Before The Cut, Ready To Cut & After The Cut - Slugger USA101 Operator's Manual

1. Select correct pilot pin and place in cutter shank from the rear, align flats on cutter shank with arbor body set
screws, insert cutter in arbor body.
2. Tighten set screws securely on cutter shank flats. NOTE: Set screws should be recessed in arbor body when tight.
3. The surface you are working on should be clean and flat, free from rust, scale, dirt and chips.
4. Place Slugger machine on workpiece with pilot pin over the center of hole to be drilled.
5. Connect machine to power source.
6. Lower Slugger cutter to surface of material to be cut. NOTE: Coolant flow starts when pilot pin contacts work
surface. Coolant flow can be stopped by lifting pilot pin off work surface.
always use safety strap
7. The safety strap must be securely fastened to machine and around work being drilled. Loop strap around
work piece and connect strap ends by attaching to D-rings on drill. NOTE: Safety strap is intended only to
restrain the drill to the workpiece in the event of a power failure to the magnetic base.
8. Position chip guard toward work area before drilling.
NOTE: if ON/Off SwiTchES ARE NOT iLLUMiNATEd, ThERE iS NOT A PROPER MAgNETic fiELd.
1. Move magnet switch to "ON" position. Switch will illuminate to indicate power is present – magnetic base should
be firmly secured to workpiece at this time. Thin materials may require an additional steel plate to achieve
proper magnet adhesion.
2. Start drill motor by depressing green motor "ON" button.
3. Using the feed handles, advance cutter into material until Slugger cutter has established an external groove
in the material. During the remainder of cut, apply smooth constant pressure without overloading motor.
NOTE: Slugger cutters are designed for uninterrupted cutting. Chips are evacuated during the cut. Do not peck
drill when using Slugger cutters.
if drill motor should stall or stop before a complete cut is made
attempting to restart motor
. :
machine note this machine
work surface
1. After Slugger cutter has finished the cut, the "slug", or uncut center portion of material, will be expelled when
motor is returned to the full up position.
2. Depress red motor "OFF" button, wait until motor completely stops.
3. Move magnet switch to "OFF" position when ready to release magnetic base from work surface.
before the cut
CAUTION!
.
failure to do so could result in personal injury
/
and or damage to the slugger drilling machine
ready to make the cut
CAUTION!
cLOSE chiP gUARd ANd LOwER TO wORk SURfAcE.
CAUTION!
.
failure to do so could result in personal injury and
'
s circuitry will automatically shut the drill motor off if magnetic base is separated from its
.
if your machine requires adjustment
after the cut
NOTE: THE SLUG WILL BE HOT AND HAVE SHARP EDGES.
.
,
always remove cutter from hole before
/
or damage to the slugger drilling
, '
contact jancy s service department

.
