Radio control model VQA054 Instruction Manual

45 class,2-cycle engine 70 class,4-cycle engine
Hide thumbs

Advertisement

Quick Links

Download this manual
45 Class
2-cycle engine
70 Class
4-cycle engine
Or Electric equivalent
TECHNISCHE DATEN
Spannweiter
Lange
Elektroantrieb
Verbrennerantrieb
Fernsteuerung
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
INSTRUCTION MANUAL / Montageanleitung
All balsa, plywood construction and almost ready to fly
VQA054 - VQA055
1520mm
1237mm
BOOST 50
7.5cc 2-T / 11cc 4-T
5 Kanal / 5 Servos
YAK
SPECIFICATIONS
Wingspan
Length
Electric Motor
Glow Engine
Radio
5 Channel / 5 Servos
59.8 in.
48.7 in.
BOOST 50
.46 2-T / .70 4-T

Advertisement

loading
Need help?

Need help?

Do you have a question about the VQA054 and is the answer not in the manual?

Questions and answers

Related Manuals for Radio control model VQA054

Summary of Contents for Radio control model VQA054

  • Page 1 45 Class 2-cycle engine 70 Class 4-cycle engine Or Electric equivalent INSTRUCTION MANUAL / Montageanleitung All balsa, plywood construction and almost ready to fly VQA054 - VQA055 SPECIFICATIONS TECHNISCHE DATEN Wingspan 59.8 in. Spannweiter 1520mm Length 48.7 in. Lange 1237mm...
  • Page 2 REQUIRED FOR OPERATION (Purchase separately) BENOTIGTE KOMPONENTEN FUR DEN ABFLUG (Nicht enthalten) Extension for aileron 10.5x6 for .40 - 2 cycle engine servo, retract servo. Retract servo x1 11x6 for .46 - 2 cycle engine 12x6 for .60 - 4 cycle engine 12x7 for .70 - 4 cycle engine 12x6...
  • Page 3 Bottom view 1- Retract landing gear / Fahwerk Ansicht von unten Trial fit the push rod into the wing. Join the pushrod to the retract gear arm and trial fit the retract into the wing. 3x12mm screw 3x12mm schraube After checking that the retract works smoothly, fix the retract on the wing with 3x12mm screws Retract pushrod Fahrwerkanlenkgestange...
  • Page 4 4- Servo mount / Servohalterung Retract servo mount (plywood A,B,C) Einziehfahrwerk servohalterung FWU1 Schneiden Sie etwas Folie weg Cut away only FWU2 the covering CENTER FWU2 WING FWU1 SECTION BOTTOM Install the retract servo onto the retract 5- Retract servo / Einziehfahrwerk servo servo mount and secure it in place with four screw (included with radio set).
  • Page 5 7- Fixed gear / Starres Fahrwerk 3x20mm Main landing gear Nylon gear 3x12mm screw strap ..8 3x20mm screw ..16 Gear mount Nylon gear strap 3x20mm screw ..4 Ply gear mount flat Square Gear mount x 2 plastic 3x20mm 3x20mm screw Ply gear mount plate x 2 Square plastic x 2...
  • Page 6 10- Air scoop / Olkuhlerattrappe Installing the wing to the fuselage and secure it in place using two 6x45mm nylon bolt. Using the ABS air scoop (part B) as a template, trace around the outside edge of the ABS air-scoop and then remove it. Using a sharp hobby knife, cut away the covering inside the lines.
  • Page 7 13- Horizontal stabilizer / Hohenruder Cut away only the 1-Trial fit the horizontal stabilizer in place . Check the alignment covering both side of the horizontal stabilizer. When you are satisfied with the alignment, use a pencil to trace around the top and bottom of the stabilizer where it meets the fuselage.
  • Page 8 Apply a thin layer of machine oil or petroleum jelly to only the 15- Elevator / Hohenruder pivot point of the hinges on the elevator, then push the elevator and its hinges into the hinge slots in the trailing edge of the horizontal stabilizer.
  • Page 9 17- Electric Motor / Elektromotor - Using a plywood motor mounting plate as a template, mark the fire wall where the four holes are to be drilled (1). - Remove the plywood motor mounting plate and drill a 13/64”(5mm) hole through the fire-wall at each of the four marks marked (2).
  • Page 10 ! Align the mark on both mounts 18- Engine mount / Motortrager with the center mark on the fire wall ! Engine thrust on balk head is already adjust at factory B=B’ ! Align the engine B’ center with fire wall marked line B’...
  • Page 11 21- Fuel tank / Treibstofftank To muffler Filler tube TOP VIEW Draufsicht Rubber stopper To engine 3x35mm screw Battery hatch Akkuklappe Magnetic piece Magnet 22- Cowling installation 1~2mm 2.5x10mm..4 Motorhaube Attach the board or transparent plastic on the side of the fuselage with the adhesive tape as show.

  • Page 12: Servo Installation

    23- Servo installation NOTE: Place of the servos may be Receiver area change depend of engine (Four-stoke or two-stroke engine) Bottom view /Ansicht von unten 24- Linkages / Ruderanlenkung Bottom view /Ansicht von unten Elevator pushrod Tail wheel pushrod Rudergestange Rudder pushrod Elevator servo Hohenruderservo...
  • Page 13 “more is not always better”. 29- Decor / Aufkleber VQA054 - Olive VQA055 - Navy blue Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once. Peel off one corner of the backing and cut off with scissors.
