CORDLESS
JIGSAW
18V Lithium Ion
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage:
18V
No Load Speed:
0 - 2,400spm
Stroke Depth:
25.4mm
Bevel:
+/- 45°
Blade Fitment:
T-Shank
Cutting Capacities:
Timber 80mm
Mild Steel 10mm
Plastic 12mm
Weight:
1.85kg
ozito.com.au
WHAT'S IN THE BOX
Jigsaw
Blade
Dust Extraction Adaptor
Splinter Guard
Parallel Guide
Line Guide
Battery & Charger sold
separately
PXJSS-600
Advertisement
Table of Contents
Related Manuals for Ozito PXJSS-600
Summary of Contents for Ozito PXJSS-600
- Page 1 Splinter Guard Voltage: No Load Speed: 0 - 2,400spm Stroke Depth: 25.4mm Bevel: +/- 45° Blade Fitment: T-Shank Parallel Guide Cutting Capacities: Timber 80mm Mild Steel 10mm Plastic 12mm Weight: 1.85kg ozito.com.au Line Guide Battery & Charger sold separately PXJSS-600...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION CORDLESS JIGSAW 1. ASSEMBLY 1 Guide Locking Screw 7 Battery Seating 2 LED Light 8 Guide Roller WARNING! ENSURE THE TOOL IS SWITCHED OFF AND 3 Blade Lock 9 Adjustable Shoe THE BATTERY IS REMOVED BEFORE PERFORMING ANY OF THE FOLLOWING TASKS. -
Page 3: Battery And Charging
2. BATTERY & CHARGING (sold separately) Charging your lithium ion battery - Eco Charger CAUTION: THE CHARGER FOR THIS PRODUCT SHOULD 1 Connect the charger into a mains power outlet. BE PROTECTED BY A RESIDUAL CURRENT DEVICE (RATED AT 30MA OR LESS). 2 T he charger LED will flash green showing power The purchased battery will be shipped in a low charge condition, and... -
Page 4: Attaching The Accessories
3. FITTING THE BATTERY & GUIDE 4. ATTACHING THE ACCESSORIES Inserting & Removing the Battery (not included) Using the Splinter Guard The splinter guard ensures that the workpiece does not splinter 1 Align the ribs of the battery and crack while cutting. with the recess at the back of the handle. -
Page 5: Operation
Medium pendulum action for faster cutting on softer materials Large pendulum action for fast cutting 2 To remove simply slide the dust extraction adaptor from along the grain on soft materials. the back of the jigsaw. PXJSS-600... -
Page 6: Pocket Cutting
Allow the blade to within the reach of children. stop before lifting Note: Ozito Industries will not be responsible for any damage or injuries the jigsaw away. caused by the repair of the jigsaw by an unauthorised person or by mishandling of the jigsaw. -
Page 7: Troubleshooting
Bunnings Warehouse. Do not expose to rain. No load speed For further information, or any parts not listed here, visit Strokes per minute www.ozito.com.au or contact Ozito Customer Service: Transformer Energy Regulatory Compliance Australia 1800 069 486 Rating (MEPS) -
Page 8: Electrical Safety
Replace the extension lead if damaged or defective. Note: The supply of 230V and 240V on Ozito tools are interchangeable for Australia and New Zealand. When using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for the power input of the tool or which is damaged or defective may result in a risk of fire and electric shock. -
Page 9: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO 1015 Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
