the trip displayed will remain until all faults are corrected and all trips are cleared. HX7+ ASD Quick Start Guide...
  • Page 75 Reset to be recognized. In the event of multiple active trips, the trip displayed will remain until all faults are corrected and all trips are cleared. HX7+ ASD Quick Start Guide...
  • Page 76 Reset to be recognized. In the event of multiple active trips, the trip displayed will remain until all faults are corrected and all trips are cleared. HX7+ ASD Quick Start Guide...
  • Page 77 Reset to be recognized. In the event of multiple active trips, the trip displayed will remain until all faults are corrected and all trips are cleared. HX7+ ASD Quick Start Guide...

  • Page 78: Viewing Trip Information

    6) Output Voltage 14) Feedback (inst.) 22) ASD Overload 30) Peak Voltage 7) Direction 15) Feedback (1 sec.) 23) DBR Overload 31) PG Speed 8) Frequency Reference 16) Torque 24) Motor Load 32) PG Position HX7+ ASD Quick Start Guide...

  • Page 79: Clearing A Trip

    • Remotely via the communications channel, • Momentarily connecting terminal RES to CC of the Control Terminal Strip, or • Via Program  Utility Parameters  Type Reset  Clear Trip (clears Trip Monitor From ASD). HX7+ ASD Quick Start Guide...

  • Page 80: Part Numbering Convention

    The thermal ratings for the HX7+ ASD are 40° and 50° C. Not all typeforms are available in both thermal ratings. Specifications for both typeforms are listed in the following sections and are separated by their 40°...

  • Page 81: Ordering Information

    Ordering Information Use the following part numbering convention when ordering the HX7+ ASD. The 518 kVA, 480 V, 40° C, NEMA 3R, 12-Pulse with Sine Wave Filter configuration is shown in the heading of Table 17 as an example (i.e., P/N HX7+C451K40CCS).

  • Page 82: Enclosure Dimensions/Weight

    Refer to the drawings on pgs. 75 for the referenced enclosure figures. Note: All Toshiba ASD enclosures carry at least an IP20 rating — NEMA 1 and NEMA 3R listed. Table 18. 6- and 12-Pulse Non-Sine Wave Enclosure Dimensions. NEMA 1...
  • Page 83 1500 (680) Figure 36. 1500 (680) Figure 33. 1900 (862) Figure 37. 2000 (907) 51K40 Figure 34. 3000 (1406) Figure 38. 3000 (1406) 93K40 10L40 Figure 35. 5000 (2268) Figure 39. 5000 (2268) 14L40 15L40 HX7+ ASD Quick Start Guide...
  • Page 84 Table 20. 18-Pulse, Sine Wave and Non-Sine Wave Enclosure Dimensions. Model Number Shipping Weight Figure HX7+C4 Lbs. (kg) Figure 40. 2550 Figure 41. 2550 3425 3650 Figure 42. 3900 51K40 5600 Figure 43. 5700 5775 HX7+ ASD Quick Start Guide...
  • Page 85 Figure 24. 66–200 kVA Non-Sine Wave NEMA 1 Enclosure. HX7+ ASD Quick Start Guide...
  • Page 86 Figure 25. 260–518 kVA Non-Sine Wave NEMA 1 Enclosure. HX7+ ASD Quick Start Guide...
  • Page 87 Figure 26. 518–1000 kVA Non-Sine Wave NEMA 1 Enclosure. HX7+ ASD Quick Start Guide...
  • Page 88 Figure 27. 1200–1500 kVA Non-Sine Wave NEMA 1 Enclosure. HX7+ ASD Quick Start Guide...
  • Page 89 Figure 28. 66–200 kVA Non-Sine Wave NEMA 3R Enclosure. HX7+ ASD Quick Start Guide...
  • Page 90 Figure 29. 260–518 kVA Non-Sine Wave NEMA 3R Enclosure. HX7+ ASD Quick Start Guide...
  • Page 91 Figure 30. 518–1000 kVA Non-Sine Wave NEMA 3R Enclosure. HX7+ ASD Quick Start Guide...
  • Page 92 Figure 31. 1200–1500 kVA Non-Sine Wave NEMA 3R Enclosure. HX7+ ASD Quick Start Guide...
  • Page 93 Figure 32. 200 kVA Sine Wave NEMA 1 Enclosure. HX7+ ASD Quick Start Guide...
  • Page 94 Figure 33. 260–518 kVA Sine Wave NEMA 1 Enclosure. HX7+ ASD Quick Start Guide...
  • Page 95 Figure 34. 518–1000 kVA Non-Sine Wave NEMA 1 Enclosure. HX7+ ASD Quick Start Guide...
  • Page 96 Figure 35. 932–1500 kVA Sine Wave NEMA 1 Enclosure. HX7+ ASD Quick Start Guide...
  • Page 97 Figure 36. 200 kVA Sine Wave NEMA 3R Enclosure. HX7+ ASD Quick Start Guide...
  • Page 98 Figure 37. 260–518 kVA Sine Wave NEMA 3R Enclosure. HX7+ ASD Quick Start Guide...
  • Page 99 Figure 38. 518–1000 kVA Sine Wave NEMA 3R Enclosure. HX7+ ASD Quick Start Guide...
  • Page 100 Figure 39. 932–1500 kVA Sine Wave NEMA 3R Enclosure. HX7+ ASD Quick Start Guide...
  • Page 101 Figure 40. 66–163 kVA 18-Pulse Enclosure. HX7+ ASD Quick Start Guide...
  • Page 102 Figure 41. 200 kVA 18-Pulse Enclosure. HX7+ ASD Quick Start Guide...
  • Page 103 Figure 42. 260–518 kVA 18-Pulse Enclosure. HX7+ ASD Quick Start Guide...
  • Page 104 Figure 43. 518–700 kVA 18-Pulse Enclosure. HX7+ ASD Quick Start Guide...

  • Page 105: Voltage/Current And Thermal Specifications

    1078 980/1176.0 93K40 1009 1121/1345.2 (104) 10L40 1000 1083 1203/1443.6 1000 1009 1121/1345.2 1000 1083 1203/1443.6 (122) (122) 1000 1200 1299 1443/1731.6 1200 14L40 1400 1515 1684/2020.8 1400 (104) (104) 15L40 1500 1623 1804/2164.8 1500 HX7+ ASD Quick Start Guide...

  • Page 106: Cable/Terminal Specifications

    Please consult the NEC for cable specifications appropriate for your application. Note: Cables and Terminals specifications are based on the rated current of the ASD — they DO NOT include a 10% Service Factor. HX7+ ASD Quick Start Guide...
  • Page 107 Table 22. Specifications for Lugs/Cables for the 6-, 12-, and 18-Pulse Non-Sine Wave HX7+ ASD. HX7+ ASD Quick Start Guide...
  • Page 108 Table 23. Specifications for Lugs/Cables for the 6-, 12-, and 18-Pulse Non-Sine Wave HX7+ ASD. HX7+ ASD Quick Start Guide...
  • Page 109 EOI, 3 Communication Error, 55, 64 EOI Operation, 36 Communication Reference Adjust, 55 Communication Setting Parameters, 54 EOI Setup Options, 47 Communication Settings, 54 Equipment Inspection, 3 Configuration and Menu Options, 39 Escape Key, 35 HX7+ ASD Quick Start Guide...
  • Page 110 Motor Overload Trip, 52 In Terminal Delays, 50 indoor systems, 70 Motor Parameters, 56 Input Phase Loss, 65 Motor Set #1, 47, 56 Input Special, 49 Motor Set #2, 56 Input Terminal Assignment, 49 Motor Set #3, 56 HX7+ ASD Quick Start Guide...
  • Page 111 Run Key, 35 RX, 24 RX terminal, 26 P24, 24 P24 terminal, 26 PA/+, 20 S/L2, 20 Parameter Changes, 33 S1, 24 Pattern Run, 54 S1 terminal, 25 Pattern Run Control Parameters, 54 S2, 24 HX7+ ASD Quick Start Guide...
  • Page 112 Torque Control, 53 Torque Limit Settings, 53 W Phase Short Circuit, 67 Torque Proving Fault, 67 W/T3, 20 Torque Setting Parameters, 52, 53 Warranty Card, 2 Torque Speed Limiting, 53 Trip History, 57, 68 Wizard Finish, 43 HX7+ ASD Quick Start Guide...
  • Page 115 Industrial Division 13131 West Little York Road, Houston, TX 77041-5807 US (800) 231-1412 • CAN (800) 872-2192 • MEX 01 (800) 527-1204 FAX: (713) 466-8773 www.toshiba.com/ind...
