10. PCB Diagram

10-1 Indoor PCB

1
12
Power
1
Motor RPM Feedback
2
Remocon Module
3
Humidity Sensor
4
Anions
5
MPI
6
Samsung Electronics
7
2
3
6
4
Temperature Sensor
7
Auto Grill
8
HVPS(High voltage Generator)
9
BLADE-H Step Motor
10
Display
11
Indoor Fan Motor
12
The red number connecter is not used.
