Installation
Preparing for Installation
The OTAC-01 Module
The OTAC-01 Pulse Encoder Interface module is an interface for
connecting a digital pulse encoder to an ACS550 drive. A pulse
encoder should be used if accurate speed or position (angle) feedback
from the motor shaft is required.
Module Layout
A
B
Through
Compatibility
The OTAC-01 module is compatible with all ACS550 drives. To confirm
compatibility with a particular pulse encoder, compare the pulse
encoders requirements to the "Specifications" on page 19.
Installation
Phone: 800.894.0412 - Fax: 888.723.4773 - Web: www.clrwtr.com - Email: info@clrwtr.com
Z
Pass
SCR
Warning Sticker
Green LED
X0061
