MicroTech II®
Chiller Unit Controller
Modbus® Communication Module
•
•
•
•
•
•
•
•
•
•
•
•
Use this manual to physically install the communications module into the unit and connect the unit to
your network. You also need the appropriate McQuay Engineering Data Sheet known as Protocol
Information to integrate the unit into your network. Protocol Information contains addressing details,
Modbus® protocol information, and a list of the data points available to the network. See the
Reference Documents section of this document for part numbers of the Protocol Information. These
documents are available from your local McQuay International representative and at the McQuay
International web site: www.mcquay.com.
© 2005 McQuay International
Installation and Maintenance
WSC
Water-Cooled Centrifugal, Single-Compressor
WDC
Water-Cooled Centrifugal, Dual-Compressor
WPV
Water-Cooled Centrifugal, Single-Compressor
HSC
Water-Cooled Single-Compressor Centrifugal, Heat Recovery
HDC
Water-Cooled Dual-Compressor Centrifugal, Heat Recovery
TSC
Water-Cooled Single-Compressor Centrifugal, Templifier
WMC
Water-Cooled Centrifugal, Magnetic Bearing
AGZ
Air-Cooled Global Scroll
ACZ
Air-Cooled Scroll Condensing Unit
WGZ
Water-Cooled Global Scroll
AGS
Air-Cooled Global Screw
WGS
Water-Cooled Global Screw
NOTICE
IM 743-1
Group: Controls
Part Number: IM 743
Date: May 2005
Supersedes: IM 743-0
