Service Tables

4.2 SERVICE TABLES

4.2.1 SP1-XXX (BIT SWITCHES)

Bit Switches
1 Mode No.
System Switch
101
001 – 032
Ifax Switch
102
001 – 016
Printer Switch
103
001 – 016
Communication Switch
104
001 – 032
G3-1 Switch
105
001 – 016
G3-2 Switch
106
001 – 016
G3-3 Switch
107
001 – 016
G4 Internal Switch
108
001 – 032
109 G4 Parameter Switch
B786
Function
Change the bit switches for system settings for the
00 – 1F fax option
"Bit Switches"
Change the bit switches for internet fax settings for
00 – 0F the fax option
"Bit Switches"
Change the bit switches for printer settings for the
fax option
00 – 0F
"Bit Switches"
Change the bit switches for communication settings
for the fax option
00 – 1F
"Bit Switches"
Change the bit switches for the protocol settings of
the standard G3 board
00 – 0F
"Bit Switches"
Change the bit switches for the protocol settings of
the optional G3 board
00 – 0F
"Bit Switches"
Change the bit switches for the protocol settings of
00 – 0F the optional G3 board
"Bit Switches"
00 – 1F Not used (Do not change the bit switches)
40 SM
