Dahua IPC-HF3200 Quick Start Manual page 7

AC 24V/ DC 12V
STATUS
Indication Light
WIFI
IN
Power port
Red light
Green light
Yellow light
3G
Antenna port
Alarm input port I/O port
TV monitor to view
video.
Power port.
Input 12V DC or
AC 24V
System boot up-
red light is on
System
upgrades-red light
flashes
System resets-
red light flashes.
Normal working
status-green light
is on.
Display record
status:Record-
green light
flashes.
Detect the
wireless device-
yellow light is on.
Connect to 3G card.
Please note it is for
3G series product
only.
Connect to 3G/WIFI
antenna to receive the
wireless signal.
Please note this
function is for some
series products only.
Alarm input port 1. To
receive the signal from
2
