Welcome
and thank you for choosing the Phonitor 2.
The Phonitor 2 is the ultimate headphone monitoring amplifier and delivers up to 3.7 W output power.
The Phonitor 2 is also an excellent preamplifier that can drive power amplifiers or active speakers.
The SPL 120V Rail Technology makes the Phonitor 2 an outstandig device in terms of dynamic range, signal-to-noise
ratio and headroom delivering an exceptional sound experience with invincible serenity, transparancy and realness.
Phonitor 2
Matrix
Cr/A All
Off
Source Solo
XLR 1 RCA L R
XLR 2 Off
Output Ø
L R
Mute Off
Model 1280 • Made in Germany
With the optional Expansion Rack you can mount the Phonitor 2 into a 19 inch rack and switch between four dif-
ferent audio outputs (see more information here).
2
IR
Stereo VU Cal
Mono +12
+6dB
120 V Audio Rail Preamplifier
Headphone Monitoring Amplifier
Voltage Selection: C AU T I O N
1. Remove Fuse Holder
RISK OF ELECTRIC SHOCK
2. Flip Over 3. Reinstall
D O N O T O P E N
Fuses: 115V AC: T 1 A L 250 V
230V AC: T 500 mA L 250 V
AVIS: RISQUE DE CHOC ÉLECTRIQUE • NE PAS OUVRIR
~ 115V AC / ~230V AC
50 Hz / 60 Hz, P max. 35 W
Learning Volume Up/Down:
1. Press LEARN button below
L
2. Point your remote at VUs
and press a button for
VOLUME DOWN (LEDs flash 1x)
Phonitor 2
3. Repeat until LEDs flash 3x
R
LEARN
PGM
Serial
4. Press a button for This output can also drive balanced headphones
Number
3
VOLUME UP (LEDs flash 1x) (Gender changer may be required).
R L
5. Repeat until LEDs flash 3x
IR REMOTE OUTPUT
Made in Germany
I F R B
D IP S W IT C H W IR IN G
XLRs: balanced, Pin 2 = Hot (+)
ON BOTTOM SIDE:
For unbalanced operation
1 ON: Output +12dB 3 ON: RCA -10dBV to +4dBu
bridge Pin 3 to GND.
2 ON: Output + 6dB 4 ON: Sources 1:1 to Output
RCAs: Unbalanced, Tip = Hot (+)
2 1
R L R L
SOURCES
