10-2 Outdoor PCB

Power N
1
2 Power L
BLDC FAN
3
4 AC FAN
Communication 485
5
10-2
5
9
The red number connecter is not used.
2
COND/OLP Temperature Sensor
6
7 DIS/OUT Temperature Sensor
EEV Connector
8
9 Comp. Connector Wire
Reactor Connector Wire
10
8
6
7
3
10
4
1
