Please ensure you are using the power cable provided to you with this device. Do not use
the power cable from your existing device as it will damage the equipment.
Plug power cord into terminal base using the middle port (see picture #1) then plug into power
source.
It is recommended that a power bar with surge protection be used.
It is important to plug into power source last to avoid any initial power surges.
After the device conducts a power up process it should read TERMINAL SET UP REQUIRED.
Helpful Hints
F1 is to say yes to any questions and to scroll down.
F3 is to say no and to scroll up.
You always need to press OK or enter for it to accept any prompts and to move on to next step.
When charging the battery for the first time, it should be left on the base for a minimum of 3
hours. The first 3 times the battery is used, allow the battery to fully discharge and then charge it
to its full capacity. Full charging time after the first time is 2 hours.
The ATB Mobile 8200 terminal does not have an ON/OFF switch. To help reduce battery usage,
power down the terminal when you are not using it.
If you need to Power On the terminal.
To power up (or turn on) the terminal when the terminal is not on a base:
•
if the battery is charged, simply press the OK key OR
•
place the terminal on a base (communications or charge-only base).The green back light
comes on, the READY screen appears until the terminal establishes the charge level of
the battery.
If you need to Power Off the terminal (ensure the terminal is off the base. The terminal cannot be
turned off when it is sitting on a base.
To power down (or turn off) the terminal from the READY screen:
Press Admin on the keypad. The MAIN MENU appears.
Press Admin on the keypad again. The ENTER ADMIN CODE prompt appears.
Key in 49 and press OK. The POWER OFF TERMINAL? prompt appears.
Press F1 (YES) to power down the terminal. The green backlight goes off and the display screen goes
blank.
When the terminal is sitting on a base, it is always on, however, it is not using battery power.
If the terminal is in stand-by mode.
•
The terminal automatically powers off and goes into stand-by mode when it is not in use for a set
time period and it is not on a base.
•
In stand-by mode, the green backlight is off and the display screen is blank.
•
To exit Stand-by mode, Power on the terminal.
•
Change the backlight timer to a longer time period before the backlight turns off automatically.
