Arturia MatrixBrute User Manual page 60

VCO1 Pitch
VCO1 Ultra Saw
VCO1 Pulse Width
VCO1 Metalizer
VCO2 Pitch
VCO2 Ultra Saw
VCO2 Pulse Width
VCO2 Metalizer
Steiner Cutoff
Ladder Cutoff
LFO 1 amount
VCA
Gate I/O (TS)
Gate (TS)
Sync (TRS)
Gate 0 – 5V
Audio I/O
Label
Master
Out L/R
Audio In
Insert
54
0 - 10V
+/- 5V
+/- 5V
+/- 5V
0 - 10V
+/- 5V
+/- 5V
+/- 5V
0 - 10V
0 - 10V
0 - 10V
0 - 10V
0 – 5V
Jack
Mono TS
Mono TS
TRS = Tip=Send;
Return; Sleeve = Gnd
Level
+4dBu
Line = 0-20dB Inst
= 0-40dB
Ring =
+4dBu
Note
68kΩ
1.1MΩ
Arturia - MatrixBrute Manual - MIDI
