This chapter will help you get to know the main aspects of how the minimoog V works.
You will be presented an overview of the different parts of the synthesizer while using the
program for the first time. You will find a detailed description of all visible settings and
controllers in the chapters that follow.
Chapter 6, A few elements of sound design is specially recommended for users who have never
worked with a subtractive synthesizer before and who wish to learn the basics in this
domain.
1.1 U
SING THE PRESETS
Use of presets is one of the major areas of evolution when the minimoog V is compared
to the original, which couldn't save sounds!
With the minimoog V, a preset (memorized sound) contains all of the parameter settings
of the synthesizer plus the «extension» part and the different real-time and effect
controllers necessary to reproduce the sound.
To get to know a few of the different sounds contained in the minimoog V, we will select
the «Bass1» preset.
To do this, click on button above the «BANK» LCD display which indicates «Arturia»
(this display shows the name of the current bank in use). When you click, you will see
a dropdown menu indicating the available banks. Choose the «JM_Blanchet» bank.
When this menu is open, it expands the sub-menus allowing you to reach the «SUB
BANK» and «PRESETS» of a sound designer with a single click.
Choose the «SUB BANK» called «Basses» and finally select «JMB_Classic1» in the
«PRESETS».
ARTURIA – minimoog V – QUICK START
1 MINIMOOG V - QUICK START
Overview of the minimoog V
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the minimoog V and is the answer not in the manual?

Questions and answers

Related Manuals for Arturia minimoog V

Summary of Contents for Arturia minimoog V

  • Page 1 «extension» part and the different real-time and effect controllers necessary to reproduce the sound. To get to know a few of the different sounds contained in the minimoog V, we will select the «Bass1» preset.
  • Page 2 Select the preset JMB_Classic1 The minimoog V comes with 400 presets, which will familiarize you with the sounds of the synthesizer. A bank called «User / Temp» offers a selection of presets with a basic configuration (or template) to start programming a sound.
  • Page 3 The names «new bank», «new sub bank…» and «new preset…» appear in their respective menu locations. Click on each of them to change the names. Saving a preset ARTURIA – minimoog V – QUICK START...

  • Page 4: The Playing Modes

    1.2 T HE PLAYING MODES The minimoog V offers 2 playing modes: • The «Close» mode is close to the original configuration of the Minimoog. The closed mode (the original Minimoog) • The «Open» mode gives access to extensions offering a modulation matrix, an arpeggiator and effects.
  • Page 5 Opening the extension To use the minimoog V exactly like the original Minimoog, you must also deactivate the chorus and delay effects on the toolbar and switch off the polyphony toggle in the output section. 1.3 O «C » VERVIEW OF THE...
  • Page 6 » MODE When the minimoog V is at the «Open» position, you access an extension to the parameters of synthesis. It is displayed in the form of a modulation matrix, a Low Frequency Oscillator (LFO) which was brought in be substituted for oscillator 3 which was being used to this effect.

  • Page 7: The Modulation Matrix

    Choose the filter cutoff frequency among the destinations. Turn down the frequency so that you can hear the result. The cutoff frequency will vary in a cyclic way, following the LFO oscillations. Modulation of the filter cutoff frequency by the LFO ARTURIA – minimoog V – QUICK START...

  • Page 8: The Arpeggiator Section

    It is also possible to keep the chord help down by clicking on the «HOLD» button. To remove one or several notes, click again on the «HOLD» button and play the note you want to remove. The arpeggiator ARTURIA – minimoog V – QUICK START...

  • Page 9: The Effects Section

    Next turn the 2 «Speed» knobs of the delay to set the speed of echoes for the right side (Time Right) and left side (Time Left). It is also possible to set the number of echoes on each side («Feedb. Right» and «Feedb. Left») Settings of the delay effect ARTURIA – minimoog V – QUICK START...
  • Page 10 HE REAL TIME CONTROLLERS AND ASSIGN Like its excellent ancestor, the minimoog V is adapted in particular to real time play. One of the major points of evolution when compared to the original is the possibility to assign any minimoog V knob to an external MIDI controller.
