QuickSpecs
Standard Features
Product Features
Dual-port 10 Gigabit
Ethernet Throughput
(theoretical bandwidth)
Jumbo Frames
MSI and MSI-X
Interrupt Coalescence
802.1p QoS Tagging
802.1Q VLANs
TCP/IP Stateless
Offloading
Dual-port 10GbE FlexibleLOM network adapter that provides the flexibility to choose the type of
LOM to meet growing infrastructure needs
Industry-leading throughput and latency performance
Up to 40Gb/s bi-directional near line rate throughput
Hardware and software acceleration and offloads for stateless TCP/IP
Supports Wake-on-LAN ( at 1 Gb)
NOTE: Wake-on-LAN is supported only on Port1 from system power state
Improved small packet performance
Interrupt Coalescing
Support for Preboot eXecution Environment (PXE)
Integrated PHY and MAC
The HP 560FLB adapter delivers 20,000 Mbps full duplex Ethernet transfer rate per port (40 Gbps
aggregate full duplex), providing the network performance needed to improve response times and
alleviate bottlenecks. 10Gb Ethernet bandwidth is ideal for high performance computing, database
clusters.
The HP 560FLB adapter supports jumbo frames (also known as extended frames), permitting up to a 9K
byte (KB) transmission unit (MTU) when running Ethernet I/O traffic. This is over 5X the size of a standard
1500-byte Ethernet frame. With jumbo frames, networks can achieve higher throughput performance and
greater CPU utilization. These attributes are particularly useful for database transfer and tape backup
operations.
Message Signaled Interrupt (Extended) provides performance benefits for multi-core servers by load
balancing interrupts between CPUs/cores
Interrupt coalescing (interrupt moderation) groups multiple packets, thereby reducing the number of
interrupts sent to the host. This process optimizes host efficiency, leaving the CPU available for other
duties.
IEEE quality of service (QoS) 802.1p tagging allows the adapter to mark or tag frames with a priority level
across a QoS-aware network for improved traffic flow.
IEEE 802.1Q virtual local area network (VLAN) protocol allows each physical port of the HP 560FLB adapter
to be separated into multiple virtual NICs for added network segmentation and enhanced security and
performance. VLANs increase security by isolating traffic between users. Limiting the broadcast traffic to
within the same VLAN domain also improves performance.
TCP, IP, UDP checksum offload, Large Send Offload (LSO), TCP, Segmentation Offload (TSO). These
features optimize host efficiency, leaving the CPU available for other duties.
DA - 14331 Worldwide — Version 10 — March 21, 2014
HP Ethernet 10Gb 2-port 560FLB Adapter
