Step 2

Communications Configuration and Initialization

For Dial Communication -
If you need a prefix to dial out continue below (If not proceed to Dial initialization Steps)
If a 9 is required press blue admin button twice, enter admin code 15, press OK.
The terminal will read PREFIX.
Press OK, enter 9.
The screen will again read PREFIX.
Cancel twice using red cancel button
The screen will return to - TERMINAL SETUP REQUIRED.
Dial Initialization Steps
Press blue admin key twice, enter admin code 01, press OK.
The terminal will now ask for your MERCHANT ID NUMBER which is your existing merchant
number with ATB Financial. It is a 13 digit number.
NOTE - You can confirm your existing merchant number by printing an ADMIN 16 report on your
existing terminal. If you currently have a 9 digit merchant number beginning with a 4 simply add
0030 to the beginning i.e., 400000000 becomes 003040000000
Key in the 13 digit merchant id and press OK
If merchant number begins with 00301 key in 1-888-699-7299
If merchant number begins with 00302 key in 1-888-358-8602
If merchant number begins with 00304 key in 1-888-332-8433
The device will now dial out. The screen will indicate words such as "sending" & "receiving".
This will take a few moments to do.
If the initialization was successful - Terminal should now say LOGON.
Press blue admin button twice, enter admin code 02, press OK and swipe one of the white admin
cards. You should have been provided 1 with the new terminal. (if terminal only accepts credit
cards, you will not be prompted for an admin card for this function)
The terminal should now be dialing out again.
When finished, the screen should indicate "PURCHASE ENTER AMOUNT". This will always be your
main screen when the terminal is ready to be used.
Your device is ready to process transactions! Please see last page for further instructions!
