Moxa AirWorks AWK-4121

Quick Installation Guide

Third Edition, July 2009
© 2009 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.
P/N: 1802041210012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the awk-4121 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Moxa Technologies awk-4121

Summary of Contents for Moxa Technologies awk-4121

  • Page 1: Quick Installation Guide

    Moxa AirWorks AWK-4121 Quick Installation Guide Third Edition, July 2009 © 2009 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. P/N: 1802041210012...

  • Page 2: Notes For The Reader

    NOTE Highlights important information related to this product. Package Checklist Moxa’s AWK-4121 is shipped with the following items. If any of these items is missing or damaged, please contact your customer service representative for assistance. 1 AWK-4121 2 Antennas (5dBi, N-type (male), 2.4GHz)

  • Page 3: Panel Layout Of The Awk-4121

    NOTE To make the change effective, you must save the change and then click Restart Save and Restart button to apply all changes. Panel Layout of the AWK-4121 Front Panel View MAIN antenna port. AUX antenna port. LEDs for PWR, FAULT, STATE, WLAN and LAN.

  • Page 4: Dimensions (Unit = Mm)

    66.5 224.0 Wall Mounting In most applications, wall mount provides an easier installation. You will find it quite easy to mount AWK-4121 on the wall, as illustrated below. STEP 1: STEP 2: Attach the wall-mounting kit with Mounting the AWK-4121 on the wall M4 screws, as shown in the requires 4 screws.

  • Page 5: Din-Rail Mounting (Optional)

    To avoid environmental vibration or shock, you can consider a robust installation with four bigger screws, which the shafts are between 7.0 mm and 8.5 mm in diameter, and fix the AWK-4121 onto wall directly and tightly. DIN-Rail Mounting (Optional)

  • Page 6: Wiring Requirements

    DIN-Rail attachment bracket snaps into place. To Release STEP 1: STEP 2: Pull out the two spring-loaded Pull the AWK-4121 out and brackets from the bottom until they upward. are fixed in the “release” position. Wiring Requirements WARNING...

  • Page 7: Grounding Moxa Awk-4121

    802.3af compliant power source or an IEC60950 compliant limited power source. When AWK-4121 is powered via DC power, the M12 A-coding connector on the bottom panel is used for the AWK-4121’s two redundant inputs. The pin assignment is shown below:...

  • Page 8: Wiring The Digital Inputs And Relay Contact (Digital Output)

    These two digital inputs can be connected to digital-output-enabled sensors for on-site status monitoring. The AWK-4121 also has one relay output, which consists of the two contacts. These relay contacts are used to detect user-configured events. The two wires attached to the Relay contacts form an open circuit when a user-configured event is triggered.
  • Page 9 The AWK-4121 has one RS-232 (8-pin RJ45) console port located on the bottom panel. Use either an RJ45-to-DB9 or RJ45-to-DB25 cable to connect the Moxa AWK-4121’s console port to your PC’s COM port. You may then use a console terminal program to access the AWK-4121 for console configuration.
  • Page 10 Tightly screw the clamp ring ④ to the housing and check to make sure that the plug is securely fastened. (NOTE: for a tighter connection, you can connect the RJ-45 plug to the AWK-4121 before STEP 4.) — 9 —...

  • Page 11: Led Indicators

    LED Indicators The front panel of the Moxa AWK-4121 contains several LED indicators. The function of each LED is described in the table below. Color State Description Power is being supplied Green (from power input 1 or 2, or PoE).
  • Page 12 Security 64-bit and 128-bit WEP encryption, WPA /WPA2 (IEEE 802.1X/ RADIUS ,TKIP and AES) Protocol General Protocols: Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, RTP AP-only Protocols: ARP, BOOTP, DHCP, dynamic VLAN-Tags for 802.1X-Clients, STP/RSTP (IEEE 802.1D/w) Data Rates 802.11b: 1, 2, 5.5, 11 Mbps...
  • Page 13 5 years Details: See http://www.moxa.com/warranty ATTENTION The AWK-4121 is NOT a portable mobile device and should be located 20cm away from the human body. The AWK-4121 is NOT designed for the general public. To deploy AWK-4121s and establish a wireless network safely, a well-trained technician is required for installation.
  • Page 14 Technical Support Contact Information www.moxa.com/support Moxa Americas: Moxa China (Shanghai office): Toll-free: 1-888-669-2872 Toll-free: 800-820-5036 Tel: +1-714-528-6777 Tel: +86-21-5258-9955 Fax: +1-714-528-6778 Fax: +86-10-6872-3958 Moxa Europe: Moxa Asia-Pacific: Tel: +49-89-3 70 03 99-0 Tel: +886-2-8919-1230 Fax: +49-89-3 70 03 99-99 Fax: +886-2-8919-1231 —...
