Replacement Parts

Part Description
A Blower/Heater Assembly
B Left Sidelight PCBA
C Flame Generator Drive Motor
D Left/Right Flame PCBA
E Emberbed Circuit Board
F Emberbed with log
G Control Panel - 8 Buttons
H Middle Flame PCBA
I Blue Flame PCBA
J Flame Generator/ Spinner
K Right Sidelight PCBA
L Main Circuit Board
M Thermostat Sensor
N Remote Control - 8 Buttons
NOTE: The scale and size of parts may be different
depending on your exact model.
