IC 550T
IC 660T
IC 880T
User Manual
Rev 1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the IC 660T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Work Pro IC 660T

Summary of Contents for Work Pro IC 660T

  • Page 1 IC 550T IC 660T IC 880T User Manual Rev 1.0...
  • Page 3 CEILING SPEAKER IC 550T IC 660T IC 880T TECHNICAL DATA IC 550T IC 660T IC 880T Elements " + 0.5" Tweeter " + 0.5" Tweeter 8" + 0.5" Tweeter Power Taps (100V line) 1.5W/3W/6W 1.5W/3W/6W 1.5W/3W/6W Power Taps (70V line) 0.75W/1.5W/3W...

  • Page 4: Install Process

    CEILING SPEAKER Install Process - Put the ceiling speaker in the installation location. - The allowed thickness of the ceiling must be between 10 to 25mm. - Make the mounting hole according to speaker data (see table). - Use the thin end of the L shape wrench to install the speaker; use the thin end of the L shape wrench to push upward the mounting tabs (legs) and rotate 180º...
  • Page 5 ALTAVOCES DE TECHO IC 550T IC 660T IC 880T DATOS TECNICOS IC 550T IC 660T IC 880T Elementos " + 0.5" Tweeter " + 0.5" Tweeter 8" + 0.5" Tweeter Potencia (100V line) 1.5W/3W/6W 1.5W/3W/6W 1.5W/3W/6W Potencia (70V line) 0.75W/1.5W/3W 0.75W/1.5W/3W...

  • Page 6: Proceso De Instalación

    ALTAVOCES DE TECHO Proceso de Instalación - Coloque el altavoz de techo en su lugar de instalación. - El grosor permitido del techo debe oscilar entre 10 y 25mm. - Realice el agujero de montaje de acuerdo a los datos del altavoz (ver tabla) - Use el lado redondeado de la llave en forma de L para instalar el altavoz, Use este lado de la llave para pulsar hacia arriba los...
  • Page 8 Este símbolo en su equipo o embalaje, indica que el presente producto This symbol on the product or on its packaging indicates that this product no puede ser tratado como residuos domésticos normales, sino que deben shall not be treated as household waste. Instead it shall be handed over to entregarse en el correspondiente punto de recogida de equipos electrónicos the applicable collection point for the recycling of electrical an electronic y eléctricos.

This manual is also suitable for:

Ic 550tIc 880t
