Nortek AB 150A Installation And Operating Manual

Airbloc ab range
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A
IRBLOC
I
NSTALLATION AND
INDEX
General Information -------------------------------------------------------- 1
Dimensions -------------------------------------------------------------------- 2
Installation Details ----------------------------------------------------------- 4
Wiring Details ---------------------------------------------------------------- 5
Servicing ---------------------------------------------------------------------- 6
Parts Replacement ---------------------------------------------------------- 7
Spare Parts -------------------------------------------------------------------- 8
Fault Finding ----------------------------------------------------------------- 9
User Instructions ----------------------------------------------------------- 10
1 This appliance must only be installed by a competent person in accordance with the requirements of
the Codes of Practice or the rules in force.
2 All external wiring MUST comply with the current IEE wiring regulations.
3 Warning this appliance must be earthed.
Nortek Global HVAC (UK) Limited, Fens Pool Avenue, Brierley Hill, West Midlands, DY5 1QA
AB R
A
A
C
MBIENT
IR
O
PERATING
ANGE
URTAIN
M
ANUAL
Part No. 702100
Doc No. 702100 Page 1 of 12
