- Page 1 MOXA AirWorks AWK-1200-AC User’ s Manual www.moxa.com/product First Edition, July 2007 Moxa Networking Co., Ltd. Tel: +886-2-8919-1230 Fax: +886-2-8919-1231 Web: www.moxa.com MOXA Technical Support Worldwide: support@moxa.com The Americas support@usa.moxa.com...
- Page 2 MOXA AirWorks AWK-1200-AC User’ s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice Copyright © 2007 Moxa Networking Co., Ltd.
-
Page 3: Table Of Contents
Table of Contents Chapter 1 Introduction....................1-1 Overview.............................. 1-2 Package Checklist..........................1-2 Product Features..........................1-2 System Requirements......................... 1-2 Inline Power Injector (PoE) ......................1-3 Chapter 2 Getting Started.................... 2-1 First Time Installation and Configuration..................2-2 Locating the Data Input and PoE Ports ................... 2-2 What to Check before You Install the AWK-1200-A C .............. -
Page 5: Chapter 1 Introduction
Introduction C h a p t e r The following topics are covered in this chapter: q Overview q Package Checklist q Product Features q System Requirements q Inline Power Injector (PoE) -
Page 6: Overview
MOXA AirWorks AWK-1200-AC User’s Manual Introduction Overview The AWK-1200 Access Point/Bridge and AP Client is ideal for applications that are hard to wire, too expensive to wire, or use mobile equipment that connects to a TCP/IP network. The AWK-1200 series is rated to operate at temperatures ranging from -20 to 70°C, and its weatherproof design allows you to set up a WLAN, or extend existing wired networks to outdoor locations. -
Page 7: Inline Power Injector (Poe)
MOXA AirWorks AWK-1200-AC User’s Manual Introduction Inline Power Injector (PoE) The AWK-1200-AC is equipped with an Inline Power Injector module. The Inline Power Injector (PoE) delivers both data and power to the AWK-1200-AC through a single Ethernet cable, and provides the following benefits to improve the performance vs. installation cost ratio. -
Page 9: Chapter 2 Getting Started
Getting Started C h a p t e r This chapter describes the procedures for installing the AWK-1200-AC. The following topics are covered: q First Time Installation and Configuration q Locating the Data Input and PoE Ports q What to Check before You Install the AWK-1200-AC q Basic Configuration Ø... -
Page 10: First Time Installation And Configuration
MOXA AirWorks AWK-1200-AC User’s Manual Getting Started First Time Installation and Configuration After unpacking the system, make sure the following items are present and in good condition. Refer to pictures below to see what each item looks like. 1. AWK-1200-A C 2. - Page 11 MOXA AirWorks AWK-1200-AC User’s Manual Getting Started Device Figures POE picture1 POE picture2 Figure 2-1 Power and Data Interface location on the PoE denoted by numbers 1-5. Mounting the AWK-1200-AC on a Wall or Mast — The AWK-1200-AC can be mounted on the wall, and you can use the Wall Mount kit to mount the AWK-1200-AC as shown in Figure 2-2.
-
Page 12: What To Check Before You Install The Awk-1200-Ac
MOXA AirWorks AWK-1200-AC User’s Manual Getting Started — You can also mount the AWK-1200-AC to the mast as shown in Figure 2-3. Figure 2-3 What to Check before You Install the AWK-1200-AC Before installing the AWK-1200-AC for outdoor applications or hard-to-reach locations, we recommend configuring and testing all devices first. -
Page 13: Basic Configuration
MOXA AirWorks AWK-1200-AC User’s Manual Getting Started Figure 2-4 Basic Configuration Basic Configuration Steps This section describes a basic 2-step configuration procedure to set up the AWK-1200-AC. Step 1: Modify the factory-default parameters on the web page “/BASIC/LAN/”, click Save Settings to save the changes, and then click Continue. - Page 14 MOXA AirWorks AWK-1200-AC User’s Manual Getting Started Figure 2-5 Step 3: Enter “root” in the Password fields, and then click Log In to enter the web configuration user interface screen as shown below. Figure 2-6...
-
Page 15: Configuring Operating Mode, Ip Address, Subnet Mask, Default Route Ip, Dns Server Ip
MOXA AirWorks AWK-1200-AC User’s Manual Getting Started Web Configuration Structure The web configuration user interface shown above in Figure 2-6 is grouped into a tree structure, and contains the following settings or information. — TOOLS Ø ADMIN Ø TIME Ø SYSTEM Ø... -
Page 16: Configuring The Wireless Ssid
MOXA AirWorks AWK-1200-AC User’s Manual Getting Started IP Address The IP address of the AC on the local area network. Your local area network settings are based on the address assigned here. For example, 192.168.1.1. Subnet Mask The subnet mask of your AWK-1200-A C on the local area network. -
Page 17: Changing The Supervisor Account & Password
MOXA AirWorks AWK-1200-AC User’s Manual Getting Started Changing the Supervisor Account & Password Enter the TOOLS à ADMIN page, shown below in Figure 2-9. Figure 2-9 ADMIN PASSWORD Change the ADMIN PASSWORD’s user name and password in the ADMIN PASSWORD Account field, click Save Setting, and then Reboot the Device to activate the configuration changes. - Page 18 MOXA AirWorks AWK-1200-AC User’s Manual Getting Started Figure 2-10 ATTENTION The Part 15 radio device operates on a non-interference basis with other devices operating at this frequency when using integrated antennas. Any changes or modification to the product not expressly approved by the Original Manufacture could void the user’s authority to operate this device.
-
Page 19: Web Console Configuration
Web Console Configuration C h a p t e r In this chapter, we will explain each web management page of the Web-based Network Manager. The following topics are covered in this chapter: q BASIC Ø LAN Ø WIRELESS Ø ADVANCED q TOOLS Ø... -
Page 20: Basic
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration BASIC These are the IP address settings of the LAN (Local Area Network) for the AWK-1200-AC. The AWK-1200-A C’s Local Area Network (LAN) settings are configured based on the IP Address and Subnet Mask assigned in this section. - Page 21 MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration Wireless Mode Select Infrastructure to connect to a wireless (AP) Access Point. Select Ad-hoc to connect to another AC or wireless station. Wireless Network Name This is the name of the wireless access point with which this station will be associated. Leave this field blank to associate with any access point.
-
Page 22: Advanced
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration — WPA-Personal This option selects Wi-Fi Protected Access (WPA), which uses security standards published by the Wi-Fi Alliance. This option uses Wi-Fi Protected Access with a Pre-Shared Key (PSK). The WPA Mode further refines the variant that the AWK-1200-A C should employ. -
Page 23: Tools
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration Fragmentation Threshold This setting should remain at its default value of 2346. Setting the Fragmentation value too low may result in poor performance. RTS Threshold This setting should remain at its default value of 2346. If you encounter inconsistent data flow, only minor modifications to the value are recommended. -
Page 24: Time
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration Admin Password Enter a password for the user admin. This user will have full access to the Web-based management interface. User Password Enter a password for the user user. This user will have read-only access to the Web-based management interface. -
Page 25: System
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration Set the Date and Time Manually You can either set the time for your bridge manually here, or you can click the Copy Your Computer’s Time Settings button to copy the time from the computer you are using. (Make sure that computer’s time is set correctly.) -
Page 26: Status
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration To upgrade the firmware, follow these steps: 1. Click the Browse button to locate the upgrade file on your computer. 2. Once you have found the file to be used, click the Upload button below to start the firmware upgrade process. -
Page 27: Wireless
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration WIRELESS The wireless page allows you to view all of the access points that can be heard by your AWK-1200-A C. MAC Address The Ethernet ID (MAC address) of the access point. -
Page 28: Logs
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration Type A value of AP indicates the detected device is an access point in infrastructure mode; a value of AdHoc indicates that the detected device is operating in ad hoc mode. Signal This is a relative measure of signal quality. -
Page 29: Statistics
MOXA AirWorks AWK-1200-AC User’s Manual Web Console Configuration Save Log Select this option to save the AWK-1200-AC log to a file on your computer. Statistics The Statistics page displays packet transmit and receive statistics for both the LAN and Wireless connections. -
Page 31: Appendix A Specifications
Specifications A p p e n d i x A WLAN Standards IEEE802.11g/b for wireless LAN, IEEE802.3u 10/100BaseTX for Ethernet LAN, IEEE802.3af for Power over Ethernet Frequency Range 2.4-2.4835 GHz, Direct Sequence Spread Spectrum (DSSS) Data Rate & Modulation OFDM@54 Mbps, CCK@11/5.5 Mbps, DQPSK@2 Mbps and DBSK@1 Mbps Operating Channels USA: 1-11 (US) - Page 32 MOXA AirWorks AWK-1200-AC User’s Manual Specifications Mechanical Casing IP68 (AP/Bridge), IP67 (AP Client) Dimensions (W × L × D) AWK-1200-AP: 284.4 × 254.3 × 77.5 mm 11.20 × 10.01 × 3.05 in AWK-1200-AC: 165.8 × 195.8 × 60.3 mm 6.53 × 7.71 × 2.37 in...
-
Page 33: Appendix B Default Settings
Default Settings A p p e n d i x B BASIC Setting Name Default Value Get LAN IP from Static IP (Manual) IP Address 192.168.127.254 Subnet Mask 255.255.255.0 Gateway 0.0.0.0 Local Domain Name NULL WIRELESS Setting Name Default Value ENABLE Enable Wireless Select... -
Page 34: Tools
MOXA AirWorks AWK-1200-AC User’s Manual Default Settings TOOLS ADMIN Setting Name Default Value ADMIN PASSWORD Password admin Verify Password root USER PASSWORD Password admin Verify Password Administration Bridge Name AWK-1200 Web Idle Timeout TIME Setting Name Default Value TIME CONFIGURATION... -
Page 35: Appendix C Regulatory Compliance Information
Regulatory Compliance Information A p p e n d i x C 15.21 CAUTION: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Prohibition of co-location This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. - Page 36 MOXA AirWorks AWK-1200-AC User’s Manual Regulatory Compliance Information Regulatory information / Disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment.
- Page 37 MOXA AirWorks AWK-1200-AC User’ s Manual Regulatory Compliance Information Declaration of Conformity for R&TTE directive 1999/5/EC Protection requirements for health and safety - Article 3.1a The protection of the health and the safety of the user and any other person, including the objectives with respect to safety requirements contained in Directive 73/23/EEC, but with no voltage limit applying.
