INSTRUCTION MANUAL
SPECIFICATIONS
Wingspan
Length
Electric Motor
Glow Engine
Radio
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
(2T engine)
(4T engine)
.45 2-T / .60 4-T
5 Channel / 5 Servos
STICK
F - 1500
60 in.
38.5 in.
650 Watt
Advertisement
Table of Contents
Related Manuals for Radio control model F-1500
Summary of Contents for Radio control model F-1500
- Page 1 Radio control model 45 Class (2T engine) STICK 60 Class (4T engine) Or Electric equivalent F - 1500 INSTRUCTION MANUAL SPECIFICATIONS Wingspan 60 in. Length 38.5 in. Electric Motor 650 Watt Glow Engine .45 2-T / .60 4-T Radio 5 Channel / 5 Servos WARNING! This radio controlled model is NOT a toy.
-
Page 2: Conversion Table
REQUIRED FOR OPERATION (Purchase separately) Propeller 11x8 for electric motor / 11x6 for glow engine Extension cord Brushless Motor Minimum 5 channel radio 650 Watt for airplane Brushless ESC Brushless Regler .46 cu.in. Battery 3700mAh-11.1V .52 cu.in EPOXY A SILICON EPOXY B Silicon Glue Cyanoacrylate Glue... - Page 3 1- Aileron extension cord WING BOTTOM-VIEW Aileron extension cord Cotton thread (pre-installed in each wing half) Cut through both the covering and the balsa wood of the wing bottom where the aileron extension cord goes. Install the servo extension cord in to the wing. 2- Aileron servo Adhesive tape...
-
Page 4: Aileron Linkage
4- Aileron linkage 2x20mm screw WING BOTTOM-VIEW ..2 2x20mm..4 ..2 Adhesive tape 3mm set Screw Aileron pushrod D=5/64”(2mm) Aileron pushrod D=5/64”(2mm) 2 mm AILERON SERVO 5- Engine - 4T 3x20mm screw 4x15mm screw ....4 ....4 3mm nut Blind-nut TOP-VIEW .....4 .....4 Handle (3mm ply wood) Magnetic hatch... -
Page 5: Electric Motor
Align the engine center with 6- Engine - 2T fire-wall marked line (A=A’) FRONT VIEW After confirming the direction . Insert and tighten the screw. To muffler Filler tube Blow Rubber stopper Water Checking for leaks - block the vents and blow into the feed - if in doubt Stopper submersing the tank in a... -
Page 6: Horizontal Stabilizer
8- Horizontal stabilizer Plastic control horn and back plate ..2 2x12mm screw ...4 HORIZONTAL STABILIZER BOTTOM-VIEW 4x20mm screw ...2 4mm washer .....2 Elev. / Rudd. Plastic control horn FUSELAGE BOTTOM-VIEW 9- Vertical stabilizer FUSELAGE TOP-VIEW Remove the vertical stabilizer from the fuselage. -
Page 7: Tail Wheel
11- Tail wheel 2.2mm collar..1 Vis 3x12mm..2 Tail wheel..1 Tail gear mount ....1 BOTTOM FUSELAGE VERTICAL FIN FUSELAGE BOTTOM-VIEW 12- Rudder Test-fit the hinges of ruder into the slots. Using a pencil, mark the rudder where the tail wheel gear meet the rudder. Cut 1-3/16”... -
Page 8: Rudder Control Horn
13- Rudder control horn Plastic control horn and back plate ABS push-rod exit guider ..1 2x12mm screw ...2 Rudder 14- Main landing gear 3x15mm screw ....4 3mm Washer .....4 3mm Blind-nut .....4 All holes pre-drilled 4x40mm screw at factory ..2 4mm Washer .......6 4mm Nut... - Page 9 16-Servo IN CASE OF BRUSLESS MOTOR Rudder servo Rudder rod Li-po Battery area Elevator rod Switch Elevator servo FUSELAGE - TOP VIEW 17- Linkages Elevator push-rod Rudder Elevator push-rod push-rod 18- Wing Nylon Wing bolt ..2...
-
Page 10: Control Surface
The recommended C.G (Center of Gravity) location for the Stick is 89 ~ 91mm 19- Balance Adjust the location of the battery pack as required to achieve this C.G location. If necessary , add weight to either the tail or nose until the correct balance is achieve. 3-33/64”...
