www.carttekcanada.ca
GRX-1200R
User Manual -
Your CartTek caddy cart was thoroughly quality control checked before
being shipped to your address. We do everything possible to assure that
your caddy is in perfect working order upon arrival. Should you have
any issues or questions about the performance of your caddy, please
contact us at
don@carttekcanada.ca
or 888-245-7835.
Page 1 of 24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRX-1200R and is the answer not in the manual?

Questions and answers

Donal
March 27, 2025

I’m not giving my credit card info out in line

0

Related Manuals for Cart-Tek GRX-1200R

Summary of Contents for Cart-Tek GRX-1200R

  • Page 1 GRX-1200R User Manual - Your CartTek caddy cart was thoroughly quality control checked before being shipped to your address. We do everything possible to assure that your caddy is in perfect working order upon arrival. Should you have any issues or questions about the performance of your caddy, please contact us at don@carttekcanada.ca...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION BASIC SET-UP PRECAUTIONS BATTERY MAINTENANCE TURNING ON YOUR GRX-1200R MANUAL MODE REMOTE TRANSMITTER REMOTE CONTROL MODE PROGRAMMING YOUR GRX-1200R CADDY CART TROUBLE SHOOTING GUIDE WARRANTY, SPARE PARTS AND ACCESSORIES: Page 2 of 24...

  • Page 3: Introduction

    INTRODUCTION Thank you for purchasing the CartTek GRX-1200R golf caddy. Please read this manual carefully before use. After unpacking please keep the carton and all internal sections in safe storage. In the unlikely possibility that you need to return the whole unit due to a defective component, you will need to repack the unit in the original manner to ensure safe and secure transit.

  • Page 4: Basic Set-Up

    QUICK TIP After unpacking the caddy and while reading this manual, place the battery on charge while you assemble the unit. Plug battery into charger and charger into power source. The battery may be delivered with a charge but should always be placed on charge before using to ensure full charge of battery.
  • Page 5  Place battery in tray. Insert battery cable into caddy, making sure to align pins. Depress silver spring lock before removing cable.  Load golf bag onto caddy. Balance weight of golf bag equally “side to side”. Attach bag straps using the metal latches;...

  • Page 6: Precautions

    3) The front wheel must stay grounded during play. The only exception is on steep inclines. Your GRX-1200R should only tip onto the rear wheel when on extreme inclines (Over 25 degree inclines).
  • Page 7 over the front wheel. Equally distribute the weight, use the center pouch or equal weight added to each side pocket. 6) IMPORTANT TIP. Do not use the parking brake button when going down steep inclines. For best control of caddy, use the reverse arrow to decrease speed.

  • Page 8: Battery Maintenance

    12 volt, 36 amp hour battery. Whenever possible we ship your battery fully charged. Before trying to operate your GRX-1200R, you should verify that the 12 Volt SLA battery contains a full charge. Plug your battery to the charger;...
  • Page 9  Battery life is 125 to 150 charging cycles. Not charging your battery because of a 9-hole game will not lengthen your battery life, it will decrease it.  Store your battery in a cool dark place, off the ground. It is best to store and charge the battery on a wooden surface.

  • Page 10: Turning On Your Grx-1200R

    TURNING ON YOUR GRX-1200R Place your battery into the battery tray and plug battery cable into caddy. Always press the silver spring lock on battery cable when inserting and removing battery cable from caddy. When first connecting the battery to the caddy, the green LED on the receiver dome will slowly flash.

  • Page 11: Manual Mode

    MANUAL MODE  Turn speed dial back to zero – counter clockwise.  Rotate speed dial clockwise to increase the speed of caddy.  Rotate speed dial counter-clockwise to slow/ stop caddy’s motion.  In manual mode there are three ways to stop your caddy. ...
  • Page 12 Pull Out Antenna Forward: Moves caddy Left & Right Arrows: forward and increases Turns caddy to the left or speed with each push. Parking Brake: The red Reverse: When button in the middle of the caddy is stopped directional controls is an it moves caddy in electronic parking brake.

  • Page 13: Remote Control Mode

    REMOTE CONTROL MODE  When the green light on the caddy is solid and the caddy is stationary, your caddy is ready for remote control transmission.  Push the forward or reverse buttons to move the caddy.  By pressing and holding Left or Right turn, the caddy will turn “upon”...

  • Page 14: Programming Your Grx-1200R Caddy Cart

    Also get comfortable with the coast and parking brake buttons. Practice turning the caddy perpendicular to hills when parking on an incline. PROGRAMMING YOUR GRX-1200R CADDY CART The caddy electronics may be customized for your personal preferences. All programing customization is done via the remote transmitter.
  • Page 15 Next press and quickly release the Coast/Program Button and then quickly press and hold the Coast/Program Button again. While still holding the program button, within a few seconds the caddy will move forward at a slow speed.” If cart does not move, repeat.
  • Page 16 5. Matching a “New Remote Transmitter” to your caddy. Should you need to replace your remote transmitter, you will need to pair (match) it to your GRX-1200R. (NO need to go into program mode.)  With the caddy on (solid green LED) and the Remote Transmitter on, plug the USB cable into the USB port under the receiver dome.

  • Page 17: Trouble Shooting Guide

     The LED on your remote will slowly flash.  Press and hold the on/off button on the caddy. The remote transmitter LED will start rapid flashing.  After a round of the rapid flashing release the on/off button.  Disconnect the USB cable and press the “Parking Brake”...
  • Page 18 My caddy will not show a solid green indicator LED on the caddy handle. 1. Make sure you can get a flashing green indicator LED first. 2. Press and hold the on/off button for 3 seconds 3. Check Caddy Battery terminal connections. Check both sides of ring terminals for corrosion;...
  • Page 19 4. Verify the battery cable is clean and securely attached to the battery. Check both sides of ring terminals for corrosion. Remove any corrosion and tighten cable to battery. 5. If your battery is over a year old or has had over 125 charges, you may need a new battery.
  • Page 20 the weight evenly distributed between left and right sides? 2. Ensure both wheels are fully engaged into the drive collars located on the axles. 3. Check that the drive collars are secured onto the axles. The drive collar is attached to the axle by a roll pin or sheer pin.
  • Page 21 Page 21 of 24...
  • Page 22 My caddy stops unexpectedly during a round. 1. The GRX-1200R is equipped with a 60 second timer that stops the caddy if you do not press additional buttons within that time period. 2. Check indicator LED's on caddy receiver dome.
  • Page 23 1. Press the blade on the wheel hub and pull wheels out of drive collar and lock wheels into groove on axle. Ensure that the wheel is locked onto the axle. 2. In free wheel mode you can pull the caddy backwards. My caddy has stopped working and I cannot figure out what is wrong.

  • Page 24: Warranty, Spare Parts And Accessories

    FOR WARRANTY, SPARE PARTS AND ACCESSORIES: Contact Us: Toll Free- 888-245-7835 http://www.carttekcanada.ca CartTek Canada 1372 Merrybrook Lane Oakville, Ontario L6M 1T4 Email: don@carttekcanada.ca Page 24 of 24...
